396-4507Y1 QuickDraw Lite Operator’s Manual Revised 03/03/2020
396-4507Y1
QuickDraw Lite
Operator’s Manual
It is the responsibility of the operator to read and understand
this manual for the safe operation of the QuickDraw.
The operator must follow all safety precautions from the
label of all products being used.
MAW
SureFire Ag Systems

396-4507Y1 QuickDraw Lite Operator’s Manual 2 Revised 03/03/2020
QuickDraw Lite
604-050310-QuickDraw Lite-Venturi
with 3 Manual and 3 Auto Valves and
Mass Meter
RINSE VALVE
Open to rinse header
between products
AUTO VALVES
Connect to
Sprayer
MANUAL PRODUCT VALVES
Open to dispense this product
CARRIER FLOW VALVE
Open to allow full carrier ow
for preload or to nish load
Connect to Carrier Supply
Connect to Product Totes
Mass Meter—
Could use optional
Gear Meter
SureFire Ag Systems

396-4507Y1 QuickDraw Lite Operator’s Manual 3 Revised 03/03/2020
Optional Gear Meter
The QuickDraw Lite can be purchased with a Gear Meter instead of the Mass Meter. The Gear Meter
provides very accurate measurement of the chemical products. The Gear Meter must be used with a
strainer to be sure no particles get into the finely machined gear mechanism. This strainer must be
drained and cleaned out if a product has been used that even a minute amount of that product may
cause harm to the crop to be treated.
The Gear Meter system also comes with a paddle flow switch plumbed into the line before the strain-
er. This flow switch guarantees that product is flowing when the meter is spinning. The meter can
turn from the venturi suction even if no product is flowing. With the flow switch, the controller will not
read flow if the meter is spinning without any liquid flow.
GEAR METER
STRAINER
FLOW SWITCH
SureFire Ag Systems

396-4507Y1 QuickDraw Lite Operator’s Manual 4 Revised 03/03/2020
QuickDraw Lite Operation
From the MENU screen
you can access the other
controller screens.
RUN PAGE brings up the
MANUAL PRODUCT
screen.
RESET TOTAL sets the
Total at 0.00 GAL. Do
this before loading each
product.
AUTO PRODUCTS takes
you to the Automatic
Products screen shown
to the left.
Enter the SETPOINT for
the amount of each prod-
uct in the batch.
Push RESET TOTAL for
each product or RESET
ALL to bring each Total
back to 0.00.
Push START to automati-
cally load a product. The
controller will open and
close the valve to get the
correct amount.
After each product, open
the rinse valve for 3-5
seconds to rinse the
plumbing.
AUTO PRODUCTS
PAGE 2 takes you to the
screen for Valves 4, 5,
and 6.
MANUAL CONTROLS
brings up the Manual Op-
eration and Debugging
Screen.
SureFire Ag Systems

396-4507Y1 QuickDraw Lite Operator’s Manual 5 Revised 03/03/2020
Running a Batch with QuickDraw Lite
Calculate the amount of each product that will be needed in the batch.
Products can be loaded in any order.
Open the carrier flow valve for preloading and for finishing the batch with carrier.
Close the carrier flow valve when loading products.
Open the rinse valve for 3-5 seconds between products.
Enter the SETPOINTS for AUTO PRODUCTS before starting the batch. RESET TOTALS (to 0.00)
for each product. (Setpoints can be entered or changed and Totals can be reset while the batch is
running, but not while that product is being loaded.) An AUTO PRODUCT that is loading can be
stopped by pressing STOP on that product.
To Load MANUAL PRODUCTS
Go to the MANUAL PRODUCT screen (RUN PAGE).
Press RESET TOTAL (to 0.00).
Open the valve for the product. Close the valve when the desired amount has been loaded.
Open the rinse valve for 3-5 seconds to flush the header.
Repeat Steps 2-4 for all Manual Products.
To Load AUTO PRODUCTS
Go to the AUTO PRODUCTS screen (RUN PAGE > AUTO PRODUCTS).
Press RESET ALL or RESET TOTAL to set the Totals to 0.00.
Enter the SETPOINT for the desired amount of each product (if not already entered).
Press START for the product. The valve will close automatically when it reaches the setpoint.
Open the rinse valve for 3-5 seconds to flush the header.
Repeat steps 4 and 5 for each Auto Product.
After all products are loaded, open the Carrier Flow Valve until the batch is completed.
Kill the pump when the batch is complete.
Run Page Help Screen
Alarm Retry
This button appears if the system has paused due to an alarm failure. Pushing the button allows the
system to restart and try again. Start pump before re-trying.
Warnings & Alarms Active
Push these buttons in order to see what alarms and warnings are active. They will only be visible if
there are active alarms or warnings.
Rate and Totals
The manual product total is the large number in the middle of the screen and can be reset.
Mass flow is the amount of flow through the mass meter.
Carrier total, if enabled, show the total carrier pumped and can be reset.
SureFire Ag Systems

396-4507Y1 QuickDraw Lite Operator’s Manual 6 Revised 03/03/2020
QuickDraw Lite Manual Operations
To manually operate a valve, press on that valve on this screen. An
ON/OFF switch will appear. Press ON to open the valve. Press the
valve again to bring back the switch. Press OFF to stop the flow.
QuickDraw Lite Maintenance Screen
If it is necessary to replace a valve, come to this
page to address the new valve.
This page also shows the software version on
this QuickDraw Lite.
SureFire Ag Systems

396-4507Y1 QuickDraw Lite Operator’s Manual 7 Revised 03/03/2020
QuickDraw Lite System Settings
If a flowmeter is installed for the Carrier, set Carrier Meter to ENABLED. Adjust Pulses per Gallon
as needed.
When Carrier supply has run empty or when starting with empty lines set Carrier Prime to
ENABLED so the controller will give it time to prime before shutting down for a flow error.
Set electric automatic valves to ENABLED. Default Valve Close Time is 1.5 seconds. If the batch is
overshooting the target, increase this number because the valve needs more time to get closed on
time. If the batch is undershooting, lower this value. 1” valve default is 1.5 seconds.
When connecting a new tote, set Prod Prime to ENABLED on the first batch, so the controller won’t
time out before the hose gets filled with the new product.
SureFire Ag Systems

396-4507Y1 QuickDraw Lite Operator’s Manual 8 Revised 03/03/2020
Alarms and Warnings
ALARMS will prevent a batch from running and must be resolved before continuing.
WARNINGS will NOT stop a batch, but
should be checked to prevent a problem.
