Swisher Trim-N-Mow Plus STS67522BS User manual

OWNER’S
MANUAL
1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093
PHONE [phone] FAX [phone]
MODEL NO.
Assembly
Operation
Service and
Adjustment
Repair Parts
Made In The
USA
19046 REV 13-259
Trim-N-Mow Plus
Visit us at www.swisherinc.com
STARTING SERIAL # L213-259001
STS67522BS
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
IMPORTANT

1) Engine Warranty All engines utilized on our products have a separate warranty extended
to them by the individual engine manufacturer. Any engine service
difficulty is the responsibility of the engine manufacturer and in no way
is Swisher or its agents responsible for the engine warranty. The Briggs
& Stratton Engine Service Hot Line is 1-800-233-3723.
2) Commercial Use This product is not intended for commercial use and carries no
commercial warranty.
3) Limitation This warranty applies only to products which have been properly
assembled, adjusted, and operated in accordance with the instructions
contained within this manual. This warranty does not apply to any
product of Swisher that has been subject to alteration, misuse, abuse,
improper assembly or installation, shipping damage, or to normal wear
of the product.
4) Exclusions Excluded from this warranty are normal wear, normal adjustments, and
normal maintenance.
In the event you have a claim under this warranty, you must return the product to an authorized
service dealer. All transportation charges, damage, or loss incurred during transportation of parts
submitted for replacement or repair under this warranty shall be borne by the purchaser. Should you
have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The
model number, serial number, date of purchase, and the name of the authorized Swisher dealer from
whom you purchased the trimmer will be needed before any warranty claim can be processed.
THIS WARRANTY DOES NOT APPLY TO ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME
PERIODS STATED HEREIN FOR ALL EXPRESSED WARRANTIES. Some states do not allow
the limitation of consequential damages or limitations on how long an implied warranty may last, so
the above limitations or exclusions may not apply to you. This warranty gives you specific legal
rights and you may have other rights, which vary from state-to-state. This is a limited warranty as
defined by the Magnuson-Moss Act of 1975.
LIMITED WARRANTY
The manufacturer’s warranty to the original consumer purchaser is: This product is free from defects in
materials and workmanship for a period of two (2) years from the date of purchase by the original consumer
purchaser. We will repair or replace, at our discretion, parts found to be defective due to materials or
workmanship. This warranty is subject to the following limitations and exclusions:
2

•Read, understand and follow all instructions in the manual and on the trimmer
before starting.
•Read this manual carefully. Become familiar with the controls and how to
operate the unit properly.
•Only allow responsible adults, who are familiar with the ins
tructions, to operate
the unit.
•Clear the area of objects such as rocks, toys, etc. that could be thrown by the
unit.
•Be sure the area is clear of other people before trimming. Stop the unit if
anyone enters the area.
•Be aware of the direction of the trimmer discharge and do not direct it at
anyone. Do not direct trimmer discharge at breakable objects, such as
windows, etc.
•Do not operate trimmer without all guards and shields in place.
•Never leave the machine running unattended.
•Trim only in daylight or good artificial light.
•Do not operate the trimmer while under the influence of alcohol or drugs.
•Watch for traffic when operating near roadways.
•Use the trimmer as the manufacturer intended and as described in the
manual.
•Do not operate trimmer if it has been dropped or damaged in any manner.
Always have the damage repaired before operating.
•Always wear safety glasses or eye shields when using the trimmer.
•Dress properly. Do not operate the trimmer when barefoot or wearing open
sandals. Wear only solid shoes for good traction when trimming. Wear a long
sleeved shirt or jacket and long pants. Do not trim in shorts.
•Keep your eyes and mind on your trimmer and the area being trimmed. Do
not let other interests distract you.
•Do not put hands and feet near or under rotating parts.
•Before cleaning, inspecting or repairing your trimmer, stop the engine and
disconnect the spark plug wire and keep it away from the spark plug to
prevent accidental starting.
•Do not operate the trimmer if it vibrates abnormally. Excessive vibration is a
sign of damage. Stop the engine and safely check for damage and repair as
required.
•Do not operate the trimmer in wet grass, where good footing may not be
possible. Walk, never run.
•Stop the trimmer when crossing gravel drives, etc.
3
Safety Instructions
This Safety Alert Symbol indicates important messages in this
manual. When you see this symbol, carefully read the message that
follows and be alert to the possibility of personal injury.

4
Slopesareamajor factor relatedtoloss of control andslipaccidents,
whichcanresultinsevere injury. All slopesrequire extracaution. If you
feel uneasyonit donot trimit.
Slope Operation
•
DO: Trim across the face of a slope and not up and down.
•DO: Remove objects such as rocks, tree limbs, etc.
•DO: Watch for holes, ruts or bumps. Tall grass can hide obstacles.
•DO NOT: Mow near drop-offs, ditches or embankments. The operator could
lose footing or balance.
•DO NOT: Trim excessively steep slopes.
•DO NOT: Trim on wet grass. Reduced footing could cause slipping.
Children
•
Keep children out of the area and under the watchful care of another
responsible adult.
• Be alert and turn the machine off if children enter the area.
• Before and when backing, look behind and down for small children.
• Never allow children to operate this machine.
•
Use extra care when approaching blind corners, shrubs, trees or other objects
that may obstruct vision.
•Use extra care handling gasoline and other fuels. They are flammable and
vapors are explosive.
•Use only an approved container for fuel.
•Never remove gas cap or add fuel with the engine running.
•Allow engine to cool before refueling. Do not smoke while refueling.
•Never refuel the machine indoors.
•Never store the machine or fuel container where there is an open flame, such
as a water heater.
•Never run a machine inside a closed area.
•Keep nuts and bolts tight and equipment in good condition.
•Never tamper with safety devices.
•Keep machine free of grass, leaves or other debris build up. Clean oil or fuel
spillage. Allow machine to cool before storing.
•Stop and inspect the equipment if you strike an object. Repair if necessary
before restarting.
•Never make repairs or adjustments with the engine running.
Service

5
The operation of any mower can encounter foreign objects to be thrown into the eyes, resulting in
severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over
spectacles before starting any cutting machine and while operating such a machine.
The operation of any mower produces sound waves that are damaging to the human ear. Ear
protection is recommended.
CAUTION!
Tragic accidents can occur if the operator is not alert to the presence of children. Children
are often attracted to the machine and the mowing activity. Never assume that children
will remain where you last saw them.
Do not operate the trimmer if it vibrates abnormally. Excessive vibration is a sign of damage.
Stop the engine and safely check for damage and repair as required.
Trim-N-Mow Plus Decal
19147

Important!Use the proper length of line. Using a line too long for the unit will cause
stalling and unacceptable operation.
Use 18” Trimmer Line Part Number P3618
•Loosely fold trimmer line in half.
•Place loop of line against outside of loop on the trimmer head (Step 1).
•Bring ends around and through the line attachment loop and over the cutter line
loop (Step 2).
•Pull ends to tighten loop (Step 3).
6
Handle Adjustment
Assembly
Preparing Unit For First Use
Installing Trimmer Line
Step 1 Step 3Step 2
Contents of Box:
• Trimmer
Parts bag containing:
• Manual
• Engine manual
• Safety goggles
• Bottle of engine oil
• Trimmer line
• Hex wrench
Tools Required:
•½” Wrench
Installation of handles:
1. Remove loose fasteners from trimmer frame handle
holes.
2. Pivot handles up and align holes in handle with holes
on trimmer frame. Install hardware removed in
previous step. Snug, but do not tighten bolts.
3. Pivot upper handles to fit the lower handles. Tighten
knobs.
4. Adjust handles for comfortable operation.
5. Tighten all bolts.
Handles may be adjusted up and down and in and out for
comfortable operation.
• Fill engine crankcase with oil. A 20oz. bottle has been provided with this unit. A new unit
requires 18-20oz. DO NOT OVERFILL.
• Fill the engine fuel tank with gasoline. GASOLINE SHOULD BE ADDED OUTSIDE IN A
WELL-VENTILATED AREA.
• Check to ensure string has been installed properly. A diagram is provided just above the trimmer
head for proper installation.
• Refer to engine manufacture’s manual for oil and fuel specifications.

4 Trimmer line Configuration
Shown set at Low cutting height 2 Trimmer line Configuration
Shown set at High cutting height
Set Screw
7
Operation
Important! To ensure proper operation, clean the engine and trimmer regularly. Remove any build up
of chaff from the top of the engine. During operation debris may get wrapped around trimmer head.
Prolonged use in this condition may result in excessive wear and part failures. Periodically turn off trimmer
and remove debris.
Trimmer line attachment positions:
•Trimmer is equipped with 4 trimmer line attachment points.
•When mowing with trimmer, the 4 trimmer line configuration is recommended for a more consistent, even cut.
•When trimming tall or thick vegetation, the 2 trimmer line configuration is recommended for improved
performance.
To adjust cutting height:
1. Loosen set screw using hex wrench provided.
2. Slide cutting head up or down to desired cutting height.
3. Tighten set screw.
4. Any cutting height may be used with either trimmer line configuration.
Trimmer Line Positions
To start the trimmer:
1. Remove any built up debris from engine and trimmer head.
2. Move throttle control to “FAST”.
3. Push primer button on engine as directed.
4. Firmly grasp rope handle and pull out slowly until resistance is felt. Then pull back rapidly with a
full arm stroke. If engine fails to start after 3 pulls, repeat step 3.
5. When engine starts, leave throttle control at “FAST”. Throttle control must be set in the fast
position for maximum performance.
6. Engage trimming head.
7. Begin trimming.
To engage/disengage trimmer head:
•Engage: Bring control bail into contact with the upper handle and grip it together with the handle.
If trimmer head does not fully engage, see belt adjustment section.
•Disengage: Release control bail. Trimmer head should stop within a few seconds. If it does not,
see belt adjustment section.
To stop the trimmer:
1. Release the control bail.
2. Move throttle control lever on engine to “SLOW” for a few seconds then move to “STOP”.
Important! For safest operation, make sure debris is directed away from you and others.

8
Trimming Tips
Troubleshooting
•If engine will not start, remove and check air filter to make sure filter and
carburetor are clean.
•
Do not lift the trimmer head when trimming. Let the head rest lightly touching the ground.
•Keep an eye on the length of the trimmer line. As the line gets shorter they become less effective
at cutting and will take longer to trim properly. Replace the line as necessary (see Installing
Trimmer Line).
•Do not trim wet grass.
•Use caution when trimming slopes.
•Use the proper length of line. Using a line too long for the unit will cause stalling and
unacceptable operation.
Make sure your trimmer is in safe working condition by keeping the following guidelines in mind every time you
use your trimmer.
•Keep trimmer in good operating condition and keep all guards and shields in place. DO NOT operate this
trimmer if any of the shields and guards are missing.
•Check all fasteners for secure fit to keep equipment in safe working order. Make adjustments as necessary.
•To reduce fire hazards, keep engine free of grass, leaves or excessive grease.
•DO NOT operate trimmer with a damaged or missing muffler. DO NOT tamper with exhaust system; this may
cause a fire hazard.
•DO NOT operate engine if air cleaner or the cover over the carburetor air intake is missing. Removal of these
parts could create a fire hazard.
•Before cleaning, making adjustments or repairing the trimmer, STOP engine, disconnect spark plug wire and
allow engine to cool.
•Handle gasoline with care. DO NOT smoke or use open flame near gasoline. Use only approved gasoline
containers. Never fuel or run trimmer in poorly ventilated areas, such as a garage or utility building.
•Always replace fuel tank cap. Be sure to clean up any spilled gasoline.
•Do not change the engine governor settings or over-speed the engine; severe injury or damage may result.
•Never store mower with gasoline in the tank inside a building where fumes may reach an open flame or spark.
Always allow engine to cool before storing.
Trimmer Maintenance
WARNING – ALWAYS STOP ENGINE AND DISCONNECT SPARK PLUG
WIRE BEFORE PERFORMING ANY ADJUSTMENTS OR SERVICE.
NEVER ADD GASOLINE TO A HOT ENGINE – ALLOW ENGINE TO
COOL BEFORE ADDING GASOLINE.

Thumb wheel
Engine
•Refer to the engine service manual provided with this unit.
Belts
•Occasionally check the belt for wear. A worn belt should be replaced.
Belt Adjustment
During the first few hours of operation all belts go through a “break-in period” after which the belts
may need to be adjusted using the following instructions. Indications that the belts need to be
adjusted include:
•Loss of power at the trimming head causing the head to spin unusually slow or stop.
•Excessive wear on belt due to slipping.
•The belt used to engage/disengage the trimmer head can be adjusted using the following
instructions:
1. Locate the thumb wheel adjuster on the control cable
(see illustration) .
2. Release control bail to disengage trimmer head.
3. Rotate thumb wheel a few turns counterclockwise (from normal operating position).
4. Re-engage trimmer head.
5. If trimmer head has not returned to normal operation, repeat steps 2-4.
Important! Do not over tighten cable adjuster. This may cause the cable to break.
Excessive force should NOT be required to fully engage control bail.
9
Belt Replacement
Head Engagement Belt A Replacement
1. Remove front belt cover.
2. Remove old belt.
3. Install new belt by first routing belt under the engine and around lower engine pulley E .
4. Then route belt between two idler pulleys as shown D .
5. Install belt around front pulley B .
6. Ensure that belt is correctly installed between the belt guides C and adjacent pulley. Ensure that belt is correctly installed in the
grove of each pulley.
7. If belt tension had previously been adjusted, reset thumb wheel adjuster by rotating wheel clockwise as far as adjuster will allow
(see illustration in belt adjustment instructions). If head does not properly engage refer to belt adjustment instructions.
8. Reinstall front belt cover.

10
Assembly
Item # Part # Description Item # Part # Description
1 N/A Engine - Briggs & Stratton 16 NB180 Nut - Nyloc 1/4-20
2 NB170 Nut - Serrated Flange 5/16-18 17 NB587 Bolt - Carriage, 5/16-18 X 1 3/4
3 NB253 Bolt- Serrated Flange, 5/16-18 X 1 1/4 18 10399* Handle - Lower
4 2063 Pulley - Engine 19 NB596 Bolt - Serrated Flange, 5/16-18 X 3/4
5 NB607 Washer - SP Bellville 20 26X249 Screw - .312-18 X .75
6 NB238N Bolt - HHC 3/8-24 X 1 21 2026* Cover - Rear
7 2019 Guard - Belt 22 2002K Wheel - 14"
8 19135 Clip - Panel 23 NB132 Bolt -1/2-13 X 4
9 NB622 Bolt - Serrated Flange, 5/16-18 X 2 1/4 24 2005* Base - Upper Motor
10 19006 Cable - Control, Trimmer 25 NB281 Nut - Nyloc 1/2-13
11 2030 Knob - Black Plastic 26 2106* Plate - Axle
12 NB275 Washer - SAE Flat 5/16 27 NB555 Washer - USS Flat,1/2
13 19005 Handle - Bail 28 NB118 Nut - Jam, 1/2-13
14 10578* Handle - Upper 29 19034 Belt - 60", Trimmer
15 NB218 Bolt - 1/4-20 X 2 HCC GR5 ZY 30 2006* Base - Lower Motor
31 19004 Shield - Rubber
When ordering replacement parts
* USE PAINT CODE: TK=BLACK
See Detail
Page 11
