Symphony SYK-1003 Manual

© 2021
Order #XXXXX
Locked layer contains
placeholder marks.
Perspective View
Plan View
10’
10’
SYK-1003 - 10’ x 10’ Portable Display
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS
REV 11/2021

© 2021
Order #XXXXX
Locked layer contains
placeholder marks.
= 1 sq ft
Plan View

© 2021
Order #XXXXX
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, keep all
knobs & connectors attached to
extrusions during disassembly.
Part Identification - Numbering
7A
Engaged Lock
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
WARNING
General Information

© 2021
Order #XXXXX
TSP49 Profile
All knobs must be tightened securely to ensure a proper connection.
Adjust connectors if necessary to
prevent gaps in connection.
Upper Horizontal Extrusion
Lower Horizontal Extrusion
Corner
Connector Corner
Connector
Corner
Connector
Corner
Connector
COMPLETED ASSEMBLY
Slide verticals over
lower connectors.
Then slide upper
connectors into
groove of verticals.
Tighten all knobs.
Corner Connection
3) Tighten all knobs to secure connection.
Disassembly
1) Loosen knobs on vertical extrusions.
2) Slide the vertical extrusions off of
corner connectors on lower and upper
horizontal extrusions.
1) Loosen knobs, then slide vertical extrusions onto
corner connectors of lower horizontal extrusion.
2) Slide corner connectors of upper horizontal
extrusion into grooves of vertical extrusions.
Disassembly
1) Loosen all knobs.
2) Slide connectors off of one extrusion.
3) Tighten knobs to prevent loss during
packing & shipping.
Keep straight connectors in groove of
extrusion. Do not remove connectors
during disassembly.
Straight Connection
3) Tighten all knobs to secure connection.
When assembling frame, first attach all straight
connectors, then attach corner connectors.
1) Place extrusions end-to-end.
Slide connector across seam of extrusions.
Tighten all knobs.
All knobs must be tightened securely to ensure a proper connection.
Straight Connector
2) Loosen all knobs, then slide straight
connector across the seam of extrusions.
Tool-less Frame Assembly

© 2021
Step 1 of 5
Order #XXXXX
Locked layer contains
placeholder marks.
Item
1
2
3
4
5
6
7
8
9
Qty.
1
1
1
1
1
1
1
1
1
Description
45”h TSP49 Vertical Extrusion
45”h TSP49 Vertical Extrusion
45”h TSP49 Vertical Extrusion
45”h TSP49 Vertical Extrusion
27.35”w TSP49 Horizontal Extrusion
27.35”w TSP49 Horizontal Extrusion
27.35”w TSP49 Horizontal Extrusion
27.35”w TSP49 Horizontal Extrusion
6” x 22” End Base Plate w/ foot
When assembled
Tool-less Spline Connector
1. Place extrusions end-to-end.
2. Slide tool-less connectors
across seam of extrusions.
*
3. Tighten all knobs to secure connection.
Tool-less Corner Connector
1. Slide extrusion onto
Corner Connector.
2. Tighten all knobs to
secure connection.
*
Keep corner connectors attached to horizontal extrusions.
Assemble frame flat on ground.
Steps:
Refer to the Tool-less Frame Assembly general information page.
1) Assemble vertical extrusions [1-2], [3-4] & horizontal extrusions [5-6], [7-8]
together, using Tool-less Spline connectors labeled [A].
2) Connect vertical assemblies [1/2], [3/4] between horizontal
assemblies [5/6], [7/8], using Tool-less Corner Connectors labeled [A].
3) Install Base Plate [9] to bottom corners of frame assembly
as shown. See Base Plate Attachment detail.
1) Place key hole over bolt on panel
& slide down.
2) Twist knob to secure connection.
Base Plate Attachment
*
bolt
knob
Base Plate
threaded
hole
key hole
*
1
2
3
4
56
7
8
9
FRONT VIEW
A
*
A
*
A
*
A*
A
*
*
A
*A
*
A
Left Backwall Frame Assembly

© 2021
Step 2 of 5
Order #XXXXX
Locked layer contains
placeholder marks.
Item
1
2
3
4
5
6
7
8
9
Qty.
1
1
1
1
1
1
1
1
1
Description
45”h TSP49 Vertical Extrusion
45”h TSP49 Vertical Extrusion
45”h TSP49 Vertical Extrusion
45”h TSP49 Vertical Extrusion
27.35”w TSP49 Horizontal Extrusion
27.35”w TSP49 Horizontal Extrusion
27.35”w TSP49 Horizontal Extrusion
27.35”w TSP49 Horizontal Extrusion
6” x 22” End Base Plate w/ foot
When assembled
Tool-less Spline Connector
1. Place extrusions end-to-end.
2. Slide tool-less connectors
across seam of extrusions.
*
3. Tighten all knobs to secure connection.
Tool-less Corner Connector
1. Slide extrusion onto
Corner Connector.
2. Tighten all knobs to
secure connection.
*
Keep corner connectors attached to horizontal extrusions.
Assemble frame flat on ground.
3
4
1
2
65
8
7
9
FRONT VIEW *
Steps:
Refer to the Tool-less Frame Assembly general information page.
1) Assemble vertical extrusions [1-2], [3-4] & horizontal extrusions [5-6], [7-8]
together, using Tool-less Spline connectors labeled [A].
2) Connect vertical assemblies [1/2], [3/4] between horizontal
assemblies [5/6], [7/8], using Tool-less Corner Connectors labeled [A].
3) Install Base Plate [9] to bottom corners of frame assembly
as shown. See Base Plate Attachment detail.
1) Place key hole over bolt on panel
& slide down.
2) Twist knob to secure connection.
Base Plate Attachment
*
bolt
knob
Base Plate
threaded
hole
key hole
A
*
A
*
A
*
A*
A
*
*
A
*A
*
A
Right Backwall Frame Assembly

© 2021
Step 3 of 5
Order #XXXXX
Locked layer contains
placeholder marks.
When assembled
U-Clamp
U-Clamp
Steps:
1) Connect left & right frames together using U-Shaped Clamps.
See Frame Connection detail.
FRONT VIEW
*
*
Frame Connection
*From back side of display, slide U-Shaped Clamp forward
then down onto V4 connectors on left & right frames.
Tighten knobs of V4 connectors to secure Clamp in place.
U-Clamp
V4
V4
FRONT VIEW
TOP VIEW
Extrusion Extrusion
Bracket
Tighten knobs
to secure.
1
2
V4 connectors stay permanently
attached to vertical extrusion.
Backwall Frames Connection

© 2021
Step 4 of 5
Order #XXXXX
Locked layer contains
placeholder marks.
Steps:
1) Apply SEG Graphics to front of assembled frame.
SEG Graphic Installation
Corner A
Corner D
Corner B
Corner C
It is important to first insert
graphic into each alternate
corner, then to the sides of
the frame. If this is not done,
graphic will not fit into the
frame correctly.
Step 1
Insert corner A. Turn edge of
graphic so silicon welt is
perpendicular to face of
graphic. Insert narrow side
of welt with fabric to outside
into the channel. Repeat for
other side of this corner.
Step 2
Repeat Step 1 for opposite
corner C, then insert corner
B, followed by corner D, to
complete the installation of
the corners.
Graphic Removal
To remove the graphic from
the frame, locate the fabric
pull tab. Gently pull up on
the tab to remove the fabric.
Step 3
Once all corners are inserted,
press one silicon edge into
channel from corners and
work toward the center.
Make sure welt is fully inserted
into channel. Continue until
all sides are done. Smooth
out edges of graphic.
When assembled
FRONT VIEW
S
E
G G
ra
phi
c
S
E
G G
r
aphi
c
Fabric Graphics Application

© 2021
Step 5 of 5
Order #XXXXX
Locked layer contains
placeholder marks.
Workstation
Light
Light
Completed Assembly
*
**
Steps:
1) Attach Workstation Mounting Bracket
to backwall vertical as shown.
See Workstation Bracket Attachment detail.
2) Assemble Workstation legs & counter top to
bracket. See Workstation Assembly detail.
3) Attach Lights to top of backwall as shown.
See Light Attachment detail.
Attach clamp of stem light
to top of horizontal extrusion
where desired.
Twist knob on back to
tighten in place.
Light Attachment
*
knob
Light
BACK VIEW
Extrusion
Hook the Mounting Bracket
over the vertical extrusion.
Slide
Bracket
forward
Slide down onto
V4 connector
Tighten knobs
to secure.
Mounting
Bracket
Workstation Bracket Attachment
Slide bracket forward, then
down onto V4 connector.
Tighten thumb screws to
secure connection to inside
of frame.
Bracket
TOP VIEW SIDE VIEW
123
V4
V4 connectors stay permanently
attached to vertical extrusion.
*
Threaded
Studs
Wing
nuts
Counter Top
Mounting
Bracket
Counter
Legs
UNDERSIDE VIEW
3) Attach power cords to
wireless chargers.
2) Connect Counter Top to
Mounting Bracket, using
wing nuts.
1) Attach threaded studs on underside
of Counter Top to Counter Legs;
secure with wing nuts.
Workstation Assembly
Keep cords attached to
underside of counter top.
Underside View of Counter
To Power
USB
charging
pad
power
cords
charging
block
Counter Top
Backwall Attachments
