Swisher 11933 SPIKE AERATOR User manual

Owner’s
Manual
11933
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
Before Operatin this
Equipment.
Made In CHINA
1602 CORPORATE DRIVE, PO BOX 67, WARRENSBURG, MISSOURI 64093
PH 660. 747. 8183 FAX [phone]
swisherinc.com
12259 REV. 60-059
40” Roller Aerator
MANUFACTURING QUALITY LAWN CARE EQUIPMENT SINCE 1945

LIMITED WARRANTY
The manufacturer’s warranty to the original consumer purchaser is: This product is free from defects in materials and
workmanship for a period of one (1) year from the date of purchase by the original consumer purchaser. We will repair or
replace, at our discretion, parts found to be defecti e due to materials or workmanship. This warranty is subject to the
following limitations and exclusions:
1) Commercial Use warranty period for any product used for commercial or rental is limited to ninety (90) days from date
of original purchase.
2) Limitations
This warranty applies only to products which ha e been properly assembled, adjusted, and operated in
accordance with the instructions contained within this manual. This warranty does not apply to any
product of Swisher Mower and Machine Co., Inc., that has been subject to alteration, misuse, abuse,
improper assembly or installation, or shipping damage.
3) Exclusions Excluded from this warranty are normal wear, normal adjustments, and normal maintenance.
In the e ent you ha e a claim under this warranty, you must return the product to an authorized ser ice dealer. All
transportation charges, damage, or loss incurred during transportation of parts submitted for replacement or repair under
this
warranty shall be borne by the purchaser. Should you ha e any questions concerning this warranty, please contact us toll
-
free at 1-800-222-
8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer
from whom you purchased the mower will be needed before any warranty claim can be processed
.
THIS WARRANTY DOES NOT APPLY TO ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES AND ANY
IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME PERIODS STATED HEREIN FOR ALL EXPRESSED
WARRANTIES. Some states do not allow the limitation of consequential damages or limitations on how long an implied
warranty may last, so the abo e limitations or exclusions may not apply to you. This warranty gi es you
specific legal rights
and you may ha e other rights, which ary from state-to-state. This is a limited warranty as defined by the Magnuson-
Moss
Act of 1975.
This Safety Alert Symbol indicates important messages in this manual. When you see
this symbol, carefully read the message that follows and be alert to the possibility of
personal injury
•Read this manual and learn to operate this equipment safely
•Stop and inspect the equipment if you strike and object. Repair if necessary, before restarting
•Dress properly. Do not operate when bare foot or wearing open sandals
•Do not operate while under the influence of alcohol or drugs
•Operate attachments up and down slopes. There is a significant risk of o erturns when operating across
slopes
•Oil or Grease mo ing parts as required.
•Keep the operating speed LOW !! Do not operate o er 5 MPH (8 KPH)
•Be sure that the area is clear before operating. Children are often attracted to the machine and
operating acti ity. Never assume that children will remain where you last saw them. Keep
children under the watchful care of another responsible adult.

ITEM# PART # DESCRIPTION QTY ITEM# PART # DESCRIPTION QTY
1 12260 Drum Body Weldmen 1 7 12102 Lock Nu M10 2
2 12261 Plug wi h Thread 1 8 12264 "U" s yle Hi ch Bracke 1
3 12262 Join Bushing Weldmen 2 9 12224 Bol M8×50 4
4 12263 Oil Valve Ø6 2 10 NB556 Fla Washer Ø8 4
5 NB630 Bol M10×55 2 11 12221 Lock Nu M8 4
6 NB271 Fla Washer Ø10 2 12 12265 "T" s yle Hi ch Bracke 1
Assembly Instructions
1. Locate and layout all parts as shown below. Use caution as the points as sharp.
2. Place U style Hitch Bracket around Drum Body , Slip Joint Bushing Weldment o er axle and install
hardware as indicated
3. Place “T” style hitch against “U” Hitch and install hardware indicated. Tighten all hardware securely.
Check all hardware periodically to assure tightness.
4. Fill Drum with water to achie e desired weight. Install Plug.
5. Grease or Oil bushings as needed.
Maintainence Instructions
1. Lubricate Bushings as needed.
2. Drain water completely from drum before winter storage.
3. Check hardware for tightness before each use.

swisherinc.com
MANUFACTURING QUALITY LAWN CARE EQUIPMENT SINCE 1945
WHEN ORDERING PARTS, PLEASE HAVE THE
FOLLOWING INORMATION AVAILABLE:
* PRODUCT – ________________
* SERIAL NUMBER - _______________
* MODEL NUMBER - _______________
TYPE - _______________
* PART NUMBER WITH PAINT CODE
* PART DESCRIPTION
TELEPHONE - 1-800-222-8183
FAX - 1-660-747-8650
SWISHER MOWER & MACHINE CO. INC.
SWISHER MOWER & MACHINE CO. INC.SWISHER MOWER & MACHINE CO. INC.
SWISHER MOWER & MACHINE CO. INC.
1602 CORPORATE DRIVE
P.O. BOX 67
WARRENSBURG, MO 64093
