Symphony Aurora WebLink User manual

Aurora WebLink
Installation Guide
IG2001EW 05/15
*IG2001EW*

AURORA WEBLINK (AWL) INSTALLATION GUIDE
1IG2001EW
General Information
There will need to be existing internet access and Wi-Fi router in the installed location of the AWL. The AWL is a Wi-Fi device
that will use the existing internet and router to send information to a web portal. The AWL must be used in conjunction with
the Aurora controls and will provide a Wi-Fi enabled comfort system. The consumer will be able to view and adjust thermostat
settings as well as view detailed energy usage graphs and they can receive fault/lockout texts and e-mail via their smart device.
The dealer/technician will have access to the Wi-Fi AID tool as well as fault/lockout texts and e-mail via their smart device. The
dealer/technician can also have access to historical data of the heat pump which includes refrigerant pressures, temperatures and
component energy consumption for troubleshooting (if unit is equipped with AXB).
NOTE: The AWL also requires one of the following thermostats be installed: TPCM32U03A, TPCM32U04A, TPCC32U01, or
MasterStat.
Components of the Symphony/AWL System
Symphony Portal Both Technician and Consumer variations (free)
Symphony Smart Device Application For Consumers (free)
AWLK01 Aurora Weblink for Symphony WiFi Enabled Comfort System
(Refer to the Compatibility Section for list of compatible products.)
APTK01
Aurora Programming ToolKit (Pickit3 x2, Flash Drives x2, Mini USB adaptor, USB cable
and USB wall plug) required to update existing ABC/AXB Firmware and TPCC32U01
and MasterStat. Includes access to Aurora Toolbox
WA01 Water (Sump) Alarm Sensor for Aurora Controls (Optional)
Aurora WebLink (AWL) Installation and Configuration
Symphony is NOT intended as a SAFETY DEVICE. Instead, Symphony is intended ONLY to provide you with convenient
notification of the status of your equipment. A Symphony/AWL limited Warranty Certificate was shipped with the device.
The system is not a certified emergency response service and may not be linked to any emergency service contact
numbers. The Symphony system has not been designed or programmed as a first response, emergency notification system.
WaterFurnace expressly disclaims any and all warranties, express, or implied, and including warranties of merchantability or
fitness for a particular purpose, that the system will detect or provide any notification of any or all problems and events – of
any kind whatsoever- at your residence. Further details of the end user license agreement can be found at HTTPS://symphony.
mywaterfurnace.com.
ATTENTION!

AURORA WEBLINK (AWL) INSTALLATION GUIDE
2IG2001EW
Aurora WebLink (AWL) Installation and Configuration
Compatibility
The Symphony Aurora WebLink (AWL) system is backward compatible to several 5 and 7 Series packaged models that support
Aurora ABC and have a communicating thermostat. Before applying the AWL to the heat pump, make sure both the ABC, AXB (if
equipped), and communicating thermostats (TPCC32U01, TPCM32U03A, TPCM32U04A, or MasterStat,) have the latest firmware.
Using the AID Tool, confirm that the firmware versions meet the requirements in the Compatibility table (Reference the chart be-
low) before installing AWL. Visit www.auroracontrols.com/toolbox to obtain the latest firmware if needed.
Without a communicating thermostat the system is NOT compatible. A communicating thermostat can however replace a 24V
thermostat and provide compatibility for relatively low cost to the homeowner. The IntelliZone and IntelliZone2 ●24V are NOT
compatible with Symphony since neither are fully communicating systems. For systems with TPCM thermostats, a revision “A” mod-
el will need to be used for compatibility. Early 5 Series units with base controls were shipped with ABC Rev1 boards. If you have an
ABC Rev1 board it will need to be replaced with p/n 17X553-00.
Sensor Kit Options
Sensor kits are all optional but obviously with more sensors, more data can be gathered and transmitted for service use. Without
an AXB, energy data cannot be collected. Sensor kits can be added to existing heat pumps. (5 and 7 Series only)
The optional sensor kits are:
• AXB Kit - 5SAK
• Refrigeration Monitoring Kit (AXB board required) - 5SRK
• Performance Monitoring Kit (AXB board required) 5SPKS-HW or 5SPKL-HW
Symphony Compatibility Chart
Control
Board
ABC Firmware
Version
AXB Firmware
Version
Communicating
Thermostats IntelliZone2 Symphony/
AWL Compatible
TPCC TPCMA**
E Series - All Premier2 NA NA NA NA NA Not Compatible
Envision - All Premier2 NA NA NA NA NA Not Compatible
Synergy and 3D - All Premier2 NA NA NA NA NA Not Compatible
NSW - All EW NA NA NA NA NA Not Compatible
NDW - All FX10 NA NA NA NA NA Not Compatible
NDZ/NDS Splits - All Premier2 &
ABC NA NA NA NA NA Not Compatible
Legend - All Premier2 NA NA NA NA NA Not Compatible
3 Series* - LD*
Intro to Symphony Launch ABC Rev2 2.02 or less NA 1.06 or less 2.00 or less Not compatible
with IZ2 24V
Yes but needs
Software Update
3 Series* -LD* -
Post Symphony Launch ABC Rev2 ≥3.00
(≥2.02 W29) NA ≥3.00
(≥1.07) ≥3.00 Not compatible
with IZ2 24V Yes no changes
5 Series*#- NSV/H-NDV/H
- “F” vintage
(Intro 3/12-6/12)
ABC Rev1 1.02 or less NA 1.06 or less 2.00 or less 1.08 or less
Yes but Replace ABC Rev1
with new ABC Rev2 board
& maybe software updated
5 Series* - NSV/H-NDV/H
“G” vintage (Shipped 6/12
to Symphony Launch)
ABC Rev2 2.02 or less optional 1.01
or less 1.06 or less 2.00 or less 1.08 or less Yes but needs
Software Update
5 Series* - “G” vintage
(Post Symphony Launch) ABC Rev2 ≥3.00
(≥2.02 W29)
≥2.00
(1.01 W09 or
greater)
≥3.00
(≥1.07) ≥3.00 ≥2.00
(≥1.08 Z20) Yes no changes
7 Series -
(From Introduction to
Symphony Launch)
ABC Rev2 2.04 or less 1.01 or less 1.06 or less 2.00 or less 1.08 or less Yes but needs
Software Update
7 Series -
(Post Symphony Launch) ABC Rev2 ≥3.00
(≥2.04 W29)
≥2.00
(1.01 W09 or
greater)
≥3.00
(≥1.07) ≥3.00 ≥2.00
(≥1.08 Z20) Yes no changes
Rev: 5/4/15 RRB
Software versions in parenthesis are compatible, but were earlier versions used during field trials. These software versions should be updated to
the latest versions at the earliest convenience.
* Although the 3 Series (and 5 Series without AXB) are compatible and will provide the consumer with wireless thermostat functionality, the
limitation remains that very little sensor data can be transmitted without an AXB expansion board. The AXB is not available on the 3 Series.
** The existing TPCM32U03 or U04 monochrome communicating thermostat is NOT compatible with the Symphony/AWL and will need replaced
with the TPCM32U03A or U04A or the TPCC thermostat with appropriate firmware version.
# Early shipments of the 5 Series with base control only (no AXB) included the ABC Rev 1 and will need to be replaced with the ABC Rev 2 for
Symphony Compatibility.
ABC Rev1 versus Rev2 can be identified per the photos included in this document.

AURORA WEBLINK (AWL) INSTALLATION GUIDE
3IG2001EW
How to Update a 3, 5, or 7 Series System for Symphony
Controls Board Firmware Upgrade
Refer to the Compatibility Section for a list of 3, 5 and 7 Series products that can be updated to be compatible with the Symphony/
AWL system. Early 5 Series units with ABC only were shipped with ABC Rev1 boards. These are NOT compatible with Symphony
and will need replaced with ABC Rev2 boards as identified in the photos below. ABC Rev2 boards have additional quick connects
visible as shown in the photos.
ABC Rev1 ABC Rev2
Added quick
connects
TPCM32U03/04
(Also Firmware Version
2.XX or less)
TPCM/TPCMA Identification (Located on the back of Thermostat)
Thermostat Firmware Upgrade
Elite thermostats (TPCM32U03 and TPCM32U04 are NOT compatible with Symphony and will need to be replaced with newer
models TPCM32U03A and TPCM32U04A. These can be identified using the photos below. The new TPCM32U03A/04A models
have several relays eliminated.
TPCM32U03A/04A
(Also Firmware Version
3.XX or greater) No relays
in “A” version

AURORA WEBLINK (AWL) INSTALLATION GUIDE
4IG2001EW
How to Update a 3, 5, or 7 Series System for Symphony
The Update Process
We have developed a central webpage (www.auroracontrols.com/toolbox) for all of this information. In addition, the Aurora Up-
date Kit and its accompanying Aurora Toolbox Software package provide all of the tools necessary for updating a system to com-
patibility. The Aurora Update Kit includes two PICkit3 ABC/AXB control board updaters, flash drives to update the TPCC32U01 and
MasterStat, and a link to the Aurora Toolbox Software to load them. Here are the general steps to update a system. Please consult
latest literature on www.auroracontrols.com/toolbox or in the Aurora Toolbox Software.
1. Purchase Aurora Programming Tool Kit (APTK01)
2. Download Aurora Toolbox Software to load most recent firmware in PICkit3 and flash drives.
3. Visit jobsite
4. Review thermostat/MasterStat, ABC and AXB firmware versions in the AID Tool.
5. Confirm thermostats are communicating style and appropriate firmware versions. If not update using Flash Drives loaded
using the Aurora Toolbox Software. TPCM thermostat may need replaced. See compatibility table and notes on pages 2-3.
6. Confirm ABC and AXB firmware versions are appropriate firmware versions. If not update using PICkit3 loaded using the
Aurora Toolbox Software.
7. Double check MasterStat and TPCC32U01 thermostat configurations. MasterStat (firmware version 1.06 or less) and TPC-
C32U01 thermostat (firmware version 1.04 or less) will not retain configuration settings. Versions later will retain configuration
settings when updated.
8. Turn Off Unit and unpack Aurora Weblink (AWLK01) and plug into front of unit.
9. Install and configure the AWL.
Troubleshooting Aurora AWL Wi-Fi Range
The Wi-Fi Range of the AWL Router is up to 100 ft. from the home router. This range can be reduced depending upon the wall and
floor material that the Wi-Fi signal must pass through. For instance metal studs of commercial buildings may attenuate the signal
and reduce the transmitting distance. It can be advantageous to move the AWL away from sheet metal ductwork to improve the
performance. If a longer cable is desired for this, standard Cat 5e or better internet cable can be substituted to relocate the AWL
further away. Consult WaterFurnace Tech Service for more details.
Troubleshooting Aurora AWL Router Connection
If internet connection issues arise a Wi-Fi ‘Repeater/Range Extender” could provide relief. These can be purchased from electronic
box stores or online. Also in unusual cases the AWL may have trouble connecting to certain routers with customized firmware such
as local cable or satellite companies with unique connections. In these situations a new router, or second standard home router can
be purchased at the electronics store and hardwired to the original home router. After installing a new router, the AWL must be
reconfigured before reconnecting to the wireless network. After reconfiguration, the AWL is wirelessly connected to the new router
utilizing its more standard firmware. Consult WaterFurnace Tech Service more more details.

AURORA WEBLINK (AWL) INSTALLATION GUIDE
5IG2001EW
Aurora WebLink (AWL) Installation and Configuration
Wi-Fi Blue
Wi-Fi Communication
Status
RS485 Yellow
ABC Communication
Status
Status Green
Local or WebLink
Mode
AWL LED’s
Orientation
The AWL can be installed either flat, or standing up. The antenna needs to be in an upward position once the final AWL
orientation is decided.
Mode Button
Switches
between
WebLink Mode
and Local Mode
AID Tool
Local AID Tool
Connection
(RJ-45)
Heat Pump ABC
Heat Pump ABC
Connection
(RJ-45)
USB Port
Factory Use
SD Card
Storage for “black
box data”
Wi-Fi Antenna
Wi-Fi Antenna to
local home router
W
i
-F
i
Wi-
Fi
S
tatu
R
S
4
A
B
C
S
ta
S
tatu
L
oca
l
M
od
e
A
WL LED’
s
Note: SD card must
be present for proper
operation of the AWL
These two RJ-45 connectors are not Ethernet ports. Never connect a laptop or router to the heat pump ABC, or
AID Tool ports. Damage to those devices will occur.

AURORA WEBLINK (AWL) INSTALLATION GUIDE
6IG2001EW
Mounting AWL on a Heat Pump Using Dual Lock (Included)
There is a piece of Dual Lock™ (actual product may vary from photo) provided in each box to mount the AWL on the
unit. The Dual Lock cannot be placed where it blocks any of the venting slots. Remove the film from one side and place
it on the back cover of the AWL as shown below. Remove the film from the other side. Select a location on the top of
the heat pump, press and hold for a few seconds.
Venting Slots
Dual Lock
Mounting AWL on a Wall: Using Screws (Not included)
To mount the AWL using screws, use the preformed slots located on the back of the AWL.
3 7/8”
(Note: Slots are approximately 3 7/8 inches apart.)
Aurora WebLink (AWL) Installation and Configuration

AURORA WEBLINK (AWL) INSTALLATION GUIDE
7IG2001EW
1. Verify the system has the latest control board and
thermostat firmware.
2. Install AWL on any heat pump with the Aurora controls.
(3, 5, and 7 Series packaged units. Refer to Compatibility
chart for more information.)
3. Plug AWL into AID Tool port on front of unit with the
cable provided. The AID tool can plug into AWL when
needed.
4. AWL is powered by the heat pump and requires no other
power supply.
Initial Configuration (For Windows Systems)
Follow these steps for the initial configuration. On your
laptop, click on the WI-Fi bars in the system tray: Or on your
smart device, using Settings -> Wi-Fi:
Select the AWL-XX-XX-XX Wireless Network and select
Connect:
Aurora WebLink (AWL) Installation and Configuration cont.
Open your web browser (Internet Explorer, FireFox, Chrome,
Etc) and enter 172.20.10.1 in your browser and press return.
Select AWL Configuration from the Aurora Main Menu. Or
click “Launch Browser with Local Aid Tool” button on the
“Local AID Tool” tab of the Aurora Toolbox Software.
Click on the change Wi-Fi Network button:
Click on the Scan for Wi-Fi Networks button:
AID Tool
port

AURORA WEBLINK (AWL) INSTALLATION GUIDE
8IG2001EW
Select your home network from the list that appears. The
example below is with the WaterFurnace networks. Your
available networks will be different than the example shows.
Once you have selected your home network from the list, enter
your Home network password or passphrase and click OK
You should see an AWL Web Setup Complete screen:
After 20 to 30 seconds, you should see the BLUE LED on the
AWL go to a solid ON state, indicating that the AWL successfully
connected to the AWL Host Server.
After configuration is complete, if ever the SD card is removed
the AWL will still communicate with the web portal until there
is a power outage. Upon power restoration the AWL will go
directly to Local Mode and will not be able to access the internet
until the original SD card has been reinstalled in the AWL. After
reinstalling the original there are 3 options to return to WebLink
Mode, press and hold the mode button for 5 or more seconds,
cycle power to the AWL, or wait for the 30 minute Local Mode
timeout. Anytime the SD card is removed from the AWL the
system data will not be saved to the SD card although it will be
sent to the web portal. If a SD card other than the original SD
card supplied with the AWL is installed it will save data but it will
be missing necessary files to allow access to the web portal.
Follow these steps for the initial configuration. On your
laptop, click on the Wi-Fi bars in the system tray: Or on your
smartphone, using Settings -> Wi-Fi: Select the AWL-XX-XX-
XX Wireless Network and select Connect:
NOTE: You many need to turn your Wi-Fi off, and then on
to detect the AWL.
Open your web browser (Safari, FireFox, Chrome, Etc) and
enter 172.20.10.1 in your browser and press return. Select
AWL Configuration from the Aurora Main Menu.
Aurora WebLink (AWL) Installation and Configuration cont.
Initial Configuration (Apple Operating Systems)

AURORA WEBLINK (AWL) INSTALLATION GUIDE
9IG2001EW
You should see an AWL Web Setup Complete screen:
After 20 to 30 seconds, you should see the BLUE LED on the
AWL go to a solid ON state, indicating that the AWL successfully
connected to the AWL Host Server.
After configuration is complete, if ever the SD card is removed
the AWL will still communicate with the web portal until there
is a power outage. Upon power restoration the AWL will go
directly to Local Mode and will not be able to access the internet
until the original SD card has been reinstalled in the AWL. After
reinstalling the original there are 3 options to return to WebLink
Mode, press and hold the mode button for 5 or more seconds,
cycle power to the AWL, or wait for the 30 minute Local Mode
timeout. Anytime the SD card is removed from the AWL the
system data will not be saved to the SD card although it will be
sent to the web portal. If a SD card other than the original SD
card supplied with the AWL is installed it will save data but it will
be missing necessary files to allow access to the web portal.
Click on the change Wi-Fi Network button:
Click on the Scan for Wi-Fi Networks button
Select your home network from the list that appears. The
example below is with the WaterFurnace networks. Your
available networks will be different than the example shows.
Once you have selected your home network from the list, enter
your Home network password or passphrase and click OK
Aurora WebLink (AWL) Installation and Configuration cont.

AURORA WEBLINK (AWL) INSTALLATION GUIDE
10 IG2001EW
In WebLink Mode, the AWL passes the heat pump system
information (data, request) back and forth between the Aurora
system and WaterFurnace Server through the customer’s
personal router and internet.
In Local Mode, the AWL passes the heat pump system
information (data, request) back and forth between the Aurora
system and your local devices (smartphone, tablet, or laptop
computer). There is a maximum of 4 local devices that can be
connected to an AWL at a given time. The AWL will only stay
in Local Mode for 30 minutes, and will automatically switch to
WebLink Mode if WebLink Mode has been pre-configured. If
the AWL was never configured for WebLink Mode, it will stay in
Local Mode continually.
Power Up Mode Notes
Before
Configuration
Local Mode Complete the configuration to
enter WebLink Mode
After
Configuration
WebLink
Mode
Allows internet access to the
web portal
Without
SD Card
Local Mode Install original SD card and
re-enter WebLink Mode
Using a different
SD Card
Local Mode
System data will be saved to
the SD card but it will not be
possible to enter WebLink
Mode due to missing files on
the SD card. Install the original
SD card or contact
WaterFurnace Technical
Service department
Enter Local Mode by pressing the AWL Mode button for 5
seconds. On your phone, select the AWL-XX-XX-XX Wireless
Network in the phone’s Wi-Fi Settings.
In WebLink Mode, the Green LED will mostly be solid (10
seconds ON / 1/2 second OFF). During Local Configuration
mode it will blink fast (1/4 second ON / 1/4 second OFF).
To switch between WebLink Mode and Local Configuration
Mode press and hold the AWL Mode button for 5 or more
seconds. You should see the Green LED blink at the new mode
rate.
The Yellow LED will stay on if the AWL is communicating to the
ABC. If communications are lost, it will blink 2 times.
The Blue LED will stay on if the AWL is connected to and
communicating with the AWL Host Server. If communications
are lost, it will blink different blink counts, depending on the
error.
Blue
LED
Blink
Codes
Description Action
2 No Wi-Fi Connectivity Make sure pass phrase
is correct
3 DNS Begin Usage Timeout Check internet pro-
vider to make sure
the internet service is
good
4 DNS Resolving Host Timeout
5 DNS Name Resolving Failed
6 Socket Connect Error
Symphony server is
temporarily out for ser-
vice. Try again later.
7 Socket Connect Timeout
8 Start SSL Timeout
9 SSL Handshake Timeout
10 Start WebSocket Timeout
11 WebSocket Handshake Timeout
Solid WebSocket Communications are
Good None
Yellow
LED
Blink
Codes
Description Action
2ABC Communications
Timeout
Make sure the connection to
the heat pump is good.
3ABC to AWL Communi-
cation Not Supported
ABC/AXB firmware needs
updated for AWL Support
Solid ABC Communications
are Good None
Green LED
Blink Codes Description
2 SD Card not Present
3 SD Card Invalid File System
4 SD Card Write Protect is On
Mostly Solid WebLink Mode (10 seconds on / 1/2 second off)
Fast Local Mode (1/4 second on / 1/4 second off)
WebLink Mode and Local Mode
Powering up the AWL
Using Local AID Tool Web Pages on a Phone
Aurora WebLink (AWL) Installation and Configuration cont.
AWL LED Status Lights and Mode Button
Android iPhone

AURORA WEBLINK (AWL) INSTALLATION GUIDE
11 IG2001EW
The menus are similar to the actual AID Tool. For example, to
see the sensor inputs, select the Diagnostics menu option:
Then select the Sensor Inputs:
Enter 172.20.10.1 in the phone’s browser, and then select the AID
Tool (Unit Found) option:
The AID Tool data screens require a Passcode. Enter 9999 for
the Passcode, and press the Submit Passcode button.
Aurora WebLink (AWL) Installation and Configuration cont.
Android Android iPhone iPhone
Android iPhone
Android iPhone

AURORA WEBLINK (AWL) INSTALLATION GUIDE
12 IG2001EW
The Sensor Input screen is shown below:
For more details on the features of the Symphony Tech Portal, please visit www.auroracontrols.com/toolbox to view and download
Instruction Guide IG2002EW “Symphony Tech Portal Quick-Start Guide.”
Android iPhone
Aurora WebLink (AWL) Installation and Configuration cont.
Accessing the Symphony Tech Portal

AURORA WEBLINK (AWL) INSTALLATION GUIDE
13 IG2001EW
Water
Siren
(WA01)
AXB P4
Aurora WebLink (AWL) Installation and Configuration
External Sump Alarm Sensor for Aurora Controls
The Symphony/AWL System provides the infrastructure not only for status and fault notification of the geothermal unit but also
sensors external to the heat pump. This is accomplished by using the exclusive Home Automation Inputs of the Aurora AXB board
and external sensors to provide the same e-mail/text notification for technicians and consumers. This provides a powerful exten-
sion of the Symphony system to include monitoring of other critical home systems. One of these other sensors can be:
• Sump Alarm WA01-Water (Sump) Alarm Sensor for Aurora Controls
This sensor provides a relay closure that can be used to trip a fault when moisture is present. This can be used as a pri-
mary sump alarm or simply a wet basement or signal a blown washing machine hose.
The sensor can be added to any Aurora Advanced Control System (including both ABC and AXB) to monitor a sump pump.
The sensor can be connected to the Aurora Home Automation inputs (HA-1 or HA-2) of the AXB board. These will each
display an E23 and E24 code respectively when the alarm is active and when Symphony/AWL is installed will also produce
text/e-mail notifications for E23 or E24. The inputs should be configured for “Normally open” and the fault text for the
E23 or E24 can be selected by the technician using the AID Setup screens for the appropriate sensor installed. The “Fault
description text” is selectable so the users are aware of exactly which sensor is installed and faulting. These faults DO NOT
affect the operation of the heat pump and are simply passed through the Aurora controls to display on the thermostat and
pass through Symphony to the e-mail/text message notification system for remote monitoring. This provides a powerful ex-
tension of the Symphony system to include monitoring of other critical home systems. The following diagram shows proper
wiring.
WA01-Water
(Sump) Alarm Sensor

AURORA WEBLINK (AWL) INSTALLATION GUIDE
14 IG2001EW
Notes:
Account Name:
Location Address/City/State:
Unit Name:
AWL ID:

FCC Compliance Statement
The equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Manufactured by
WaterFurnace International, Inc.
9000 Conservation Way
Fort Wayne, IN 46809
www.waterfurnace.com
©2015 WaterFurnace International, Inc., 9000 Conservation Way, Fort Wayne, IN 46809-9794. WaterFurnace has a policy of continual product re-
search and development and reserves the right to change design and specifications without notice.
Product: Aurora WebLink (AWL) Installation Guide
Document: Installation Guide IG2001EW
IG2001EW 05/15
*IG2001EW*
IG2001EW
