SUZUKI
BOULEVARD C90T
HONDA
INTERSTATE
YAMAHA
V-Star Tourer
Overall length 2,560 mm (100.8 in.) 2,650 mm 2,490 mm
Seat height 720 mm (28.3 in.) 681 mm 690 mm
Curb mass 363 kg (800 lbs) 323 kg 323 kg
Displacement 1462 cm3(89.2 cu. in) 1312 cm31304 cm3
Max output 59.6 kw / 4,800 40 kw / 4,250 rpm 53.5 kw / 5,500 rpm
Max torque 131.4 N.m / 2,600 103 N.m / 2,750 rpm 106 N.m / 4,000 rpm
Fuel capacity 18.0 L (4.8 US gal.) 16.5 L 18.5 L
Rear tire size 200/60-16 170/80-15 170/70-16
Features
Fuel gauge
Gear position indicator
Hard sidecase
Tail lamp LED
Voices
f
rom ma
g
azine editor
s
On the highway, the B.O.S.S. is a beast. The distinctive three-airbox set-up feeds plenty of oxygen into the Mikuni 42mm throat,
and the five-speed transmission pulls in every phase, from a dead stop all the way into top gear. Shift cycles are so generous you
won’t even need fifth until, say, 70 mph. Judging by the merits of its powerplant alone, this is a touring machine, fully capable and
eager to please. But of course, it’s outfitted with a host of amenities to make the journey more comfortable.
Value is in the eye of the beholder, yet the 2013 Boulevard C90T does look more upmarket than its price tag reflects. The bike’s
general appearance makes it difficult for this reviewer to criticize. The big windscreen is positioned and designed to provide ample
protection at freeway speeds, with buffeting minimized by allowing just the right amount of air to pass above the headlight and
into the space between the screen and operator that normally induces turbulence between the screen and operator. Each bag
also is easily accessible from atop the bike, with the bags opening like a gaping clam once the ignition key is used in the locking
mechanism at the top of the bag.
Saddle up on the B.O.S.S.'s 28.3-inch seat (wider and flatter than the M90's) to find yourself in a comfortable touring-cruiser
position. There's a wide pullback handlebar right at your fingers and an open floorboard layout with a heel-toe shifter giving you
plenty of foot placement options. Its handling is surprisingly lively once up to speed, with neutral steering and good stability in the
corners. The tank-mounted multi- function instrument package is far more impressive, especially in this class; highlights include a
large analog speedometer, gear-position indicator, clock, and a large, five-segment LCD fuel gauge.
A
d
vantage summar
y
.Most Powerful engine in its class.
.Complete touring package including hard sidecase, windscreen, etc.
.Authentic classic style, designed with rider comfort in mind.
.Bold and unique, all black finish.
QUICK GUIDE
2013
Specifications, appearance, colors (including body color), equipment, materials and other
aspects of the “SUZUKI” products shown in this catalogue are subject to change by Suzuki at
any time without notice, and they may vary depending on local conditions or requirements.
Some models are not available in some regions. Each model may be discontinued without
notice. Image contains computer-generated composites.
300 Takatsuka-cho, Minami-ku, Hamamatsu City, JAPAN 432-8611 www.globalsuzuki.com
.Always wear a helmet, eye protection and protective clothing.
.Enjoy riding safely.
.Read your Owner’s Manual carefully.
.Never ride under the influence of alcohol or other drugs.
SUZUKI BOULEVARD C90T
Overall length 2,560 mm (100.8 in.)
Overall width 990 mm (39.0 in.)
Overall height 1,440 mm (56.7 in.)
Wheelbase 1,675 mm (65.9 in.)
Ground clearance 140 mm (5.5 in)
Seat height 720 mm (28.3 in.)
Curb mass 363 kg (800 lbs)
Engine type 4-stroke, 2-cylinder, Liquid-cooled, SOHC, 54° V-twin
Bore x stroke 96.0 mm x 101.0 mm
Displacement 1462 cm3(89.2 cu. in)
Compression ratio 9.5 : 1
Fuel system Fuel injection
Starter system Electric
Lubrication system Wet sump
SUZUKI BOULEVARD C90T
Transmission 5-speed constant mesh
Primary drive ratio 1.407 (76 / 54)
Final drive ratio 3.137 (20/17 x 32/12)
Suspension Front Telescopic, coil spring, oil damped
Rear Link type, coil spring, oil damped
Rake/trail 31°10' / 132 mm (5.2 in.)
Brakes Front 330 mm disc
Rear 275 mm disc
Tires Front 130/80R17M/C 65H, tubeless
Rear 200/60R16M/C 79H, tubeless
Ignition Electronic ignition (Transistorized)
Fuel tank 18.0 L (4.8 US gal.)
Oil capacity (overhaul) 4.0 L
Technical Features

Technical Features
P
ower
f
ul engin
e
1Most powerful engine in its class
Liquid-cooled, long stroke 1,462cm3V-twin engine produces highest power
and torque in its class.*
* 1000 - 1600cm3cruiser class.
2Suzuki fuel injection
Suzuki's unique SDTV fuel injection system, delivers seamless throttle
response while boosting fuel efficiency. The same technologies used in
Championship winning GSX-R or Hayabusa, the Legendary Sportbike.
3Smooth shift
The clutch features back torque limiting clutch system, resulting in
smooth down shift operation.
F
eatures
f
or tourin
g
4Factory built hard sidecases
.
Designed as part of bike, not lugguage add-ons.
.
They can be locked/unlocked with ignition key.
.
Made of impact resistant PP plastic.
.
The leather covers are custom matched with seat leather.
.
The inner lid are designed to protect inside from dust and water.
(They are not complete water proof, it has drain hole in the bottom of
the case.)
.
Sidecases are shaped not to invade passenger's foot space.
5Well cushioned comfortable seat
Seat is shaped to allow rider a freedom to move around in long range ride,
and designed to accept variety type of riders.
6Ready for long ride
.
Windscreen is designed to make great
wind protection while minimizing
the wind buffeting.
.
18 Litre (4.8 gallon) fuel tank enables
long riding range.
.
Handlebars are made wide and pulled back,
to fit wide range of riders size.
.
Floorboards are standard equipment enables
relaxed long ride.
S
ty
li
ng
d
es
i
g
n
7Sleek & traditional styling design
.
The bike is designed to show sleek flow line.
.
The side case is designed as part of bike, follow the whole flow line.
.
Long angled rear fender features a bright LED taillight for a sleek, thin form of styling.
.
Large multi-reflector headlight is designed to create a traditional look and
supply bright lighting.
.
Blacked-out finish of engine, exhaust and exterior make the C90T stand
out in the crowd with a bold and tough look.
A
dd
i
t
i
o
n
a
l
f
e
a
t
u
r
e
s
8Multi function instrument
.
Large speedo, LCD, indicators are made easy
to read.
.
Gear position indicator is shown in LCD.
.
Clock is always displayed in LCD
for convenience.
9Convenient features
.
Lockable storage is inside the side cover.
.
Easy to use helmet holder is on the left side.
Suzuki genuine accessorie
s
Backrest & Backrest mount :
Backrest has unique pivoting
action for increased passenger
comfort.
Radiator cover :
Resin chrome plating accessory.
Accessories bar :
This bar by two piece design
becomes more attractive for
appearance of this vehicle.
Rear carrier :
This carrier fits to this vehicle
and Maximum loading capacity
is 2.3kg.
17
7
4
2
4
6
3
5
6
6
out
i
n t
h
e crow
d
w
i
t
h
a
b
o
ld
an
d
tou
gh
l
oo
k.
8
9
8
9
Backrest &
Backrest mount
Radiator cover Accessory bar Rear Carrier
