Speaker Volume
Speed (SPD) LED (AMBER)
The Speed (SPD) LED illuminates AMBER for a 100Mb link
or is off for a 10MB link when the network link to the device is established.
Status LED (GREEN)
The GREEN Status LED illuminates after supplying power to the device.
Link/Activity (Link/Act.) LED (GREEN)
The GREEN Link/Activity (Link/Act.) LED blinks to indicate network traffic.
Power (PWR) LED (GREEN/BLUE)
The Power (PWR) LED is GREEN in low power mode (802.3af)
and BLUE during high power mode (802.3at).
RTFM Switch
To broadcast the device’s current IP address, press and hold the RTFM switch for a couple
of seconds and then release it.
To restore the factory defaults, complete the following steps:
1. Press and hold the RTFM switch until you hear the device announce the words,
“restoring defaults” and “rebooting”.
2. Release the RTFM switch. The device will be restored to the factory default settings.
Mono(+)/Left Spkr (+) - 12
Left Spkr (-) - 11
Right Spkr (+) - 10
Mono(-)/Right Spkr (-) - 9
Line-Out (+) - 8
Line-Out (-) - 7
Line-In (-) - 6
Line-In (+) - 5
Relay COM - 4
Relay NO/NC - 3
Door Sense/Button Common (GND) - 2
Door Sense/Button Contact (+) - 1
CLASS II WIRING
Speaker Connections*
Line-Out Connection (10K Ohm)
Line-In Connection
Relay Connection
Sensor Connection
Line-In Connection Sensor Connection
Relay Connection
High PIV Ultrafast
Switching Diode
Output Contacts
AC or DC-rated
depending upon
controlled device
requirements
DC Power Supply
(Max. 30 VDC @ 1A)
Solid State or
Mechanical
Relay
AC or DC
Power
Source
IN
OUT
External device
such as an
electric door strike
or an LED strobe
light
When line-in is enabled on
the device, the audio
received from the line-in
connection will be played
to the speaker(s) and line-
out connection as the
lowest priority audio.
Music Source
Paging Amplifier
*See the Operations Guide for diagrams and
information about the connections in this section.
Paging Amplifier
Paging Amplifier
