User Guide

Fusion4Home™3.0

Voice and 4G Data Booster Kit for Home and Ofce

112017

Introduction

Thank you for purchasing SureCall’s Fusion4Home 3.0 cellular signal booster kit. SureCall’s Fusion4Home was

specically designed to eliminate frustrations over dropped calls and limited range by amplifying incoming and

outgoing cellular signals in homes and ofces.

If you have any questions during setup, please reach out to our US-based experienced support technicians:

Call: 1-888-365-6283

Email: [email protected]

Visit: www.surecall.com/support

Watch

installation,

optimization and

troubleshooting

techniques on

our SureCall

YouTube

channel

@SureCall Stay up to date

with all things

SureCall

Table of Contents

TABLE OF CONTENTS

How it works ..................................................................................................................................... 4

PACKAGE CONTENTS........................................................................................................................ 4

BEFORE INSTALLATION..................................................................................................................... 6

Installation Overview......................................................................................................................... 6

INSTALLATION .................................................................................................................................... 6

Step 1. Find the Area With the Strongest Signal............................................................................... 6

Step 2. Install the Outside Antenna................................................................................................... 7

Step 3. Install the Booster and Inside Antenna. ............................................................................. 10

Step 4: Connect to Power and Turn On .......................................................................................... 12

Step 5: Congure Gain Settings If Needed..................................................................................... 12

IF YOU WANT TO IMPROVE PERFORMANCE................................................................................ 12

LED INDICATORS.............................................................................................................................. 13

TROUBLESHOOTING ....................................................................................................................... 14

SPECIFICATIONS.............................................................................................................................. 14

USER GUIDELINES........................................................................................................................... 16

WARRANTY ....................................................................................................................................... 17

Three-Year Product Warranty ......................................................................................................... 17

How It Works

How it works

1. An outside antenna collects signal from the cell tower.

2. The outside antenna sends the signal to the booster through coax cable.

3. The booster amplies the cell signal and rebroadcasts the signal indoors from via the inside antenna to all

mobile devices within range.

4. The system also works in reverse amplifying outgoing signal back to the tower.

Cable

Booster

Outside

Antenna

Inside

Antenna

How the SureCall Fusion4Home 3.0 Booster Works

PACKAGE CONTENTS

Unpack all package contents. For missing or damaged items, contact your reseller.

Turn over the signal booster and record the model and serial number for reference:

Serial #: ________________________________________________________________

Purchase Date: __________________________________________________________

Keep the carton and packing material to store the product in case you need to return.

SureCall, Inc | 1-888-365-6283 | [email protected] | www.surecall.com 5

Package Contents

1. Fusion4Home Cellular

Booster and power supply

3. Inside Cable

(20 ft.)

4. Outside Antenna Options:

Your Fusion4Home 3.0 signal booster package includes the following items:

1. SureCall Fusion4Home signal booster and power supply

2. Cable for connecting the outside antenna to the signal booster (RG6, 50 ft)

3. Cable for connecting the booster to the inside antenna (SC-240, 20 ft)

4. One outside antenna (either omni or Yagi antenna)

5. One Inside antenna (either omni-directional whip or directional panel antenna)

2. Outside Cable

(50 ft)

« OR » 4.b Outside Yagi

Antenna

4.a Outside Omni

Antenna

5. Inside Antenna Options:

« OR » 5.b Inside Directional

Panel Antenna

5.a Inside Omni

Whip Antenna

Warning: Changes or modications not expressly approved by SureCall could void the user’s authority to operate the equipment.

BEFORE INSTALLATION

1. Prior to securing the location of any booster parts, a “soft install” is recommended as adjustments may be

needed to optimize performance.

2. Ensure adequate separation between the planned locations of the inside and outside antenna – at least 25

ft (see diagram ”Antenna Separation” on page 7).

3. For kits that use directional antennas (outside or inside), the directional antenna(s) should be oriented in a

way that they do not “face” the other antenna (see “Aiming Directional Antennas” Diagram).

4. Ensure sufcient cable length between the outside antenna location and booster

location. The length of the provided cable is 50 ft.

Installation Overview

Step 1. Find the outside area with the strongest signal.

Step 2. Install the outside antenna identied in step 1.

Step 3. Install the Inside antenna and booster.

Step 4. Connect power source and turn on.

Step 5. Congure gain settings if needed.

INSTALLATION

Step 1. Find the Area With the Strongest Signal

Using your phone, identify the outside location with the strongest signal for placement of your outside antenna.

Generally, this is found above the rooine on the side facing your nearest cell tower and as high as possible

– where the antenna can ‘see’ your cell tower. To nd the location of your carrier’s closest cell tower, go to

www.antennasearch.com.

The coverage area that the booster provides is directly related to the strength of incoming signal received

by the outdoor antenna. Mounting the outside antenna where the signal is the strongest will provide the

best results. Please note, as seen in the table below, if signal is extremely weak where the outside antenna is

installed, indoor coverage will be limited.

Estimated coverage:

Outdoor signal strength

(dB)

1-2 Bars

(-85 to -95)

3-4 Bars

(-75 to -84)

5 Bars

(-65 to -74)

Fusion4Home Omni/Whip Kit

Estimated coverage (sq. ft.)

500 1000 2,000

Fusion4Home Yagi/Whip Kit

Estimated coverage (sq. ft.)

1000 2,000 4,000

Fusion4Home Yagi/Panel Kit

Estimated coverage (sq. ft.)

1,500 3,000 6,000

Before Installation

Aiming Directional

Antennas

SureCall, Inc | 1-888-365-6283 | [email protected] | www.surecall.com 7

Note that Bars are not always a reliable measure of signal. The best way to conrm signal coverage is the ability

to place and hold a call.

Putting your phone in Field Test mode will also indicate what level of decibels (dB) your phone is currently

receiving. Decibels are measured in the negatives, and a score closer to zero indicates you have a better

signal. A signal of -120 dB indicates you have no service, while a score of about -50 dB means you have

excellent signal strength

For specic dB signal measurements, use the methods below.

• Apple iPhones: Dial *3001#12345#* and press Call. In the top-left corner, a dB number appears instead of

bars.

• Android devices: download the app “Network Signal Info” in the Google Play store.

Signal Strength

Excellent

-50 dB

-60 dB

-70 dB

-80 dB

-90 dB

-100 dB

GoodPoor

Step 2. Install the Outside Antenna

After identifying the area of strongest signal, choose the surface where you will mount your outside antenna.

The location should allow for sufcient separation between the outside antenna and inside antenna. Vertical

separation is preferred as it is more effective than horizontal separation.

The minimum separating distance recommended is 25 vertical feet; however, increased separation, up to 40

- 60 ft, may be needed, especially where vertical separation cannot be

achieved.

Option A: Omni Antenna

The omni antenna is omni-directional, which receives and sends signals

in a 360º radius. The provided hardware allow for either a surface mount

or pole-mount.

Installation

Best

Antenna Separation

Warning: Do not collocate antennas or operate the outdoor antenna with any other antenna or signal booster.

Mount antenna to a vertical surface:

1. Using vertical plate of bracket, mark position of desired placement. The omni

antenna should be mounted in an upright position (See “Omni Antenna Install

Illustration”)

2. Unscrew nut from end of stucco screw and remove it along with lock washer and

regular washer.

3. Place vertical plate into desired location and tap the screws, head rst, along with

sleeve, into stucco 1/2 to 5/8 inches deep into place.

4. In this order, place washer, lock washer and nut on each screw and tighten until

secure. When tightening screw, sleeve will expand to secure plate.

5. Use provided screws to secure antenna base onto horizontal plate.

6. Connect antenna to one end of the provided RG6 cable and tighten the

connection. Run the cable along route to planned location of your booster.

Note: Alternate screws may be required for differing surfaces such as wood or concrete.

Nuts &

Washers

L-Bracket

Cable

Anchors /

Sleeves

Screws

Omni Antenna Install Illustration

Installation

Option B:

Yagi Antenna

Option A:

Omni Antenna

Pole-mount hardware

Omni antenna with

surface mount hardware

SureCall, Inc | 1-888-365-6283 | [email protected] | www.surecall.com 9

Installation

Yagi Antenna Assembly

Nut

Washer U-bolt

Bracket

Drip Hole

RG6 Cable

Outside

Antenna

Yagi Antenna Install Illustration

Caution: Do Not aim a directional antenna towards another antenna

Aiming Directional

Antennas

Option B: Outside Yagi Antenna

Before installing a Yagi, or directional antenna, note that the antenna should be mounted on a pole or pipe (not

provided), at the highest possible location above the rooine – at least 25 ft above the indoor antenna – aimed

in the direction of your nearest cell tower. To nd the location of your

carrier’s closest cell tower, go to www.antennasearch.com.

Ensure that the mounting area has at least a 3 ft radius clear of

obstructions, other radiating elements and metal objects such as pipes or

metal siding and orient the antenna with the drip hole at the bottom.

Once you have identied your install location, assemble the u-bolt, bracket,

nuts and washers onto a pole (available separately) as shown in the illustration. Keep the connections loose

enough to allow the antenna to rotate until the optimum direction is found.

Once the outside antenna is secured to a pipe or pole, connect antenna to one end of the provided RG6 cable

and tighten the connection. Run the cable along route to planned location of your booster.

Installation

Step 3. Install the Booster and Inside Antenna.

Choose a location for the booster and inside antenna that is near a working outlet and at least 25 Ft from the

outside antenna. Consider the below factors affecting booster performance.

1. Signal strength at the location of the outside antenna.

2. Interior building materials between the inside antenna and your mobile device.

3. Distance between the outside antenna and inside antenna (minimum 25 ft. separation)

Note: This booster should not be used near open re or ame. Storage and transportation: Store and place in non-extreme room-temperature and dry environment.

Option A:

Whip Antenna

Option B:

Panel Antenna

Option A: Whip Antenna

Place the booster in a central location where signal is needed. When placing the booster, note that further

separation between the booster and outside antenna will increase booster performance. Connect the whip

antenna to the booster connector labeled INSIDE.

Whether you choose to mount the booster on a wall or set on a shelf, note that the antenna should be vertical.

Option B: Panel Antenna

SureCall’s Inside panel antennas are directional with a 120˚ reach. They

should be mounted facing the area signal is needed and away from the

outdoor antenna (See “Aiming Directional Antennas” on page 6).

Mount on a vertical surface that is the approximate height of normal cell

phone use. The antenna may be concealed behind a wall provided there are

no materials that could obstruct signals.

Besides the antenna itself, parts include mounting equipment for a at

horizontal surface.

1. Using plate, mark position of desired screw placement.

2. Screw mounting plate into place with the slide panel protruding towards

you.

3. Slide antenna securely onto mounting plate.

Mounting

Plate

Screws

SC-240

SureCall, Inc | 1-888-365-6283 | [email protected] | www.surecall.com 11

Installation

Power Jack

Power Switch

Connector to Inside Antenna

N connector to inside antenna

F connector to outside antenna

OFF

Screw tab holes for optional wall mounting

Booster Diagram

4. Connect antenna to one end of the SC-240 cable and run to planned location of your booster

5. Place the booster on a at surface or mounted to a wall and connect the remaining end of the SC-240

cable to booster port marked INSIDE.

Place the Booster

To install the booster to a wall, select a location that is near a working AC outlet. Use the supplied screws or

appropriate screws for surface of mounting location and drill through screw tab holes on booster (see “Booster

Diagram” illustration) and mount the booster to a wall.

Next, connect the outside antenna and booster by connecting the open end of the 50 ft. cable leading from the

outside antenna to the port of the booster marked “OUTSIDE”.

IMPORTANT:: FCC 27.5 (d)(4): Fixed, mobile, and portable (hand-held) stations operating in the 1710-1755 MHz band as well as mobile and portable stations

operating in the 1695-1710 MHz and 1755-1780 MHz bands are limited to 1 watt EIRP.

Fixed stations operating in the 1710-1755 MHz band are limited to a maximum antenna height of 10 meters above ground.

Step 4: Connect to Power and Turn On

Connect the AC power cord to the booster and plug into a 110V AC power outlet. Once the booster has been

completely assembled, turn the booster’s power switch to ON.

Note: If the Power LED does not turn ON or the Alert LEDs continue to ash, see the ”Troubleshooting” on page 14

section.

Note: This booster is rated for 5-15V input voltage. DO NOT use the booster with a higher voltage power supply. This can damage the booster, cause personal injury,

and void your warranty.

Step 5: Congure Gain Settings If Needed

Place a call in the room where the inside antenna is located to conrm that your phone is receiving a boosted

signal.

Note: Bars are not always a reliable measure of signal. The best way to conrm signal coverage is the ability to

place and hold a call.

Booster gain dials or switches should always be at maximum level unless the control light for a specic

frequency band is ashing red or ashing red-yellow. In either case, only reduce gain dials if the recommended

actions found in “LED Indicators” on page 13 do not resolve the issue.

It is best to avoid turning the gain dial below 40 dB as this could cause affected frequency band to stop

amplifying.

IF YOU WANT TO IMPROVE PERFORMANCE

• Identify a location outside that receives a stronger signal and move the outside antenna to that location

(higher is usually better.

• Increase the distance between the booster and outside antenna - vertical separation is better than

horizontal.

• If using an omni outside antenna, upgrade to a directional yagi antenna that can be aimed toward your

closest tower.

Installation

SureCall, Inc | 1-888-365-6283 | [email protected] | www.surecall.com 13

Installation LED Indicators

LED INDICATORS

LED

Color

LED

Condition Resolution

Yellow Solid Indicates that the frequency band is not being used. After a period of time, if there’s no activity, that

band will go into sleep mode. Light is off while band is active. This is part of normal operation.

Yellow Flashing Indicates that the Automatic Gain Control (AGC) is self-adjusting. This is part of normal operation.

Red Flashing Indicates that the booster is receiving too much signal which could cause the affected band to

automatically turn off. When this happens:

1. For kits using an OMNI outside antenna, relocate the outside antenna to a location where the

signal is weaker.

2. For kits using a YAGI outside antenna, turn the antenna in short increments away from the signal

source.

3. Increase the separation between antennas (additional vertical separation works best).

4. Add an inline attenuator to the cable coming into the outside port of the booster.

5. Though not desirable as amplication will not be optimum, lower the dB gain setting in small

increments until the light turns off or ashes yellow.

Red Solid The frequency band is off.

If a red light has been ashing for an extended time due to too much signal, that frequency band will

display a solid red light indicating that the circuitry for that frequency band has been turned off.

This can also happen when the gain dial for a frequency band has been turned all the way down.

Yellow/

Red

Alternately

Flashing

Self-oscillation has been detected and to prevent it, one or more of the frequency bands have shut

down.

If this happens:

First, try increasing the separation between the inside and outside antennas. If your booster kit uses

directional antennas (example: outside Yagi antenna and inside panel antenna), ensure that they are

facing away from one another.

If condition continues, lower the dB gain setting in small increments until the light turns off or ashes

yellow.

Note: The term “IC” before the radio certication number only signies that Industry Canada technical specications were met.

Troubleshooting & Specications

TROUBLESHOOTING

If you have any questions during setup, please reach out to our US-based experienced support technicians:

Call: 1-888-365-6283

Email: [email protected]

Visit: www.surecall.com/support

Problem Resolution

Signal booster has no

power

Connect the power supply to an alternate power source.

Verify that the power source is not controlled by a switch that has removed power from the outlet.

If it remains OFF, contact tech support at: 1-888-365-6283 or [email protected]

After completing

installation, indoor

signal coverage has not

improved

Verify that cable connections are tightly tted to the booster and antenna.

Try further separating the booster and antenna.

Verify that there is usable signal where the antenna is placed.

 Note: Bars are not always a reliable measure of signal. The best way to conrm signal

coverage is the ability to place and hold a call.

SPECIFICATIONS

Model Fusion4Home 3.0 (US), Fusion4Home 3.0 CA (Canada)

Uplink Frequency Range (MHz): 698-716 / 776 – 787 / 824-849 / 1850-1915 / 1710-1755 (G Block Included)

Downlink Frequency Range (MHz): 728-746 / 746 – 757 / 869-894 / 1930-1995 / 2110-2155 (G Block Included)

Maximum Gain: 72 dB

Supported Standards: CDMA, WCDMA, GSM, EDGE, HSPA+, EVDO, LTE and all cellular standards

Input Impedance: 75Ω donor port / 50Ω server port

Noise Figure: 8 dB

AC Input: Input AC110V, 60 Hz; Output DC 5-15V

Maximum Output Power: 1 Watt EIRP

Cable: RG6 / SC-240

RF Connectors: F Female (outdoor) / N Female (indoor)

Power Consumption: <15W

Operation Temperature: -4º to +158º F

Dimensions: 7.875 x 5 x 1.188 inches

Weight: 2 LB 3 oz

Certications: FCC ID: RSNF4HOME (US), IC: 7784A-F4HOME (Canada)

SureCall, Inc | 1-888-365-6283 | [email protected] | www.surecall.com 15

Kitting

Component Product number Gain/Loss Note

LTE-A

707 MHz

LTE-V

731 MHz

Cellular

800 MHz

PCS

1900 MHz

AWS

1700 / 2100 MHz

Outdoor

Antenna*

SC-289W-75Ω 3 dBi 3 dBi 3 dBi 4 dBi 4 dBi / 4 dBi

SC-231W-75Ω 7 dBi 7 dBi 8 dBi 10 dBi 10 dBi / 10 dBi

Outdoor Cable* RG6 - 50 (50’) 3.32 dB 3.32 dB 3.75 dB 6.42 dB 6.22 dB / 6.68 dB 50 Feet or longer

Inside Cable* SC-240-20NN (20’) 2.06 dB 2.06 dB 2.29 dB 3.56 dB 3.36 dB / 3.76 dB 20 Feet or longer

Inside Antenna* SC-248W 7 dBi 7 dBi 7 dBi 10 dBi 10 dBi / 10 dBi

SC-222W 3 dBi 3 dBi 3 dBi 6 dBi 6 dBi / 6 dBi

SC-121W 1.2 dBi 1.2 dBi 1.2 dBi 3 dBi 3 dBi / 3 dBi

SC-302W 2.5 dBi 2.5 dBi 3 dBi 5 dBi 4 dBi / 5 dBi

* All equivalent antennas and cables are suitable for use with the Fusion4Home 3.0

PreAGC PreAGC

Pulse GSM 4.1 MHz AWGN Limit

Frequency Input Output Gain Input Output Gain Gain

(MHz) (dBm) (dBm) (dB) (dBm) (dBm) (dB) (dB)

Uplink: 1710-1755 -48.9 20.8 69.7 -48.2 21.6 69.8 71.3

Uplink: 1850-1915 -50.3 20.4 70.7 -47.6 20.6 68.2 72.0

Uplink: 824-849 -34.9 25.1 60.0 -35.5 24.1 59.6 64.9

Uplink: 698-716 -33.6 25.7 59.3 -36.2 24.4 60.6 63.5

Uplink: 777-787 -31.8 26.0 57.8 -35.8 25.4 61.2 64.4

Downlink: 2110-2155 -53.5 9.2 62.7 -60.6 9.1 59.7 N/A

Downlink: 1930-1995 -59.2 7.9 67.1 -58.0 8.5 56.5 N/A

Downlink: 869-894 -46.4 8.2 54.6 -56.5 6.4 62.9 N/A

Downlink: 728-746 -42.2 8.6 50.8 -57.3 3.7 61.0 N/A

Downlink: 746-757 -45.8 6.3 52.1 -54.7 6.4 61.1 N/A

Warning: Any product modications that use unauthorized antennas, cables, and/or coupling devices are prohibited by the FCC. Contact FCC for details:

1-888-CALL-FCC. Changes or modications not expressly approved by SureCall could void the user’s authority to operate the equipment.

USER GUIDELINES

This is a CONSUMER device

BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider’s consent. Most wireless providers consent to the use of signal boosters.

Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider.

In Canada, BEFORE USE you must meet all requirements set out in ISED CPC-2-1-051

You MUST operate this device with approved antennas and cables as specied by the manufacturer. Antennas MUST NOT be installed within 20 cm of any person.

You MUST cease operation of this device immediately if requested by ISED or a licensed wireless service provider.

WARNING: E911 location information may not be provided or may be inaccurate for calls served by using this device.

This device may operate in a xed location only, for in-building use.

Ce produit est un appareil de CONSOMMATION

AVANT DE L’UTILISER, vous DEVEZ ENREGISTRER CE DISPOSITIF auprès de votre fournisseur de services cellulaires et obtenir son consentement. La plupart des fournisseurs

de services cellulaires autorisent l’utilisation d’amplicateurs de signal. Il se peut que certains fournisseurs n’autorisent pas l’utilisation de ce dispositif sur leur réseau. Si vous

n’êtes pas sûr, contactez-le.

Au Canada, AVANT DE L’UTILISER vous devez répondre à toutes les exigences ISED CPC-2-1-052

Vous DEVEZ utiliser ce dispositif avec les antennes et les câbles autorisés, tel que le spécie le fabricant. Les antennes DOIVENT être installées à au moins 20 cm (8 po) (NE

DOIVENT PAS être installées à moins de 20 cm) de toute personne avoisinante.

Vous DEVEZ arrêter cet appareil immédiatement à la demande de la FCC (ISED au Canada) ou de tout fournisseur de services cellulaires autorisé.

AVERTISSEMENT: Il se peut que les informations relatives à la localisation E911 ne soient pas disponibles ou soient inexactes pour les appels qui utilisent cet appareil.

Cet appareil peut fonctionner seulement à un emplacement xe à l’intérieur d’un bâtiment;

Verizon: http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html

AT&T: https://securec45.securewebsession.com/attsignalbooster.com/

T-Mobile: https://support.t-mobile.com/docs/DOC-9827

Sprint: https://www.sprint.com/legal/fcc_boosters.html

U.S. Cellular: http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation

[1] For details on the requirements specied in ISED CPC-2-1-05, visit: http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08942.html

[2] Pour plus de détails sur les exigences ISED CPC-2-1-05, reportez-vous au site: http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08942.html

User Guidelines

SureCall, Inc | 1-888-365-6283 | [email protected] | www.surecall.com

WARRANTY

Three-Year Product Warranty

To activate your three-year manufacturer’s warranty, register your SureCall product at www.SureCall.com

SureCall warrants its products for three years from the date of purchase against defects in workmanship and/or materials. Specications are subject to change. The three-

year warranty only applies to products meeting the latest FCC Certication Guidelines stated on 2/20/2013 and going into effect April 30, 2014. A two-year warranty applies

to any products manufactured before May 1, 2014.

Products returned by customers must be in their original, un-modied condition, shipped in the original or protective packaging with proof-of-purchase documentation

enclosed, and a Return Merchandise Authorization (RMA) number printed clearly on the outside of the shipping container.

Buyers may obtain an RMA number for warranty returns by calling the SureCall Return Department toll-free at 1-888-365-6283. Any returns received by SureCall without an

RMA number clearly printed on the outside of the shipping container will be returned to sender. In order to receive full credit for signal boosters, all accessories originally

included in the signal booster box must be returned with the signal booster. (The Buyer does not need to include accessories sold in addition to the signal booster, such as

antennas or cables.)

This warranty does not apply to any product determined by SureCall to have been subjected to misuse, abuse, neglect, or mishandling that alters or damages the product’s

physical or electronic properties.

SureCall warrants to the Buyer that each of its products, when shipped, will be free from defects in material and workmanship, and will perform in full accordance with

applicable specications. The limit of liability under this warranty is, at SureCall’s option, to repair or replace any product or part thereof which was purchased up to THREE

YEARS after May 1, 2014 or TWO YEARS for products purchased before May 1, 2014, as determined by examination by SureCall, prove defective in material and/or

workmanship. Warranty returns must rst be authorized in writing by SureCall. Disassembly of any SureCall product by anyone other than an authorized representative of

SureCall voids this warranty in its entirety. SureCall reserves the right to make changes in any of its products without incurring any obligation to make the same changes on

previously delivered products.

As a condition to the warranties provided for herein, the Buyer will prepay the shipping charges for all products returned to SureCall for repair, and SureCall will pay the return

shipping with the exception of products returned from outside the United States, in which case the Buyer will pay the shipping charges.

The Buyer will pay the cost of inspecting and testing any goods returned under the warranty or otherwise, which are found to meet the applicable specications or which are

not defective or not covered by this warranty.

Products sold by SureCall shall not be considered defective or non-conforming to the Buyer’s order if they satisfactorily fulll the performance requirements that were

published in the product specication literature, or in accordance with samples provided by SureCall. This warranty shall not apply to any products or parts thereof which

have been subject to accident, negligence, alteration, abuse, or misuse. SureCall makes no warranty whatsoever in respect to accessories or parts not supplied by it.

Limitations of Warranty, Damages and Liability:

EXCEPT AS EXPRESSLY SET FORTH HEREIN, THERE ARE NO WARRANTIES, CONDITIONS, GUARANTEES, OR REPRESENTATIONS AS TO MERCHANTABILITY,

FITNESS FOR A PARTICULAR PURPOSE, OR OTHER WARRANTIES, CONDITIONS, GUARANTEES, OR REPRESENTATIONS, WHETHER EXPRESSED OR IMPLIED, IN

LAW OR IN FACT, ORAL OR IN WRITING.

SURECALL AGGREGATE LIABILITY IN DAMAGES OR OTHERWISE SHALL NOT EXCEED THE PAYMENT, IF ANY, RECEIVED BY CELLPHONE-MATE, INC. FOR THE

UNIT OF PRODUCT OR SERVICE FURNISHED OR TO BE FURNISHED, AS THE CASE MAY BE, WHICH IS THE SUBJECT OF CLAIM OR DISPUTE. IN NO EVENT SHALL

SURECALL BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, OR SPECIAL DAMAGES, HOWSOEVER CAUSED.

All matters regarding this warranty shall be interpreted in accordance with the laws of the State of California, and any controversy that cannot be settled directly shall be

settled by arbitration in California in accordance with the rules then prevailing of the American Arbitration Association, and judgment upon the award rendered may be

entered in any court having jurisdiction thereof. If one or more provisions provided herein are held to be invalid or unenforceable under applicable law, then such provision

shall be ineffective and excluded to the extent of such invalidity or unenforceability without affecting in any way the remaining provisions hereof.

SureCall has made a good faith effort to ensure the accuracy of the information in this document and disclaims the implied warranties of merchantability and tness for a

particular purpose and makes no express warranties, except as may be stated in its written agreement with and for its customers. SureCall shall not be held liable to anyone

for any indirect, special or consequential damages due to omissions or errors. The information and specications in this document are subject to change without notice.

Warranty
