Sure Electronics TA2024 User manual

2 X 15Watt Class-D Audio
Amplifier - TA2024
User’s Guide
©2004-2010 Sure Electronics Inc. AA-AB32155_Ver1.0

2 X 15WATT CLASS-D AUDIO
AMPLIFIER - TA2024
USER’S GUIDE
©2004-2010 Sure Electronics Inc.
A
A-AB32155_Ver1.0_Page i
Table of Contents
Chapter 1. Overview ..........................................................................................................1
1.1 Overview.............................................................................................................. 1
1.2 Features............................................................................................................... 1
Chapter 2. How to Connect Load .....................................................................................3
Chapter 3. Mechanical Drawing........................................................................................4
Chapter 4. Contact Us .......................................................................................................5

2 X 15Watt Class-D Audio Amplifier - TA2024
©2004-2010 Sure Electronics Inc
A
A-AB32155_Ver1.0_Page ii
NOTES:
Product Version ：Ver 1.4
Document Version ：Ver 1.0

2 X 15WATT CLASS-D AUDIO
AMPLIFIER - TA2024
USER’S GUIDE
©2004-2010 Sure Electronics Inc.
Chapter 1. Overview
1.1 Overview
Thanks for using this 2 X 15Watt Class-D Audio Amplifier by Sure Electronics. This
product provides an easy engineering evaluation platform for Tripath Technology’s
TA2024 product. It is capable of delivering up to 15W each channel. Powered by DC 12V,
it can be used to drive any passive 4 or 8Ωspeakers.
FIGURE 1-1 TOPVIEW
Note: All the diagrams in this manual are for reference only.
1.2 Features
yClass-T architecture
yProprietary Digital Power Processing Technology
yRequires single +12V power source
yOutput Power (per channel @ VS = 12V):
15W per channel (4Ω, 10% THD+N)
10W per channel (4Ω0.1%, THD+N)
y“Audiophile performance” typically:
0.04% THD+N (9Wrms, 4Ω)
0.18% IHF-IM (1Wrms, 4Ω)
yEfficiency - >88% @ full power (RL = 8Ω)
yNo heat sink required up to 15W per channel
yMUTE and SLEEP inputs
yTurn-on & turn-off pop suppression
yIntelligent short-circuit protection
yIntelligent over-temperature protection
A
A-AB32155_Ver1.0_Page 1

2 X 15Watt Class-D Audio Amplifier - TA2024
©2004-2010 Sure Electronics Inc
A
A-AB32155_Ver1.0_Page 2
yTakes standard audio line output from any sound system
yCost-effective 2-layer PCB design
y36-pin Power SOP package

2 X 15WATT CLASS-D AUDIO
AMPLIFIER - TA2024
USER’S GUIDE
©2004-2010 Sure Electronics Inc.
Chapter 2. How to Connect Load
FIGURE 2-1 LOAD CONNECTION
Note:
1. GND should be connected to GND or the housing of your instrument.
2. There are two audio-input methods. One is via audio input. Another is via terminals
(J2, J5).
3. There are two audio-output methods. One is via terminals (J3and J9). Another is
via corresponding banana jack.
A
A-AB32155_Ver1.0_Page 3

2 X 15WATT CLASS-D AUDIO
AMPLIFIER - TA2024
USER’S GUIDE
©2004-2010 Sure Electronics Inc.
Chapter 3. Mechanical Drawing
FIGURE 3-1 MECHANICAL DRAWING
A-AB32155_Ver1.0_Page 4
A

2 X 15WATT CLASS-D AUDIO
AMPLIFIER - TA2024
USER’S GUIDE
©2004-2010 Sure Electronics Inc.
Chapter 4. Contact Us
Sure Electronics Co., Ltd.
East zone, 3F, Building 6
Jingang Technology Innovation Center
No.108 Ganjiabian Rd (ZIP: 210000)
Qixia District
Nanjing
P.R.China
Tel: [phone]
Fax: [phone]
Website: www.sure-electronics.com
Email: [e-mail]
