Sure Sweep STR1100E with TRS User manual

Operating manual
Alphaline
PO Box 228
Salisbury
QLD 4107
Australia
Phone: [phone]
Fax: [phone]
www.suresweep.com.au

Table of contents
18/11/2014 I
Table of contents
1Introduction.......................................................................................................................................4
1.1 Usage conformant with intended purpose..........................................................................4
2Safety information............................................................................................................................5
3Device Description...........................................................................................................................7
3.1 Initial Startup.......................................................................................................................8
4Operation.........................................................................................................................................10
4.1 Driving...............................................................................................................................10
4.1.1 Forward motion:.................................................................................................11
4.1.2 Reverse motion: ................................................................................................11
4.2 Sweeping ..........................................................................................................................12
4.2.1 Sweeping Roller Drive.......................................................................................12
4.2.2 Operatting the Sweeping Rollers.......................................................................12
4.3 Operating the Side Brushes..............................................................................................13
4.4 Information provided by LED indicators on the battery condition display:........................13
4.5 Operating the Suction.......................................................................................................13
4.6 Adjustment of Driver`s Seat..............................................................................................14
4.7 Turning Off the Sweeping & Suction Machine..................................................................14
4.8 Operating the Filter Cleaning Device................................................................................14
4.9 Emptying the Dust Container............................................................................................15
4.9.1 Removing the Dust Container ...........................................................................15
4.9.2 Reinserting the Dust Container .........................................................................16
5Maintenance....................................................................................................................................17
5.1 Safety Information.............................................................................................................17
5.2 Cleaning............................................................................................................................17
5.3 Charging the Batteries......................................................................................................18
5.4 Battery...............................................................................................................................19
5.5 Brake.................................................................................................................................19
5.5.1 Adjusting the Brake ...........................................................................................19
5.6 Brake Check .....................................................................................................................20
5.6.1 Correct Operating of Brake................................................................................20
5.7 Steering.............................................................................................................................21
5.8 Replacement of Filter........................................................................................................21

Table of contents
II 18/11/2014
5.8.1 Removal.............................................................................................................21
5.8.2 Reinsertion ........................................................................................................22
5.9 Sweeping Rollers Replacement........................................................................................22
5.9.1 Dismounting the Sweeping Rollers ...................................................................22
5.9.2 Installing the Sweeping Rollers .........................................................................23
5.10 Setting the Sweeping Rollers............................................................................................24
5.10.1 Sweeping Contour Adjustment..........................................................................24
5.10.2 Adjusting the Sweeping Contour.......................................................................25
5.10.3 Further Possible Adjustment: ............................................................................25
5.11 Replacing the Side Brush .................................................................................................26
5.11.1 Dismounting the Side Brush..............................................................................26
5.11.2 Mounting the Side Brush...................................................................................26
5.12 Adjustment of the Side Brush ...........................................................................................27
5.13 Wheels..............................................................................................................................28
5.14 Fuses ................................................................................................................................28
5.15 Maintenance Chart............................................................................................................28
5.15.1 Daily maintenance.............................................................................................28
5.15.2 After each 50 operating hours also ...................................................................28
5.15.3 After each 100 operating hours also .................................................................29
5.15.4 After each 200 operating hours also .................................................................29
5.16 Disturbances, Disturbance Display, Remedy ...................................................................30
5.17 Technical Data..................................................................................................................31
5.18 Product Marking................................................................................................................32
5.19 Disposal ............................................................................................................................32
5.20 Accessories and spare parts ............................................................................................33
5.21 Service..............................................................................................................................33
5.22 Transport...........................................................................................................................33
6EC Declaration of conformity (Translation of the original version)..........................................34

Table of contents
18/11/2014 III

4 18/11/2014
1 Introduction
This operating manual contains instructions for using the hand-operated
sweeper.
Our products are subject to continuous improvement. Therefore, design
changes that were made after this manual went to print could not be
incorporated. If you have any questions, please contact our Service
department.
The operating manual must be read and applied by all persons who
operate the sweeper.
Apart from the operating manual and the regulations for accident pre-
vention applicable in the country of use and the location of use, the
common, recognised rules for safe and technically correct working must
also be followed.
1.1 Usage conformant with intended purpose
The appliance is intended exclusively for sweeping on solid surfaces (for
example: parking areas, walkways, shop floors). The area to be swept
should not be wet.
The sweeper may only be used by reliable and instructed personnel.
Prevent children, juveniles and other unauthorised persons from using
the machine (e.g. by pulling out the key after use).
Any other use, or any use over and above that, will be considered to be
non-conformant with intended purpose. The manufacturer rejects any
and all liability for damage resulting from such use. The risk is that of the
user alone.
Usage conformant with intended purpose also includes compliance with
the operating manual and the inspection and maintenance specifica-
tions. Drive the sweeper only along expressly marked routes and spac-
es.

18/11/2014 5
2 Safety information
1. The machine should only be used in a flawless state, as
well as in keeping with its intended purpose, in a safety-
conscious and risk-conscious manner and in compliance
with these operating instructions.
2. In addition to the operating manual, please heed general le-
gal and other binding regulations for accident prevention
and environmental protection.
3. Sweeping and picking up of flammable, toxic or explosive
substances, along with flammable gases or diluted acids
and solvents, burning or smouldering objects is prohibited!
4. The appliance is not suitable for picking up fluids, cables,
cords, wires or the like.
5. The machine should only be used with the dust box fitted to
prevent injuries caused by parts being slung out.
6. Transporting loads with the sweeper is not allowed.
7. Faults should be eliminated immediately, particularly those
that could impair safety.
8. Do not make any changes, modifications or additions to the
sweeper without the approval of the manufacturer.
9. Replacement parts must meet manufacturer specifications.
This is always ensured by using original replacement parts.
10. Ensure that operating media, auxiliary media and replace-
ment parts are disposed of in a safe and environmentally-
friendly manner, particularly batteries!
11. Suitable non-slip footwear should be worn to avoid acci-
dents.
12. If you have any questions, please contact our Service de-
partment.
13. Persons (including children) who are not able to use this
machine safely due to their physical, sensory or mental ca-
pabilities or their inexperience or lack of knowledge may not
use this machine without the supervision or instruction by a
responsible person! Children should be supervised to en-
sure that they do not play with the appliance.
14. Caution: loose clothing can be caught and drawn in on rotat-
ing parts.
15. The operating instructions provided by the battery manufac-
turer relating to his product and legal specifications for the
handling of accumulator batteries should be heeded!

6 18/11/2014
16. Charge flat batteries directly after use and only in well-
ventilated rooms.
17. Keep naked flames and electrical sparks away from the
charging area, since a highly-explosive electrolytic gas mix-
ture is generated when batteries are being charged.
18. Note that the accumulator batteries are filled with battery ac-
id.
19. Batteries should always be kept clean and dry to avoid
leakage currents! Never short-circuit battery poles!
20. Smoking, eating and drinking should be avoided in the vicin-
ity of the battery charging station to avoid risks to health.
21. Batteries should only be charged with the hood opened and
secured with the holder.

18/11/2014 7
3 Device Description
The Sweeping & Suction Machine is driven by electric motors. Model
STR1100EwithTRS is equipped with two pivotable side brushes. If nec-
essary, the dust stirred up by the sweeping rollers is caught by the dust
suction unit in a lamellar filter inside the machine. The lamellar filter is
cleaned by an electrically controlled filter cleaning device.
1
battery condition display
2
switch for the direction of motion
3
switch for sweeping rollers
4
switch for side brushes
5
switch for suction
6
switch for filter cleaning
7
lowering lever for the sweeping
roller
8
key switch
9
battery master switch (EMER-
GENCY OFF)
1
steering wheel with steer-
ing pillar
2
driver`s seat
3
main trim panel
4
steering pillar trim
5
dust container
6
front trim panel
7
driving wheel
8
left side trim panel
9
rear wheel with drum break
10
lowering lever for side
brushes
11
pivotable side brushes

8 18/11/2014
3.1 Initial Startup
The Sweeping & Suction Machine standard delivery is without batteries
or charging device.
Optional:
The Sweeping & Suction Machine is supplied with batteries
Standard:
Open the transport packaging.
Take off the complete hood. Lift up hood at back and lift the front
spigots of the hood out of the retaining.
Fit in the batteries.
Connect the batteries. Compare technical data circuit diagram.
Replace the hood panel.
Mount the side brushes (cf. 5.11.2).
The Sweeping & Suction Machine is ready for use.
Drive the Sweeping & Suction Machine over a ramp out of the
transport packaging.
Use a unit ramp. The ramp must be designed in such a way as to allow
the rear wheel as well as the drive wheels to travel across it.
If this is not observed, damages to the Sweeping & Suction Machine
mechanics will occur.
1
Elements of the Transport
Packaging.

18/11/2014 9
Optional:
The Sweeping & Suction Machine is equipped with batteries.
Open the transport packaging.
Open the hood
Lock hood securely using the hood arrester.
The hood is equipped with drill holes at the bottom
Fit the hood arrester into the corresponding drill hole.
Connect the positive pole of the battery.
Close the hood.
Mount the side brushes (cf. 5.11.2).
1
Unit Ramp
Drive the Sweeping & Suction Machine over a ramp out of the
transport packaging. (Cf. 4.1)
Use a unit ramp. The ramp must be designed in such a way as to allow
the rear wheel as well as the drive wheels to travel across it.
If this is not observed, damages to the Sweeping & Suction Machine
mechanics will occur.
The Sweeping & Suction Machine is ready for use.

10 18/11/2014
4 Operation
4.1 Driving
Starting the Sweeping & Suction Machine
Sit down in the driver`s seat
The Sweeping & Suction Machine cannot be started if the driver's
seat is not weighed down.
Check position of direction of motion switch.
The direction of motion switch is a toggle switch with two positions.
1
Control panel
2
Battery condition display
3
direction of motion switch
4
Pilot lamp forward motion
5
Pilot lamp reverse motion
6
key switch
7
battery master switch
Insert the battery master switch into the socket.
Press it down and turn it clockwise until it is firmly latched.
Now pull up the battery master switch.
Insert the key into the key switch.
Turn the key clockwise.
On the control panel a red LED starts flashing. (This indicates machine
ready for operation.) After that the LEDs indicating the battery's charg-
ing condition light up.
Depress the brake pedal.
Release the parking brake.
Actuate the direction of motion switch.

18/11/2014 11
4.1.1 Forward motion:
Push the direction of motion switch forward.
Optical signal:
Green pilot lamp on the switch
4.1.2 Reverse motion:
Push the direction of motion switch backward.
Optical signal:
Red pilot lamp on the switch,
Acoustical signal: Beeper (optional)
The speed of the Sweeping & Suction Machine can be adjusted with
infinite variability by depressing the accelerator.
1
Parking brake
2
Brake pedal
3
Accelerator

12 18/11/2014
4.2 Sweeping
Do not switch on suction when sweepings are wet. This will cause dam-
age to the suction device and the filter. Provide good aeration when
using the machine in closed rooms or buildings.
Do not sweep up materials that may cause health impairment.
1
switch for the sweeping rollers
2
switch for the side brushes
3
switch for the suction
4
switch for the filter cleaning
5
lowering lever for the sweeping roller
4.2.1 Sweeping Roller Drive
The sweeping roller drive is situated on the right side of the Sweeping &
Suction Machine facing in driving direction.
The sweeping rollers are driven by an electric motor via a chain.
The chain is deflected by a sprocket and guided over the sprockets of
the roller drive.
A spring biased chain tensioner keeps the chain tight.
Grease the sprockets at regular intervals. Cf. Maintenance Chart.
To grease the sprockets, open the hood and remove the side trim panel.
4.2.2 Operatting the Sweeping Rollers
Start the Sweeping & Suction Machine
Switch the toggle switch for the sweeping rollers to ON Position.
Unlatch the lowering lever of the sweeping roller.
The pilot lamp on the switch lights up.
The sweeping rollers begin rotating.
Stopping Sweeping Rollers Operation
Pull lowering lever of the sweeping rollers towards yourself
Switch toggle switch for the sweeping rollers to OFF position
Let the lever snap in arresting position

18/11/2014 13
4.3 Operating the Side Brushes
The side brushes are fixed to swingers.
Whenever the side brushes hit an obstacle they swing back under the
vehicle to avoid damages.
Start the Sweeping & Suction Machine.
Unlatch the lowering lever of the side brushes.
Switch toggle switch for the side brushes to ON position.
Push the lever down.
The pilot lamp on the switch lights up.
The side brushes begin to rotate.
Stopping Side Brush Operating.
Switch toggle switch for the side brushes to OFF position.
Pull up the lowering lever for the side brushes. Let the lever snap in
arresting position
4.4 Information provided by LED indicators on the
battery condition display:
charging condition of battery
lit LED
Red
Yellow
Green
Green
Green
condition fully charged
operating/charging condition uncritical
operating/only for a short time longer
operating/soon critical
operating/critical
4.5 Operating the Suction
The suction prevents dust formation duringsweeping operations.
Start the Sweeping & Suction Machine.
Switch the toggle switch for the suction to ON position.
The pilot lamp on the switch lights up.
The suction begins operating.
To turn off suction operation switch the toggle switch for the suction to
OFF position.

14 18/11/2014
Please observe!
Do not switch on suction when sweepings are wet.
This will cause damage to the suction device!
To turn off suction operation switch the toggle switch for the suction to
OFF position.
4.6 Adjustment of Driver`s Seat
Loosen the seat arresting device and shift the driver's seat on the
seat support to a position that feels comfortable to you.
4.7 Turning Off the Sweeping & Suction Machine
Depress the brake pedal.
Lock the brake by pulling the locking lever towards the driver's seat.
When the brake now is relieved the brake pedal must remain in de-
pressed position.
All of the pilot lamps on the switch are off.
Switch off all actuators.
Lift up the side brushes and arrest the lowering lever for the side
brushes.
Lift up the sweeping rollers and arrest the lowering lever for the
sweeping rollers.
Turn the key counterclockwise and remove it from the key switch.
Turn the battery master switch counterclockwise and remove it from
the socket.
4.8 Operating the Filter Cleaning Device
The filter cleaning device prevents the lamellar filter from being blocked
by debris.
Switch off suction.
Wait until ventilation wheel stands still.
Apply filter cleaning device at regular intervals.
Depress the toggle switch for the filter cleaning device for about 5 to
10 seconds.
The filter cleaning device begins operation.

18/11/2014 15
4.9 Emptying the Dust Container
The dust container is the place where the sweepings are collected.
It is positioned at the back of the Sweeping & Suction Machine.
The dust container must be emptied regularly and especially after each
use.
4.9.1 Removing the Dust Container
Turn the dust container locking upward.
Pull out the dust container from the Sweeping –& Suction Machine by
the gripping handle until the front dust container guide rails are free.
1
locking device
2
recessed grip
3
locking device
4
guide rail
5
dust container guides
6
roller
At the back of the dust container two guiding rollers are installed to
make the removal easier.
Lower the dust container to the ground
A number of rollers and a recessed grip are positioned at the bottom of
the dust container.
Remove the dust container completely from the Sweeping & Suction
Machine.
In order to empty the dust collecting box, use the free hand to take
hold of the recessed grip.
The sweepings are discharged through the opening at the bottom of
the dust bin.
Empty sweepings into appropriate containers only.

16 18/11/2014
4.9.2 Reinserting the Dust Container
Place the dust container before the dust container retaining.
Bring the dust container's front guides up to the same level as the
guide rails.
Slide the dust container into the Sweeping & Suction Machine.
Turn the locking device downward.

18/11/2014 17
5 Maintenance
5.1 Safety Information
Only complete the type of maintenance work described in the following
chapter. All other maintenance and upkeep work may only be carried
out by the manufacturer or by companies and persons authorised by the
manufacturer, who are familiar with the relevant safety specifications,
because portable devices in industrial use are subject to the safety test
according to VDE 0701.
Closely follow the steps listed in the maintenance instructions. The im-
proper completion of maintenance tasks may result in malfunctions
when using the sweeper and may possibly render the warranty granted
null and void.
When working on the electrical system, the battery should be discon-
nected.
Maintenance work/ troubleshooting at the electric motor must not be
done while the electric motor is running.
Use only flawless and appropriate tools to complete maintenance work.
Note the requirements for spare parts (see Spare parts).
If covers and/or safety devices were removed during maintenance
work/repairs, they will have to be reattached prior to starting the sweep-
er.
For carrying out any work on the sweeper, it must be switched off and
secured from rolling away by accident.
5.2 Cleaning
The suction sweeper may only be cleaned in the off state, when it is dry.
The suction sweeper is a machine with electrical components.
Moisture damages the eletronics of the device. Moisture can result
in leaking of currents and short-circuits!
Do not use any high-pressure cleaners
WARNING

18 18/11/2014
5.3 Charging the Batteries
Turn off the Sweeping & Suction Machine.
Open the hood.
Secure the hood position by the hood arresting device.
Guide the hood arresting into the holes at the bottom of the hood.
Connect the charging device to the charging plug of the Sweeping &
Suction Machine.
Connect the mains plug of the charging device to a power supply
socket.
1
charging socket of Sweep-
ing & Suction Machine
2
charging plug of charging
device
The charging process lasts for approx. 10 hours when the batteries
have been completely used up (with the device originally provided by
the manufacturer).
The original charging device of the manufacturer can/should remain
connected after charging is completed, because it is equipped with a
charge saver allowing it to provide highest possible battery capacities
even after long periods of standstill.
Be careful only to use the Sweeping & Suction Machine if there is
enough voltage left in the batteries.
The machine automatically switches itself off, if the batteries are dis-
charged to such a degree that damages may arise (exhaustive dis-
charge protection)
In this case: Switch off all consumers and let the machine stand for
about one or two minutes.
Switch on the machine again and drive to the charging device (without
sweeping operation!) Charge batteries immediately to avoid possible
damage.
