Supero A+ Server 1022TC-IBQF User manual

®
SUPER
USER’S MANUAL
Revision 1.0d
A+ SERVER
1022TC-IBQF
1022TC-TF

ii
The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu-
mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.
IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the manufacturer’s instruction manual, may cause harmful interference
with radio communications. Operation of this equipment in a residential area is likely to cause harm-
ful interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn-
ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to the
State of California to cause birth defects and other repro-
ductive harm.
Manual Revision Revision 1.0d
Release Date: March 06, 2014
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2014 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC techni-
cians. It provides information for the installation and use of the A+ Servers
1022TC-IBQF/1022TC-TF. Installation and maintainance should be performed by
experienced technicians only.
The A+ Server 1022TC-IBQF/1022TC-TF is a high-end server based on the
SC808T-920B 1U rackmount chassis and the dual processor H8DCT-F (for the
1022TC-TF) and H8DCT-IBQF (for 1022TC-IBQF) serverboards. The only differ-
ence between the two servers is that the 1022TC-IBQF server has an InniBand®
port and the 1022TC-TF does not.
Manual Organization
Chapter 1: Introduction
The rst chapter provides a checklist of the main components included with the
server system and describes the main features of the Super H8DCT-F/IBQF moth-
erboard and the SC808T-920B chassis.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the A+ Server
1022TC-IBQF/1022TC-TF into a rack and check out the server conguration prior
to powering up the system. If your server was ordered without the processor and
memory components, this chapter will refer you to the appropriate sections of the
manual for their installation.
Chapter 3: System Interface
Refer to this chapter for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as other LEDs
located throughout the system.

iv
A+ Server 1022TC-IBQF/1022TC-TF User's Guide
Chapter 4: Warning Statements for AC Systems
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the A+
Server 1022TC-IBQF/1022TC-TF.
Chapter 5: Advanced Motherboard Setup
Chapter 5 provides detailed information on the H8DCT-F/IBQF motherboard,
including the locations and functions of connectors, headers and jumpers. Refer
to this chapter when adding or removing processors or main memory and when
reconguring the motherboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC808T-920B 1U rackmount
server chassis. You should follow the procedures given in this chapter when in-
stalling, removing or reconguring drives and when replacing system power supply
units and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: POST Error Beep Codes
Appendix B: System Specications

v
Preface
vi
Contents
Chapter 1 Introduction
1-1 Overview ......................................................................................................... 1-1
1-2 Motherboard Features..................................................................................... 1-2
Processor ........................................................................................................ 1-2
Memory ........................................................................................................... 1-2
Onboard SATA................................................................................................. 1-2
PCI Expansion Slots ....................................................................................... 1-2
Onboard Controllers/Ports .............................................................................. 1-2
InniBand ....................................................................................................... 1-2
Other Features................................................................................................ 1-3
1-3 Server Chassis Features ................................................................................ 1-4
System Power................................................................................................. 1-4
SATA Subsystem............................................................................................. 1-4
Control Panel .................................................................................................. 1-4
Expansions Cards........................................................................................... 1-4
Cooling System............................................................................................... 1-4
1-4 Contacting Supermicro.................................................................................... 1-5
Chapter 2 Server Installation
2-1 Overview ......................................................................................................... 2-1
2-2 Unpacking the System .................................................................................... 2-1
2-3 Preparing for Setup......................................................................................... 2-1
Choosing a Setup Location............................................................................. 2-1
2-4 Warnings and Precautions.............................................................................. 2-2
Rack Precautions............................................................................................ 2-2
Server Precautions.......................................................................................... 2-2
Rack Mounting Considerations ....................................................................... 2-3
Ambient Operating Temperature ................................................................ 2-3
Reduced Airow ......................................................................................... 2-3
Mechanical Loading ................................................................................... 2-3
Circuit Overloading..................................................................................... 2-3
Reliable Ground ......................................................................................... 2-3
2-4 Installing the Server into a Rack..................................................................... 2-4
Identifying the Sections of the Rack Rails...................................................... 2-4
Installing the Rack Rails ................................................................................. 2-5
Installing the Server into a Telco Rack ........................................................... 2-7

vi
A+ Server 1022TC-IBQF/1022TC-TF User's Guide
2-5 Checking the Serverboard Setup.................................................................... 2-8
2-6 Preparing to Power On ................................................................................... 2-9
Chapter 3 System Interface
3-1 Overview ......................................................................................................... 3-1
3-2 Control Panel Buttons ..................................................................................... 3-2
3-3 Control Panel LEDs ........................................................................................ 3-2
Overheating..................................................................................................... 3-3
3-4 Drive Carrier LEDs.......................................................................................... 3-4
3-5 Power Supply LEDs ........................................................................................ 3-4
Chapter 4 Standardized Warning Statements for AC Systems
4-1 About Standardized Warning Statements....................................................... 4-1
Warning Denition........................................................................................... 4-1
Installation Instructions.................................................................................... 4-4
Circuit Breaker ................................................................................................ 4-5
Power Disconnection Warning ........................................................................ 4-6
Equipment Installation..................................................................................... 4-8
Restricted Area................................................................................................ 4-9
Battery Handling............................................................................................ 4-10
Redundant Power Supplies .......................................................................... 4-12
Backplane Voltage ........................................................................................ 4-13
Comply with Local and National Electrical Codes........................................ 4-14
Product Disposal........................................................................................... 4-15
Hot Swap Fan Warning................................................................................. 4-16
Power Cable and AC Adapter ...................................................................... 4-18
Chapter 5 Advanced Motherboard Setup
5-1 Handling the Motherboard .............................................................................. 5-1
Precautions ..................................................................................................... 5-1
Unpacking ....................................................................................................... 5-2
5-2 Motherboard Installation.................................................................................. 5-2
5-3 Connecting Cables.......................................................................................... 5-3
Connecting Data Cables ................................................................................. 5-3
Connecting Power Cables .............................................................................. 5-3
Connecting the Control Panel......................................................................... 5-3
5-4 Rear I/O Ports................................................................................................. 5-4
5-5 Processor and Heatsink Installation................................................................ 5-5
Installing a Passive CPU Heatsink ................................................................. 5-7
Removing the Heatsink................................................................................... 5-7

vii
Preface
5-6 Installing Memory............................................................................................ 5-8
DIMM Module Population Conguration .................................................. 5-10
5-7 Adding PCI Expansion Cards ........................................................................5-11
5-8 Motherboard Details...................................................................................... 5-12
5-9 Connector Denitions ................................................................................... 5-14
Power Connectors ................................................................................... 5-14
Auxiliary Power Connector....................................................................... 5-14
PW_ON Connector................................................................................... 5-14
Reset Connector ...................................................................................... 5-14
Overheat/Fan Fail LED (OH).................................................................... 5-14
NIC2 (LAN2) LED..................................................................................... 5-15
NIC1 (LAN1) LED..................................................................................... 5-15
HDD LED.................................................................................................. 5-15
Power On LED ......................................................................................... 5-15
NMI Button ............................................................................................... 5-15
Video Connector....................................................................................... 5-15
Serial Ports............................................................................................... 5-16
LAN1/2 (Ethernet Ports)........................................................................... 5-16
Overheat LED........................................................................................... 5-16
Chassis Intrusion ..................................................................................... 5-16
IPMB......................................................................................................... 5-17
Trusted Platform Module Header ............................................................. 5-17
Power SMB (I2C)...................................................................................... 5-17
Universal Serial Bus Ports ....................................................................... 5-17
T-SGPIO................................................................................................... 5-18
USB Headers ........................................................................................... 5-18
Unit Identier Button................................................................................. 5-18
Fan Headers............................................................................................. 5-18
5-10 Jumper Settings ............................................................................................ 5-19
Explanation of Jumpers ................................................................................ 5-19
CMOS Clear............................................................................................. 5-19
InniBand Port Enable/Disable
(H8DCT-IBQF only) .................................................................................. 5-20
I2C to PCI-Express Slots ......................................................................... 5-20
BMC Jumper ............................................................................................ 5-20
VGA Enable/Disable................................................................................. 5-20
LAN Enable/Disable ................................................................................ 5-20
Watch Dog Enable/Disable ...................................................................... 5-21

viii
A+ Server 1022TC-IBQF/1022TC-TF User's Guide
5-11 Onboard Indicators........................................................................................ 5-22
LAN1/LAN2 LEDs..................................................................................... 5-22
Dedicated IPMI LAN LEDs ..................................................................... 5-22
Power LED ............................................................................................... 5-22
UID LED (LE1) ........................................................................................ 5-22
5-12 SATA Drive Connections ............................................................................... 5-23
SATA Ports ............................................................................................... 5-23
5-13 Enabling SATA RAID..................................................................................... 5-24
Serial ATA (SATA).......................................................................................... 5-24
Installing the OS/SATA Driver ....................................................................... 5-24
Building a Driver Diskette......................................................................... 5-24
Enabling SATA RAID in the BIOS................................................................. 5-25
Using the Adaptec RAID Utility ..................................................................... 5-26
Installing the RAID Driver During OS Installation......................................... 5-26
5-14 Installing Software......................................................................................... 5-27
SuperDoctor III.............................................................................................. 5-28
5-15 Serverboard Battery...................................................................................... 5-30
Chapter 6 Advanced Chassis Setup
6-1 Static-Sensitive Devices.................................................................................. 6-1
Precautions ..................................................................................................... 6-1
Unpacking ....................................................................................................... 6-1
6-2 Control Panel .................................................................................................. 6-2
6-3 Drive Installation and Removal ....................................................................... 6-3
6-4 System Fans ................................................................................................... 6-5
System Fan Replacement............................................................................... 6-5
Air Shrouds ..................................................................................................... 6-7
6-5 Power Supply.................................................................................................. 6-7
Replacing the Power Supply........................................................................... 6-8
Chapter 7 BIOS
7-1 Introduction...................................................................................................... 7-1
7-2 Main Menu ...................................................................................................... 7-2
7-3 Advanced Settings Menu ................................................................................ 7-2
7-4 Security Menu ............................................................................................... 7-14
7-5 Boot Menu..................................................................................................... 7-15
7-6 Exit Menu ...................................................................................................... 7-16
Appendix A POST Error Beep Codes
Appendix B System Specications

Chapter 1
Introduction
1-1 Overview
The Supermicro A+ Server 1022TC-IBQF/1022TC-TF is a dual processor, 1U
rackmount server. It is comprised of two main subsystems: the SC808T-920B
chassis and two serverboards. The 1022TC-TF server uses two H8DCT-F
serverboards; the 1022TC-IBQF uses two H8DCT-IBQF serverboards, the latter
offering a QSFP Inband port. Refer to our web site for information on certied
operating systems.
In addition to the serverboards and chassis, various hardware components may
have been included with the 1022TC-IBQF/1022TC-TF, as listed below.
•Four SATA drive carriers (MCP-220-00001-01)
•One SATA backplane (BPN-SAS-808-O-P)
•Two riser cards (RSC-R1U-E16R-O-P) for expansion cards
•Six 40x56mm 4-pin cooling fans (FAN-0085L4)
•Four 1U passive CPU heatsinks (SNK-P0022+)
•Two air shrouds (MCP-310-18008-ON)
•One set of rack rails (MCP-290-00042-0V)
Note: For your system to work properly, please follow the links below to download
all necessary drivers/utilities and the user’s manual for your server.
•Product manuals: http://www.supermicro.com/support/manuals/
•Product drivers and utilities: ftp://ftp.supermicro.com
•Product safety information:
http://super-dev/about/policies/safety_information.cfm
For support, email [email protected].
Chapter 1: Introduction
1-1

1-2
A+ Server 1022TC-IBQF/1022TC-TF User's Manual
1-2 Motherboard Features
At the heart of the A+ Server 1022TC-IBQF/1022TC-TF lies two H8DCT-F/IBQF dual
processor motherboards based upon one AMD SR5670 chipset and one SP5100
Southbridge chipset. Below are the main features of the H8DCT-F/IBQF. Note that
the features on each board are doubled for the server, which includes two nodes.
Processor
Each H8DCT-F/IBQF supports up to two AMD Opteron 4000 series (AMD Socket C32
type) processors. Please refer to our web site for a complete listing of supported
processors (www.supermicro.com).
Memory
Each H8DCT-F/IBQF serverboard has Twelve (12) dual channel DIMM slots that
can support up to 64 GB of ECC/Non-ECC UDIMM or up to 192 GB of ECC RDIMM
DDR3-1600/1333/1066 Mhz in 1 GB, 2 GB, 4 GB, 8 GB or 16 GB sizes of 1.5V
or 1.35V voltages.
Onboard SATA
A SATA controller is built into the AMD SP5100 chipset to provide support for a four
port, 3 Gb/sec Serial ATA subsystem, which is RAID 0, 1 and 10 compatible.
PCI Expansion Slots
Each H8DCT-F/IBQF has one (1) PCI-Express x16 Gen. 2 slot.
Onboard Controllers/Ports
Onboard I/O backpanel ports include one COM port, a VGA port, two Gb LAN ports, a
dedicated IPMI LAN port, two USB ports and one single QSFP InniBand connector
(H8DCT-IBQF only). Two USB headers are included on the motherboard.
InniBand
The AS 1022TC-IBQF server includes a QDR (quad data rate) speed InniBand
QSFP connector. InniBand is a scalable serial communications link intended for
connecting processors with high-speed peripherals

Chapter 1: Introduction
1-3
Figure 1-1. AMD SR5670/SP5100 Chipset:
System Block Diagram
Note: This is a general block diagram and may not exactly represent
the features on your motherboard. See the previous pages for the
actual specications of your motherboard.
AMD
Socket C32
CPU2
HT3 Link
16x16 bits 5.2GT/s
PCI-E GEN2 X16
Slot1
PCI-E GEN2 X4
INTEL
KAWELA
A-Link
SP5100
SATA x4
BMC
VGA
WPCM450-R
PCI
SMBus
SIO
W83527
SPI Flash
RMII
DDR2 SDRAM
64Mb X16bit
PSU I2C
IPMB
VGA
RJ45USB x4
FE PHY
RTL8201N
LPC
HWM
W83795G
SR5670
RJ45
RJ45
COM1
PCI-E GEN2 X8
Mellanox
ConnectX
DDR3
1600/1333/1066 MT/s
DIMM 1A
DIMM 1B
DIMM 1C
DIMM 2A
DIMM 2B
DIMM 2C
CH 2
CH 1
DDR3
1600/1333/1066 MT/s
DIMM 1A
DIMM 1B
DIMM 1C
DIMM 2A
DIMM 2B
DIMM 2C
CH 1
HT3 Link
16 x16 bits 6.4GT/s
HT3 Link
16 x16 bits 6.4GT/s
CH 2
AMD
Socket C32
CPU1
Other Features
Other onboard features that promote system health include voltage monitors, a
chassis intrusion header, auto-switching voltage regulators, chassis and CPU
overheat sensors and virus protection.

1-4
A+ Server 1022TC-IBQF/1022TC-TF User's Manual
1-3 Server Chassis Features
The following is a general outline of the main features of the SC808T-920B 1U
twin rackmount server chassis. Details on the chassis can be found in Chapter 6.
System Power
The SC808T-920B chassis includes a single high-efciency 920W power supply,
which provides the power to both serverboards housed in the chassis.
SATA Subsystem
The SC808 chassis was designed to support four SATA hard drives, which are
hot-swappable units.
Note: The operating system you use must have RAID support to enable the hot-
swap capability of the SATA drives (RAID 0, 1 and 10 supported).
Control Panel
The SC808 features two independant control panels, one associated with each node
(serverboard). LEDs indicate power on, network activity, hard disk drive activity and
system overheat. The control panel also includes a main power button and a system
reset button as well as a UID LED.
Expansions Cards
The SC808 supports the use of two low prole PCI-E expansion cards.
Cooling System
The SC808 chassis has an innovative cooling design that features an air shroud
and three sets of 4-cm counter-rotating fans per node (congured as six fans placed
back to back in pairs). A fan speed control setting in BIOS allows fan speed to be
determined by system temperature.

Chapter 1: Introduction
1-5
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Web Site: www.supermicro.com
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Email: [email protected]
Tel: [phone]
Web Site: www.supermicro.com.tw

1-6
A+ Server 1022TC-IBQF/1022TC-TF User's Manual
Notes

Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your server system up and
running. Following these steps in the order given should enable you to have the
system operational within a minimum amount of time. This quick setup assumes
that your system has come to you with the processors and memory preinstalled. If
your system is not already fully integrated with a serverboard, processors, system
memory etc., please turn to the chapter or section noted in each step for details on
installing specic components.
2-2 Unpacking the System
You should inspect the box the server was shipped in and note if it was damaged
in any way. If the server itself shows damage you should le a damage claim with
the carrier who delivered it.
2-3 Preparing for Setup
Decideonasuitablelocationfortherackunitthatwillholdthe1022TC-IBQF/1022TC-TF.
It should be situated in a clean, dust-free area that is well ventilated. Avoid areas
where heat, electrical noise and electromagnetic elds are generated. You will also
need it placed near a grounded power outlet. Be sure to read the Rack and Server
Precautions in the next section.
The box the server was shipped in should include two sets of rail assemblies, two
rail mounting brackets and the mounting screws you will need to install the system
into the rack. Follow the steps in the order given to complete the installation process
in a minimum amount of time. Please read this section in its entirety before you
begin the installation procedure outlined in the sections that follow.
Choosing a Setup Location
•Leave enough clearance in front of the rack to enable you to open the front
door completely (~25 inches).
•Leave approximately 30 inches of clearance in the back of the rack to allow for
sufcient airow and ease in servicing.

2-2
A+ Server 1022TC-IBQF/1022TC-TF User's Manual
•This product is for installation only in a Restricted Access Location (dedicated
equipment rooms, service closets and the like).
•This product is not suitable for use with visual display work place devices accord-
ing to §2 of the the German Ordinance for Work with Visual Display Units.
2-4 Warnings and Precautions
Rack Precautions
•Ensure that the leveling jacks on the bottom of the rack are fully extended to
the oor with the full weight of the rack resting on them.
•In single rack installation, stabilizers should be attached to the rack.
•In multiple rack installations, the racks should be coupled together.
•Always make sure the rack is stable before extending a component from the
rack.
•You should extend only one component at a time - extending two or more si-
multaneously may cause the rack to become unstable.
Server Precautions
•Review the electrical and general safety precautions in Chapter 4.
•Determine the placement of each component in the rack before you install the
rails.
•Install the heaviest server components on the bottom of the rack rst, and then
work up.
•Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
•Allow the hot plug hard drives and power supply modules to cool before touch-
ing them.
•Always keep the rack's front door and all panels and components on the servers
closed when not servicing to maintain proper cooling.
•Make sure all power and data cables are properly connected and not blocking
the chassis airow. See Chapter 5 for details on cable connections.

Chapter 2: Server Installation
2-3
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating
temperature of the rack environment may be greater than the ambient temperature
of the room. Therefore, consideration should be given to installing the equipment
in an environment compatible with the manufacturer’s maximum rated ambient
temperature (Tmra).
Reduced Airow
Equipment should be mounted into a rack so that the amount of airow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack
itself should be grounded. Particular attention should be given to power supply
connections other than the direct connections to the branch circuit (i.e. the use of
power strips, etc.).
Warning! To prevent bodily injury when mounting or servicing this unit in a
rack, you must take special precautions to ensure that the system remains
stable. The following guidelines are provided to ensure your safety:
•This unit should be mounted at the bottom of the rack if it is the only unit in
the rack.
•When mounting this unit in a partially lled rack, load the rack from the bottom
to the top with the heaviest component at the bottom of the rack.
•If the rack is provided with stabilizing devices, install the stabilizers before
mounting or servicing the unit in the rack.

2-4
A+ Server 1022TC-IBQF/1022TC-TF User's Manual
2-4 Installing the Server into a Rack
This section provides information on installing the server into a rack unit with the
rack rails provided. If the system has already been mounted into a rack, you can
skip ahead to Sections 2-5 and 2-6.
There are a variety of rack units on the market, which may mean the assembly
procedure will differ slightly. You should also refer to the installation instructions that
came with the rack unit you are using.
Note: This rail will t a rack between 26" and 33.5" deep.
Identifying the Sections of the Rack Rails
You should have received two rack rail assemblies in the rack mounting kit. Each
assembly consists of two sections: an inner xed chassis rail that secures directly
to the server chassis and an outer xed rack rail that secures directly to the rack
itself (see Figure 2-1).
Figure 2-1. Identifying the Sections of the Rack Rails
(right side rail shown)
SCALE 0.500
Rail Extension
(Inner Rail is preinstalled
to the chassis) Outer Rails

Chapter 2: Server Installation
2-5
Installing the Rack Rails
The SC808 chassis includes a set of inner rack rails in two sections: inner rails
and inner rail extensions. The inner rails are preattached and do not interfere with
normal use of the chassis if you decide not to use a server rack. Attach the inner
rail extensions to to the inner rails, to stabilize the chassis within the rack.
Installing the Inner Rail Extensions (Figure 2-2)
1. Place the inner rack extensions on the side of the chassis aligning the hooks
of the chassis with the rail extension holes. Make sure the extension faces
"outward" just like the preattached inner rail.
2. Slide the extension toward the front of the chassis.
3. Secure the chassis with two screws as illustrated.
4. Repeat steps 1-3 for the other inner rail extension.
Figure 2-2. Installing the Inner Rail Extensions
1
1
1
2
1
3

2-6
A+ Server 1022TC-IBQF/1022TC-TF User's Manual
Installing the Outer Rails to the Rack
1. Attach the short bracket to the outside of the long bracket. You must align the
pins with the slides. Also, both bracket ends must face the same direction.
2. Adjust both the short and long brackets to the proper distance so that the rail
ts snugly into the rack.
3. Secure the long bracket to the front side of the outer rail with two M5 screws
and the short bracket to the rear side of the outer rail with three M5 screws.
4. Repeat steps 1-4 for the left outer rail.
Figure 2-3. Assembling the Outer Rails
SCALE 0.500
Secure to the
Front of the Rack
Secure to the
Rear of the Rack
Attach Outer Racks
together
Installing the Chassis into a Rack
1. Conrm that chassis includes the inner rails (A) and rail extensions (B). Also,
conrm that the outer rails (C) are installed on the rack. (See Figure 2-4.)
2. Line chassis rails (A and B) with the front of the rack rails (C).
3. Slide the chassis rails into the rack rails, keeping the pressure even on both
sides (you may have to depress the locking tabs when inserting). When the
server has been pushed completely into the rack, you should hear the locking
tabs "click".
4. (Optional) Insert and tightening the thumbscrews that hold the front of the
server to the rack.
