Sylvania ROADSIGHT PLUS User manual

ROA D S I GHTPLUS
Dash Camera
Caméra-témoin de circulation
Cámara Delantera

1
The Dash Cam must not be fitted in a position which obscures the driver’s view of the road ahead.
Depending on the country of use, recordings made with this device may be subject to Data
Protection Laws. Ensure these are complied with. If the dash cam is to be used in a commercial
environment e.g. taxi or truck, then CCTV Regulations may apply. Playback of video which is
visible to the driver while the vehicle is in motion is prohibited in some countries. Only use the
supplied power adapter, otherwise damage may occur to the dash cam. Take care when cleaning
the dash cam lens and only use a suitable lens cleaner and a soft cloth. Do NOT expose this
product to rain, moisture or water under any circumstances; doing so may result in the risk of
electric shock or fire. Do NOT perform servicing other than that contained in the instruction
manual, unless you are qualified to do so. When installing in a vehicle, always place the device
securely against the windscreen and where possible conceal the power cable under the vehicles
interior trim. Make sure that the power cable doesn’t interfere with the driver’s controls such as the
steering wheel, pedals or gear lever. Do NOT mount the dash cam in front of an airbag
deployment area or in a position to obscure any interior mirrors. Do NOT operate while driving and
only adjust settings or review recordings while not driving.
WARNING

If you haven’t already downloaded the app, do so now to
get the most from your dash camera.
1 Download the app by searching for SYLVANIA
CONNECT in the App Store (iPhone) or Google
Play (Android).
2 Open the app, follow the setup process shown
and enable all necessary settings when prompted.
BEFORE YOU BEGIN

RECORDING GRABANDO NOUS ENREGISTRONS
LOREM IPSUM
1 Dash Cam
2 Quick Start Guide
3 Magnetic Mount
4 USB Charging Cable
5 Trim Removal Tool
6 Window Sticker
PACKAGE CONTENTS

ATTENTION! Choose the installation location in advance, as the adhesive tape on
the mount is of single use.
1 Ensure glass is dirt, dust and grease free.
2 Warm adhesive pad part of mount in hands to ensure strong adhesion to glass.
3 Once mount has been positioned connect dash camera to the magnetic mount.

To power the device and charge the battery, use only the power adapter included. Connect the
power cable to the mount, and then plug the USB charger into the vehicles 12v power socket.
When the vehicle’s engine starts, the device turns on automatically.

ADJUSTING VIEWING ANGLE
ATTENTION! Adjusting the viewing angle can only be done along the vertical axis, so
be sure to position the device correctly on the windshield along the horizontal axis as
close as possible to the windshield’s center.
While pulling or pushing the device in the holder, ensure that the camera captures the
image in proportions of 30% sky / 70% road.
GOOD BAD

CONNECTING TO MOBILE
1 Hold down power button to
switch on dash camera.
2 Press UP arrow for 3 seconds
to open Wi-Fi hotspot details
screen.
3 Open your phone’s Settings.
4 Tap on Wi-Fi or Connections.
5 Select the dash camera
hotspot and enter the
password that is displayed on
the dash camera.
6 You are now connected to
your device.
Wi-Fi
Wi-Fi
CHOOSE A NETWORK...
Settings
SAMPLE_NETWORK i
DashcamPlus i
SAMPLE_NETWORK i
SAMPLE_NETWORK i
SAMPLE_NETWORK i
SAMPLE_NETWORK i
Other...

CONFIGURATION
Power Button: Press to turn the device on. Press and hold to turn the device off.
Menu Button: Use this button to switch between the video, photo and playback.
Press this button during recording to take picture.
Up Button: Press to move up the menu. In the VIDEO and PHOTO mode, press
and hold to zoom in; in Playback mode, use to select a file.
Down Button: Press to move down the menu. In the VIDEO and PHOTO mode,
press and hold to delete the image (if you used zoom + before); in the Playback
mode, press to select a file.
Rec Button: Press to start/stop recording. When in the menu, use to confirm the
selected menu item.
Reset Button (on bottom of camera):Press to reboot, if no other button responds.

PHOTO MODE
Stop recording and then press and hold Menu button for 2 seconds to
enter Photo Mode. Press Rec to capture image.
PLAYBACK MODE
When in Photo Mode press and hold the Menu button for 2 seconds to
enter Playback Mode. Press the Up and Down button to choose video
playback or image viewer. Press Ok button to play selected video.
Press and hold the Menu button for 2 seconds to exit Playback Mode.
MENU OPTIONS
Stop recording then press Menu key once to enter Menu options and
using Up and Down button to set the options, press Rec to confirm.

1 Before installing a memory card, make
sure the device is turned off.
2 Insert the memory card until it clicks into
place.
3 Removing a card: press the card slightly
and then remove it from the slot.
INSTALLING microSD CARD
WARNING! Do not apply excessive force when inserting a memory card to avoid
damage to the device. If necessary, use a thin pointed device to push the card
further. To remove the memory card, push the card until it clicks and remove the
card from the slot.

TURNING ON / OFF
•When the vehicle ignition is turned ON
the dash cam turns on automatically.
•To turn the device on manually, press
the power button.
•To turn the device off press and hold the
power button for approx. 3 seconds.

1 Insert the microSD card into the
memory card slot; the Loop
Recording mode is set to 3 minutes
as default.
2 When the memory card storage is
full, the device will automatically
replace the oldest video file with the
newest one; exception is the files
protected from deletion.
LOOP RECORDING
Loop Recording Image 2

EMERGENCY RECORDING
1 Emergency recording is to protect the
current video file from being overwritten
and deleted.
2 Emergency recording is activated
automatically when the G-sensor
triggers (sudden acceleration /
deceleration), or at point of collision.
Emergency recording is locked
automatically to avoid erasing during
loop recording.

1 Playback (ensure dash cam recording
has stopped).
•In the standby mode, press and
hold the MENU button to switch
between Video & Photo.
2 Video & Photo Mode.
• Select the file to view using the
Up / Down and Confirm buttons.
•Using the Up / Down buttons,
select the file you need to view
and click the Confirm button to
start playback.
RECORDING PLAYBACK

DELETE FILES
1 Press the Menu button to enter the
submenu (ensure dash cam recording
has stopped).
2 Use the Up / Down buttons to select
Delete and press the Rec button.
3 Select the option to delete all files/one
file, then confirm your choice by
following the instructions on the display.
ATTENTION! Locked files can only be
deleted when unlocked; to unlock them, use
the Lock item of the submenu in the Playback
mode. Another way to delete locked files is to
format the memory card all data from memory
card will be deleted!
WARNING! Deleted files cannot be
restored. Backup necessary files before
proceeding with deletion.

GENERAL SETTINGS
To access General Settings, press the
Menu Button once from the Home screen.
Video Resolution: Select required option
(the highest option provides the optimum
viewing performance).
Loop Recording: 3 or 5 minutes
G-Sensor: OFF / LOW / MEDIUM / HIGH
Night Vision: OFF / ON / AUTO
Recording Audio: OFF / ON
Date Stamp: OFF / ON

ADVANCED SETTINGS
To access Advanced Settings, press the
Menu Button twice from the Home screen.
WiFi: OFF / ON
Date / Time: Adjust for correct Date and Time.
Language: Select the preferred menu
language from the list.
Plate Number: OFF / ON
Screen Saver: OFF / ON
Button Sound: OFF / ON
Parking Monitor: OFF / ON

ADVANCED SETTINGS
Card Formatting: Before using camera,
format SD card for optimal performance.
Version: Shows installed firmware version,
and where to get updates.
Default Settings: Reset the camera to its
original configuration.

LICENSE PLATE
When choosing ON, you will be
prompted to enter in your license plate
number. The license plate number will
display on your recording.
