Supermicro SuperServer 5019S-MN4 User manual

2
USER’S MANUAL
Revision 1.0
SuperServer®
5019S-MN4
The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual
at any time and without notice. This product, including software and documentation, is the property of Supermicro and/
or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except
as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIALDAMAGESARISING FROM THE USE OR INABILITYTO USE THIS PRODUCT
OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,
may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only
to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
WARNING: Handling of lead solder materials used in this product may expose you to lead, a
chemical known to the State of California to cause birth defects and other reproductive harm.
The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,
nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical
systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products
for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
Manual Revision 1.0
Release Date: November 25, 2015
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this
document. Information in this document is subject to change without notice. Other products and companies referred
to herein are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2015 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

433
PrefaceSuperServer 5019S-MN4 User's Manual
Preface
About this Manual
This manual is written for professional system integrators and PC technicians. It provides
information for the installation and use of the SuperServer 5019S-MN4. Installation and
maintainance should be performed by experienced technicians only.
Please refer to the 5019S-MN4 server specications page on our website for updates on
supported memory, processors and operating systems (http://www.supermicro.com).
Notes
For your system to work properly, please follow the links below to download all necessary
drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety info: http://www.supermicro.com/about/policies/safety_information.cfm
If you have any questions, please contact our support team at:
[email protected]m
This manual may be periodically updated without notice. Please check the Supermicro website
for possible updates to the manual revision level.
Warnings
Special attention should be given to the following symbols used in this manual.
Warning! Indicates high voltage may be encountered when performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage
or personal injury.
Table of Contents
Chapter 1 Introduction
1.1 Overview...............................................................................................................................8
1.2 Unpacking the System .........................................................................................................8
1.3 System Specications ..........................................................................................................9
1.4 Server Chassis Features....................................................................................................10
Control Panel ....................................................................................................................10
Front Features...................................................................................................................11
Rear Features ...................................................................................................................12
1.5 Motherboard Layout ...........................................................................................................13
Quick Reference Table......................................................................................................14
Chapter 2 Server Installation
2.1 Overview.............................................................................................................................17
2.2 Preparing for Setup ............................................................................................................17
Choosing a Setup Location...............................................................................................17
Rack Precautions ..............................................................................................................17
Server Precautions............................................................................................................18
Rack Mounting Considerations .........................................................................................18
Ambient Operating Temperature....................................................................................18
Airow ............................................................................................................................18
Mechanical Loading.......................................................................................................18
Circuit Overloading ........................................................................................................19
Reliable Ground.............................................................................................................19
2.3 Installing the Rails..............................................................................................................20
Identifying the Rails...........................................................................................................20
Installing the Chassis Rails...............................................................................................20
Installing the Rack Rails ...................................................................................................21
2.4 Installing the Server into a Rack........................................................................................22
Installing the Server into a Telco Rack .............................................................................23
Chapter 3 Maintenance and Component Installation
3.1 Removing Power ................................................................................................................24
3.2 Accessing the System........................................................................................................24

65
PrefaceSuperServer 5019S-MN4 User's Manual
3.3 Motherboard Components..................................................................................................25
Processor and Heatsink Installation..................................................................................25
Memory Installation ...........................................................................................................30
Memory Support ............................................................................................................30
PCI Expansion Card Installation .......................................................................................31
DIMM Module Population Sequence ................................................................................31
Motherboard Battery .........................................................................................................32
3.4 Chassis Components .........................................................................................................33
Hard Drives .......................................................................................................................33
Hard Drive Carrier Indicators.........................................................................................34
System Cooling .................................................................................................................35
Installing Fans................................................................................................................35
Air Shroud......................................................................................................................36
Power Supply ....................................................................................................................37
Power Supply Failure ....................................................................................................37
3.5 Server Connections............................................................................................................39
Control Panel ....................................................................................................................39
Rear I/O Ports ...................................................................................................................40
Data Cables ......................................................................................................................40
Power Cables....................................................................................................................40
Peripheral Drives...............................................................................................................41
SAS/SATA Drives...........................................................................................................41
DVD-ROM Drive (Optional) ...........................................................................................41
Chapter 4 Motherboard Connections
4.1 Power Connections ............................................................................................................42
4.2 Headers and Connectors ...................................................................................................43
Control Panel.................................................................................................................48
Data Cables...................................................................................................................51
Power Cables ................................................................................................................51
4.3 Ports ...................................................................................................................................52
Rear I/O Ports................................................................................................................52
4.4 Jumpers..............................................................................................................................55
Explanation of Jumpers.................................................................................................55
4.5 LED Indicators....................................................................................................................58
Chapter 5 Software
5.1 OS Installation....................................................................................................................61
Installing the Windows OS for a RAID System ................................................................61
Installing Windows to a Non-RAID System ......................................................................61
5.2 Driver Installation................................................................................................................62
5.3 SuperDoctor®5...................................................................................................................63
5.4 IPMI ....................................................................................................................................64
Chapter 6 BIOS
6.1 Introduction.........................................................................................................................65
Starting the Setup Utility ...................................................................................................65
6.2 Main Setup .........................................................................................................................66
How To Change the Conguration Data ...........................................................................66
6.3 Advanced Setup Congurations.........................................................................................68
6.4 Event Logs......................................................................................................................... 90
6.5 IPMI ....................................................................................................................................91
6.6 Security...............................................................................................................................94
6.7 Boot Settings......................................................................................................................96
6.8 Save & Exit.........................................................................................................................98
Appendix A BIOS Error Codes
Appendix B Standardized Warning Statements for AC Systems
Appendix C System Specications

7
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Website: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected]
Website: www.supermicro.com.tw
SuperServer 5019S-MN4 User's Manual

98
SuperServer 5019S-MN4 User's Manual Chapter 1: Introduction
Chapter 1
Introduction
1.1 Overview
This chapter provides a brief outline of the functions and features of the 5019S-MN4. The
5019S-MN4 is based on the X11SSH-LN4F motherboard and the SC813MFTQC-350CB
chassis.
In additon to the motherboard and chassis, several important parts that are included with the
system are listed below.
1.2 Unpacking the System
Inspect the box the SuperServer 5019S-MN4 was shipped in and note if it was damaged in
any way. If any equipment appears damaged, please le a damage claim with the carrier
who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well ventilated. Avoid areas where heat, electrical noise and
electromagnetic elds are generated. It will also require a grounded AC power outlet nearby.
Be sure to read the precautions and considerations noted in Appendix B.
Main Parts List
Description Part Number Quantity
Air Shroud MCP-310-19007-0N 1
Heatsink (passive) SNK-P0046P 1
Riser Card RSC-RR1U-E16 1
1.3SystemSpecications
The following table provides you with an overview of the main features and specications of
the 5019S-MN4. Please refer to Appendix C for additional specications.
SystemSpecications
Motherboard
X11SSH-LN4F
Chassis
SC813MFTQC-350CB
CPU
Intel®E3-1200 v5 and 6th Gen Core i3, Pentium and Celeron processors
Socket Type
LGA 1151 (H4)
Memory
Four 288-pin DIMM slots to support up to 64 GB of 72-bit DDR4 unbuffered ECC 2133/1866/1600/1333MHz
SDRAM
Chipset
C236 chipset
Expansion Slots
One PCI Express 3.0 x4 in x8 slot (PCH Slot 4)
One PCI Express 3.0 x8 (CPU Slot 5)
One PCI Express 3.0 x8 in x16 slot (CPU Slot 6)
One M.2 Mini PCI Express 3.0 x2 connector
Hard Drives
Four hot-swap SATA hard drives
Power
Single 350W power supply
Form Factor
1U rackmount
Dimensions
(WxHxD) 17.2 x 1.7 x 19.85 in. (437 x 43 x 504 mm)

1110
SuperServer 5019S-MN4 User's Manual Chapter 1: Introduction
Control Panel Features
Item Feature Description
1Overheat/Fan Fail LED When ashing, this LED indicates a fan failure. When on continuously it
indicates an overheat condition.
2NIC2 LED Indicates network activity on LAN port 2 when ashing
3NIC1 LED Indicates network activity on LAN port 1 when ashing
4HDD LED Indicates activity on the hard drive when ashing.
5Power LED Indicates power is being supplied to the system power supply. This LED should
normally be illuminated when the system is operating.
6Reset Button The reset button is used to reboot the system
7Power Button
The main power button is used to apply or remove power from the power supply
to the server. Turning off system power with this button removes the main power
but maintains standby power. To perform many maintenance tasks, you must
also unplug system before servicing
Figure 1-1. Control Panel View
1.4 Server Chassis Features
Control Panel
The switches and LEDs located on the control panel are described below. See Chapter 4 for
more details on the control panel.
1 765432
Front Chassis Features
Item Feature Description
1SATA HDD Hot-swap 3.5" SATA hard disk drive
2USB Ports Two front-access USB 3.0 ports
3COM Port Front-access COM (serial) port
4Control Panel Front control panel with LEDs and buttons (see preceding page)
5Rack Ear Brackets Attaches server chassis to the rack
Figure 1-2. Chassis Front View
Front Features
The SC813MFTQC-350CB is a mini 1U chassis. See the illustration below for the features
included on the front of the chassis.
1
5 5
432
1 11

1312
SuperServer 5019S-MN4 User's Manual Chapter 1: Introduction
Rear Chassis Features
Item Feature Description
1Power Supply 350W Platinum Level Power Supply (p/n PWS-350-1H)
2I/O Backpanel Rear I/O ports (see Section 4.3)
3Expansion Card Slot Slot for one expansion card (requires pre-installed riser card)
4Rack Ear Brackets Attaches server chassis to the rack
Figure 1-3. Chassis Rear View
Rear Features
The illustration below shows the features included on the rear of the chassis.
1
44
3
2
Figure 1-4. Motherboard Layout
1.5 Motherboard Layout
Below is a layout of the X11SSH-LN4F with jumper, connector and LED locations shown. See
the table on the following pages for descriptions. For detailed descriptions, pinout information
and jumper settings, refer to Chapter 4.
VGA
LAN2 LAN1
USB6/7
USB0/1 COM1
IPMI_LAN
JUIDB1
LE1
LAN3
LAN4
J7 J8
FAN4
COM2
JPWR2
JPWR1
FAN2FAN1
JPI2C1
FAN3
FANA
USB8/9 JF1
USB4/5
I-SATA0
I-SATA1
LEDPWR
JSTBY1
JWD1
USB10
I-SATA2
I-SATA3
I-SATA4
I-SATA5
I-SATA6
I-SATA7
JSD1
JSD2
JTPM1
LE3
J23
BT1
USB2/3
JIPMB1
JD1
JI2C1
SP1
JPB1
JBR1
JPG1
JPL4 JPL2
JPL3
JPL1
LEDBMC
JOH1
DIMMA2
DIMMB1
DIMMA1
DIMMB2
I-SGPIO1
I-SGPIO2
JL1
JBT1
JI2C2
JPME2

1514
SuperServer 5019S-MN4 User's Manual Chapter 1: Introduction
Quick Reference Table
Jumper Description Default Setting
J7 LAN4 LINK ACK Off (Disabled)
J8 LAN3 LINK ACK Off (Disabled)
JBR1 BIOS Recovery Pins 1-2 (Normal)
JBT1 Clear CMOS See Chapter 4
JI2C1/JI2C2 SMB to PCI Slots Pins 2-3 (Disabled)
JPB1 BMC Enable/Disable Pins 1-2 (Enabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1-JPL4 LAN1-LAN4 Enable Pins 1-2 (Enabled)
JPME2 Manufacturing Mode Select Pins 1-2 (Normal)
JWD1 Watch Dog Enable Pins 1-2 (Reset)
LED Description Status
LE1 Rear UID LED Blue: On; Unit identied
LE3 PCI-E 3.0 M.2 LED Green: Blinking; Active
LEDBMC BMC Heartbeat LED Green: Blinking; BMC normal
LEDPWR Onboard Power LED Green: Solid on; Power on
Connector Description
BT1 Onboard Battery
COM1/COM2 COM1/COM2 Port Headers
Fan1-Fan4, FanA System/CPU Fan Headers
I-SATA0-I-SATA7 SATA 3.0 Connectors via Intel PCH (6Gb/s)
I-SGPIO 1/2 Serial_Link General Purpose I/O Connection Headers 1/2
IPMI_LAN Dedicated IPMI Gigabit (RJ45) Port
J23 M.2 Socket
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I2C Header (for an IPMI Card)
JL1 Chassis Intrusion Header
JOH1 Overheat LED Indicator
JPI2C1 Power I2C System Management Bus (Power SMB) Header
JPWR1 24-pin ATX Main Power Connector (Required)
JPWR2 +12V 8-pin CPU power Connector (Required)
JSD1/JSD2 SATA Disk On Module (DOM) Power Connectors
JSTBY1 Wake-On-LAN Enable Header
JTPM1 Trusted Platform Module/Port 80 Connector
JUIDB1 UID (Unit Identication) Switch
LAN1-LAN4 Gigabit (RJ45) LAN Ports
Connector Description
PCI-E (PCH) Slot 4 PCI-Express 3.0 x4in x8 Slot
PCI-E (CPU) Slot 5 PCI-Express 3.0 x8 Slot
PCI-E (CPU) Slot 6 PCI-Express 3.0 x8 in x16 Slot
SP1 Internal Speaker/Buzzer
USB 0/1 Back Panel USB 2.0 Ports
USB 2/3, USB 4/5 Front Accessible USB 2.0 Headers
USB 6/7 Back Panel USB 3.0 Ports
USB 8/9 Front Accessible USB 3.0 Header
USB 10 USB 3.0 Type-A Header
VGA Back Panel VGA Port

16
SuperServer 5019S-MN4 User's Manual
Figure 1-5. C236 Chipset Block Diagram
Note: This is a general block diagram and may not exactly represent the features on your
motherboard. See the System Specications appendix for the actual specications of your
motherboard.

SuperServer 5019S-MN4 User's Manual Chapter 2: Server Installation
1817
Chapter 2
Server Installation
2.1 Overview
This chapter provides advice and instructions for mounting your system in a server rack.
If your system is not already fully integrated with processors, system memory etc., refer to
Chapter 4 for details on installing those specic components.
Caution: Electrostatic Discharge (ESD) can damage electronic components. To prevent such
damage to PCBs (printed circuit boards), it is important to use a grounded wrist strap, handle
all PCBs by their edges and keep them in anti-static bags when not in use.
2.2 Preparing for Setup
The box in which the system was shipped should include the rackmount hardware needed to
install it into the rack. Please read this section in its entirety before you begin the installation.
Choosing a Setup Location
• The system should be situated in a clean, dust-free area that is well ventilated. Avoid areas
where heat, electrical noise and electromagnetic elds are generated.
• Leave enough clearance in front of the rack so that you can open the front door completely
(~25 inches) and approximately 30 inches of clearance in the back of the rack to allow
sufcient space for airow and access when servicing.
• This product should be installed only in a Restricted Access Location (dedicated equipment
rooms, service closets, etc.).
• This product is not suitable for use with visual display workplace devices acccording to §2
of the the German Ordinance for Work with Visual Display Units.
Rack Precautions
• Ensure that the leveling jacks on the bottom of the rack are extended to the oor so that
the full weight of the rack rests on them.
• In single rack installations, stabilizers should be attached to the rack. In multiple rack in-
stallations, the racks should be coupled together.
• Always make sure the rack is stable before extending a server or other component from
the rack.
• You should extend only one server or component at a time - extending two or more simul-
taneously may cause the rack to become unstable.
Server Precautions
• Review the electrical and general safety precautions in Appendix B.
• Determine the placement of each component in the rack before you install the rails.
• Install the heaviest server components at the bottom of the rack rst and then work your
way up.
• Use a regulating uninterruptible power supply (UPS) to protect the server from power
surges and voltage spikes and to keep your system operating in case of a power failure.
• Allow any drives and power supply modules to cool before touching them.
• When not servicing, always keep the front door of the rack and all covers/panels on the
servers closed to maintain proper cooling.
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating temperature of
the rack environment may be greater than the room's ambient temperature. Therefore,
consideration should be given to installing the equipment in an environment compatible with
the manufacturer’s maximum rated ambient temperature (TMRA).
Airow
Equipment should be mounted into a rack so that the amount of airow required for safe
operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not arise due
to uneven mechanical loading.

SuperServer 5019S-MN4 User's Manual Chapter 2: Server Installation
2019
Circuit Overloading
Consideration should be given to the connection of the equipment to the power supply circuitry
and the effect that any possible overloading of circuits might have on overcurrent protection
and power supply wiring. Appropriate consideration of equipment nameplate ratings should
be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself should be
grounded. Particular attention should be given to power supply connections other than the
direct connections to the branch circuit (i.e. the use of power strips, etc.).
To prevent bodily injury when mounting or servicing this unit in a rack, you must take
special precautions to ensure that the system remains stable. The following guidelines
are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially lled rack, load the rack from the bottom to the top
with the heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or
servicing the unit in the rack.
2.3 Installing the Rails
There are a variety of rack units on the market, which may require a slightly different assembly
procedure.
The following is a basic guideline for installing the system into a rack with the rack mounting
hardware provided. You should also refer to the installation instructions that came with the
specic rack you are using.
Identifying the Rails
The rack rails and the related hardware should have been included with the system. Refer to
Figure 2-1 to identify the rail sections. Note that these two rails are left/right specic
Installing the Chassis Rails
Begin the rack mounting procedure by installing the inner rails to the server chassis.
1. Position the front and rear chassis rail sections along the side of the server making sure
the screw holes line up. Note that these two rails are left/right specic.
2. Screw the front chassis rail (the long piece) securely to the side of the chassis (see
Figure 2-2). There should be two screws for each side. Repeat this procedure for the
other rail on the opposite side of the chassis.
3. Attach the two rear chassis rails to the chassis in the same manner, again keeping in
mind that the rails are left/right specic. (You will also need to attach the rail brackets
when installng into a telco rack.)
Warning: do not pick up the server with the front handles. They are designed to pull
the system from a rack only.
Slide rail mounted equipment is not to be used as a shelf or a work space.

SuperServer 5019S-MN4 User's Manual Chapter 2: Server Installation
2221
Installing the Rack Rails
Determine where you want to place the server in the rack (see the Rack and Server
Precautions in Section 2.2). Note that servers should always be installed to the bottom of a
rack rst for stability reasons.
1. Position the chassis rail guides at the desired location in the rack, keeping the sliding
rail guide facing the inside of the rack.
2. Screw the assembly securely to the rack using the brackets provided.
3. Attach the other assembly to the other side of the rack, making sure that both are at the
exact same height and with the rail guides facing inward.
Note: Both front chassis rails and the rack rails have a locking tab, which serves two functions.
First, it locks the server into place when installed and pushed fully into the rack (its normal
operating position. In addition, these tabs lock the server in place when fully extended from
the rack. This prevents the server from coming completely out of the rack when pulled out
for servicing.
Figure 2-1. Installing the Rear Inner Rails
Figure 2-2. Installing the Server into a Rack
Note: Figures are for illustrative purposes only. Always install servers to the bottom of a rack
rst.
2.4 Installing the Server into a Rack
You should now have rails attached to both the chassis and the rack. The next step is to
install the server into the rack.
1. Line up the rear of the chassis rails with the front of the rack rails.
2. Slide the chassis rails into the rack rails, keeping the pressure even on both sides (you
may have to press the locking tabs when inserting). See Figure 2-2.
3. When the server has been pushed completely into the rack, you should hear the locking
tabs "click".
Warning: Stability hazard. The rack stabilizing mechanism must be in place, or the
rack must be bolted to the oor before you slide the unit out for servicing. Failure to
stabilize the rack can cause the rack to tip over.

SuperServer 5019S-MN4 User's Manual
23
Note: Figure is for illustrative purposes only. Always install servers to the bottom of a rack rst.
Installing the Server into a Telco Rack
To install the SuperServer 5019S-MN4 into a Telco (or “open”) type rack, use two L-shaped
brackets on either side of the chassis (four total).
1. First, determine how far the server will extend out from the front of the rack. The chassis
should be positioned so that the weight is balanced between front and back.
2. Attach the two front brackets to each side of the chassis, then the two rear brackets
positioned with just enough space to accommodate the width of the rack.
3. Finish by sliding the chassis into the rack and tightening the brackets to the rack. See
Figure 2-4.
Figure 2-3. Installing the Server into a Telco Rack

SuperServer 5019S-MN4 User's Manual
2524
Chapter 3: Maintenance and Component Installation
Chapter 3
Maintenance and Component Installation
This chapter provides instructions on installing and replacing main system components. To
prevent compatibility issues, only use components that match the specications and/or part
numbers given.
Installation or replacement of most components require that power rst be removed from the
system. Please follow the procedures given in each section.
3.1 Removing Power
Use the following procedure to ensure that power has been removed from the system. This
step is necessary when removing or installing non hot-swap components or when replacing
a non-redundant power supply.
1. Use the operating system to power down the system.
2. After the system has completely shut-down, disconnect the AC power cord(s) from the
power strip or outlet. (If your system has more than one power supply, remove the AC
power cords from all power supply modules)
3. Disconnect the power cord(s) from the power supply module(s).
3.2 Accessing the System
The SC813MFTQC-350CB features a removable top cover, which allows easy access to the
inside of the chassis.
Removing the Top Cover
1. Disconnect the chassis from any power source if necessary (see above).
2. Remove the screws securing the cover to the chassis.
3. Slide the cover toward the rear of the chassis.
4. Lift the cover from the chassis.
3.3 Motherboard Components
Processor and Heatsink Installation
Follow the procedures in this section to install a processor (CPU) and heatsink to the
motherboard.
Notes:
• The motherboard should be installed into the chassis rst and the processor should be
installed into the CPU socket before you install a CPU heatsink.
• If you bought a CPU separately, make sure that you use an Intel-certied multi-directional
heatsink only.
• When receiving a motherboard without a processor pre-installed, make sure that the plastic
CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your
retailer immediately.
• Refer to the Supermicro website for updates on CPU support.
Installing the Processor(s)
Begin by removing power from the system as described in Section 3.1.
1. Remove the cover plate that protects the CPU#1 socket: press the load lever to release
the load plate, which covers the CPU socket, from its locked position.
Figure 3-1. Removing the Top Cover
4
3
2
2
Note: the gure above is for illustrative purposes only. The 5019S-MN4 features a single
power supply only.

SuperServer 5019S-MN4 User's Manual
2726
Chapter 3: Maintenance and Component Installation
Figure 3-2. Removing the Processor Cover Plate
Figure 3-3. Placing the Processor into the Socket
2. Gently lift the load lever to open the load plate. Remove the plastic cover plate.
Load Lever
Load Plate
Bottom Edge
Top Edge
3. Use your thumb and your index nger to hold the edges of the processor. Align the CPU
key (the semi-circle cutouts) with the socket keys.
4. Once aligned, carefully place the processor into the socket. Do not drop the processor
on the socket, move or rub the processor against the socket or against any socket pins,
which may damage the components.
5. With the processor inserted into the socket, inspect the four corners of the CPU to make
sure that it is properly installed and ush with the socket.
Figure 3-5. Installing/Removing the Heatsink
Figure 3-4. Inspecting the Processor Installation
CPU properly
installed
Load lever locked into
place
6. Carefully press the processor load lever down until it locks into its retention tab.
Installing a Heatsink
A passive type heatsink is used on the X11SSH-LN4F.
Note: Do not apply any thermal grease to the heatsink or the CPU die; the required amount
has already been applied.
1. Place the heatsink on top of the CPU so that the four mounting holes are aligned with
those on the heatsink retention mechanism.
2. Screw in two diagonal screws (i.e. the #1 and the #2 screws) until they are just snug.
Do not fully tighten the screws or you may damage the CPU.

SuperServer 5019S-MN4 User's Manual
2928
Chapter 3: Maintenance and Component Installation
Figure 3-6. Installing the Heatsink
3. Add the two remaining screws then nish the installation by fully tightening all four
screws (be careful not to overtighten).
Mounting Holes
Screw#1
Heatsink Bracket
Screw#2
Motherboard
Removing a Heatsink
We do not recommend removing the heatsink. If necessary, please follow the instructions
below to prevent damage to the CPU or the CPU socket.
1. Unscrew and remove the heatsink screws from the motherboard in the sequence as
show in the gure above.
2. Hold and gently pivot the heatsink back and forth to loosen it from the CPU. (Do not use
excessive force when dislodging the heatsink.)
Loosen screws in sequence as
shown.
Screw#2
Motherboard
Screw#1
Screw#3
Screw#4
Heatsink Bracket
Figure 3-7. Removing the Heatsink
Note: Wait for the heatsink to cool down before removing it.
3. Once the heatsink is loose, remove it from the CPU.
4. Clean the surface of the CPU and the heatsink to get rid of the old thermal grease.
Reapply the proper amount of thermal grease to the surface before you re-install the
heatsink.

SuperServer 5019S-MN4 User's Manual
3130
Chapter 3: Maintenance and Component Installation
Figure 3-8. Installing DIMMs
Memory Installation
Memory Support
The X11SSH-LN4F supports up to 64GB of ECC DDR4-2133/1866/1600/1333 unbuffered
(UDIMM) memory in four memory slots. Populating these DIMM slots with memory modules
of the same type and size will result in interleaved memory, which will improve memory
performance.
Check the Supermicro website for possible updates to memory support.
Installing Memory
Begin by removing power from the system as described in Section 3.1.
1. Starting with DIMMB2 (blue slot), push the release tabs outwards on both ends of the
DIMM slot to unlock it.
2. Align the key of the DIMM with the receptive point on the memory slot and the notches
on both ends of the module with the receptive points on the slot.
3. With your thumbs on both ends of the module, press it straight down into the slot until
the module snaps into place.
4. Press the release tabs to the locked positions to secure the DIMM module into the slot.
Repeat for other DIMM slots as needed. See next page for population sequence.
5. To remove a DIMM, unlock the release tabs then pull the DIMM from the memory slot.
Caution: Exercise extreme caution when installing or removing memory modules to prevent
any possible damage to the DIMMs or slots.
Release Tabs
Notches
Press both notches
straight down into
the memory slot.
Note: Visit the product page on the Supermicro website for possible updates to memory
support (www.supermicro.com).
Figure 3-9. Populating DIMMs
PCI Expansion Card Installation
The system includes a pre-installed riser card (p/n CSE-RR1U-E16) that positions a standard
size PCI-E x16 card at a 90 degree angle, allowing it to t inside the chassis.
Installing PCI Expansion Cards
The CSE-RR1U-E16 riser card has already been pre installed into the motherboard. Perform
the following steps to install an add-on card:
Begin by removing power from the system as described in section 3.1.
1. Remove the chassis cover to access the inside of the system.
2. Remove the PCI slot shield on the chassis by releasing the locking tab.
3. Insert the expansion (add-on) card into the riser card.
4. Secure the card with the locking tab.
DIMMB2 (Blue Slot)
DIMMA2 (Blue Slot)
Towards the edge of the motherboard
Towards the CPU
DIMMA1
DIMMB1
DIMM Module Population Sequence
When installing memory modules, the DIMM slots should be populated in the following order:
DIMMB2, DIMMA2, DIMMB1, DIMMA1.
• Always use DDR4 DIMM modules of the same type, size and speed.
• Mixed DIMM speeds can be installed. However, all DIMMs will run at the speed of the
slowest DIMM.
• The motherboard will support odd-numbered modules (1 or 3 modules installed). However,
for best memory performance, install DIMM modules in pairs to activate memory interleav-
ing.

SuperServer 5019S-MN4 User's Manual
3332
Chapter 3: Maintenance and Component Installation
OR
Figure 3-10. Installing the Onboard Battery
Motherboard Battery
The motherboard uses non-volatile memory to retain system information when system power
is removed. This memory is powered by a lithium battery residing on the motherboard.
Replacing the Battery
Begin by removing power from the system as described in section 3.1.
1. Push aside the small clamp that covers the edge of the battery. When the battery is
released, lift it out of the holder.
2. To insert a new battery, slide one edge under the lip of the holder with the positive (+)
side facing up. Then push the other side down until the clamp snaps over it.
Note: Please handle used batteries carefully. Do not damage the battery in any way; a
damaged battery may release hazardous materials into the environment. Do not discard a
used battery in the garbage or a public landll. Please comply with the regulations set up by
your local hazardous waste management agency to dispose of your used battery properly.
Warning: There is a danger of explosion if the onboard battery is installed upside down (which
reverses its polarities). This battery must be replaced only with the same or an equivalent type
recommended by the manufacturer (CR2032).
Figure 3-11. Removing a Drive Carrier
Warning: Only enterprise level HDDs are recommended for use in the server.
3.4 Chassis Components
Hard Drives
Your server may or may not have come with hard drives installed. Up to four 3.5" hard drives
are supportd by the chassis.
The SATA drives are mounted in drive carriers to simplify their installation and removal from
the chassis. (Both procedures may be done without removing power from the system.)
Removing a Hot-Swap Drive Carrier
1. Push the release button on the carrier.
2. Swing the handle fully out.
3. Grasp the handle and use it to pull the drive carrier out of its bay.
Mounting a Drive in a Drive Carrier
1. To add a new drive, install it into the carrier with the printed circuit board side facing
down so that the mounting holes align with those in the carrier.
2. Secure the drive to the carrier with the screws provided, then push the carrier
completely into the drive bay. You should hear a *click* when the drive is fully inserted.
This indicates that the carrier has been fully seated and connected to the midplane,
which automatically makes the power and logic connections to the hard drive.

SuperServer 5019S-MN4 User's Manual
3534
Chapter 3: Maintenance and Component Installation
Figure 3-12. Mounting a Drive in a Carrier
Hard Drive Carrier LED Indicators
LED State/Condition Indication
Green Blinking Indicates drive activity
Red Solid on Drive failure
Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and
servers. For information on recommended HDDs, visit the Supermicro website at http://www.
supermicro.com/products/nfo/les/storage/SBB-HDDCompList.pdf
Removing a Drive from a Drive Carrier
1. Remove the screws that secure the hard drive to the carrier and separate the hard drive
from the carrier.
2. Replace the carrier back into the drive bay.
Hard Drive Carrier Indicators
Each hard drive carrier has two LED indicators: an activity indicator and a status indicator. In
RAID congurations, the status indicator lights to indicate the status of the drive. In non-RAID
congurations, the status indicator remains off. See the table below for details.
System Cooling
Four 4-cm fans provide the cooling for the system. It is very important that the chassis top
cover is installed for the cooling air to circulate properly through the chassis and cool the
components.
Installing Fans
Fan speed is controlled by system temperature via IPMI. If a fan fails, the remaining fans
will ramp up to full speed. Replace any failed fan at your earliest convenience with the same
type and model (the system can continue to run with a failed fan).
Replacing a System Fan
3. If necessary, open the chassis while the power is running to determine which fan
requires changing. (Never run the server for an extended period of time with the chassis
open.)
4. Power down the system and unplug the AC power cord from the rear of the power
supply. Open the chassis cover.
5. Remove the failed fan's cable from the connector on the motherboard.
6. Gently pull upward to remove the failed fan from the housing.
7. Place the new fan into the vacant space in the housing. Make sure that the arrows on
the side of the fan (indicating air direction) point in the same direction as the arrows on
the other fans.
8. Connect the fan wires to the same fan header as the fan just removed.
9. Plug the power cord into the rear of the power supply, power up the system and check
that the fan is working properly before replacing the chassis cover.

SuperServer 5019S-MN4 User's Manual
3736
Chapter 3: Maintenance and Component Installation
Figure 3-13. Replacing a System Fan
Air Shroud
The air shroud is used to concentrate airow to maximize fan efciency. The air shroud does
not require screws to set up.
Installing the Air Shroud
1. Lay the chassis on a at, stable surface and remove the chassis cover.
2. If necessary, move any cables that interfere with the air shroud placement.
3. Place the air shroud in the chassis. The air shroud ts just behind the fans. Slide the air
shroud into the grooves just behind the fan rack.
4. Reroute any cables that were moved and replace the chassis cover.
Power Supply
The 5019S-MN4 has a single high-efciency power supply, which is auto-switching capable.
This enables it to automatically sense and operate with a 100V to 240V input voltage.
Power Supply Failure
If the power supply unit fails, the system will shut down and you will need to replace the unit.
Replacement units can be ordered directly from Supermicro (see contact information in the
Preface).
Removing the Power Supply
Begin by removing power from the system as described in Section 3.1.
1. Releasing the retention screws that secure the chassis to the rack, then grasp the two
handles on either side and pull the system straight out until it locks (you will hear a
"click").
2. Next, remove the top chassis cover as described in Section 3.2.
3. To remove the failed power unit, remove the two screws on the back and the single
screw on the front of the power supply, which secure it to the chassis. You can then lift
the unit straight out of the chassis.
Installing a New Power Supply
1. Replace the failed power supply with another identical power supply module (exact
same model).
2. Carefully insert the new module into position in the chassis and secure it with the three
screws you removed previously.
3. Reconnect the AC power cord.
4. Replace the chassis top cover and push the server back into the rack.
5. Finish by pressing the power button on the control panel.
Note: the gure above is for illustrative purposes only. The 5019S-MN4 features a single
power supply only.
