Swann DIY Security Cam User manual

DIY Security Cam
Color Video Camera with Audio
With Tripod and Telephoto Lens
English
If this device does not work when you first plug it in,
do not take it back to the store. See the back cover
for Swann Technical Support.
Installation Guide
Swann Communications warrants this product against defects in workmanship and material for
a period of one (1) year from it’s original purchase date. You must present your receipt as
proof of date of purchase for warranty validation. Any unit which proves defective during the
stated period will be repaired without charge for parts or labour or replaced at the sole
discretion of Swann. The repair or replacement will be warranted for either ninety days or the
remainder of the original one year warranty period, whichever is longer. The end user is
responsible for all freight charges incurred to send the to Swann’s repair centres.
shipping from and to any country
other than the country of origin. The warranty does not cover any incidental, accidental or
consequential damages arising from the use of or the inability to use this . Any costs
associated with the fitting or removal of this product by a tradesman or other person or any
other costs associated with its use are the responsibility of the end user. This warranty applies
to the original purchaser of the only and is not transferrable to any third party.
Unauthorised end user or third party modifications to any component or evidence of misuse or
abuse of the device will render all warranties void.
product The
end user is responsible for all shipping costs incurred when
product
product
Help Desk / Support Details
Warranty Information
www.swannsecurity.com
Swann Technical Support
All Countries E-mail: [email protected]
Telephone Helpdesk
See http://www.worldtimeserver.com for information on different time zones
and the time in Melbourne Australia compare to your local time.
UNITED STATES toll free
1-800-627-2799
1-877-274-3695
(Su, 2pm-10pm US PT)
(M-Th, 6am-10pm US PT)
(F 6am-2pm US PT)
USA Exchange & Repairs
562-777-2551
(M-F, 9am-5pm US PT)
AUSTRALIA toll free
1300 138 324
(M 9am-5pm AUS ET)
(Tu-F 1am-5pm AUS ET)
(Sa 1am-9am AUS ET)
New Zealand toll free
0800 479 266
International
[phone]
NOTE: This equipment has been tested and found to comply with the limits for Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Swann Communications U.S.A. Inc.
10612 Shoemaker Avenue, Bldg A
Santa Fe Springs, CA 90670 USA
1-800-627-2799
WARNING: IMPORTANT NOTICE ABOUT CORRECT USE OF POWER ADAPTER
The correct orientation
for the enclosed power
adapter is in a vertical
or floor mount position
L’orientation correcte pour
L’adapteur secteur fourni
est dans une position
verticale ou plancher-
monte.
La orientacion correcta para
el adaptador electrico incluido
es en posicion vertical o instalado
en el suelo.

1. DIY Security Camera
2. 12V DC Power Adaptor (adaptor design varies depending on country)
3. 9V Battery Snap
4. Tripod
5. Telephoto Lens
6. This Quick Start Guide
YELLOW
VCR, TV or MONITOR
TOU
IN
VD O
I E
OID
V E
DA O
I
U
D
AIO
U
VIDEO IN
AUDIO IN
3 4
2
3
WHITE BLACK
POWER
PLUG
DIY SECURITYCAM
25
6
1
4
1
POWER
ADAPTOR
7
Contents and Parts Identification
WARNING - IMPORTANT SAFETY INSTRUCTIONS
How to connect DIY Security Cam to your TV or VCR
Your DIY SecurityCam is designed to transmit quality color images and sound to
your television and is operated by mains power.
To help guide you through the process of setting up the DIY SecurityCam, we
have outlined the steps and numbered each of the components required in the
diagram below.
5
* To extend the operating distance
from your TV or VCR you will need
to purchase an A/V extension cable
(sold separately) which are available
At most electronics stores.
Image Sensor: 1/3” Color CMOS
Picture Elements: NTSC - 510 (H) x 492 (V)
PAL - 628 (H) x 582 (V)
Video System*: NTSC - USA & Canada
PAL - AU, UK & EU
Horizontal Resolution: 380 TV Lines
Lens Focus and Visual Angle: 6mm / 52 degree
S/N Ratio: > 40db
Minimum Illumination: < 3 Lux (Color)
Electronic Shutter: Auto 1/60 ~ 1/15,000sec
Video Output: 1.0v (P-P) @ 75 ohm
Power Supply: 12V DC
Video Cable Connector: RCA connector
Housing Material: Aluminium Alloy
Operating Environment: 14°F ~ 104°F (-10°C ~ 40°C)
*Please note that this camera ships in the appropriate TV/Video system for the
country of sale. In countries using the NTSC TV standard the camera will be built
to the NTSC standard, and in countries using the PAL TV standard, the camera
will be built to the PAL standard. The camera cannot be switched from one
standard to the other.
Technical Specifications
To reduce fire or shock hazard do not expose the unit or adapters to rain or moisture
Do not handle damaged or leaking Lithium-Ion batteries
Do not use if any of the terminals or wires are exposed
Use only the power adapter that is included in this pack in an upright or vertical position
Any modifications not approved by Swann Communications PTY LTD. may void the user’s ability to
operate this product

You should position your cameras to cover the areas most exposed to risk.
See our suggestions below for some ideas:
Where to Place The Security Stickers:
1. On your front window
2. On side windows
3. Near entrance points - doors, gates
4. Next to a dummy camera mounted outside
5. On the front counter
6. On the cash register
7. Next to an obvious camera
1. Doorways
5. Reception
areas 6. Cash
register
7. Mix
dummies
& real
cameras
2. Windows 3. Car Parks 4. Verandahs
Tips for locating your camera
Step 1: At the end of your DIY SecurityCam cable you will find three colored plugs:
Yellow (Video RCA) ~ White (Audio RCA) ~ Black (DC Power)
Step 2: Plug the yellow RCA plug into the "Video In" input (3) (usually located at
the back of your TV or VCR).
Step 3: Plug the white RCA plug into the "Audio In" input (4) (usually located at
the back of your TV or VCR).
Step 4: Connect the black plug (5) at the end of your DIY SecurityCam into the
black plug at the end of the
power adaptor (6).
Step 5: Plug the power adaptor (7) into the mains power point in your wall.
Step 6: If you have an A/V TV with RCA sockets you will need to switch the TV to
the AV channel to view the camera. To connect the camera to your VCR, you will
need to turn the VCR to the A/V Input selection and turn your TV onto the channel
you would normally use to view a tape or movie on your VCR. This channel may be
activated by a button on your remote that is marked with this symbol , or L1 or
L2 or possibly AV, AV1 or AV2. Please read the instructions for your VCR or TV for
more information on using their A/V inputs.
Step 7: If the picture is not clear, you will need to focus the camera by loosening
the small locking screw below the lens, and turning the lens in a clockwise or anti-
clockwise direction until the image is clear. Once the lens is focussed correctly,
tighten the locking screw to hold it in place.
Step 8: If you are fitting the Telephoto lens, loosen the locking screw below the
lens and remove the Standard lens completely. Once the Standard lens is
removed, carefully screw the Telephoto lens into the lens socket and adjust for
correct focus. When the focus is correct, tighten the locking screw to hold the lens
in place. Reverse this procedure if you wish to refit the Standard lens.
How to connect DIY Security Cam to your TV or VCR
NOTE:
All jurisdictions have specific laws and regulations relating to the use of
cameras. Before using any camera for any purpose, it is the buyer’s
responsibility to be aware of all applicable laws and regulations that prohibit
or limit the use of cameras and to comply with the applicable laws and
regulations.
The legality of watching people other than yourself changes from country to
country and even state to state. Contact your local government's privacy
information body or your local Police for more information on what if any
restrictions you may face.

Mounting the camera
1. Once you have chosen the best position for the camera, switch the power to
the camera off and unplug the power lead from the camera.
2.
3. Hold the camera base in the position you wish to fix it, and mark the holes
with an appropriate pen or pencil. Once this is done, remove the stand and
drill a hole with the appropriate drill bit for the material you are mounting your
camera to and the screws or fasteners you are using (on some materials you
may not need to drill holes at all).
4. Run the camera cable back to the TV/VCR, any holes that you drill need to
9
be at least / ” (14mm) in diameter to allow the connectors to pass through.
16
5. Reconnect the power lead to the camera and switch the camera power back
on.
When mounting the DIY SecurityCam to your ceiling or wall, please ensure
that you swing the mounting bracket backwards so that the small holes
(microphone) at the top of the camera lens are ‘up’, otherwise you will find
that your pictures are displayed upside down.
To mount the tripod, screw the tripod into the mounting hole which is located
underneath the camera bracket. Extend the legs of the tripod to get the
camera into a higher position or adjust for an un-even surface area.
Please Note: The camera must not be placed where it looks directly into the sun
or any other bright light source, as this will not only result in a poor image, but will
eventually damage the electronics of the camera.
Areas with a high degree of contrast in the light levels may require re-positioning
of the camera in order to obtain the best image.
For night-time use or when situated in a dimly-lit environment the camera requires
the aid of suitable exterior lighting to ensure a good picture is achieved.
!
!Please test all devices before final installation as it is far easier to rectify
problems at this stage.
!To avoid the risk of damage to your product, use only the supplied power
adaptors.
!Areas with a bright background may cause degradation of the image. If
possible position your camera so that it doesn’t point towards a very bright
light source.
!Do not cut the DC power cable of the Camera to fit with another power
source. This may result in damage to the Camera & any unauthorised
modifications will void your warranty.
Best Results are achieved when the camera is looking down on the subject.
1. Deterrence is the best and most cost effective security method for:
- preventing criminal activity before it occurs is preferable to, and cheaper
than, cleaning up after it occurs
- the Swann DIY Security Camera is an example of cost effective security
utilising the 'art of deterrence' to outsmart thieves and criminals
2. Always place cameras high enough that they can't be closely inspected or
easily accessed
3. Position cameras and dummies where they can be easily seen for maximum
deterrence
4. Position a monitor where it can be seen but not touched
5. If you have more than one camera use a monitor with channel switching
function, a Quad Processor or DVR with multiple views to show potential
offenders the level of coverage you have protecting your site.
6. Add extra Swann dummy cameras to give the impression of heightened
security
7. Purchase a Swann DVR to monitor and record activity on your cameras.
Depending on the settings used, DVRs can record for months.
Tips for using your Swann Security camera
Important Information about this product

Mounting the camera
1. Once you have chosen the best position for the camera, switch the power to
the camera off and unplug the power lead from the camera.
2.
3. Hold the camera base in the position you wish to fix it, and mark the holes
with an appropriate pen or pencil. Once this is done, remove the stand and
drill a hole with the appropriate drill bit for the material you are mounting your
camera to and the screws or fasteners you are using (on some materials you
may not need to drill holes at all).
4. Run the camera cable back to the TV/VCR, any holes that you drill need to
9
be at least / ” (14mm) in diameter to allow the connectors to pass through.
16
5. Reconnect the power lead to the camera and switch the camera power back
on.
When mounting the DIY SecurityCam to your ceiling or wall, please ensure
that you swing the mounting bracket backwards so that the small holes
(microphone) at the top of the camera lens are ‘up’, otherwise you will find
that your pictures are displayed upside down.
To mount the tripod, screw the tripod into the mounting hole which is located
underneath the camera bracket. Extend the legs of the tripod to get the
camera into a higher position or adjust for an un-even surface area.
Please Note: The camera must not be placed where it looks directly into the sun
or any other bright light source, as this will not only result in a poor image, but will
eventually damage the electronics of the camera.
Areas with a high degree of contrast in the light levels may require re-positioning
of the camera in order to obtain the best image.
For night-time use or when situated in a dimly-lit environment the camera requires
the aid of suitable exterior lighting to ensure a good picture is achieved.
!
!Please test all devices before final installation as it is far easier to rectify
problems at this stage.
!To avoid the risk of damage to your product, use only the supplied power
adaptors.
!Areas with a bright background may cause degradation of the image. If
possible position your camera so that it doesn’t point towards a very bright
light source.
!Do not cut the DC power cable of the Camera to fit with another power
source. This may result in damage to the Camera & any unauthorised
modifications will void your warranty.
Best Results are achieved when the camera is looking down on the subject.
1. Deterrence is the best and most cost effective security method for:
- preventing criminal activity before it occurs is preferable to, and cheaper
than, cleaning up after it occurs
- the Swann DIY Security Camera is an example of cost effective security
utilising the 'art of deterrence' to outsmart thieves and criminals
2. Always place cameras high enough that they can't be closely inspected or
easily accessed
3. Position cameras and dummies where they can be easily seen for maximum
deterrence
4. Position a monitor where it can be seen but not touched
5. If you have more than one camera use a monitor with channel switching
function, a Quad Processor or DVR with multiple views to show potential
offenders the level of coverage you have protecting your site.
6. Add extra Swann dummy cameras to give the impression of heightened
security
7. Purchase a Swann DVR to monitor and record activity on your cameras.
Depending on the settings used, DVRs can record for months.
Tips for using your Swann Security camera
Important Information about this product

You should position your cameras to cover the areas most exposed to risk.
See our suggestions below for some ideas:
Where to Place The Security Stickers:
1. On your front window
2. On side windows
3. Near entrance points - doors, gates
4. Next to a dummy camera mounted outside
5. On the front counter
6. On the cash register
7. Next to an obvious camera
1. Doorways
5. Reception
areas 6. Cash
register
7. Mix
dummies
& real
cameras
2. Windows 3. Car Parks 4. Verandahs
Tips for locating your camera
Step 1: At the end of your DIY SecurityCam cable you will find three colored plugs:
Yellow (Video RCA) ~ White (Audio RCA) ~ Black (DC Power)
Step 2: Plug the yellow RCA plug into the "Video In" input (3) (usually located at
the back of your TV or VCR).
Step 3: Plug the white RCA plug into the "Audio In" input (4) (usually located at
the back of your TV or VCR).
Step 4: Connect the black plug (5) at the end of your DIY SecurityCam into the
black plug at the end of the
power adaptor (6).
Step 5: Plug the power adaptor (7) into the mains power point in your wall.
Step 6: If you have an A/V TV with RCA sockets you will need to switch the TV to
the AV channel to view the camera. To connect the camera to your VCR, you will
need to turn the VCR to the A/V Input selection and turn your TV onto the channel
you would normally use to view a tape or movie on your VCR. This channel may be
activated by a button on your remote that is marked with this symbol , or L1 or
L2 or possibly AV, AV1 or AV2. Please read the instructions for your VCR or TV for
more information on using their A/V inputs.
Step 7: If the picture is not clear, you will need to focus the camera by loosening
the small locking screw below the lens, and turning the lens in a clockwise or anti-
clockwise direction until the image is clear. Once the lens is focussed correctly,
tighten the locking screw to hold it in place.
Step 8: If you are fitting the Telephoto lens, loosen the locking screw below the
lens and remove the Standard lens completely. Once the Standard lens is
removed, carefully screw the Telephoto lens into the lens socket and adjust for
correct focus. When the focus is correct, tighten the locking screw to hold the lens
in place. Reverse this procedure if you wish to refit the Standard lens.
How to connect DIY Security Cam to your TV or VCR
NOTE:
All jurisdictions have specific laws and regulations relating to the use of
cameras. Before using any camera for any purpose, it is the buyer’s
responsibility to be aware of all applicable laws and regulations that prohibit
or limit the use of cameras and to comply with the applicable laws and
regulations.
The legality of watching people other than yourself changes from country to
country and even state to state. Contact your local government's privacy
information body or your local Police for more information on what if any
restrictions you may face.

1. DIY Security Camera
2. 12V DC Power Adaptor (adaptor design varies depending on country)
3. 9V Battery Snap
4. Tripod
5. Telephoto Lens
6. This Quick Start Guide
YELLOW
VCR, TV or MONITOR
TOU
IN
VD O
I E
OID
V E
DA O
I
U
D
AIO
U
VIDEO IN
AUDIO IN
3 4
2
3
WHITE BLACK
POWER
PLUG
DIY SECURITYCAM
25
6
1
4
1
POWER
ADAPTOR
7
Contents and Parts Identification
WARNING - IMPORTANT SAFETY INSTRUCTIONS
How to connect DIY Security Cam to your TV or VCR
Your DIY SecurityCam is designed to transmit quality color images and sound to
your television and is operated by mains power.
To help guide you through the process of setting up the DIY SecurityCam, we
have outlined the steps and numbered each of the components required in the
diagram below.
5
* To extend the operating distance
from your TV or VCR you will need
to purchase an A/V extension cable
(sold separately) which are available
At most electronics stores.
Image Sensor: 1/3” Color CMOS
Picture Elements: NTSC - 510 (H) x 492 (V)
PAL - 628 (H) x 582 (V)
Video System*: NTSC - USA & Canada
PAL - AU, UK & EU
Horizontal Resolution: 380 TV Lines
Lens Focus and Visual Angle: 6mm / 52 degree
S/N Ratio: > 40db
Minimum Illumination: < 3 Lux (Color)
Electronic Shutter: Auto 1/60 ~ 1/15,000sec
Video Output: 1.0v (P-P) @ 75 ohm
Power Supply: 12V DC
Video Cable Connector: RCA connector
Housing Material: Aluminium Alloy
Operating Environment: 14°F ~ 104°F (-10°C ~ 40°C)
*Please note that this camera ships in the appropriate TV/Video system for the
country of sale. In countries using the NTSC TV standard the camera will be built
to the NTSC standard, and in countries using the PAL TV standard, the camera
will be built to the PAL standard. The camera cannot be switched from one
standard to the other.
Technical Specifications
To reduce fire or shock hazard do not expose the unit or adapters to rain or moisture
Do not handle damaged or leaking Lithium-Ion batteries
Do not use if any of the terminals or wires are exposed
Use only the power adapter that is included in this pack in an upright or vertical position
Any modifications not approved by Swann Communications PTY LTD. may void the user’s ability to
operate this product

DIY Security Cam
Color Video Camera with Audio
With Tripod and Telephoto Lens
English
If this device does not work when you first plug it in,
do not take it back to the store. See the back cover
for Swann Technical Support.
Installation Guide
Swann Communications warrants this product against defects in workmanship and material for
a period of one (1) year from it’s original purchase date. You must present your receipt as
proof of date of purchase for warranty validation. Any unit which proves defective during the
stated period will be repaired without charge for parts or labour or replaced at the sole
discretion of Swann. The repair or replacement will be warranted for either ninety days or the
remainder of the original one year warranty period, whichever is longer. The end user is
responsible for all freight charges incurred to send the to Swann’s repair centres.
shipping from and to any country
other than the country of origin. The warranty does not cover any incidental, accidental or
consequential damages arising from the use of or the inability to use this . Any costs
associated with the fitting or removal of this product by a tradesman or other person or any
other costs associated with its use are the responsibility of the end user. This warranty applies
to the original purchaser of the only and is not transferrable to any third party.
Unauthorised end user or third party modifications to any component or evidence of misuse or
abuse of the device will render all warranties void.
product The
end user is responsible for all shipping costs incurred when
product
product
Help Desk / Support Details
Warranty Information
www.swannsecurity.com
Swann Technical Support
All Countries E-mail: [email protected]
Telephone Helpdesk
See http://www.worldtimeserver.com for information on different time zones
and the time in Melbourne Australia compare to your local time.
UNITED STATES toll free
1-800-627-2799
1-877-274-3695
(Su, 2pm-10pm US PT)
(M-Th, 6am-10pm US PT)
(F 6am-2pm US PT)
USA Exchange & Repairs
562-777-2551
(M-F, 9am-5pm US PT)
AUSTRALIA toll free
1300 138 324
(M 9am-5pm AUS ET)
(Tu-F 1am-5pm AUS ET)
(Sa 1am-9am AUS ET)
New Zealand toll free
0800 479 266
International
[phone]
NOTE: This equipment has been tested and found to comply with the limits for Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Swann Communications U.S.A. Inc.
10612 Shoemaker Avenue, Bldg A
Santa Fe Springs, CA 90670 USA
1-800-627-2799
WARNING: IMPORTANT NOTICE ABOUT CORRECT USE OF POWER ADAPTER
The correct orientation
for the enclosed power
adapter is in a vertical
or floor mount position
L’orientation correcte pour
L’adapteur secteur fourni
est dans une position
verticale ou plancher-
monte.
La orientacion correcta para
el adaptador electrico incluido
es en posicion vertical o instalado
en el suelo.

DIY SecurityCam
Caméra vidéo couleur avec audio
Avec trépied et téléobjectif
Quebec Français
Si cet appareil ne fonctionne pas lors du premier
branchement, ne le rapportez pas au magasin.
Communiquez avec le Centre d'assistance Swann en
utilisant notre service rapide de courrier électronique
[email protected] ou appelez-nous à un des numéros
sans frais listés sur la couverture arrière de ce livret.
La plupart des problèmes peuvent rapidement et facilement
être résolus par un simple courriel ou une conversation rapide
avec un de nos techniciens qualifiés. (Numéros sans frais
disponible aux États-Unis ou en Australie seulement)
Guide d'installation
Soutien Technique Swann
Centre d'assistance téléphonique
Pour tous les pays : courriel : [email protected]
(Dim, 14h00- 22h00 Heure du Pacifique)
(Lun-Jeu, 6h00-10h00 Heure du Pacifique)
(Ven, 6h00-14h00 Heure du Pacifique)
(Lun-Ven, 9h00-17h00 Heure du Pacifique)
(Lun, 9h00-17h00 Heure de l'Est AU)
(Mar-Ven, 1h00-17h00 Heure de l'Est AU)
(Sam, 1h00-9h00 Heure de l'Est AU)
(Lun, 11h00-19h00 Heure Nouvelle-Zélande)
(Mar-Ven, 3h00-19h00 Heure Nouvelle-Zélande)
(Lun-Jeu, 12h00-7h00 et 15h00-12h00 Greenwich)
(Fri, 12h00-7h00 et 15h00-23h00 Greenwich)
Visitez le site web http://www.worldtimeserver.com pour plus d'information sur les
différents fuseaux horaires et sur l'heure actuelle à Melbourne, en Australie, afin de
faire la comparaison avec votre heure locale.
Sans frais États-Unis : 1-800-627-2799, 1-877-274-3695
Échanges et Réparations États-Unis USA : 562-777-2551
Sans frais Australie : 1300 138 324
Sans frais Nouvelle-Zélande : 0800 479 266
International : [phone]
Swann Communications garantit ce produit contre toutes défectuosités de main d'œuvre et de
matériel pour une période d'un an de la date d'achat originale. Vous devez présenter votre reçu
comme preuve de date d'achat pour valider la garantie. Tout appareil qui devient défectueux
durant la dite période sera réparé sans frais pour les pièces et la main d'œuvre, ou remplacé à la
seule discrétion de Swann. La réparation ou le remplacement sera garanti soit pour quatre-vingt-
dix jours ou pour la balance de la garantie originale d'un an, selon celui de ces délais qui est le
plus long. L'utilisateur est responsable de tous les frais de transport encourus pour envoyer le
produit aux centres de réparation de Swann. L'utilisateur est responsable de tous les coûts
d'expédition encourus lorsque l'appareil est expédié de, ou vers tout pays autre que le pays
d'origine. La garantie ne couvre pas tous dommages circonstanciels, accidentels ou
conséquents pouvant survenir de l'utilisation, ou de la mauvaise utilisation de ce produit. Tous
les coûts associés à l'ajustement ou à la réparation de ce produit par une personne non qualifiée
ou toute autre personne, ou tous les coûts associés avec son utilisation sont la responsabilité de
l'utilisateur. Cette garantie s'applique uniquement à l'acheteur original du produit, et n'est
transférable à aucun tiers.
Les modifications faites par un utilisateur non autorisé ou un tiers à tout composant ou toute
preuve de mauvaise utilisation ou d'utilisation abusive annuleront toutes les garanties.
Détails du centre d'assistance/support
Information de garantie
www.swannsecurity.com
ARRÊT
Centre d'assistance
Pour des réponses
Cet appareil est conforme avec la Partie 15 des
Règlements du FCC. Le fonctionnement est sujet à ces
deux conditions :
(1) Cet appareil pourrait ne pas causer d'interférences
nocives et,
(2) Cet appareil doit accepter toutes les interférences
reçues, incluant les interférences qui pourraient
causer un fonctionnement non-désiré
AVERTISSEMENT FCC

JAUNE
VCR, TV ou MONITEUR
OUT
IN
VIDEO
VIDEO
AUDIO
AUDIO
ENTRÉE VIDÉO
ENTRÉE AUDIO
3 4
BLANC NOIR
FICHE
D'ALIMENTATION
ÉLECTRIQUE
CAMÉRA DE SÉCURITÉ FVM
25
6
1
ADAPTATEUR
DE COURANT
7
1. Caméra de sécurité FVM
2. Adaptateur d'alimentation DC 9-12V (le design de l'adaptateur varie, dépendant des
pays)
3. Connecteurs de batteries 9V
4. Trépied
5. Téléobjectif
6. Ce Manuel de Démarrage
Contenu et identification des pièces
Comment brancher la caméra de sécurité FVM à votre TV ou à votre VCR
Votre caméra de sécurité FVM est conçue pour transmettre des images couleurs et du son
de qualité, et fonctionne grâce à un conducteur principal.
Pour vous guider à travers le processus d'installation de votre caméra de sécurité FVM,
nous avons exposé les grandes lignes des étapes et nous avons numéroté chacune des
pièces requises dans le diagramme ci-dessous.
2
3
4
1
5
* Afin d'étendre la distance d'opération de votre TV ou de
votre VCR, vous devrez acheter un câble de raccordement
A/V (vendu séparément), qui est disponible dans la plupart
des magasins d'électroniques.
Capteur d'image : 1/3” po (8,5 mm) CMOS couleur
Éléments d'image : NTSC - 510 (H) x 492 (V)
PAL - 628 (H) x 582 (V)
Système vidéo * : NTSC - USA et Canada
PAL - AU, UK et EU
Résolution horizontale : 380 lignes TV
Focus de lentille et angle visuel : 6 mm / 52 degrés
Ratio S/N : > 40 db
Illumination minimale : < 3 Lux (couleur)
Obturation électronique : Auto 1/60 ~ 1/15,000 seconde
Sortie Vidéo : 1,0v (P-P) @ 75 ohm
Alimentation de courant : 9/12V DC
Connecteur du câble vidéo : Connecteur RCA
Matériel de la carcasse : Aluminium d'alliage
Environnement d'opération : 14°F ~ 104°F (-10°C ~ 40°C)
*Veuillez noter que cette caméra est expédiée dans le système TV/vidéo approprié
pour le pays de vente. Dans les pays qui utilisent NTSC TV standard, la caméra
sera construite avec le standard NTSC TV, et dans les pays utilisant le standard
PAL TV, la caméra sera construite pour le standard PAL. La caméra ne peut sauter
d'un mode à l'autre.
Spécifications techniques
