sweeek. AUDI Q8 User manual

ROCQ8RCUK
AUDI Q8
29/08/2022
30
MIN
1
3-8
ANS
30KG
sweeek.fr - sweeek.be - sweeek.es - sweeek.nl - sweeek.co.uk
sweeek.pt - sweeek.it - alicesgarden.com.au - sweeek.de
ATTENTION
ATENCIÓN
CAUTION
LET OP
ATENÇÃO
ATTENZIONE
ACHTUNG

230/10/2023
ENGLISH
Warning ..............................................................................................................................29
Safety information...............................................................................................................30
Advice in the case of a breakdown.....................................................................................34
Maintenance.......................................................................................................................35
Car use...............................................................................................................................36
Car radio use......................................................................................................................37
R/C function use.................................................................................................................37
Remote control use ............................................................................................................38
Warranty .............................................................................................................................39
Assembly............................................................................................................................85
IMPORTANT, RETAIN FOR FUTURE
REFERENCE: PLEASE READ
CAREFULLY
CONTENTS

3
30/10/2023
Garantie : 2 ans
Garantía : 2 años
Garantie: 2 jaar
Garantia: 2 anos
Garanzia : 2 anni
Garantie: 2 Jahre
30KG
Poids d’assise maximal : 30kg
Peso asiento máximo : 30kg
Maximum seat weight: 30kg/66 lbs
Maximale zitplaatsen gewicht: 30kg
Peso máximo do banco: 30kg
Peso massimo area di seduta: 30kg
Maximales Sitzgewicht: 30kg
Destiné à un usage domestique
Destinado a un uso doméstico
Bestemd voor huishoudelijk gebruik
Para uso doméstico
Destinato ad un uso domestico
Nur für den Privatgebrauch vorgesehen
Attention : risques de blessures
Cuidado : riesgo de lesión
Waarschuwing: risico op verwondigen
Cuidado: risco de ferimentos
Attenzione : rischio infortunio
Warnung: Verletzungsgefahr

EN
430/10/2023
WARNING
Warning - for domestic use only.
This product must be assembled, operated and then stored by an adult.
THE AUDI LOGO AND THE AUDI BRAND NAME ARE REGISTERED TRADEMARKS
OF AUDI SWEEEK AND ARE USED UNDER LICENCE.
• Follow the assembly instructions carefully. Assembly must be carried out by an adult.Keep children
away during assembly: risk of suffocation due to small parts.
• Always keep the instructions in a safe place for future reference, e.g. for identication of compo-
nents by the Customer Service department.
• Before assembly, make sure that no parts are missing. You may also have spare parts in the box.
• Before starting to assemble your car, please check that it is in the «OFF» position.
• Before using the car for the rst time, we recommend that you leave it to charge for at least 4-6
hours.
Battery Lead acid battery 1x 12V (4.5Ah)
Battery dimensions 90 x 70 x 60 mm
Charger 12V1000mA
Motor 2x 25W
Recommended for children 3 to 8 years
Maximum weight 30kg
Speed 2 à 2,6 km/h
Car dimensions 108 x 66 x 55 cm
Remote control 2,4GHz
Charging time 8 à 12 heures
Batteries required (not included) 2 piles AAA (LR03)
2 piles AA (LR6)

EN
5
30/10/2023
SAFETY INFORMATION
GENERAL SAFETY RULES
• CAUTION: Not suitable for children under 36 months (small components may be swallowed).
• It is intended for use by children aged 3 to 8 years, with a maximum weight of 30 kg. It must be used
under adult supervision. Never leave a child unattended.
• CAUTION: This product is intended for family use only. It cannot be used in schools, campsites,
hotels, public places etc...
• CAUTION: Do not use it on public roads.
• CAUTION: Do not use it in green areas.
• CAUTION: This car must not be used near motorized vehicles, stairs, slopes, water or swimming
pools in order to avoid risks of falls and other injuries.
• Use your car on a at surface (indoor, garden or playground)
• CAUTION: Do not use the vehicle in dirt, sand or gravel. This could damage moving parts, the en-
gine or the electrical system.
• Do not operate this car in the dark, as unexpected obstacles may be encountered, causing your
child to fall. Use the vehicle during the day or in a well-lit area.
• This toy should be used with care to avoid falls or collisions that could cause injury to the driver or
others.
• Check the condition of your car regularly.
• WARNING this car does not have brakes.
• This car has an adjustable seat belt. Teach your child how to use the seatbelt before using the car
to ensure their safety.
CHILD SAFETY
• Always keep your child within sight when using the vehicle.
• The child should remain seated in the seat at all times when in use.
• The child should always wear shoes.
• CAUTION: Protective equipment should be worn.
• Do not let your children touch the wheels when they are in motion.
• We advise you to teach your child the safety, use and braking instructions in order to avoid injuries
and collisions.
BATTERY SAFETY RULES
• Non-rechargeable batteries must not be recharged.
• Batteries must be removed from the toy before charging.
• Rechargeable batteries should be charged under adult supervision.
• Different batteries or batteries of different ages should not be mixed.
• Batteries must be inserted and aligned with the correct polarity.
• Unusable batteries must be removed from the toy.
• The power terminals must not be short-circuited.

EN
630/10/2023
BATTERY SAFETY RULES
• Only adults should handle and recharge the battery. Never allow a child to do so. The battery is
heavy and contains lead acid.
• A battery pack should only be charged using the charger recommended by the manufacturer. Using
a charger with an incompatible battery pack may result in a re hazard.
• The toy should only be used with the recommended transformer.
• The transformer is not a toy.
• Only use the battery pack specically intended for the machine.
• Use of any other battery pack may result in re, electric shock, or serious injury.
• Do not use the battery pack on any other product. Doing so may cause overheating, re or explo-
sion.
• Do not place battery-powered devices or their batteries near re or heat sources. This will reduce
the risk of explosion and injury.
• Do not open or attempt to disassemble the battery. It contains lead, acid and other toxic and corro-
sive materials.
• Do not open the charger. Wires and circuits could cause electric shock.
• Avoid direct contact between the battery terminals. This could cause a re or explosion.
• Do not allow liquid to come into contact with the battery or its components.
• Leaking electrolyte is corrosive and may cause eye or skin damage. Electrolyte is highly toxic and
is very dangerous if swallowed. If electrolyte comes into contact with your skin or eyes, wash them
immediately with plenty of water and contact
• your doctor as soon as possible.
• Do not short-circuit the battery pack. There is a risk of explosion.
• Protect the battery pack from moisture and water, do not charge this device in damp or wet condi-
tions. This will reduce the risk of electric shock.
• If the battery pack is damaged or used improperly, fumes may be released.
• Ventilate the area immediately and seek medical attention if you experience breathing difculties.
• The vapours are very irritating.
• Explosive gases are created during charging. Do not charge the battery near heat or ammable
materials. Charge the battery in a well ventilated area.
• Charge the battery in a dry area.
• Do not drop the battery. This could cause permanent damage and severe injury.
• Before recharging the battery, check the battery, charger, leads or connectors for wear or damage.
Do not charge the battery if any part is damaged.
• Do not allow the battery to become completely discharged. Recharge it after each use or once a
month if you do not use the vehicle regularly.
• Do not charge the battery upside down.
• Make sure the battery cover is always on. If the vehicle tips over and the battery falls out this could
cause injury to the child.
• This car has a protection feature: once the car is charging all its other functions will be will be una-
vailable.
• Do not grab the battery by one of the cables or by the charger, as this could damage it and cause a
re. Hold the battery by the case.
• Batteries should only be charged by adults or by children aged 8 years or older.
• Some parts of your car contain lead and lead compounds. Wash your hands after handling.
• Do not leave the device in the rain or sun.
Batteries should only be charged by adults or by children of at least 8 years of age.

EN
7
30/10/2023
Battery Voltage Battery status
1x 12V (4.5Ah)
≥ 12.88 The battery is recharged.
12.88 - 12.6 The car can run normally.
≤ 12.6 Stop the car, the battery needs to be
recharged.
• Do not dispose of the battery in ordinary household waste.
• Do not incinerate the battery.
• Dispose of the battery at an authorised waste disposal centre or recycling centre.
BATTERY USAGE RULES
• The switch must be set to «OFF» when charging.
• • Before the rst use, you should charge the battery for 4-6 hours. Do not charge the battery for more
than 10 hours to avoid the charger overheating.
• • When the vehicle starts to slow down, recharge the battery.
• • After each use or once a month, recharge the battery for 8-12 hours. Do not leave the battery
charging for more than 20 hours.
•
The voltage display on the dashboard allows you to see how much charge is left in the battery.

EN
830/10/2023
BATTERY AND FUSE REPLACEMENT
The battery has a thermal fuse that will automatically trip and cut power to the engine if the electrical system
or battery is overloaded. The fuse will reset, the vehicle will be switched off for 20 seconds and then power
will be restored again.
To avoid losing power, follow these guidelines:
• Do not overload the vehicle.
• Do not tow anything with the vehicle.
• Do not use on steep slopes.
• Do not hit objects, as this will cause the wheels to continue to rotate, causing the engine to overheat.
• Do not operate in high heat, as components may overheat.
• Do not expose the battery or any other component to water or any other liquid.
• Do not modify the electrical system. This could cause the fuse to blow.
RECYCLING THE BATTERY
Your battery will eventually stop charging. Depending on how it is used, the battery can provide optimal
performance for 1 to 3 years.
Follow these steps to replace and recycle the battery:
1. Remove the seat.
2. Disconnect the battery connectors.
3. Remove all battery covers.
4. Lift the battery carefully.
- Depending on the condition of the battery (e.g. leaking), wear protective gloves.
- Do not lift the battery by its connectors or cables.
5. Place the used battery in a plastic bag.
The battery components contain toxic and corrosive elements and should not be disposed of in the
environment or with your household waste. In order to avoid any risk to the environment, here is
the best practice to dispose of your battery:
- Cover the battery terminals with tape.
- Do not attempt to disassemble or access the battery components.
- If liquid is found to be leaking from the battery, be aware that it is corrosive and toxic, so it is
advisable to handle the battery with care (wearing gloves).
- Do not place the battery in ordinary household waste.
- Do not incinerate the battery.
- Dispose of the battery at a waste disposal centre or an authorised recycling centre.
6. Replace the new battery and reconnect the connectors.
7. Replace the bracket.
8. Replace the seat..

EN
9
30/10/2023
ADVICE IN CASE OF BREAKDOWN
PROBLEM POSSIBLE CAUSE SOLUTION
The car will not start
The battery is not charged Recharge the battery
The thermal fuse has blow Turn the fuse back on, see page
31
Loose wires or connectors Check that the battery connectors
are rmly connected
The battery is defectiv Replace the battery
Car does not run for long
Battery is undercharged Check that the connectors are
rmly connected when charging
Old battery Replace battery
Vehicle moves slowly
Battery low Recharge battery
Old battery Replace battery
Vehicle overloaded Reduce the weight in the vehicle.
Maximum weight: 30kgs
Vehicle is used in difcult
conditions Check safety instructions.
Vehicle must be pushed to
move forward
Poor contact between wires and
connector
Check that the battery connectors
are rmly connected
Difcult to change from forward
to reverse gear
Transition while the car is in
motion
Stop the car completely before
changing between forward and
reverse
Battery does not charge
Battery connector is loose Check that the battery connec-
tors are rmly connected
The charger is not connected Check that the battery charger is
plugged into a power outlet
The charger becomes hot
when charging Normal operation, no effect on consequences for the product

EN
10 30/10/2023
MAINTENANCE
• It is the responsibility of the adult to check the main parts of the toy before use. Check the battery char-
ger regularly for any malfunctions. If any are found, the charger should not be used until it has been
repaired.
• Make sure that the plastic parts of the vehicle are not cracked or broken.
• Occasionally apply light oil to grease moving parts such as wheels.
• If you apply oil, make sure you disconnect the transformer before cleaning.
• Store the vehicle indoors or cover it with a tarpaulin to protect it from the weather.
• Keep the vehicle away from heat sources. Plastic parts may melt.
• Recharge the battery after each use. Only an adult should handle the battery. Recharge the battery at
least once a month when the vehicle is not in use.
• Do not clean the vehicle with a garden hose. Do not clean the vehicle with soap and water. Do not use
the vehicle when it is raining or snowing. Water will damage the engine, electrical system and battery.
• Clean the vehicle with a soft, dry cloth. To shine the plastic parts, use a furniture polish without wax. Do
not use car wax. Do not use abrasive cleaners.

EN
11
30/10/2023
REMOTE CONTROL USE
When using the remote control, the driver has no control over the vehicle.
ASSEMBLY
Lift the cover on the back of the remote control and insert 2 AAA (LR03) batteries (not included).
1. CONNECT THE REMOTE CONTROL TO THE CAR
Press the pairing button for 2-4 seconds, then press the car switch (located on the dashboard).
If the LED on the remote control lights up, your remote control
is connected. If the LED ashes, the connection has failed, please change the batteries and repeat the
operation.
2. REMOTE STOP
Press the PARKING button (P) to stop the vehicle remotely and disable the accelerator pedal.
3. GEAR CHANGE
The speed selector (S) allows you to choose several speed levels; Slow (1 LED), Medium (2 LED), Fast
(3 LED).
Forward
Speed indicator :
Slow, medium, fast
Reverse
Speed
selector
Pairing
Turn left
Turn right
Park
The remote control will turn off automatically after 10 seconds of non-use.
Please repeat step 1 of connecting to the car when you change the batteries.

EN
12 30/10/2023
WARRANTY
• Sweeek guarantees your appliance against defects in workmanship and materials for a period of 2
years from the date of receipt by the consumer.
• If a part proves to be defective during the warranty period, your sole and exclusive remedy shall be
the repair or replacement of the defective part in accordance with the terms and conditions dened
by Sweeek after-sales service.
• The implementation of the Sweeek (WALIBUY) warranty is carried out by replacing the damaged
parts, with the purchaser paying the return costs.
• This warranty does not apply in case of abuse, mishandling or unauthorized repair of the product. If
it is necessary to return the defective product to our warehouse, it will be assessed and you will be
informed of the repairs to be made.
• Our equipment is intended for private and personal use, professional use will automatically void our
warranty.
LIST OF WARRANTY EXCLUSIONS
• LDamage, breakdowns, failures or defects attributable to external causes.
• Breakdowns resulting from modication of the construction and original characteristics of the ap-
pliance.
• Breakdowns affecting parts that do not conform to those recommended by the manufacturer.
• Adjustments accessible to the beneciary without dismantling the appliance.
• The costs of commissioning, adjustment, cleaning and tests not resulting from a guaranteed da-
mage.
• Non-compliance with the manufacturer’s instructions.
• Repairs and damage to the appliance after a repair carried out by anyone other than a repairer from
our workshops, or without prior agreement from us.
• Makeshift or temporary repairs as well as the consequences of any aggravation of the damage
resulting thereof.
• Damage due to corrosion, oxidation or incorrect connection.
• The replacement of missing/damaged parts upon receipt, not indicated on the delivery note.
• Replacement of wearing parts.

13
30/10/2023
2
1
4
3
5
3RZHUEXWWRQ7XUQVWKHYHKLFOHRQDQGRII
)RRWSHGDO$SSOLHVSRZHUVSHHGWRWKHYHKLFOH
Ɣ7RPRYHWKHFDUSUHVVWKHSHGDOGRZQ
Ɣ7REUDNHRUVORZGRZQUHOHDVHSUHVVXUHIURPWKHSHGDO
)RUZDUGUHYHUVHVZLWFK&KDQJHVWKHGLUHFWLRQWKDWYHKLFOHPRYHVIURPIRUZDUG
WRUHYHUVH
Ɣ7RPRYHWKHYHKLFOHIRUZDUGVKLIWWKHOHYHUWRWRSSRVLWLRQ
Ɣ7RPRYHWKHYHKLFOHEDFNZDUGVKLIWWKHOHYHUWRGRZQSRVLWLRQ
6RXQGEXWWRQVLIHTXLSSHG3UHVVIRUVRXQGSOD\LQJ
+LJK/RZVSHHGVZLWFKLIHTXLSSHG
2SHUDWHVWKHYHKLFOHWRPRYHIRUZDUGLQKLJKVSHHGRUORZVSHHG
+,177KHYHKLFOHLVGHVLJQHGWRRSHUDWHLQORZVSHHGRQO\LQUHYHUVH
8VH<RXU5LGHRQŇ
8VHWKHYHKLFOHRQJHQHUDOO\OHYHOJURXQG21/< '21278VHWKHYHKLFOHRQ/DZQVSDFH
7
6
CAR USE
CAUTION
Always stop the vehicle before changing gear or direction in order to avoid damaging
the gearbox and engine.
1. Start/Stop button: Turns the vehicle on and off.
2. Accelerator: Increases the speed of the vehicle.
- To move the car forward, press the pedal.
- To stop or slow down, release the pressure on the pedal.
3. FORWARD/STOP/REVERSE lever: Selects the direction of travel of the vehicle: Forward, Stop and
Reverse.
- To move the car forward, push the lever forward.
- To move the car backwards, pull the lever backwards.
- To stop the car, leave the lever in the middle.
4. Steering wheel controls: use the horn by pressing the button on the left and the button on the right for
the engine start sound! (Requires batteries - not provided)
5. Speed: This switch allows you to choose slow or fast speed.
NOTE: The vehicle is designed so that reversing can only be done at low speed.
6. Car radio: Allows you to listen to an audio source and adjust the volume. Supported format MP3 (via
USB/microSD). The display shows the battery charge level (in Volts, see P.9)
CAUTION Make sure your child knows how to steer, start, stop and knows the rules of safe driving.

14 30/10/2023
• USB : Plays any MP3 le from a USB stick..
• MP3 : Allows you to play any source from a device equipped with a mini jack port (cable supplied).
• TF : Plays any MP3 le from a TF or microSD card.
• V+/V- : Increases or decreases the volume.
• DISPLAY : Displays the remaining battery charge level (See P.9).
• The vehicle must be switched on for the music function to be used.
• The storage medium (micro SD or USB stick) must be inserted after the car is switched on. Playback
will automatically start from the last connected storage medium.
MP3 TF TF
USB
MP3
V
USB V+ V-
CAR RADIO USE

15
30/10/2023
8VHWKH5&IXQFWLRQŇ
A
B
R/C
PEDAL
Ɣ The R/C Protective cover must be removed by adults.
Ɣ This switch is only allowed to be operated by adults.
IMPORTANT
A. Remove the screw on the top of the protective cover with a screwdriver.
B. Remove the protective cover. (TIPS: Keep the protective cover and screw for
future use)
R/C - PEDAL Switch:
Press the switch into the “R/C” position, the turning and movement of the product
will be controlled by the remote controller. Press the switch into the “PEDAL”
position to turn off the remote control function. Product steering will be controlled by
the steering wheel and movement by the foot pedal.
R/C FUNCTION USE
• Remove the screw (A) and the protective cover (B). Keep these parts for future use.
• R/C: The driving of the vehicle will be controlled by the remote control
• PEDAL: The driving of the vehicle will be controlled by the driver with the steering wheel and the pedal.

16 30/10/2023
ASSEMBLY
PRE-ASSEMBLY INSTRUCTIONS
• Carefully remove the product and any accessories from the packaging. Make sure that all listed items
are included.
• Inspect the product carefully, to ensure that no parts have been damaged in transit.
• Do not discard the packaging until you have carefully inspected and veried that the product is working
properly.
EN
Materials
needed for
assembly :
Screwdriver (not
provided)
Long-nose pliers (not
provided) Keys (supplied)

17
30/10/2023
B
A
C
C
3
4
5
5
5
7
16
15
14
13
12
12
11
10 9
8
7
1
6
6
2

18 30/10/2023
× 1
1
× 2
2
× 2
3
× 2
4
× 6
5
× 4
6
× 4
7
× 2
8
× 1
9
× 1
10
× 1
11
× 2
12
× 1
13
× 1
14
× 1
15
× 2
16
× 2
B
× 8
C
× 1
M5x16 M4x12
M5x40
A
C
5
4
5
6
7
2

19
30/10/2023
× 1
1
× 2
2
× 2
3
× 2
4
× 6
5
× 4
6
× 4
7
× 2
8
× 1
9
× 1
10
× 1
11
× 2
12
× 1
13
× 1
14
× 1
15
× 2
16
× 2
B
× 8
C
× 1
M5x16 M4x12
M5x40
A
C
Insert motor 2onto the wheel axle as shown in the diagram provided. The right motor is labelled «R».
The left motor is labelled «L». Drive wheel 3has a notched hole in it.
3
5
2
6
7
1
5
4
5
6
7
2

20 30/10/2023
Remove the cap in the centre of the steering wheel by removing the screw, then insert two AA (LR6)
batteries
9
3
Unscrew screw Aand nut 10 from the steering wheel. Align the holes in the steering wheel and the
steering shaft 9, then replace screw Aand tighten nut 10
10
A
4
Ax1
