Swedstyle Memory T User manual

1 Swedstyle Memory T Swedstyle Memory T 1
/ MEMORY T 1.0
MANUAL
Document Version 2.0 / October 2019
TOUCHfamily
Valid for:
• TOUCHfx
• TOUCHdown
• TOUCHinlay
Swedstyle Memory T
Operating manual

Swedstyle Memory T 3
CONTENTS
1 General information........................................................................ 4
2. Safety........................................................................................................ 4
2.1 General safety regulations..................................................... 4
2.2 Intended use............................................................................... 4
2.3 Reasonably foreseeable misuse............................................ 4
2.4 Liability .........................................................................................5
2.5 Residual risks ..............................................................................5
3 The product............................................................................................6
3.1 Key product features ............................................................... 6
3.2 Dimensions................................................................................. 7
4 Assembly.................................................................................................7
4.1 Required components ............................................................. 9
4.2 Process.......................................................................................... 9
4.3 Completing assembly............................................................... 9
5 OPERATION .......................................................................................10
5.1 Adjusting the table top height .............................................11
5.2 Saving a memory position.....................................................11
5.3 Adjusting the table to a memory position........................11
5.4 Key lock...................................................................................... 12
5.5 Locked handset........................................................................ 13
6 ADDITIONAL INFORMATION............................................... 13
6.1 Disassembly.............................................................................. 13
6.2 Maintenance ............................................................................ 13
6.3 Cleaning..................................................................................... 14
6.4 Replacing a handset............................................................... 14
6.5 Troubleshooting...................................................................... 14
6.6 Disposal...................................................................................... 14

4 Swedstyle Memory T Swedstyle Memory T 5
1 GENERAL INFORMATION
Assembly personnel must read all documentation before starting assembly. Keep all
documentation for as long as the product is in your possession. Ensure that all documentation
is provided to subsequent owners. This Manual may change without notice. The most recent
version is available on our website.
2. SAFETY
Handsets may only be installed by Skilled Persons. A Skilled Person is defined as someone who:
• Is authorized for installation planning, installation, commissioning,
or servicing of the product
• Has read and understood all documentation relevant to the Handset
• Has the technical education, training, and/or experience to perceive risks and avoid hazards
• Has knowledge of the specialist standards applicable to the product
• Has the expertise to test, assess, and manage electrical and mechatronic products and
systems in accordance with the generally accepted standards and guidelines of electrical
engineering and furniture manufacturing
2.1 General safety regulations
In general, the followng safety regulations and obligations apply when handling the product:
• Do not operate the product unless it is in a clean and perfect condition
• Do not remove, change, bridge, or bypass any protection, safety, or monitoring equipment
• Do not convert or modify any components
• In the event of malfunction or damage, faulty components must be replaced immediately
• Unauthorized repairs are prohibited
• Do not attempt to replace hardware unless the product is in a de-energized state
• Only Skilled Persons are allowed to work with ”Memory T” hand controller
• Ensure that national worker protection conditions and national safety and accident
prevention regulations are observed during operation of the system
2.2 Intended use
This product is a Handsets for electrically Height-Adjustable Tables. It is used to control
Height-Adjustable Table systems via a Control Box. It is intended for indoor use only.
It may only be installed in compatible Height-Adjustable Tables and with Swedstyle-approved
accessories. Use beyond or outside the intended use will void the product’s warranty.
2.3 Reasonably foreseeable misuse
Usage outside of the intended use may lead to minor injury, serious injury, or even death.
Reasonably foreseeable misuse of the Handset includes, but does not extend to:
• Connecting unauthorized parts to the product. If you are unsure as to whether a part can
be used with a Handset, contact Swedstyle for further information
2.4 Liability
Swedstyle products comply with all currently applicable health and safety regulations.
However, risk can result from incorrect operation or misuse. Swedstyle is not liable for damage
or injury caused by:
• Improper product use
• Disregard of the documentation
• Unauthorized product alterations
• Improper work on and with the product
• Operation of damaged products
• Wear parts
• Improperly performed repairs
• Unauthorized changes to the operating parameters
• Disasters, external influence, and force majeure
The information in this Operating Manual describes the characteristics of products without
assurances. Resellers assume responsibility for the Swedstyle products installed in their
applications. They must ensure their product complies with all relevant directives, standards,
and laws. Swedstyle shall not be held liable for any damage that is directly or indirectly caused
by the delivery or use of this document. Resellers must observe the relevant safety standards
and guidelines for each product in the Table System.
2.5 Residual risks
Residual risks are the risks that remain after all relevant safety standards have been complied
with. These have been evaluated in the form of a risk assessment. Residual risks associated with
the installation of the hand controller are listed here and throughout this Operating Manual.
WARNING. Risk of death or serious injury through electric shocks
Hand controllers are electrical devices. Although you will not have to connect the Handset to
the Control Box during assembly, basic safety precautions must be taken at all times. Failure to
observe electrical safety precautions may lead to death or serious injury through electric shocks.
• Never open the Handset
• Ensure that the Handset is not connected to the Control Box during assembly
• Do not convert or modify the Handset in any way
• Do not immerse the Handset or its components in liquid. Clean only with a dry
or slightly damp cloth
• Do not place the Cable of the Handset on heated surfaces
• Check the housing and cables of the Handset for visible damage. Do not install
or operate damaged products.

6 Swedstyle Memory T Swedstyle Memory T 7
WARNING. Risk of death or serious injury in explosive atmospheres
Operating the Handset in potentially explosive atmospheres may lead to death or serious injury
through explosions.
• Read the relevant directives to determine if an atmosphere is potentially explosive
• Do not operate the Handset in potentially explosive atmospheres
CAUTION. Risk of minor or moderate injury through tripping
During the assembly process, you may have to step over Cables. Tripping over Cables may lead
to minor or moderate injury.
• Ensure that the assembly area is kept clear of unnecessary obstructions
• Be careful not to trip over Cables
CAUTION. Risk of minor or moderate injury through crushing
If any Handset Key becomes stuck while the system is in motion, the system may not stop
properly. This may lead to minor or moderate injury through crushing.
• Disconnect the system immediately if any Handset Key becomes stuck
3 THE PRODUCT
3.1 Key product features
3.2 Dimensions
Length 85.9 mm
Width 132.5 mm
Height (to underside of Table Top) 32.8 mm
4 ASSEMBLY
CAUTION. Risk of minor or moderate injury through improper handling
Improper handling of the product during assembly may lead to minor or moderate injury
through cutting, pinching, and crushing.
• Avoid contact with sharp edges
• Be careful while handling tools that may cause personal injury
• Ensure assembly complies with the generally accepted standards and guidelines of
electrical engineering and furniture manufacturing
• Read all instructions and safety advice carefully
CAUTION. Risk of minor or moderate injury through tripping
During assembly and operation, poorly routed Cables may become a trip hazard. Tripping over
Cables may lead to minor or moderate injury.
• Ensure that Cables are routed properly to avoid trip hazards
• Be careful not to trip over Cables when installing the Handset
NOTICE
• Ensure proper ESD handling during assembly. Damage that can be attributed to
electrostatic discharge will void warranty claims.
• To avoid damage to the product, measure the dimensions of the Handset before assembly.
• Before assembly, all parts must be acclimatised to the ambient conditions.
• Do not lift the Handset by its cable. This will cause irreparable damage to the product
• Perform a product risk assessment so that you can respond to potential residual hazards.
Assembly instructions must be included in your end user Operating Manual.
MANUAL
Document Version 2.0 / October 2019
TOUCHfamily
Valid for:
• TOUCHfx
• TOUCHdown
• TOUCHinlay
1 Strain Relief
2 Drilling Holes
3 Memory Position Keys
4 Display
5 UP/DOWN keys
6 SAVE key
*Cable not shown
Supply voltage 5 V DC ± 200 mV
Current Consumption (average) 60 mA
Current Consumption (standby) <1.3 mA
Service life 10 000 cycles
Cable length 2 000 mm / 78.740” (± 40 mm / 1.575”)
Dimensions (l x w x h ) 132.5 × 85.9 × 32.8 mm / 5.216“ x 3.380“ x 1.289“
Weight (including cable) 138 g
Ambient conditions during
operation
+5 °C to +40 °C at max. 68% relative air humidity (non-condensing),
up to an altitude of 2,000 m.
Ambient conditions during
transport and storage
-25 °C to +40 °C at max. 68% relative air humidity (non-condensing).
+40 °C to 60 °C at max. 32% relative air humidity (non-condensing).
Temperatures of more than 40 °C for periods not exceeding 10h.
Product must be acclimatised to acceptable operating conditions
Compatibility All LOGICDATA Control Boxes, except integrated Control Units in
the LOGICdrive and DYNAMIC MOTION families.
Degree of protection (IEC 60529) IP 20
Standards and regulations EMC directive 2014/30/EU
RoHS directive 2011/65/EU
Order Code TOUCH-FX-MDF-4M2-LD (4 Memory Positions, no Key Lock)
TOUCH-FX-MDF-4M2-KL (4 Memory Positions, Key Lock)
TOUCH-FX-MDF-6M2-LD (6 Memory Positions, no Key Lock)
TECHNICAL DATA
85,9 mm
132,5 mm
32,8 mm
Supply voltage 5 V DC ± 200 mV
Current Consumption (average) 60 mA
Current Consumption (standby) <1.3 mA
Service life 10 000 cycles
Cable length 2 000 mm / 78.740” (± 40 mm / 1.575”)
Dimensions (l x w x h ) 132.5 × 85.9 × 32.8 mm / 5.216“ x 3.380“ x 1.289“
Weight (including cable) 138 g
Ambient conditions during
operation
+5 °C to +40 °C at max. 68% relative air humidity (non-condensing),
up to an altitude of 2,000 m.
Ambient conditions during
transport and storage
-25 °C to +40 °C at max. 68% relative air humidity (non-condensing).
+40 °C to 60 °C at max. 32% relative air humidity (non-condensing).
Temperatures of more than 40 °C for periods not exceeding 10h.
Product must be acclimatised to acceptable operating conditions
Compatibility All LOGICDATA Control Boxes, except integrated Control Units in
the LOGICdrive and DYNAMIC MOTION families.
Degree of protection (IEC 60529) IP 20
Standards and regulations EMC directive 2014/30/EU
RoHS directive 2011/65/EU
Order Code TOUCH-FX-MDF-4M2-LD (4 Memory Positions, no Key Lock)
TOUCH-FX-MDF-4M2-KL (4 Memory Positions, Key Lock)
TOUCH-FX-MDF-6M2-LD (6 Memory Positions, no Key Lock)
TECHNICAL DATA
85,9 mm
132,5 mm
32,8 mm

8 Swedstyle Memory T Swedstyle Memory T 9
5.3 DRILLING TEMPLATES
5.3.1 TOU CHFX
Fig. 8: Drilling Template, TOUCHfx
38 mm
70 mm
SIDE EDGE
FRONT EDGE
4.1 Required components
Hand controller
Screwdriver
2 Mounting Screws
4.2 Process
1. Position the Handset under the table top and mark the position of the drilling holes.
If necessary, use the Drilling Template to help you.
2. Insert the Strain Relief into the designated slot on the Handset.
NOTICE Inserting the Strain Relief incorrectly may cause damage to the Cable and Handset.
Ensure that the Cable does not protrude over the housing
3. Use the screwdriver and 2 Mounting Screws to attach the Handset to the Table Top at the
marked drilling points.
NOTICE The required tightening torque depends on the material of the Table Top.
Do not exceed 2 Nm.
4.3 COMPLETING ASSEMBLY
After the ”Memory T” is attached to the Table Top, you must connect the Cable to
the Control Box.
DRILLING TEMPLATE
6.2 ASSEMBLY: TOUCH fx
6.2.1 REQUIRED COMPONENTS
1 TOUCHfx
2 2 Mounting Screws (supplied by Reseller)
Tool Screwdriver
INFO Thread diameter: max. 5 mm | Head diameter: 8.5 mm - 10.6 mm
If possible, do not use countersunk-head screws.
6.2.2 PROC ESS
1. Position the Handset under the table top and mark the position of the drilling holes. If necessary,
use the Drilling Template in chapter 5.3.1 to help you.
2. Insert the Stra in Reli ef into the designated slot on the Handset (Fig. 6).
NOTICE Inserting the Strain Relief incorrectly may cause damage to the Cable and Handset.
Ensure that the Cable does not protrude over the housing
Fig. 10: Inserting the TOUCHfx Strain Relief
3. Use the screwdriver and 2 Mounting Screws to attach the Handset to the Table Top at the
marked drilling points.
NOTICE The required tightening torque depends on the material of the Table Top. Do not exceed
2 Nm.
6.2.3 COMPLETING ASSEMBLY
After the TOUCHfx is attached to the Table Top, you must connect the Cable to the Control Box. Refer to the
manual for your chosen Control Box for instructions.

10 Swedstyle Memory T Swedstyle Memory T 11
5 OPERATION
CAUTION. Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the table’s
movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION. Risk of minor or moderate injury through unsecured objects
While the table moves up and down, unsecured objects may fall off the table and onto body
parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION. Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
• Do not slide your finger to a different Handset key while another button is pressed
• Disconnect the system immediately if any Handset Key becomes stuck
INFO. The technology within the Handset may be interrupted by external interferences during
operation. This may lead to certain user inputs (i.e. button presses) not being recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table
System to which the Handset is connected. Handset Keys are represented as follows:
UP Key
DOWN Key
SAVE Key
Memory Position Key 1
Memory Position Key 2
Memory Position Key 3
Memory Position Key 4
5.1 Adjusting the table top height
CAUTION. Risk of minor or moderate injury through crushing
Your fingers may be crushed when you attempt to change the height of the table
• Keep fingers away from moving parts
• Ensure that no persons or objects are in the table’s range of motion
INFO The Table Top will move up or down until the UP or DOWN Key is released,
or if a pre-defined stopping point has been reached.
To move the Table Top UP:
Press and hold until the desired height has been reached
To move the Table Top DOWN:
Press and hold until the desired height has been reached
5.2 Saving a memory position
This function saves a set Table Top position. One Memory Position can be saved
per Memory Position Key.
1. Move the table to the desired height.
The display shows the Table Top height (e.g. 73 cm)
2. Press
3. Press the Memory Position Key (e.g. 2)
4. The display shows
5. After about two seconds, the Table Top height is displayed again
5.3 Adjusting the table to a memory position
Version A (without double-click function):
1. Press and hold the required Memory Position Key (e.g. 2).
The Table Top will move until the saved Table Top height has been reached.
If you release the Key before the Memory Position is reached, the table will stop.
2. Release the Memory Position Key
3. The display shows the Table Top height (e.g. 73 cm)
7 OPERATION
CAUTION Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
•
• Disconnect the system immediately if any Handset Key becomes stuck
INFO The technology within the Handset may be interrupted by external interferences
during operation. This may lead to certain user inputs (i.e. button presses) not being
recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table System
to which the TOUCH Handset is connected. TOUCH Handsets are compatible with a large number of
LOGICDATA Control Boxes. Before using the Table System, you must also read the Operating Manual for
the installed Control Box, including all relevant safety information, in full.
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE Key
Memor y Position Key 1
Memory Position Key 2
Memory Position Key 3
Mem ory Position Key 4
SAVE
1
2
3
4
7 OPERATION
CAUTION Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
•
• Disconnect the system immediately if any Handset Key becomes stuck
INFO The technology within the Handset may be interrupted by external interferences
during operation. This may lead to certain user inputs (i.e. button presses) not being
recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table System
to which the TOUCH Handset is connected. TOUCH Handsets are compatible with a large number of
LOGICDATA Control Boxes. Before using the Table System, you must also read the Operating Manual for
the installed Control Box, including all relevant safety information, in full.
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE Key
Memor y Position Key 1
Memory Position Key 2
Memory Position Key 3
Mem ory Position Key 4
SAVE
1
2
3
4
7 OPERATION
CAUTION Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
•
• Disconnect the system immediately if any Handset Key becomes stuck
INFO The technology within the Handset may be interrupted by external interferences
during operation. This may lead to certain user inputs (i.e. button presses) not being
recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table System
to which the TOUCH Handset is connected. TOUCH Handsets are compatible with a large number of
LOGICDATA Control Boxes. Before using the Table System, you must also read the Operating Manual for
the installed Control Box, including all relevant safety information, in full.
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE Key
Memor y Position Key 1
Memory Position Key 2
Memory Position Key 3
Mem ory Position Key 4
SAVE
1
2
3
4
7 OPERATION
CAUTION Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
•
• Disconnect the system immediately if any Handset Key becomes stuck
INFO The technology within the Handset may be interrupted by external interferences
during operation. This may lead to certain user inputs (i.e. button presses) not being
recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table System
to which the TOUCH Handset is connected. TOUCH Handsets are compatible with a large number of
LOGICDATA Control Boxes. Before using the Table System, you must also read the Operating Manual for
the installed Control Box, including all relevant safety information, in full.
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE Key
Memor y Position Key 1
Memory Position Key 2
Memory Position Key 3
Mem ory Position Key 4
SAVE
1
2
3
4
7 OPERATION
CAUTION Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
•
• Disconnect the system immediately if any Handset Key becomes stuck
INFO The technology within the Handset may be interrupted by external interferences
during operation. This may lead to certain user inputs (i.e. button presses) not being
recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table System
to which the TOUCH Handset is connected. TOUCH Handsets are compatible with a large number of
LOGICDATA Control Boxes. Before using the Table System, you must also read the Operating Manual for
the installed Control Box, including all relevant safety information, in full.
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE Key
Memor y Position Key 1
Memory Position Key 2
Memory Position Key 3
Mem ory Position Key 4
SAVE
1
2
3
4
TOUCH FAMILY - OPERATING MANUAL // PAGE 23
7.1 ADJUSTING THE TABLE TOP HEIGHT
CAUTION Risk of minor or moderate injury through crushing
Your ngers may be crushed when you attempt to change the height of the table
• Keep ngers away from moving parts
• Ensure that no persons or objects are in the table's range of motion
INFO The Table Top will move up or down until the UP or DOWN Key is released, or if a pre-de-
ned stopping point has been reached.
To move the Table Top UP:
Press and hold the UP Key until the desired height has been reached
To move the Table Top DOWN:
Press and hold the DOWN Key until the desired height has been reached
7.2 SAVING A MEMORY POSITION
This function saves a set Table Top position. One Memory Position can be saved per Memory Position Key.
1. Move the table to the desired height
▸ The display shows the Table Top height (e.g. 73 cm)
SAVE 2. Press the SAVE Key.
23. Press the Memory Position Key (e.g. 2)
▸ The display shows S 2
7 3 ▸ After about two seconds, the Table Top height is displayed again
7 3
s 2
TOUCH FAMILY - OPERATING MANUAL // PAGE 23
7.1 ADJUSTING THE TABLE TOP HEIGHT
CAUTION Risk of minor or moderate injury through crushing
Your ngers may be crushed when you attempt to change the height of the table
• Keep ngers away from moving parts
• Ensure that no persons or objects are in the table's range of motion
INFO The Table Top will move up or down until the UP or DOWN Key is released, or if a pre-de-
ned stopping point has been reached.
To move the Table Top UP:
Press and hold the UP Key until the desired height has been reached
To move the Table Top DOWN:
Press and hold the DOWN Key until the desired height has been reached
7.2 SAVING A MEMORY POSITION
This function saves a set Table Top position. One Memory Position can be saved per Memory Position Key.
1. Move the table to the desired height
▸ The display shows the Table Top height (e.g. 73 cm)
SAVE 2. Press the SAVE Key.
23. Press the Memory Position Key (e.g. 2)
▸ The display shows S 2
7 3 ▸ After about two seconds, the Table Top height is displayed again
7 3
s 2
7 OPERATION
CAUTION Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
•
• Disconnect the system immediately if any Handset Key becomes stuck
INFO The technology within the Handset may be interrupted by external interferences
during operation. This may lead to certain user inputs (i.e. button presses) not being
recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table System
to which the TOUCH Handset is connected. TOUCH Handsets are compatible with a large number of
LOGICDATA Control Boxes. Before using the Table System, you must also read the Operating Manual for
the installed Control Box, including all relevant safety information, in full.
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE Key
Memor y Position Key 1
Memory Position Key 2
Memory Position Key 3
Mem ory Position Key 4
SAVE
1
2
3
4
7 OPERATION
CAUTION Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
•
• Disconnect the system immediately if any Handset Key becomes stuck
INFO The technology within the Handset may be interrupted by external interferences
during operation. This may lead to certain user inputs (i.e. button presses) not being
recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table System
to which the TOUCH Handset is connected. TOUCH Handsets are compatible with a large number of
LOGICDATA Control Boxes. Before using the Table System, you must also read the Operating Manual for
the installed Control Box, including all relevant safety information, in full.
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE Key
Memor y Position Key 1
Memory Position Key 2
Memory Position Key 3
Mem ory Position Key 4
SAVE
1
2
3
4
TOUCH FAMILY - OPERATING MANUAL // PAGE 23
7.1 ADJUSTING THE TABLE TOP HEIGHT
CAUTION Risk of minor or moderate injury through crushing
Your ngers may be crushed when you attempt to change the height of the table
• Keep ngers away from moving parts
• Ensure that no persons or objects are in the table's range of motion
INFO The Table Top will move up or down until the UP or DOWN Key is released, or if a pre-de-
ned stopping point has been reached.
To move the Table Top UP:
Press and hold the UP Key until the desired height has been reached
To move the Table Top DOWN:
Press and hold the DOWN Key until the desired height has been reached
7.2 SAVING A MEMORY POSITION
This function saves a set Table Top position. One Memory Position can be saved per Memory Position Key.
1. Move the table to the desired height
▸ The display shows the Table Top height (e.g. 73 cm)
SAVE 2. Press the SAVE Key.
23. Press the Memory Position Key (e.g. 2)
▸ The display shows S 2
7 3 ▸ After about two seconds, the Table Top height is displayed again
7 3
s 2
7 OPERATION
CAUTION Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
•
• Disconnect the system immediately if any Handset Key becomes stuck
INFO The technology within the Handset may be interrupted by external interferences
during operation. This may lead to certain user inputs (i.e. button presses) not being
recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table System
to which the TOUCH Handset is connected. TOUCH Handsets are compatible with a large number of
LOGICDATA Control Boxes. Before using the Table System, you must also read the Operating Manual for
the installed Control Box, including all relevant safety information, in full.
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE Key
Memor y Position Key 1
Memory Position Key 2
Memory Position Key 3
Mem ory Position Key 4
SAVE
1
2
3
4
7 OPERATION
CAUTION Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
•
• Disconnect the system immediately if any Handset Key becomes stuck
INFO The technology within the Handset may be interrupted by external interferences
during operation. This may lead to certain user inputs (i.e. button presses) not being
recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table System
to which the TOUCH Handset is connected. TOUCH Handsets are compatible with a large number of
LOGICDATA Control Boxes. Before using the Table System, you must also read the Operating Manual for
the installed Control Box, including all relevant safety information, in full.
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE Key
Memor y Position Key 1
Memory Position Key 2
Memory Position Key 3
Mem ory Position Key 4
SAVE
1
2
3
4
TOUCH FAMILY - OPERATING MANUAL // PAGE 23
7.1 ADJUSTING THE TABLE TOP HEIGHT
CAUTION Risk of minor or moderate injury through crushing
Your ngers may be crushed when you attempt to change the height of the table
• Keep ngers away from moving parts
• Ensure that no persons or objects are in the table's range of motion
INFO The Table Top will move up or down until the UP or DOWN Key is released, or if a pre-de-
ned stopping point has been reached.
To move the Table Top UP:
Press and hold the UP Key until the desired height has been reached
To move the Table Top DOWN:
Press and hold the DOWN Key until the desired height has been reached
7.2 SAVING A MEMORY POSITION
This function saves a set Table Top position. One Memory Position can be saved per Memory Position Key.
1. Move the table to the desired height
▸ The display shows the Table Top height (e.g. 73 cm)
SAVE 2. Press the SAVE Key.
23. Press the Memory Position Key (e.g. 2)
▸ The display shows S 2
7 3 ▸ After about two seconds, the Table Top height is displayed again
7 3
s 2

12 Swedstyle Memory T Swedstyle Memory T 13
Version B (Auto-Movement with double-click function):
INFO The double-click function is available only for Table Systems sold in US markets.
INFO If you press any Key while the table moves to a Memory Position, the Table Top will stop
moving immediately. To continue, you must select the Memory Position again.
CAUTION. Risk of minor or moderate injury through unauthorized modifications
The firmware is delivered with a deactivated double-click function. If you activate this function,
the grading of the safety functions according to EN ISO 13849-1 PL b, Category B, are no longer
valid, as the legal requirements in the standard are no longer met.
• If you activate the function, perform a new risk new assessment to meet the higher safety
requirements (EN 60335-1).
• Swedstyle is not liable for injuries or damage caused by activating the doubleclick function
1. Double-click the required Memory Position Key (e.g. 2)
The table will move to the Memory Position. You do not have to hold the Key
2. The display shows the Table Top height (e.g. 73 cm)
5.4 Key lock
CAUTION. Risk of minor or moderate injury through uncontrolled movement
When attempting to activate the Key Lock, pressing the Handset too forcefully may cause the
table to move unexpectedly. Failure to anticipate the table’s movements may lead to minor or
moderate injury through crushing.
• Do not press the Handset too forcefully while activating the Key Lock
INFO The Handset must be turned on for the Key Lock to be activated. To activate a locked
Handset, press any key.
INFO The Key Lock is available as standard.
Activating the Key Lock prevents you from moving the table if you accidentally press a Key.
The Key Lock can be activated and deactivated by swiping across the bottom edge of the
Handset. Alternatively, swipe horizontally across the left or right-hand side of the Handset.
The display must be active for you to activate the Key Lock. To activate an inactive display,
press any Key.
5.5 Locked handset
After you have activated the Key Lock, a key is displayed on the screen.
6 ADDITIONAL INFORMATION
6.1 Disassembly
To disassemble your Handset, ensure that it has been disconnected from the Power Unit.
Then, follow the assembly instructions in reverse order.
6.2 Maintenance
The hand controll is maintenance-free for their entire service lifetime.
WARNING. Risk of death or serious injury through electric shocks and other hazards
Using a Handset alongside unauthorized spare or accessory parts may lead
to death or serious injury through electric shocks and other hazards.
• Only use accessory parts produced or approved by Swedstyle
• Only use replacement parts produced or approved by Swedstyle
• Only allow Skilled Persons to perform repairs or install accessory parts
• Contact customer services immediately if the system malfunctions
The use of unauthorized spare or accessory parts may cause system damage. Warranty
claims are void in this scenario.
7 OPERATION
CAUTION Risk of minor or moderate injury through uncontrolled movement
The table may not always stop exactly at the expected position. Failure to anticipate the
table's movements may lead to minor or moderate injury through crushing.
• Wait until the system has completely stopped before attempting to use the table
CAUTION Risk of minor or moderate injury through unsecured objects
body parts. This may lead to minor or moderate injury through crushing.
• Ensure loose objects are kept away from the edge of the table
• Do not leave unnecessary objects on the table during movement
CAUTION Risk of minor or moderate injury through crushing
Failure to release Handset Keys correctly may result in the table failing to stop properly.
This may lead to minor or moderate injury through crushing.
•
• Disconnect the system immediately if any Handset Key becomes stuck
INFO The technology within the Handset may be interrupted by external interferences
during operation. This may lead to certain user inputs (i.e. button presses) not being
recognized.
This section of the Operating Manual contains a selection of instructions for operating the Table System
to which the TOUCH Handset is connected. TOUCH Handsets are compatible with a large number of
LOGICDATA Control Boxes. Before using the Table System, you must also read the Operating Manual for
the installed Control Box, including all relevant safety information, in full.
Handset Keys are represented as follows for further description:
UP Key
DOWN Key
SAVE Key
Memor y Position Key 1
Memory Position Key 2
Memory Position Key 3
Mem ory Position Key 4
SAVE
1
2
3
4
TOUCH FAMILY - OPERATING MANUAL // PAGE 23
7.1 ADJUSTING THE TABLE TOP HEIGHT
CAUTION Risk of minor or moderate injury through crushing
Your ngers may be crushed when you attempt to change the height of the table
• Keep ngers away from moving parts
• Ensure that no persons or objects are in the table's range of motion
INFO The Table Top will move up or down until the UP or DOWN Key is released, or if a pre-de-
ned stopping point has been reached.
To move the Table Top UP:
Press and hold the UP Key until the desired height has been reached
To move the Table Top DOWN:
Press and hold the DOWN Key until the desired height has been reached
7.2 SAVING A MEMORY POSITION
This function saves a set Table Top position. One Memory Position can be saved per Memory Position Key.
1. Move the table to the desired height
▸ The display shows the Table Top height (e.g. 73 cm)
SAVE 2. Press the SAVE Key.
23. Press the Memory Position Key (e.g. 2)
▸ The display shows S 2
7 3 ▸ After about two seconds, the Table Top height is displayed again
7 3
s 2
MANUAL
Document Version 2.0 / October 2019
TOUCHfamily
Valid for:
• TOUCHfx
• TOUCHdown
• TOUCHinlay
ACTIVATING THE KEY LOCK
TOUCH FAMILY - OPERATING MANUAL // PAGE 25
7.4 KEY LOCK
CAUTION Risk of minor or moderate injury through uncontrolled movement
When attempting to activate the Key Lock, pressing the Handset too forcefully may
cause the table to move unexpectedly. Failure to anticipate the table's movements may
lead to minor or moderate injury through crushing.
• Do not press the Handset too forcefully while activating the Key Lock
INFO The Handset must be turned on for the Key Lock to be activated. To activate a locked
Handset, press any key.
INFO The Key Lock is only available as standard on certain models of the TOUCHfx and
TOUCHdown. On other models it can be activated during parameterization. Check the
Order Code for your Handset to see if Key Lock is activated as standard.
Activating the Key Lock prevents you from moving the table if you accidentally press a Key. The Key Lock
can be activated and deactivated by swiping across the bottom edge of the Handset. Alternatively, swipe
horizontally across the left or right-hand side of the Handset (gure 5, Activating the Key Lock). The display
must be active for you to activate the Key Lock. To activate an inactive display, press any Key.
Fig. 13: Activating the Key Lock (example TOUCH-FX)
After you have activated the Key Lock, a key is displayed on the screen.
Fig. 14: Locked Handset

14 Swedstyle Memory T
6.3 Cleaning
1. Disconnect the height-adjustable desks power supply from the power source.
2. Wait 30 seconds for residual voltage to dissipate.
3. Wipe the surface of the Handset with a dry soft cloth or a soft cloth lightly moistened
in water. Never immerse the Handset into any liquid.
4. Wait for the Handset to dry completely.
5. Reconnect the power supply.
6.4 Replacing a handset
1. Disconnect the Control Box from the Mains.
2. Disconnect the Handset from the Control Box.
3. Remove the Handset from the Table Top.
4. Mount the new Handset onto the Table Top.
5. Plug the Handset back into the Control Box.
6. Reconnect the Control Box to the Mains.
6.5 Troubleshooting
Usually, malfunctions occur when Handsets are pressed while calibrating. If the Handset fails to
function, you will need to restart the system. To do this:
1. Unplug the Handset from the Control Box.
2. Plug the Handset back to the motor Control Box.
3. After a few seconds the Handset is ready for operation.
A list of common problems and their solutions can be found in the Operating Manual
of the installed Control Box.
6.6 Disposal
The Memory T is subject to the WEEE Directive 2012/19/EU.
Dispose of all components separately from household waste.
Use designated collection points or disposal companies
authorized for this purpose.

Swedstyle AB.
Box 171, SE-567 24 Vaggeryd, Sweden
[e-mail]
[phone]
www.swedstyle.com
Smart office solutions
