SY Xcalibur 44 User manual

SY Electronics Ltd., 7 Worrall Street, Manchester, M5 4TH, United Kingdom
Tel: [phone] – Web: sy.uk
Xcalibur 44
Xcalibur 88
User Manual
SY-HX150-44-18G
SY-HX150-88-18G
4x4 and 8x8 150m Matrix System
HDMI 2.0 (4K60 4:4:4), Down-Scaler, Test Pattern, VKA,
EDID, HDCP & CEC control, Audio de-embed, PoC

sy.uk 2V1.0
Thank you for purchasing this PRODUCT.
This PRODUCT is designed with the professional AV installers in mind. The many extensive
features assist with system integration, validation and maintenance.
Installation precautions
This product has special circuitry to protect it against moderate surges and static discharges.
However, to ensure reliable operation and long service life, it is important to take the
necessary precautions against any spikes, surges and static discharges.
Place the units away from heat sources and allow adequate ventilation.
Shielded cable and in particular cat6, cat6a or cat7 is highly recommended. As much as
possible signal cables should be routed away from any noisy sources and should avoid long
runs in close proximity to AC mains cables.

V1.0 3sy.uk
CONTENTS
FEATURES 6
CONNECTORS AND CONTROLS 6
FRONT 6
Xcalibur-44 (SY-HX150-44-18G) 6
Xcalibur-88 (SY-HX150-88-18G) 6
REAR 7
Xcalibur-44 (SY-HX150-44-18G) 7
Xcalibur-88 (SY-HX150-88-18G) 7
CONNECTING TO THE MATRIX 8
RJ45 WIRING 8
IR CONNECTOR WIRING 8
USING THE MATRIX PRODUCTS 9
USING THE FRONT PANEL CONTROLS 9
Making Video Selections 9
Normal Operating Mode 9
Selecting the Menu Options 9
Select EDID Menu 10
Select Baud 10
IP Settings 10
HDCP Settings 10
Test Pattern Settings 11
Power Button 11
Lock Button 11
IR REMOTE CONTROLLERS 11
XCALIBUR 44 IR REMOTE 11
FIGURE 1 - IR REMOTE FOR XCALIBUR 44 11
XCALIBUR 88 IR REMOTE 12
DEFAULT SETTINGS 12
IR ROUTING AND PASS-THROUGH 13
IR INPUTS 13
IR Outputs 13
COAX DIGITAL AUDIO OUTPUTS 13
ANALOGUE AUDIO OUTPUTS 13
RS232 CONTROL PORT WIRING 13
RS232 COMMANDS 13

sy.uk 4V1.0
SYSTEM COMMANDS 14
VIDEO ROUTING 15
PRESETS 15
Feedback Messages 15
ENABLING OR DISABLING THE OUTPUT STREAM 16
TEST PATTERN COMMANDS 16
VIDEO KEEP-ALIVE COMMANDS 17
DOWN-SCALER MODE 17
HDCP OPTIONS 18
EDID CONTROL 18
SENDING RS232 COMMANDS TO HX RECEIVERS 20
Sending an ASCII Command 20
Sending an Hexadecimal Command 20
CONTROLLING DEVICES USING CEC COMMANDS 21
Input Port CEC Commands 21
Output Port CEC Commands 22
NETWORK CONFIGURATION COMMANDS 23
USING THE BUILT-IN WEB INTERFACE 24
LOGIN PAGE 24
After Logging In 25
STATUS PAGE 25
VIDEO PAGE 25
INPUT PAGE 26
Input 26
Active 26
Name 26
HDCP 26
EDID 26
Load EDID to User Memory 26
Download EDID to your computer 26
OUTPUT PAGE 27
Output 27
Test Parameter 27
Pattern 27
Minutes 27
VKA 27
Cable 27
Name 27
Scaler Mode 27
Stream 28
TX HDCP 28
CEC PAGE 28

V1.0 5sy.uk
Input Control 28
Output Control 28
NETWORK PAGE 29
IP Setting 29
IP Mode 29
IP Address, Gateway and Subnet 29
Telnet Port and TCP Port 29
Web Login Setting 29
Set Network Defaults 29
Save 29
SYSTEM PAGE 30
CONTROL PAGE 30
SPECIFICATIONS 32
GENERAL 32
ENVIRONMENTAL 32
PHYSICAL 32
ORDERING PART NUMBERS 32
PACKING LIST 33
SAFETY INSTRUCTIONS 34
AFTER SALES SERVICE 34

sy.uk 6V1.0
The Xcalibur-44 and Xcalibur-88 are 4x4 and 8x8 HDMI 2.0 (18Gbps) Matrix, with mirrored HDMI
and HX outputs. 4/8 displays can be placed up to 150m @ 1080p or 120m @ 4K2K away, using
the Xcalibur-11 Receivers. These high quality matrix are feature rich with facilities such as Test
Pattern generator, 4K down-scaler options and much more.
Note: The Xcalibur units are not compatible with HDBaseT products.
Features
•HDMI 2.0 compatible – 18Gbps signal bandwidth
•Supports all PC and HDMI resolutions up to 4K60 4:4:4
•Mirrored HDMI and HX (cat6) outputs
•150m for 1080p or 120m for 4K, using single Cat5e, 6, 6a, 7
•Built-in Test Pattern feature with several pattern types and resolutions
•Video Keep-Alive (VKA) option prevents displays entering standby mode
•Down-Scaler – Each HDMI and HX outputs can independently scale 4K → 1080p
•HDCP 1.4 and HDCP 2.2 compliant
•HDCP and EDID management
•Supports HDR, HDR10, HDR10+, HLG and Dolby vision
•HDMI audio support up to 7.1 surround sound
•Audio de-embedding at the Matrix – Balanced analogue stereo (L/R) outputs
•Audio de-embedding at the Matrix – Digital audio coax outputs (5.1 channels max.)
•Audio de-embedding at the Receiver – Analogue stereo (L/R) output
•Selectable RS232 and IR routing to each output
•CEC control – Sources and displays can be controlled via CEC commands
•Control – Front panel, IR, RS232, or LAN
•Built-in web-based control interface
•PoC – All Receivers are powered directly by the matrix
Connectors and Controls
Front
Xcalibur-44 (SY-HX150-44-18G)
Xcalibur-88 (SY-HX150-88-18G)

V1.0 7sy.uk
Name
Description
Display Panel
Displays the current signal routing or menu options
Power LED
Green – Unit is powered and functional
Red – Unit is in standby mode
IR Sensor
IR control input sensor
Input Selection Buttons
Select the desired input channel
Output Selection Buttons
Select the desired output channel
Menu Button
Activates the menu options on the display panel
Up Button
Use to navigate up through the menu options
Power Button
Press and hold for 3 seconds to turn the unit ON / OFF
Enter Button
Accept the displayed menu option
Down Button
Use to navigate down through the menu options
Lock Button
Press and hold for 3 seconds to Lock / Unlock the front panel
Rear
Xcalibur-44 (SY-HX150-44-18G)
Xcalibur-88 (SY-HX150-88-18G)
Name
Description
IR IN
Input for IR signals to the Xcalibur Receiver units
IR OUT
IR signal outputs from the Xcalibur Receiver units
AUDIO OUT
RCA connectors – Digital S/PDIF coax audio outputs
5-way pluggable connectors – Differential stereo analogue audio (Balanced outputs)
LAN
RJ45 – TCP/IP control input allowing access to the built-in web interface
RS232
RS232 control port – Matrix control and RS232 comms with Receivers
Power Input
Mains power input and Switch (110-240Vrms)
OUT 1~4
Video output ports 1~4 – Mirrored HDMI and RJ45 to the Xcalibur-11 Receivers
OUT 5~8
Video output ports 5~8 – Mirrored HDMI and RJ45 to the Xcalibur-11 Receivers
INPUTS
HDMI 2.0 video input ports

sy.uk 8V1.0
Connecting to the Matrix
1. Connect the HDMI sources to the HDMI inputs
2. Connect the Xcalibur 11 receivers to the HX outputs
3. Connect HDMI display devices to the Xcalibur 11 receivers
4. If required, connect local HDMI displays to the HDMI outputs
5. Connect any other signals such as IR, audio or control inputs
6. Power up the matrix
RJ45 Wiring
Both connectors must be wired identically.
IMPORTANT: The signals used by this extender set will not pass through any Ethernet device.
The Matrix and Receivers provided in this set will only work with the Xcalibur product range.
Please make sure that the Cat6 cable uses 4 pairs of 23AWG solid copper wires. Do not use
inferior copper clad cables as these exhibit high resistances.
It is recommended for the HX cable run between the Transmitter and Receiver units to be
continuous cable run of either cat5e/6/6a. Cat6a cabling is preferred for best signal quality.
IR Connector Wiring
The following diagrams detail the IR Eye/Emitter wiring connections for the Xcalibur matrix and
the Xcalibur-11 Receivers.
Figure 1 - Xcalibur IR Eye
Figure 2 – Xcalibur IR Emitter
Figure 3 - IR Eye Connector Wiring
Figure 4 - IR Blaster Connector Wiring
The IR emitter (blaster) connector can be a 3.5mm mono style, in which case the entire sleeve
is the +ve signal. IR signals with a carrier frequency in the range of 25-60 KHz can pass through.

V1.0 9sy.uk
Using the Matrix Products
The following table lists the available ports for the two matrix models.
Model
Xcalibur 44
Xcalibur 88
HDMI Inputs
4
8
HX150 Outputs
4
8
HDMI Outputs
4
8
Digital Audio Outputs (Coax)
4
8
Analogue Audio Outputs
4
8
TCP/IP Ports
1
1
RS232 Ports
1
1
IR Inputs
4 + 1 ALL
8 + 1 ALL
IR Outputs
4 + 1 ALL
8 + 1 ALL
Using the Front Panel Controls
If the front display is blank, press any button to wake it up. All the following sections assume this
as the starting state. Pressing the MENU button while the display is blank, starts with the Select
EDID menu option.
Making Video Selections
To make video selections from the front panel:
1. Press the desired output number, which will now flash, then
2. Press the desired input number.
Normal Operating Mode
In this mode the front panel display (when not blank) shows the video routing assignments:
OUTPUT: 12345678
INPUT: 32568324
Selecting the Menu Options
Pressing the MENU button will cycle through the following options:
•If the unit is left alone for a few seconds, the menu will close and the unit will revert
back to its normal operating mode and the currently selected option is not updated.
•Use the UP / DOWN buttons to scroll through the above menu options.
•Use the ENTER button to confirm menu selections as described for each menu option
in the following sections.

sy.uk 10 V1.0
Select EDID Menu
The Select EDID menu provides the following options on the front panel display:
1080p 2.0 CH
1080p 5.1 CH
1080p 7.1CH
1080i 2.0 CH
1080i 5.1 CH
1080i 7.1CH
1080p 3D 2.0 CH
1080p 3D 5.1 CH
1080p 3D 7.1 CH
4K*2K 2.0 CH
4K*2K 5.1 CH
4K*2K 7.1 CH
4K*2K@60 420 2.0 CH
4K*2K@60 420 5.1 CH
4K*2K@60 420 7.1 CH
4K*2K@60 2.0 CH
4K*2K@60 5.1 CH
4K*2K@60 7.1 CH
4K@60 HDR 2.0 CH
4K@60 HDR 5.1 CH
4K@60 HDR 7.1 CH
User Define 1
User Define 2
Copy HDMI Out 1
Copy HDMI Out 2
Copy HDMI Out 3
Copy HDMI Out 4
Copy HDMI Out 5
Copy HDMI Out 6
Copy HDMI Out 7
Copy HDMI Out 8
Copy HX Out 1
Copy HX Out 2
Copy HX Out 3
Copy HX Out 4
Copy HX Out 5
Copy HX Out 6
Copy HX Out 7
Copy HX Out 8
The menu items shown in bold in the above table are only available on the Xcalibur 88.
Note: 4K@60 HDR 2.1/51/7.1 resolutions are with 4:2:0 YCbCr colour space setting.
The factory default EDID setting is 1080p 2.0 CH.
To select a new EDID:
1. Press the MENU button until Select EDID is displayed
2. Press the UP / DOWN buttons until the desired setting is displayed.
3. Press the ENTER button to accept the EDID selection.
4. Select the input number to copy the EDID setting to by using the UP / DOWN buttons.
5. Then press ENTER again to transfer the EDID setting to that input.
Select Baud
This menu option sets the baud rate for the RS232 control port only. The options are: 4800,
9600, 19200, 38400, 57600 and 115200. The factory default baud rate is 115200 (115.2 K).
1. Press the MENU button until Select Baud is displayed
2. Use the UP / DOWN buttons to select the desired baud rate.
3. Press ENTER to accept the new baud rate setting selection.
IP Settings
The IP settings menu is used to toggle the DHCP mode to be ON or OFF. Once the menu selection
is set, press ENTER to make it active. The factory default IP settings are:
DHCP = ON
IP = Will self-configure to the network settings.
Please note that the IP settings are not affected by a Factory Reset command.
1. Press the MENU button until the DHCP option is displayed
2. Use the UP / DOWN buttons to change the DHCP mode.
3. Press ENTER to accept the DHCP setting selection.
HDCP Settings
This menu option configures the HDCP mode for each output channel or for all output channels.
Use is as follows:
1. Press the MENU button until Select HDCP is displayed
2. Select either ON / OFF using the UP / DOWN buttons
3. Press ENTER
4. Select the desired output number or ALL output using the UP / DOWN buttons
5. Press ENTER to make the change active for that output

V1.0 11 sy.uk
Test Pattern Settings
This menu option enables or disables the Test Pattern for each output channel or for all output
channels. Use is as follows:
1. Press the MENU button until the Test Pattern is displayed.
2. Select either ON / OFF using the UP / DOWN buttons.
3. Press ENTER.
4. Select the desired output number or ALL output using the UP / DOWN buttons.
5. Press ENTER to make the change to the Test Pattern setting.
Power Button
The POWER button toggles the matrix switcher between normal operation and standby mode.
To do this, press and hold the POWER button for more than 3 seconds and then release.
Power LED Colour
Operating Mode
Green
Normal Operation
Red
Standby
Lock Button
Press the LOCK button for 3 seconds to Lock / Unlock the front panel buttons. When the front
panel is locked, only the POWER and LOCK buttons are functional. The Panel Lock / Unlock state
can be changed by using the LOCK button, sending RS232 or Web interface commands.
NOTE: The panel lock status is always remembered, even after a complete power down.
Pressing any button other than POWER or LOCK while the front panel is locked will cause the
“Panel Lock!” message to appear on the front panel display.
IR Remote Controllers
Xcalibur 44 IR Remote
The Xcalibur-44 Matrix can also be
controlled using the provided IR remote
controller:
The top left button on both the IR remote
controllers, toggles the matrix power state.
The numbered buttons in each Output group
directly selects the desired input for that
output. The left and right arrow buttons
cycle, with full wraparound, through the
HDMI input ports.
Figure 5 -
IR Remote for
Xcalibur 44

sy.uk 12 V1.0
Xcalibur 88 IR Remote
The Xcalibur-44 Matrix can also be controlled
using the provided IR remote controller:
The top left button on both the IR remote
controllers, toggles the matrix power state.
Button Sequence: Output → Input
The numbered buttons in the lower Output
section select the desired output channel, or
all outputs together.
The numbered buttons in the upper Input
section select the desired input for the chosen
output selected in the previous step. The left
and right arrow buttons cycle, with full
wraparound, through the HDMI input ports.
Figure 6 -
IR Remote for
Xcalibur 88
Default Settings
The following table lists the factory default settings for the matrix unit:
Feature
Factory Default Value
Power
On
Beep
On
ID
0
LCD on time
30 seconds
Panel Lock
Off
Command Baud Rate
115200, n, 8, 1
AV Routing
1-1, 2-2, 3-3, etc.
HDMI Stream
Enabled
HX Stream
Enabled
HDMI Scaler
Auto
HX Scaler
Auto
Input HDCP
On
HDMI Output HDCP
Bypass
HX Output HDCP
Bypass
VKA Mode
Off
VKA Timeout
0
Test Pattern
Chequerboard, 1080p60
EDID
1080p, Stereo Audio 2.0
IP Address
192.168.1.100
Gateway
192.168.1.1
Subnet Mask
255.255.255.0
IP Mode
DHCP

V1.0 13 sy.uk
IR Routing and Pass-Through
IR Inputs
The numbered IR IN connectors on the rear of the matrix units always go directly to the IR OUT
of the Xcalibur-11 receiver connected to the identically numbered HX output in a one-to-one
relationship. The IR IN ALL connector sends the IR data to all HX outputs simultaneously.
IR Outputs
The numbered IR outputs will follow with the video routing selections. The IR OUT ALL port sums
IR signals from all connected receivers. Take care when using this port to ensure that only one
Xcalibur Receiver is passing the IR signal to ensure proper output of that signal.
Coax Digital Audio Outputs
The coax digital audio outputs support any audio up to 5.1 channels. Any HDMI input with more
than 5.1 channels will have no sound at the digital audio output when routed to that output.
Analogue Audio Outputs
The differential analogue audio outputs only output the Front Left and Front Right channels
when the HDMI input audio has more than 2.0 channels.
RS232 Control Port Wiring
The RS232 control port 9-way DSUB connector uses transmit (TxD), receive (RxD) and Ground
only. The wiring of this connector is as follows:
Xcalibur Matrix DSUB Pin
PC DSUB Pin
2 (TxD)
3 (RxD)
3 (RxD)
2 (TxD)
5 (GND)
5 (GND)
RS232 Commands
All the following RS232 commands must be sent to the RS232 D-type connector on rear of the
Excalibur matrix units. The default RS232 settings are:
115200 baud, 8 data bits, no parity and one stop bit.
All commands are in lowercase and any spaces shown must always be included. Commands
should be sent as a single burst, as manual typing will often result no response being returned
or the error code E00 or E01.
Every command must end with an exclamation mark (!). Any carriage-return (0x0d) or line-feed
(0x0a) characters sent will be ignored by the device.
Every response message will terminate with a carriage-return and line-feed (0x0d 0x0a)
character sequence.
In the following tables, x, y and z represent parameter values that are presented in the
description of the respective command.

sy.uk 14 V1.0
System Commands
RS232 Command
Description
Response Example
s reboot!
Reboot the matrix switcher.
Reboot…(note 1)
s reset!
Restore the matrix unit to factory defaults.
Reset to factory defaults (note 1)
r fw version!
Get the installed firmware versions.
MCU BOOT: Vx.xx.xx
MCU APP: Vx.xx.xx
help!
List all available commands.
(note 2)
s power z!
Set the power state of the matrix,
z = 0 power off z = 1 power on
power on
r power!
Get the matrix power status
Power off
r type!
Get the matrix type
SY-HX150-44-18G
r status!
Get a report of the current status of the
matrix unit
(note 3)
r link in x!
Get the connection status for input x.
hdmi input 3: connect
r link out y!
Get the connection status for output y. Note
that both the HDMI and HX outputs are
reported on separate lines.
hdmi output 2: disconnect
hx output 2: connect
s beep z!
Set keypress buzzer sound.
z = 0 beep off z = 1 beep on
beep off
r beep!
Get the key beep mode current status.
beep on
s lock z!
Set the front panel lock status.
z = 0 unlock z = 1 lock
panel button lock on
r lock!
Get the current front panel lock status.
panel button lock off
s lcd on time z!
Set the dwell time that the front panel LCD
remains on.
z = 0 always off z = 1 always on
z = 2 15 seconds z = 3 30 seconds
z = 4 60 seconds
lcd on 30 seconds
r lcd on time!
Get the lcd on time.
lcd on always
s logo1 ******!
Set the product name displayed on the LCD to
the text in ******. The text is limited to a
maximum 16 characters
logo1:SY-HX150-44-18G
s baud rate xxx!
Set the baud rate for control commands
where xxx is the desired baud rate(note 4)
Baudrate: 115200
r baud rate!
Get the current baud rate for control
commands.
Baudrate: 115200
Notes:
1. The “s reboot!” and “s reset!” commands both respond with System initialising…
followed by several other messages.
2. The “help!” command lists all available commands present in the installed firmware
version. This list is too long to present as in this document, but each command is
detailed individually in its own section.
3. The “r status!” command returns a very detailed report of all the settings and current
configuration of the matrix unit.
4. For the “s baud rate xxx!” command, only the following baud rates values are valid for
xxx: 4800, 9600, 19200, 38400, 57600, and 115200.

V1.0 15 sy.uk
Video Routing
The following commands allow the making of video selections as well as discovering which input
is assigned to a specific output. Note that for any output y, both the HDMI and HX outputs always
show the same (mirrored) input HDMI source.
RS232 Command
Description
Response Example
s in x av out y!
Route input x video to the output y.
x = HDMI input number
y = Output number or 0 for all outputs.
input 2 -> output 3
r av out y!
Get the routing for output y
input 1 -> output 5
Presets
The four Preset memories can each store video signal routings for later recall. Any of these
preset stores can also be cleared at any time.
RS232 Command
Description
Response Example
s save preset z!
Save the current video routing to preset z,
where z = 1~4
save to preset 2
s recall preset z!
Set the video routing to settings in preset z,
where z = 1~4
recall from preset 1
s clear preset z!
Clear the video routing from preset z, where
z = 1~4
clear preset 1
r preset z!
Get the video routing information for preset
z, where z = 1~4
Depends on values stored in
preset z
Feedback Messages
The matrix units will also report the following events:
1. A video selection occurred either at the front panel, from an RS232 command, or from
the web interface.
2. When an input HDMI signal is detected.
3. When any HDMI or HX cable is connected or disconnected.
RS232 Output Message
Description
input x -> output y
A video selection occurred, where x is the input number and y is the
output number(s).
hdmi input x: connect
A new source was connected to HDMI input x
hdmi input x: sync
An HDMI signal was detected at HDMI input x
hdmi input x: disconnect
An HDMI signal was lost from HDMI input x
hdmi output y: connect
A cable was connected to HDMI output y
hdmi output y: disconnect
A cable was disconnected from HDMI output y
hx output y: connect
A cable was connected to HX output y
hx output y: disconnect
A cable was disconnected from HX output y
E00
Unrecognised command
E01
Incorrect parameter value

sy.uk 16 V1.0
Enabling or Disabling the Output Stream
The HDMI and HX output video stream can be enabled or disabled individually using the
following commands:
RS232 Command
Description
Response Example
s hdmi y stream z!
Enable / Disable the video stream for HDMI output y.
y = desired HDMI output port number
y = 0 for all HDMI outputs
z = 0 disable the HDMI output stream
z = 1 enable the HDMI output stream
enable hdmi output 2
stream
r hdmi y stream!
Get the video stream state for HDMI output y,
where:
y is the desired HDMI output port number or 0 for all
HDMI outputs.
disable hdmi output 5
stream
s hx y stream z!
Enable / disable the video stream for HX output y.
y = HX output port number
y = 0 for all HX outputs
z = 0 disable the HX output stream
z = 1 enable the HX output stream
enable hx output 2
stream
r hx y stream!
Get the data stream state for HX output y, where:
y is the desired HX output port number or 0 for all
HX outputs.
disable hx output 5
stream
Test Pattern Commands
These commands enable or disable the Test Pattern modes of the matrix outputs. Used for
diagnostics or VKA mode.
Both the HDMI and HX outputs will display the Test Pattern at the same time. These commands
also set the Test Pattern displayed when the Video Keep Alive (VKA) mode is activated.
RS232 Command
Function
Response Example
s out y tp pattern x
resolution z!
This command sets the desired Test Pattern and its
resolution.
Where, y is the output channel, x is the Test
Pattern and z is the resolution.
y = Output number
y = 0 All outputs
x = 0 Chequerboard x = 1 Red x = 2 Green
x = 3 Blue x = 4 Black x = 5 White
z = 0 1080p60 z = 1 4K30 z = 2 4K60
output 1 test pattern:
chequerboard,
resolution: 1080p60
r out y tp pattern!
Get the current Test Pattern settings for output y or
0 for all outputs
output 3 test pattern:
chequerboard,
resolution: 4K30
s out y test pattern
on!
Enable the Test Pattern for output y or 0 for all
outputs
output 5 test pattern: on
s out y test pattern
off!
Turn off the Test Pattern to output y or 0 for all
outputs
output 2 test pattern: off
r out y test pattern!
Set the Test Pattern status for output y or 0 for all
outputs
output 3 test pattern: off

V1.0 17 sy.uk
Video Keep-Alive Commands
Whenever the Video Keep-Alive (VKA) feature is enabled for an output, that output will display
a Test Pattern when the input HDMI signal assigned to that output is lost. This will keep devices
such as projectors active, stopping them from going into standby mode. When a valid input
signal assigned to the output is detected, or VKA time-out, then VKA is stopped.
The VKA mode can be set to time out after several minutes or remain on indefinitely. The VKA
Test Pattern is displayed on both the HDMI and HX outputs for that output port.
For the following commands y is the desired output (or 0 for All Outputs).
RS232 Command
Description
Response Example
s out y vka time z!
Set the time, in minutes, after which the VKA
mode is automatically disabled, for output y.
Where z is a value in the range of 0 to 240.
Note: a value of 0 or greater than 240 will set
the VKA mode to never time out.
video keep-alive timeout:
100 minutes
r out y vka time!
Get the current maximum timeout value.
ouptut 2 video keep-alive
timeout: 100 minutes
s out y vka mode x!
Set the VKA mode:
x = 0 VKA mode off
x = 1 VKA mode on
output 3 video keep-alive on
r out y vka mode!
Get the current state of the VKA mode.
output 1 video keep-alive off
Down-scaler Mode
The HDMI and HX output can be independently set to down-scale any 4K input video to 1080p
at the same refresh rate. The Auto Down-scaler option will use the EDID of the display to
determine the scaling mode.
RS232 Command
Description
Response Example
s hdmi y scaler
mode z!
Set the HDMI output down-scaler.
y = HDMI output number
y = 0 All HDMI outputs
z = 1 Bypass – No scaling
z = 2 4K → 1080p
z = 3 Auto, use display EDID for scaling
hdmi output 1 set to bypass
mode
r hdmi y scaler
mode!
Get the current status of the output
downscaler mode for HDMI output y.
hdmi output 3 set to 1080p
s hx y scaler mode
z!
Set the HX output down-scaler.
y = HX output number
y = 0 All HX outputs
z = 1 Bypass – No scaling
z = 2 4K → 1080p
z = 3 Auto, use display EDID for scaling
hx output 1 set to auto
r hx y scaler mode!
Get the current status of the output down-
scaler mode for HX output y.
hx output 2 set to bypass
mode

sy.uk 18 V1.0
HDCP Options
The following commands control the HDCP options for the inputs and outputs. Note that the
HDMI and HX outputs are controlled separately for the same output port number.
RS232 Command
Description
Response Example
s input x hdcp z!
Enable / disable the HDCP for the HDMI inputs
x = HDMI input number
x = 0 All HDMI inputs
z = 0 off z = 1 on
Input 2 HDCP:ON
r input x hdcp!
Get the current status of the input HDCP for
input x, or 0 for all inputs
Input 4 HDCP:OFF
s hdmi y hdcp z!
Set the HDCP mode for the HDMI outputs.
y = HDMI output number
y = 0 All HDMI outputs
z = 0 Cascade mode z = 1 HDCP 1.4
z = 2 HDCP 2.2 z = 3 Bypass mode
hdmi output 3
hdcp:CASCADE
r hdmi y hdcp!
Get the current status HDCP mode for the
HDMI output of the receiver,
hdmi output 1:HDCP 1.4
s hx y hdcp z!
Set the HDCP mode for the HX outputs.
y = HX output number
y = 0 All HX outputs
z = 0 Cascade mode z = 1 HDCP 1.4
z = 2 HDCP 2.2 z = 3 Bypass mode
hx output 1:HDCP 1.4
r hx y hdcp!
Get the current status HDCP mode for the HX
output y
hx output 1:HDCP 1.4
EDID Control
These matrix products provide several EDID management commands to ensure that the source
is able to provide the correct image resolution to the display device.
RS232 Command
Description
Response Example
s edid in x from z!
Set HDMI input x to use one of the built-in
EDID settings. The z value is given in the tables
below.
Input 2 EDID:1080p, Stereo
Audio 2.0
r edid in x!
Get the current EDID setting for HDMI input x
Input 1 EDID: 4K2K_444,
Dolby/DTS 5.1
r edid data hdmi y!
Get the EDID data from HDMI output y
See below
r edid data hx y!
Get the EDID data from HX output y
See below
For all EDID commands that either require or return EDID data, the EDID data is always given as
pairs of ASCII characters representing the hexadecimal data, for example, where … represent
the remainder of the EDID data:
s edid user1 00 FF FF FF FF FF FF 00 …!
The <edid data> marker shown in the above table is where the actual EDID, as shown in the
above example, should be placed.
The “r edid data!”, “r edid data hdmi x!” and “r edid user1!” all return their respective EDID
data values as ASCII encoded hexadecimal values.
Note: 4K@60 HDR 2.1/51/7.1 resolutions are with 4:2:0 YCbCr colour space setting.

V1.0 19 sy.uk
z Value
HDMI Resolution (max)
Audio Format
Audio Channels
1
1080p
Stereo Audio
2.0
2
1080p
Dolby/DTS
5.1
3
1080p
HD Audio
7.1
4
1080i
Stereo Audio
2.0
5
1080i
Dolby/DTS
5.1
6
1080i
HD Audio
7.1
7
1080p 3D
Stereo Audio
2.0
8
1080p 3D
Dolby/DTS
5.1
9
1080p 3D
HD Audio
7.1
10
4K2K 30Hz 4:4:4
Stereo Audio
2.0
11
4K2K 30Hz 4:4:4
Dolby/DTS
5.1
12
4K2K 30Hz 4:4:4
HD Audio
7.1
13
4K2K 60Hz 4:2:0
Stereo Audio
2.0
14
4K2K 60Hz 4:2:0
Dolby/DTS
5.1
15
4K2K 60Hz 4:2:0
HD Audio
7.1
16
4K2K 60Hz 4:4:4
Stereo Audio
2.0
17
4K2K 60Hz 4:4:4
Dolby/DTS
5.1
18
4K2K 60Hz 4:4:4
HD Audio
7.1
19
4K2K 60Hz 4:4:4 HDR
Stereo Audio
2.0
20
4K2K 60Hz 4:4:4 HDR
Dolby/DTS
5.1
21
4K2K 60Hz 4:4:4 HDR
HD Audio
7.1
The next table allows for reading the EDID data from the connected display devices or enabling
the programmable User EDID memory location when using the “s edid in from z!” command.
z Value
Xcalibur 44
Xcalibur 88
22
User EDID data stored in User1 location
User EDID data stored in User1 location
23
User EDID data stored in User2 location
User EDID data stored in User2 location
24
Copy EDID from HDMI 1 output
Copy EDID from HDMI 1 output
25
Copy EDID from HDMI 2 output
Copy EDID from HDMI 2 output
26
Copy EDID from HDMI 3 output
Copy EDID from HDMI 3 output
27
Copy EDID from HDMI 4 output
Copy EDID from HDMI 4 output
28
Copy EDID from HX 1 output
Copy EDID from HDMI 5 output
29
Copy EDID from HX 2 output
Copy EDID from HDMI 6 output
30
Copy EDID from HX 3 output
Copy EDID from HDMI 7 output
31
Copy EDID from HX 4 output
Copy EDID from HDMI 8 output
32
—
Copy EDID from HX 1 output
33
—
Copy EDID from HX 2 output
34
—
Copy EDID from HX 3 output
35
—
Copy EDID from HX 4 output
36
—
Copy EDID from HX 5 output
37
—
Copy EDID from HX 6 output
38
—
Copy EDID from HX 7 output
39
—
Copy EDID from HX 8 output

sy.uk 20 V1.0
Sending RS232 Commands to HX Receivers
The matrix units are able to send RS232 commands from the HX outputs to the connected
Xcalibur-11 Receivers Using the control RS232 port as well as the Web interface. The HX ports
can be individually selected or the RS232 command can be sent to all the HX outputs.
RS232 Command
Description
Response Example
s rs232 y a
b:****END!
Send an RS232 command to the HX output port
y at the specified baud rate.
y = HX Output number
y = 0 All HX outputs
a = 0 ASCII Format
a = 1 Hexadecimal Format
b is baud rate from one of the following:
b = 1 115200 b = 2 57600 baud
b = 3 38400 b = 4 19200 baud
b = 5 9600 b = 6 4800 baud
b = 7 2400
**** is the actual command transmitted to the
HX Receiver, this must be 80 characters or less.
END! marks the end of the command and is
required
Hx baud rate is 9600, ascii
format command:****
Sending an ASCII Command
The following example shows how the ASCII command POWR=ON<cr> is sent from HX output 3
using a baud rate 19200:
s rs232 3 0 4:POWR=ON
END!
Note: the above example is two lines and that the <cr> (represented by the  character) is
entered by using the Enter on the PC keyboard.
Everything between the colon (:) and the END! marker, are sent exactly as entered and character
the case will not be altered.
Sending an Hexadecimal Command
There are occasions where certain ASCII control characters are not immediately available from
the PC keyboard, this is where hexadecimal notation is used. The following example is for a
display power on command, this time sent to HX port 1 at 9600 baud:
s rs232 1 1 5:99A2B3C402FF0100END!
This example shows several values that are not easily accessible as a single character from a PC
keyboard and need to use hexadecimal notation. All the values between the colon (:) and the
END! marker are converted to the correct binary values before being sent to the HX output port.
