SwitchDin SA User manual

Document Number: QRG-SMA-1 Quick Reference Guide
Revision: Issue 1.0
Quick Reference Guide
Droplet + SMA for Flexible Exports (SA)
For SA Power Networks
Flexible Exports
Prepared by:
SwitchDin Pty Ltd
91 Parry Street
Newcastle West 2302

Document Number: QRG-SMA-1 Quick Reference Guide
Revision: Issue 1.0
1. Required Hardware & Software Checklist
❑SMA Sunny Boy 3.0-6.0
❑Any Compatible Smart Meter
❑SwitchDin Residential Droplet
❑GPO for SwitchDin Droplet
❑Sets of cables (ethernet & ethernet to
USB adaptor)
❑SwitchDin App:
www.switchdin.com/app
2. Onsite, wire up Smart Meter on grid or load configuration. Refer OTR Wiring Information and
Diagram
3. Enable Modbus TCP and port 502 as follows:
1. Establish a connection to the user interface.
2. Log into the user interface as an Installer.
3. Select the Device Parameters tab.
4. Select [Edit parameters].
5. Select the Parameter group External Communication
6. Select Modbus>TCP Server.
7. In the drop-down list Activated, select the entry Yes.
8. If necessary, change the port in the field Port. (required setting: 502)
9. Select [Save all].

Document Number: QRG-SMA-1 Quick Reference Guide
Revision: Issue 1.0
4. Wiring the droplet to the inverter
Follow one of the processes below
4.1. SMA Energy Meter
OPTION 1 : Direct connect between inverter and meter
OR
OPTION 2 : Connect meter to the router
4.2. Eastron Meter
Connect the SMA Energy Meter
to the inverter via ethernet
cable
Connect the inverter to the
droplet via wifi
Connect the droplet to the
router via ethernet or WiFi
Connect the inverter to the
droplet via an ethernet to USB
converter
Connect the droplet to the
router via ethernet or WiFi
Connect the meter to the
router via ethernet cable
Connect the inverter to the
droplet via an ethernet to USB
converter
Connect the droplet to the
router via ethernet or WiFi
Connect the meter to the
droplet via two options
below
or
Serial
Connection
or
or

Document Number: QRG-SMA-1 Quick Reference Guide
Revision: Issue 1.0
Serial Connection: Eastron RJ45 cable + RS485 to USB converter
1. Use the cable provided by Eastron meter
2. Match and connect the pin between the Eastron Meter and the RS485 to USB
converter.
3. Connect the USB adaptor to any of the USB ports on the droplet
Examples of RS485 to USB converter
DTECH 0.5m USB to RS422
RS485 Serial Port Converter
USB Port to RS-485/422
Converter
Industrial USB to RS485
Converter
5. Commissioning
5.1. Commission the inverter
1. In the Installer app, select installer from
the side menu, the scanner will start
2. Scan the QR code on the side of the
droplet, follow the prompts and select
to connect via ethernet or Wi-Fi
3. Add a device by clicking the “+” icon on
the bottom right of the screen
4. Select the discovery option
5. Click “Select meter role if…“ dropdown
list and select
For Option 1
5.1. Grid meter role –for grid meter
configuration (proceed to step 5.4)
5.2. Load meter role –for load meter
configuration (proceed to step
5.3.7)
For Option 2
5.3. Ignore meter role –if the meter is
connected to the router
DB9
Output Signal
Full Duplex
connection
Half-Duplex
connection
1
T/R+
TXD(A+)
RS485(A+)
2
T/R-
TXD(B-)
RS485(B-)

Document Number: QRG-SMA-1 Quick Reference Guide
Revision: Issue 1.0
5.2. SMA Energy Meter (ONLY FOR OPTION 2)
6. Scroll down and look for SMA
Speedwire Energy Meter
7. Click “Select meter role to…“ dropdown
list and select
7.1. Grid meter role –for grid meter
configuration
7.2. Load meter role –for load meter
configuration
8. Click the configure button (blue
hammer and spanner)
For Load meter role - proceed to step 5.3.7
5.3. Eastron Meter
Complete the following steps to configure the meter.
1. Click “+” on the USB port number where the
meter comms cable is connected.
2. Then select “Eastron” from the device list.
3. Select the correct Eastron meter for your
installation (single or three-phase)
4. Click back in the top left corner

Document Number: QRG-SMA-1 Quick Reference Guide
Revision: Issue 1.0
5. Click the “Select meter role to con…” drop down
and select “Grid meter role” or “Load meter role”
6. Click the configure button (blue hammer and
spanner)
7. Click back on the top left corner and select
“Manual” discovery
8. Search “Site Aggregates”, and click ‘+’
5.4. Register device for Flexible Exports
1. Close the “Add device” window, click next.
2. Select the option “Flexible Exports Program
–SAPN”
3. Enter NMI, click next
4. The screen indicates if the connection and
registration is successful. Click done

Document Number: QRG-SMA-1 Quick Reference Guide
Revision: Issue 1.0
6. Troubleshooting
6.1. Droplet status indicator meanings
Indication
Red
Green
Blue
PWR
Power
N/A
Power
N/A
WIFI
WiFi
No Wi-Fi
Wi-Fi connected
Weak Wi-Fi signal
iNet
Internet
No Internet
Internet connected
Configure via
SwitchDin app
SDin
SwitchDin comms
Cannot see
SwitchDin
Connected to
SwitchDin
N/A
Devs
Devices attached
No devices
Devices detected
N/A
