Symcode BROCHURE User manual

2D Desktop Barcode Scanner
User Manual

Contents
I
2D Desktop Barcode Scanner
Electrical Parameters............................................................................................ 2
Physical Parameter.............................................................................................. 2
Environment.......................................................................................................... 2
Factory Default Setting..........................................................................................4
Decode Ability........................................................................................................ 2
Depth of Scan......................................................................................................... 2
Appearance............................................................................................................ 3
3rd Chapter :Parameters......................................................................... 2
1st Chapter:Introduction......................................................................... 1
2nd Chapter: Product Features............................................................... 1
5rd Chapter:Input/Output Settings........................................................ 6
Introduction........................................................................................................... 4
RS232...................................................................................................................... 4
RS232 Baud Rate....................................................................................................4
RS232 ：Data Bits,Stop Bits,Parity......................................................................5
USB..........................................................................................................................6
USB HID .................................................................................................................6
USB COM................................................................................................................6
Introduction.......................................................................................................... 6
Buzzer Setting when Electrifyin........................................................................... 6
Buzzer Setting when Decode successfully.......................................................... 7
Buzzer ON or OFF Setting................................................................................ 7
Volume Settings............................................................................................... 7
Frequency Settings.......................................................................................... 7
Beep Status Setting after Decoding Successfully......................................... 7
Output Delayed................................................................................................ 8
Lighting Setting.................................................................................................... 8
Standby Setting................................................................................................... 8
4nd Chapter: Interfaces........................................................................... 4
Prefix/Suffix Settings............................................................................................. 9
Ending Character Settings.................................................................................. 10
6th Chapter:Data Editing..........................................................................9
Keyboard Operation............................................................................................ 10
Function Code Transmission Setting................................................................. 10
Data Transmission Delayed................................................................................ 10

II
2D Desktop Barcode Scanner
All Code Types..........................................................................................................11
Decode Length Settings...........................................................................................11
1D Code types...........................................................................................................11
2D Code Types..........................................................................................................11
Codabar.....................................................................................................................12
Enable/Disable......................................................................................................12
Start/Stop Bit.........................................................................................................12
Check Bit................................................................................................................12
Cascade..................................................................................................................12
Decode Lenth Setting............................................................................................13
Code 39 .....................................................................................................................13
Enable/Disable.......................................................................................................13
Start/Stop Bit.........................................................................................................13
Check Bit................................................................................................................13
Decode Length Setting..........................................................................................14
Code 32 Pharmaceutical (PARAF) ...........................................................................14
Enable/Disable........................................................................................................14
Interleaved 2 of 5.......................................................................................................14
Enable/Disable.......................................................................................................14
Check Bit.................................................................................................................14
Decode Length Setting...........................................................................................15
NEC 2of5 ....................................................................................................................15
Enable/Disable........................................................................................................15
Check Bit..................................................................................................................15
Decode Length Setting...........................................................................................15
Code 93 .....................................................................................................................16
Enable/Disable.......................................................................................................16
Decode Length Setting..........................................................................................16
Straight 2 of 5 Industrial (three-bar start/stop)......................................................16
Enable/Disable.......................................................................................................16
Decode Length Setting..........................................................................................16
Straight 2 of 5 IATA (two-bar start/stop).................................................................17
Enable/Disable......................................................................................................17
Decode Length Setting.........................................................................................17
Matrix 2 of 5...............................................................................................................17
Enable/Disable......................................................................................................17
Decode Length Setting .........................................................................................17
Code 11......................................................................................................................18
7th Chapter:Code Types............................................................................ 11

III
2D Desktop Barcode Scanner
Enable/Disable.....................................................................................................18
Check Bits.............................................................................................................18
Decode Length Setting.........................................................................................18
Code 128 ..................................................................................................................18
Enable/Disable......................................................................................................18
ISBT 128 Cascade..................................................................................................19
Decode Length Setting.........................................................................................19
UPC-A........................................................................................................................19
Enable/Disable......................................................................................................19
Check Bits..............................................................................................................19
Digital System.......................................................................................................19
Supplementals......................................................................................................20
Necessary Supplementals....................................................................................20
Supplementals Separator....................................................................................20
GS1-128.....................................................................................................................20
Enable/Disable......................................................................................................20
Decode Length Setting.........................................................................................21
UPC-E0......................................................................................................................21
Enable/Disable......................................................................................................21
Barcode Expand...................................................................................................21
Necessary Supplementals...................................................................................21
Supplementals Separator....................................................................................21
Check Bits..............................................................................................................22
Digital System.......................................................................................................22
Supplementals......................................................................................................22
UPC-E1......................................................................................................................22
EAN/JAN-13...............................................................................................................23
Enable/Disable......................................................................................................23
Check Bits..............................................................................................................23
Supplementals.....................................................................................................23
Necessary Supplementals...................................................................................24
Supplementals Separator....................................................................................24
ISBN Translate.........................................................................................................24
EAN/JAN-8.................................................................................................................24
Enable/Disable......................................................................................................24
Check Bits..............................................................................................................24
Supplementals......................................................................................................25
Necessary Supplementals....................................................................................25
Supplementals Separator....................................................................................25

IV
2D Desktop Barcode Scanner
MSI............................................................................................................................25
Enable/Disable.....................................................................................................25
Check Bits.............................................................................................................26
Decode Length Settings.......................................................................................26
GS1 DataBar Omnidirectional................................................................................26
Enable/Disable.....................................................................................................26
GS1 DataBar Limited...............................................................................................26
Enable/Disable.....................................................................................................26
GS1 DataBar Expanded ..........................................................................................27
Enable/Disable.....................................................................................................27
Decode Length Settings.....................................................................................27
PDF417.....................................................................................................................27
Enable/Disable.....................................................................................................27
Decode Length Settings......................................................................................27
QRC ODE .................................................................................................................28
Enable/Disable.....................................................................................................28
Decode Length Settings......................................................................................28
Data Matrix..............................................................................................................28
Enable/Disable.....................................................................................................28
Decode Length Settings......................................................................................28
Aztec Code ..............................................................................................................29
Enable/Disable.....................................................................................................29
Decode Length Settings.......................................................................................29
China Post (Hong Kong 2 of 5)................................................................................29
Enable/Disable....................................................................................................29
Decode Length Settings......................................................................................30
Korea Post................................................................................................................30
Enable/Disable.....................................................................................................30
Decode Length Settings.......................................................................................30
Check Bits.............................................................................................................30
Han Xin code ...........................................................................................................31
Enable/Disable.....................................................................................................31
Decode Length Settings......................................................................................31
Maxi code.................................................................................................................31
Enable/Disable.....................................................................................................31
Decode Length Settings......................................................................................31
M ICROPDF ........................................................................................... ..................32
Enable/Disable.....................................................................................................32
Decode Length Settings......................................................................................32

V
2D Desktop Barcode Scanner
Software Version Display.....................................................................................34
Image Mirror.........................................................................................................34
Code Reverse........................................................................................................34
Safe Mode.............................................................................................................34
QR Code Website Setting.....................................................................................34
Code ID Prefix.......................................................................................................34
Keyboard Language Settings..............................................................................35
USA....................................................................................................................35
FINLAND............................................................................................................35
SPAIN.................................................................................................................35
FRANCE.............................................................................................................35
GERMANY..........................................................................................................35
ITALY.................................................................................................................35
DENMARK..........................................................................................................35
NORWAY............................................................................................................35
ICELAND.............................................................................................................35
CZECH...............................................................................................................35
HUNGARY..........................................................................................................35
SWEDEN............................................................................................................35
ARAB..................................................................................................................35
RUSSIA..............................................................................................................35
SWITZERLAND_FRENCH..................................................................................35
SLOVENIA..........................................................................................................35
CROATIA............................................................................................................36
ALBANIA............................................................................................................36
SERBIA_LATIN..................................................................................................36
SERBIA_CYRILLIC.............................................................................................36
CZECH_QWERTZ..............................................................................................36
8th Chapter: Other Function Settings......................................................34
GS1 Composite Codes...........................................................................................32
Enable/Disable...................................................................................................32
Decode Length Settings....................................................................................32
Codablock A...........................................................................................................33
Enable/Disable...................................................................................................33
Decode Length Settings....................................................................................33
Codablock F...........................................................................................................33
Enable/Disable...................................................................................................33
Decode Length Settings.....................................................................................33

VI
2D Desktop Barcode Scanner
Appendix 1：Code Types ID Table....................................................................39
Code Type ID Table...............................................................................40
Postal Code............................................................................................40
Appendix 2：ASCI I Transform...........................................................................41
Appendix 3：Special Setting Codes..................................................................44
Appendix 4：ASCII Transform In Keyboard Operation....................................45
9th Chapter:FAQ & Solutions.................................................................38
10th Chapter:Equipment Maintanence................................................38
CZECH_QWERTY...............................................................................................36
DUTCH...............................................................................................................36
ESTONIA............................................................................................................36
LITHUANIA.........................................................................................................36
IRISH..................................................................................................................36
FAEROESE.........................................................................................................36
TURKEY_F..........................................................................................................36
TURKEY_Q..........................................................................................................36
JAPAN_ASCII......................................................................................................36
Chinese Keyboard Setting...................................................................................37
Chinese Output Format.......................................................................................37
Case Switch..........................................................................................................37

1st Chapter:Introduction
2nd Chapter:Product Features
This user manual are applied for our 2D desktop barcode scanner which based
on 2D image scanning to identify 1D and 2D barcodes. They apply a complete set
of newly developed patented technologies and have strong recognition performance.
Support automatic continuous scanning mode, fast and flexible.
This chapter will introduce the method of using the product step by step with
the picture. Please compare the actual product you have purchased when reading the
document, so that it is more conducive to your understanding of this document.
This chapter is applicable to ordinary users, maintenance personnel and software
developers.
1
2D Desktop Barcode Scanner
* Research and development independently, with a full set of patents,
plug and play without installing drivers.
*The wide voltage design avoids the situation that data transmission
cannot be uploaded due to voltage fluctuations.
*The 32-bit main control chip is equipped with patented software, which
can smoothly interpret reflective, wrinkled, blurred, and colored barcodes,
and can also decode normally in strong light and dark light environments.
*Support RS232, USB, USB-COM, multiple interfaces to ensure
compatibility with your existing and future terminals.
*Smooth and coordinated appearance can reduce user fatigue, make the
operation extremely comfortable, and improve work efficiency significantly

3rd Chapter:Parameters
2
2D Desktop Barcode Scanner
Physical Characteristics
Dimensions：152mm x 152.5mm x81.5mm Power Voltage：5V
Weight：550g Curent of Power ON：380mA
Stanby Current：：190mA Working Current：240mA
Performance Characteristics
Light Source：Warm Yellow LED Interfaces Supported：USB，USB-COM, RS232
Image (Pixels)：1024 pixels (H)x 1280 pixels (V) Roll / Pitch / Yaw：360°, ±65° , ±65°
User Environment
Symbology Decode Capability
Decode Ranges
Operating Temperature：-20°C to 60°C
Storage Temperature：-30°C to 70°C
Humidity：5% to 95% relative hum idity,non-condensing
Ambient Light：It will not affect the normal office and factory lighting environment or direct
exposure to sunlight
Drop Test: Can withstand the impact of multiple drops from a height of 0.7 meters to
mixed ground
Electrostatic Discharge: Meet the requirements of 15kV air discharge and 8kV contact discharge
1-D: Codabar, Code 11, Code 39, Code 93, Code 128/EAN128, EAN.UCC Composite,
Interleaved 2 of 5,MSI Code, Planet, Plessey Code, Postnet, RSS,
Standard 2 of 5, Telepen, UPC/EAN, etc.
Code39(5mil)：0mm-120mm Code39(13mil)：0mm-240mm
UPC-A(13mil)：1-17cm QR(20mil)：0-13cm
QR(20mil)：0mm-210mm
*Min distance of scanning depend of scan angle and code length
*Payment code of Alipay and Wechat depeng on the phone brightness
2-D: PDF417, QR code, Matrix 2 of 5, MicroPDF417, Australian Post, Canada Post,
Japan Post, MaxiCode, Codablock, Aztec, Dutch Post, TLC 39,DataMatrix, etc.

3
2D Desktop Barcode Scanner
Appearance
Scan Window
Buzzer
Scan Button
RJ-45 Interface
Scanner Port

4
2D Desktop Barcode Scanner
(800006.)
(8810010.)
(8310030.)
300
(8310031.)
600
(8310032.)
1200
(8310033.)
2400
(8310034.)
4800
(8310035.)
9600
Factory Default Setting
If you want to apply the factory default settings to the barcode scanner, scanning
following setting code,the "Factory Default Setting" barcode.
Factory Default Setting
RS232
Introduction
4nd Chapter: Interfaces
Introducing USB and RS232 interfaces and their related configurations in this chapter.
RS232
Scanning setting code“RS232”barcode to connect with host via serial.
Serial interface default configuration:Baud Rate: 115200; Data Bit: 8; Parity Bit: none;
Stop Bit: 1, Ending Character: CR+LF
RS232 Baud Rater
Baud rate: Send data from the barcode scanner to the terminal at the specified rate.
The terminal must be set to the same baud rate as the barcode scanner to
communicate normally. Default=115200

5
2D Desktop Barcode Scanner
(8310036.)
19200
(8310038.)
57,600
(8310037.)
38400
(8310039.)
*115,200
(8310063.)
(8310060.)
(8310066.)
(8310064.)
(8310061.)
(8310067.)
(8310065.)
(8310062.)
RS232 ：Data Bits,Stop Bits,Parity
Data Bits:7, Stop Bits:1, Even Parity Data Bits:7, Stop Bits:1, Parity:None
Data Bits:7, Stop Bits:1, Odd Parity Data Bits:7, Stop Bits:2, Even Parity
Data Bits:7, Stop Bits:2, Parity:None Data Bits:7, Stop Bits:2, Odd Parity
Data Bits:8, Stop Bits:2, Even Parity
Data Bits:8, Stop Bits:1, Odd Parity
* Data Bits:8, Stop Bits:1, Parity:None
(8310068.)

6
2D Desktop Barcode Scanner
(881001124. )
USB HID
USB COM
(881001133.)
Note: No additional configuration is required（E.g.:Baud Rate)
USB
USB HID
Scan the following bar code to configure the bar code scanner to USB HID Keyboard
mode. CR and LF are added by default
USB COM
Scan following barcode to configure the bar code scanner to USB-COM mode,and
emulate the conventional COM port which is based on RS232. If your host are used
Microsoft Windows system, you need to download the driver. If your host are used
Apple Macintosh system, the computer will recognize the barcode scanner as a
USBCDC device automatically.
Introduction
5rd Chapter:Input/Output Settings
Introduce the configuration of the buzzer and LED when the barcode
scanner is electrified, decoded, and pressed.
Buzzer Setting when Electrifying
Scan following setting codes to choose buzzer on or off of when barcode
scanner get electrified.Default setting is buzzer ON.
（8410130.）
Buzzer OFF * Buzzer ON
(8410131.)

7
2D Desktop Barcode Scanner
(8410010.)
(8410011.)
(8410091.)
(8410092.)
(8410093.)
(8410090.)
Buzzer Setting when Decode successfully
Buzzer ON or OFF Setting
Scan following setting codes to choose buzzer on or off of when decode successfully.
Default setting is buzzer on.
Volume Settings
Scan the following setting code to choose the volume of buzzer of when decode
successfully.Default setting is high.
Frequency Settings
Scan the following setting codes to choose the buzzer frequency of when decode
successfully.Default setting is middle
Buzzer OFF
Low Middle
*High
Low( 1600 Hz) * Middle( 2400 Hz) High(4200 Hz)
OFF
*Buzzer ON
(8410061600.)
(8410064200.)
(8410020.)
(8410021.)
Beep Status Setting after Decoding Successfully
Scan following setting code to choose normal beep or short beep of when decode
successfully.Default setting is normal beep.
* Normal Beep Short Beep
(8410062400.）

8
2D Desktop Barcode Scanner
5s（Default） 1Minutes
3Minutes 5Minutes
Never Standby
Standby Setting
ON OFF
Lighting Setting
(8980051.) (8980050.)
(8510060.)
(851006750.)
No Delay
(851006350.)
(350 ms)
( 750 ms) ( 1, 000 ms)
(8510061000.)
Output Delayed
Scan following setting codes to choose time interval between 1st scanning and
next scanning. Default time interval is 750ms.

9
2D Desktop Barcode Scanner
6th Chapter:Data Editing
Prefix/Suffix Settings
Note:Add up to 10 characters as prefix and suffix to each barcode
1:Add customize prefix or suffix to all code types.
E.g.1:Add XYZ as prefix or suffix:
Step 1:Checking Appendix 1: the HEX value of all code is 99.
Step 2:Checking Appendix 2: the HEX value of X Y Z are 58,59,5A.
Step 3:Scanning setting code“Add Prefix”or “Add Suffix”in page 16.
Step 4:Find the setting codes corresponding to 9, 9, 5, 8, 5, 9, 5, A in Appendix 3 and scan them
one by one
Step 5:Scanning setting code“Save”in page 17.
Note:If an error occurs while scanning the setup code in Appendix 3,scan setting code
"Abandon", and repeat step 3.
2:Add customize prefix or suffix for a specific code type.
E.g.2:Add Q as prefix for QR code.
Step 1:Checking Appendix 1:the HEX value of QR code is 73
Step 2:Checking Appendix 2:the HEX value of Q is 51
Step 3:Scanning setting code“Add Prefix”or “Add Suffix”in page 16.
Step 4:Find setting codes corresponding to 7, 3, 5,1 in Appendix 3 and scan them one by one
Step 5:Scanning setting code“Save”in page 17.
3:Cancel customize prefix or suffix for a specific code type
E.g.3:Cancel customize prefix or suffix for QR code.
Step 1:Checking Appendix 1:the HEX value of QR code is 73
Step 2:Scan setting code“Clear Prefix for one code”or “Clear Suffix for one code”in page 16
Step 3:Find setting codes corresponding to 7, 3 in Appendix 3 and scan them one by one
Note:If you need to cancel the prefix or suffix of all code types, please scan setting code"Clear
All Prefix"or"Clear All Suffix".
(889002.)
(888002.)
Add Prefix Add Suffix
(889004.)
(888004.)
(889003.)
(888003.)
Clear Prefix for one code Clear Suffix for one code
Clear All Prefix Clear All Suffix
(800002.)
Save Abandon
(800000.)

10
2D Desktop Barcode Scanner
Ending Character Settings
CR(Carriage Return)
(890000.)
(888002990A.)
(888002990D0A.)
（8210042）
（8210040）
LF(Line Feed)
CR+LF
Start Keyboard Operation Stop Keyboard Operation
Keyboard Operation
Function Code Transmission Setting
When the function characters transmission is enabled and the data of code contains
the function characters, the barcode scanner will transmit the data of function
character to the terminal.Default setting is enable.
Enable Disable
(8000051.) (8000050.)
E.g.1：Setting all code types adding keyboard operation.
Step 1:Checking Appendix 1:the HEX value of all barcode types is 99
Step 2:Checking Appendix 4:the HEX value of save is 13 in keyboard operation ASCII transform.
Step 3:Scanning following setting code”Start Keyboard Operation”
Step 4:Find setting codes corresponding to 9,9,1,3 in Appendix 3 and scan them one by one
Step 5:Scanning setting code“Save”
E.g.1：Setting data transmission 100ms delayed
Step 1:Scanning setting code“Data Transmission Delayed”in page 18
Step 2:Find setting codes corresponding to 2, 0 in Appendix 3 and scan them one by
one(Why 2,0? Because 100/5=20,if setting 150ms delayed,it will be 3,0)
Step 3:Scanning setting code“Save”in page 18
(851004.)
Data Transmission Delayed
Data Transmission Delayed

11
2D Desktop Barcode Scanner
Enable All Codes Disable All Codes
(9990011.)
(9990010.)
All Code Types
7th Chapter:Code Types
Scan following setting codes to choose all code types enabled or disabled.
Decode Length Settings
Introduction:The effective reading length of some code types can be set. If the data
length of the code does not match the effective reading length, the barcode scanner
will beep specially to show the error. If setting the same value for the minimum and
maximum length, the bar code scanner will only read a code of a fixed length. It helps
reduce misreading.
E.g.: Setting Code 93 code decode length as 06-10 characters
Minimum Length=06,Maximum Length=10
Step 1:Scanning setting code“Min Decode Length”of Code 93 in page 24
Step 2:Find the setting code corresponding to 6 in Appendix 3 and scan it
Step 3:Scanning setting code“Save”.
Step 4:Scanning setting code“Max Decode Length”of code 93 in page 24
Step 5:Find the setting code corresponding to 1,0 in Appendix 3 and scan them one by one
Step 6:Scanning setting code“Save”.
Done
Notes:1:It also can read setting codes in this manual after scanning setting code
“Disable All Codes”.
2:It can not read 2D postal code even scanning setting code“Enable All Code”
Scanning setting code“Enable”of 2D postal code in page
3:If you need the scanner only read one or several code types,scanning“Disable
All Codes”and then scanning “Enable”of those code types.
Enable All 1D Code Disable All 1D Code
Enable All 2D Code Disable All 2D Code
1D Code types
2D Code Types
(9950040.) (9950041.)
(9950070.) (9950071.)

12
2D Desktop Barcode Scanner
(900000.)
(9000031.)
（9000030.）
Codabar
Enable/Disable Default All Codabar Settings
Enable
Enable Transmit
ON Need OFF
Disable Transmit
Disable
(9000061.) (9000060.)
Start/Stop Bit
Check Bit
Cascade
Scan following setting code to select whether to transmit or not to transmit the
start/stop bits.Default setting is disable transmit.
(9000010.)
(9000011.)
(9000012.)
A 1 2 3 4 D D 5 6 7 8A
(9000021.)
(9000022.)
(9000020.)
When barcode cascading is enabled, the barcode scanner will look for a barcode with a "D"
character at the beginning and a neighboring barcode with a "D" character at the end. In this
case, the two barcodes will form one barcode, and ignore all the "D" characters in the barcode
No Check Bit Disable Transmit Check Bit EnableTransmit Check Bit
ON：Barcode Scanner not only read normal codabar codes,but also cascaded codabar code
Need：Scanning”Need”after scanning “ON”,the scanner will only read cascaded
codabar codes
OFF：Barcode Scanner will not read cascaded codabar codes.
