Supero SUPERSERVER 6016T-6RFT+ User manual

SUPERSERVER 6016T-6RFT+
SUPERSERVER 6016T-6RF+
SUPER ®
USER’S MANUAL
1.0a

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this
manual, please see our web site at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software and docu-
mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.
Any use or reproduction of this product is not allowed, except as expressly permitted by the terms
of said license.
IN NO EVENT WILLSUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATASTORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the manufacturer’s instruction manual, may cause harmful interference
with radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn-
ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”
WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to the
State of California to cause birth defects and other repro-
ductive harm.
Manual Revision 1.0
Release Date: August 26, 2013
Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.
Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.
Copyright © 2013 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America

iii
Preface
Preface
About This Manual
This manual is written for professional system integrators and PC technicians.
It provides information for the installation and use of the SuperServer 6016T-
6RFT+/6016T-6RF+. Installation and maintenance should be performed by expe-
rienced technicians only.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
server system and describes the main features of the X8DTU-6TF+/X8DTU-6F+
serverboard and the SC819TQ-R700U chassis, which comprise the SuperServer
6016T-6RFT+/6016T-6RF+.
Chapter 2: Server Installation
This chapter describes the steps necessary to install the SuperServer into a rack and
check out the server configuration prior to powering up the system. If your server
was ordered without processor and memory components, this chapter will refer you
to the appropriate sections of the manual for their installation.
Chapter 3: System Interface
Refer here for details on the system interface, which includes the functions and
information provided by the control panel on the chassis as well as other LEDs
located throughout the system.
Chapter 4: Warning Statements
You should thoroughly familiarize yourself with this chapter for a general overview
of safety precautions that should be followed when installing and servicing the
SuperServer 6016T-6RFT+/6016T-6RF+.

SUPERSERVER 6016T-6RFT+/6016T-6RF+ User's Manual
iv
Chapter 5: Advanced Serverboard Setup
Chapter 5 provides detailed information on the X8DTU-6TF+/X8DTU-6F+
serverboard, including the locations and functions of connections, headers and
jumpers. Refer to this chapter when adding or removing processors or main memory
and when reconfiguring the serverboard.
Chapter 6: Advanced Chassis Setup
Refer to Chapter 6 for detailed information on the SC819TQ-R700U server chassis.
You should follow the procedures given in this chapter when installing, removing or
reconfiguring SATA or peripheral drives and when replacing system power supply
modules and cooling fans.
Chapter 7: BIOS
The BIOS chapter includes an introduction to BIOS and provides detailed informa-
tion on running the CMOS Setup Utility.
Appendix A: BIOS Error Beep Codes
Appendix B: System Specifications

v
Preface
Notes

vi
SUPERSERVER 6016T-6RFT+/6016T-6RF+ User's Manual
Table of Contents
Chapter 1 Introduction
1-1 Overview .........................................................................................................1-1
1-2 Serverboard Features..................................................................................... 1-2
Processors ......................................................................................................1-2
Memory ...........................................................................................................1-2
UIO..................................................................................................................1-2
Onboard SAS.................................................................................................. 1-2
Onboard Serial ATA ........................................................................................1-2
Rear I/O Ports................................................................................................. 1-3
Graphics Controller......................................................................................... 1-3
Other Features................................................................................................ 1-3
1-3 Server Chassis Features ................................................................................1-3
System Power................................................................................................. 1-3
Hard Drives.....................................................................................................1-3
PCI Expansion Slots....................................................................................... 1-4
Front Control Panel.........................................................................................1-4
Cooling System............................................................................................... 1-4
1-4 Contacting Supermicro....................................................................................1-6
Chapter 2 Server Installation
2-1 Overview .........................................................................................................2-1
2-2 Unpacking the System....................................................................................2-1
2-3 Preparing for Setup.........................................................................................2-1
Choosing a Setup Location............................................................................. 2-1
2-4 Warnings and Precautions.............................................................................. 2-2
Rack Precautions............................................................................................ 2-2
Server Precautions..........................................................................................2-2
Rack Mounting Considerations....................................................................... 2-3
Ambient Operating Temperature................................................................2-3
Reduced Airflow .........................................................................................2-3
Mechanical Loading ................................................................................... 2-3
Circuit Overloading.....................................................................................2-3
Reliable Ground ......................................................................................... 2-3
2-5 Installing the System into a Rack ...................................................................2-4
Identifying the Sections of the Rack Rails......................................................2-4
Installing the Inner Rails .................................................................................2-4
Installing the Outer Rails.................................................................................2-5

vii
Table of Contents
Installing the Server into a Telco Rack........................................................... 2-6
2-6 Checking the Serverboard Setup.................................................................... 2-8
Chapter 3 System Interface
3-1 Overview .........................................................................................................3-1
3-2 Control Panel Buttons.....................................................................................3-1
3-3 Control Panel LEDs ........................................................................................ 3-2
3-4 Drive Carrier LEDs..........................................................................................3-3
Chapter 4 Standardized Warning Statements for AC Systems
4-1 About Standardized Warning Statements.......................................................4-1
Warning Definition........................................................................................... 4-1
Installation Instructions.................................................................................... 4-4
Circuit Breaker ................................................................................................ 4-5
Power Disconnection Warning........................................................................4-6
Equipment Installation.....................................................................................4-8
Restricted Area................................................................................................ 4-9
Battery Handling............................................................................................ 4-10
Redundant Power Supplies .......................................................................... 4-12
Backplane Voltage ........................................................................................ 4-13
Comply with Local and National Electrical Codes........................................ 4-14
Product Disposal........................................................................................... 4-15
Hot Swap Fan Warning.................................................................................4-16
Power Cable and AC Adapter ...................................................................... 4-18
Chapter 5 Advanced Serverboard Setup
5-1 Handling the Serverboard...............................................................................5-1
Precautions .....................................................................................................5-1
Unpacking .......................................................................................................5-1
5-2 Processor and Heatsink Installation................................................................5-2
Installing LGA1366 Processors....................................................................... 5-2
Installing the Heatsink.....................................................................................5-4
Removing the Heatsink................................................................................... 5-5
5-3 Connecting Cables..........................................................................................5-6
Connecting Data Cables.................................................................................5-6
Connecting Power Cables .............................................................................. 5-6
Connecting the Control Panel......................................................................... 5-6
5-4 I/O Ports.......................................................................................................... 5-7
5-5 Installing Memory............................................................................................ 5-8
5-6 Adding PCI Cards......................................................................................... 5-12
5-7 Serverboard Details ...................................................................................... 5-13

viii
SUPERSERVER 6016T-6RFT+/6016T-6RF+ User's Manual
X8DTU-6TF+/X8DTU-6F+ Quick Reference.................................................5-14
5-8 Connector Definitions.................................................................................... 5-15
5-9 Jumper Settings............................................................................................ 5-23
5-10 Onboard Indicators........................................................................................5-25
5-11 SATA Port Connections................................................................................. 5-27
5-12 Installing Software.........................................................................................5-28
SuperDoctor III.............................................................................................. 5-29
5-13 Onboard Battery............................................................................................5-30
Chapter 6 Advanced Chassis Setup
6-1 Static-Sensitive Devices..................................................................................6-1
Precautions .....................................................................................................6-1
6-2 Control Panel .................................................................................................. 6-2
6-3 System Fans................................................................................................... 6-3
System Fan Failure......................................................................................... 6-3
Hard Drive Installation.....................................................................................6-5
Hard Drive Backplane.....................................................................................6-6
DVD-ROM Drive Installation ...........................................................................6-7
6-4 Power Supply.................................................................................................. 6-8
Power Supply Failure...................................................................................... 6-8
Chapter 7 BIOS
7-1 Introduction...................................................................................................... 7-1
Starting BIOS Setup Utility..............................................................................7-1
How To Change the Configuration Data.........................................................7-1
Starting the Setup Utility................................................................................. 7-2
7-2 Main Setup...................................................................................................... 7-2
7-3 Advanced Setup Configurations......................................................................7-4
7-4 Security Settings........................................................................................... 7-25
7-5 Boot Configuration ........................................................................................ 7-27
7-6 Exit Options...................................................................................................7-28
Appendix A BIOS Error Beep Codes
Appendix B System Specifications

Chapter 1
Introduction
1-1 Overview
The SuperServer 6016T-6RFT+/6016T-6RF+ is a comprised of two main subsys-
tems: the SC819TQ-R700U 1U server chassis and the X8DTU-6TF+/X8DTU-6F+
dual processor serverboard. Please refer to our web site for information on operating
systems that have been certified for use with the system (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the 6016T-6RFT+/6016T-6RF+, as listed below:
• One slim DVD-ROM drive (DVM-TEAC-DVD-SBT)
• Five sets of 4-cm counter-rotating fans (FAN-0086L4)
• One air shroud (MCP-310-81901-0B)
• Two passive CPU heatsinks (SNK-P0037P)
• Riser Cards: (see Section 5-6 for details)
One RSC-R1UU-2E8
One RSC-R1UU-E8R+
• SATA Accessories
One SATA backplane (BPN-SAS-815TQ)
One SAS cable (CBL-00288L)
Four drive carriers (MCP-220-00075-0B)
• One rackmount kit (MCP-290-00062-0N)
• One SuperServer 6016T-6RFT+/6016T-6RF+ User's Manual
Note: For your system to work properly, please follow the links below to download
all necessary drivers/utilities for your server.
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety info: http://super-dev/about/policies/safety_information.cfm
• If you have any questions, please contact our support team at:
[email protected]
Chapter 1: Introduction
1-1

1-2
SUPERSERVER 6016T-6RFT+/6016T-6RF+ User's Manual
1-2 Serverboard Features
At the heart of the SuperServer 6016T-6RFT+/6016T-6RF+ lies the X8DTU-6TF+/
X8DTU-6F+, a dual processor serverboard based on the Intel® 5520 chipset. Below
are the main features of the serverboard. (See Figure 1-1 for a block diagram of
the chipset).
Processors
The X8DTU-6TF+/X8DTU-6F+ supports single or dual Intel® 5500/5600 Series
processors in LGA1366 sockets. Please refer to our web site for a complete listing
of supported processors.
Memory
The X8DTU-6TF+/X8DTU-6F+ features 18 DIMM sockets that can support up to 288
GB of registered ECC DDR3-1333/1066/800 or 48 GB of unbuffered ECC/non-ECC
DDR3-1333/1066/800 SDRAM. Please refer to Chapter 5 for installing memory.
UIO
The X8DTU-6TF+/X8DTU-6F+ is a specially-designed serverboard that features
Supermicro's UIO (Universal I/O) technology. UIO serverboards have a PCI Ex-
press 2.0 x8 slot that can support any one of several types of UIO card types to add
SAS ports, SATA ports, additional LAN ports or other additional functions to the
serverboard. This allows the user to tailor the serverboard to their own needs.
Note: the server does not come with a UIO card installed.
Onboard SAS
An onboard LSI 2108 SAS controller in integrated into the X8DTU-6TF+/X8DTU-
6F+. The hot-swap SAS drives are connected to a backplane that provides power,
bus termination and configuration settings.
Note: The operating system you use must have RAID support to enable the
hot-swap capability and RAID function of the SAS drives. RAID 0, 1, 5, 6,
10, 50 and 60 is supported. Refer to the following ftp site for setup guidelines
<ftp://ftp.supermicro.com/driver/SAS/LSI/LSI_SAS_EmbMRAID_SWUG.pdf>.
Onboard Serial ATA
An on-chip (ICH10R) SATA controller is integrated into the X8DTU-6TF+/X8DTU-
6F+ to provide a six-port, 3 Gb/sec SATA subsystem, which is RAID 0, 1, 5 and

1-3
Chapter 1: Introduction
10 supported (RAID 5 is supported with Windows OS only). The SATA drives are
hot-swappable units.
Note: You must have RAID set up to enable the hot-swap capability of the SATA
drives. Documentation on RAID setup guidelines can be found on our web site.
Rear I/O Ports
The color-coded I/O ports include one COM port, a VGA (monitor) port, two USB
2.0 ports, PS/2 mouse and keyboard ports, one dedicated IPMI LAN port and two
gigabit Ethernet ports. The 6016T-6RFT+ (X8DTU-6TF+) includes two additional
Ethernet ports.
Graphics Controller
The X8DTU-6TF+/X8DTU-6F+ features an integrated Matrox G200eW graphics
chip.
Other Features
Other onboard features that promote system health include onboard voltage moni-
tors, auto-switching voltage regulators, chassis and CPU overheat sensors, virus
protection and BIOS rescue.
1-3 Server Chassis Features
The 6016T-6RFT+/6016T-6RF+ is built upon the SC819TQ-R700U chassis. Details
on the chassis and on servicing procedures can be found in Chapter 6.The following
is a general outline of the main features of the chassis.
System Power
The SC819TQ-R700U features a redundant 700W power supply consisting of two
power modules. The system does not need to be shut down when replacing or
removing a single power supply module.
Hard Drives
The SC819TQ-R700U chassis was designed to support four hot-swap SAS or
SATA hard drives.

1-4
SUPERSERVER 6016T-6RFT+/6016T-6RF+ User's Manual
PCI Expansion Slots
Two riser cards are included. The RSC-R1UU-E8R+ is located on the right side of
the chassis and supports one low-profile PCI-E x4 card (in a x8 slot). The RSC-
R1UU-2E8 is located on the left side of the chassis and supports two PCI-E x8
add-on cards. See our web site for details (http://www.supermicro.com/products/
nfo/UIO.cfm). See section 5-6 of this manual for details.
Front Control Panel
The chassis' control panel provides you with system monitoring and control. LEDs
indicate system power, HDD activity, network activity (2), overheat/fan/power failure
and UID (Unit Identifier). A main power button and a UID button is also included.
Cooling System
The SC819TQ-R700U has an innovative cooling design that features five sets
of 4-cm counter-rotating fans located in the middle section of the chassis. There
is a "Fan Speed Control Mode" setting in BIOS that allows chassis fan speed to
be determined by system temperature. The power supply module also includes a
cooling fan.

1-5
Chapter 1: Introduction
Figure 1-1. Intel 5520 + IOH-36D/ICH10R Chipset:
System Block Diagram
Note: This is a general block diagram. Please see Chapter 5 for details.
Processor#1
QPI
DDR3 DIMM
C
A
B
D
E
F
DDR3 DIMM DDR3 DIMM DDR3 DIMM DDR3 DIMM DDR3 DIMM
B
C
E
F
3,4
BMC
VGA SWITCH
ESI
SPI
ATMEL
AT25DF321
CLINK
CLINK PCIE Port 1-4
PCI-E x8
Gen2 x16
Gen2 x8
ICH10R
ESI
IOH
36D
PORT0
PORT
PORT
7,8,9,10
5,6
PCI-E x16
PORT
PCI-Ex8 in x4 slot
RJ45
COMA
COMB
SIO
PS2 KB/MS
USB 0/1
USB
QPI
QPI
Gen2 x8
PORT
8,10
(Lane Reversal)
SATA #2
SATA #3
SATA #4
SATA #5
SATA #0
SATA
PCI USB
TPM
LPC
PORT1 PORT1
Gen2 x4 PORT
1,2
in x16 slot
VGA VGA
KAWELA
RJ45 RJ45
Gen1x2
KAWELA
RJ45 RJ45
Gen1 x4
PCIE Port 5-6
Processor#0
SATA #1 USB 2/3
USB 4/5
USB 6
USB 7
PORT0

1-6
SUPERSERVER 6016T-6RFT+/6016T-6RF+ User's Manual
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 23511
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone]

Chapter 2: Server Installation
2-1
Chapter 2
Server Installation
2-1 Overview
This chapter provides a quick setup checklist to get your 6016T-6RFT+/6016T-6RF+
up and running. Following these steps in the order given should enable you to have
the system operational within a minimum amount of time. This quick setup assumes
that your system has come to you with the processors and memory pre-installed. If
your system is not already fully integrated with a serverboard, processors, system
memory etc., please turn to the chapter or section noted in each step for details on
installing specific components.
2-2 Unpacking the System
You should inspect the box the 6016T-6RFT+/6016T-6RF+ was shipped in and note
if it was damaged in any way. If the server itself shows damage you should file a
damage claim with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the 6016T-6RFT+/6016T-
6RF+. It should be situated in a clean, dust-free area that is well ventilated. Avoid
areas where heat, electrical noise and electromagnetic fields are generated. You
will also need it placed near a grounded power outlet. Be sure to read the Rack
and Server Precautions in the next section.
2-3 Preparing for Setup
The box the 6016T-6RFT+/6016T-6RF+ was shipped in should include two sets of
rail assemblies, two rail mounting brackets and the mounting screws you will need
to install the system into the rack. Follow the steps in the order given to complete
the installation process in a minimum amount of time. Please read this section in
its entirety before you begin the installation procedure outlined in the sections that
follow.
Choosing a Setup Location
• Leave enough clearance in front of the rack to enable you to open the front door
completely (~25 inches) and approximately 30 inches of clearance in the back
of the rack to allow for sufficient airflow and ease in servicing.This product is for

2-2
SUPERSERVER 6016T-6RFT+/6016T-6RF+ User's Manual
installation only in a Restricted Access Location (dedicated equipment rooms,
service closets and the like).
• This product is not suitable for use with visual display work place devices
acccording to §2 of the the German Ordinance for Work with Visual Display Units.
2-4 Warnings and Precautions
Rack Precautions
• Ensure that the leveling jacks on the bottom of the rack are fully extended to
the floor with the full weight of the rack resting on them.
• In single rack installation, stabilizers should be attached to the rack. In multiple
rack installations, the racks should be coupled together.
• Always make sure the rack is stable before extending a component from the
rack.
• You should extend only one component at a time - extending two or more si-
multaneously may cause the rack to become unstable.
Server Precautions
• Review the electrical and general safety precautions in Chapter 4.
• Determine the placement of each component in the rack before you install the
rails.
• Install the heaviest server components on the bottom of the rack first, and then
work up.
• Use a regulating uninterruptible power supply (UPS) to protect the server from
power surges, voltage spikes and to keep your system operating in case of a
power failure.
• Allow the hot plug SAS/SATA drives and power supply modules to cool before
touching them.
• Always keep the rack's front door and all panels and components on the servers
closed when not servicing to maintain proper cooling.

Chapter 2: Server Installation
2-3
Rack Mounting Considerations
Ambient Operating Temperature
If installed in a closed or multi-unit rack assembly, the ambient operating tempera-
ture of the rack environment may be greater than the ambient temperature of the
room. Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient tempera-
ture (Tmra).
Reduced Airflow
Equipment should be mounted into a rack so that the amount of airflow required
for safe operation is not compromised.
Mechanical Loading
Equipment should be mounted into a rack so that a hazardous condition does not
arise due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the power
supply circuitry and the effect that any possible overloading of circuits might have
on overcurrent protection and power supply wiring. Appropriate consideration of
equipment nameplate ratings should be used when addressing this concern.
Reliable Ground
A reliable ground must be maintained at all times. To ensure this, the rack itself
should be grounded. Particular attention should be given to power supply connec-
tions other than the direct connections to the branch circuit (i.e. the use of power
strips, etc.).
Warning! To prevent bodily injury when mounting or servicing this unit in a
rack, you must take special precautions to ensure that the system remains
stable. The following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in
the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom
to the top with the heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before
mounting or servicing the unit in the rack.

2-4
SUPERSERVER 6016T-6RFT+/6016T-6RF+ User's Manual
2-5 Installing the System into a Rack
This section provides information on installing the 6016T-6RFT+/6016T-6RF+ into
a rack unit with the rack rails provided. If the system has already been mounted
into a rack, you can skip ahead to Sections 2-5 and 2-6. There are a variety of rack
units on the market, which may mean the assembly procedure will differ slightly.
You should also refer to the installation instructions that came with the rack unit
you are using.
Identifying the Sections of the Rack Rails
You should have received two rack rail assemblies in the rack mounting kit. Each
assembly consists of two sections: an inner fixed chassis rail that secures directly
to the server chassis and an outer fixed rack rail that secures directly to the rack
itself (see Figure 2-1). Two pairs of short brackets to be used on the front side of
the outer rails are also included.
Installing the Inner Rails
Both the left and right side inner rails have been pre-attached to the chassis. Pro-
ceed to the next step.
Figure 2-1. Identifying the Sections of the Rack Rails
(left side rail shown)
Inner Rail Outer RailLocking Tab
Warning: do not pick up the server with the front handles. They are de-
signed to pull the system from a rack only.

Chapter 2: Server Installation
2-5
Installing the Outer Rails
Installing the Outer Rails to the Rack
1. Measure the distance from the front rail to the rear rail of the rack.
2. Attach a short bracket to the front side of the right outer rail and a long
bracket to the rear side of the right outer rail.
3. Adjust both the short and long brackets to the proper distance so that the rail
can fit snugly into the rack.
4. Secure the short bracket to the front side of the outer rail with two M4 screws
and the long bracket to the rear side of the outer rail with three M4 screws.
5. Repeat these steps for the left outer rail.
Locking Tabs
Both chassis rails have a locking tab, which serves two functions. The first is to
lock the server into place when installed and pushed fully into the rack, which is
its normal position. Secondly, these tabs also lock the server in place when fully
extended from the rack. This prevents the server from coming completely out of the
rack when you pull it out for servicing.
Figure 2-2. Installing the Rack Rails

2-6
SUPERSERVER 6016T-6RFT+/6016T-6RF+ User's Manual
Installing the Server into the Rack
Installing the Chassis into a Rack (Figure 2-3)
1. Confirm that chassis includes the inner rails and rail extensions . Also, confirm
that the outer rails are installed on the rack.
2. Line chassis rails with the front of the rack rails.
3. Slide the chassis rails into the rack rails, keeping the pressure even on both
sides (you may have to depress the locking tabs when inserting). When the
server has been pushed completely into the rack, you should hear the locking
tabs "click".
4. (Optional) Insert and tightening the thumbscrews that hold the front of the
server to the rack.
Installing the Server into a Telco Rack
To install the 6016T-6RFT+/6016T-6RF+ into a Telco type rack, use two L-shaped
brackets on either side of the chassis (four total).
1. First, determine how far follow the server will extend out the front of the rack.
Larger chassis should be positioned to balance the weight between front and
back. If a bezel is included on your server, remove it.
2. Then attach the two front brackets to each side of the chassis, then the two
rear brackets positioned with just enough space to accommodate the width of
the telco rack.
3. Finish by sliding the chassis into the rack and tightening the brackets to the
rack.
Note: Figure is for illustrative purposes only. Always install servers to the bottom
of a rack first.
Stability hazard. The rack stabilizing mechanism must be in place, or the
rack must be bolted to the floor before you slide the unit out for servicing.
Failure to stabilize the rack can cause the rack to tip over.
