Synapse CONTROL-485-101 User manual

DOC-1000560-B-1
Part Number: CONTROL-485-101
DESCRIPTION
The Control Thermostat works in conjunction with other
SimplySnap nodes to provide access to BACnet MSTP
thermostats.
SPECIFICATIONS
Input power: 12-24VDC +/-10% or
24VAC +/- 10% from an UL listed Class 2, 24V
transformer (not provided), half-wave compatible.
Dimensions: 7.8” L x 3.9” W x 2.8” H
(200mm x 100mm x 70mm)
IP Rating: IP-66
Mounting: Independently surface mounted, Wall or
I-Beam (mounting brackets included)
Control: Operating (Non-safety) HVAC/MAU control
Supported Thermostats: Honeywell BACnet FF TB3026
Serial Interface: RS-485 or RS-422
Baud Rates: 9600, 19200, 38400, 76800 and 115200
Radio: 2.4 GHz (IEEE 802.15.4), +20 dBm Transmit
Power, -103 dBm Receive Sensitivity
Warranty: 1 Year
See www.synapsewireless.com/warranty for warranty
terms.
CAUTION
•The Control Thermostat hardware must be installed in
accordance with national, state, and local electrical codes
and requirements.
•All work must be performed by qualified personnel.
• The common signal from the Control Thermostat
hardware should not be tied to earth ground.
•Disconnect all power before installation or service.
INCLUDED MATERIAL
•2 Cable glands
•1 Hole plug
•Mounting brackets
NEEDED MATERIAL
•Screw Driver: A #2 Phillips is required to connect the
cables to the terminals.
•Mounting Screws: Mounting bracket holes fit #10
screws
•Conduit: To maintain the 4X rating of the enclosure, it
must be installed with the 4X ½” cable glands supplied
or with minimum 4X liquid-tight ½” conduit fittings, not
supplied, at the power/signal entry points.
INSTALLATION INSTRUCTIONS
1. Select a suitable installation location for the Control
Thermostat hardware e.g. between the BACnet
thermostat and the HVAC/MAU.
2. Select between inline or adjacent installation, see
Figure 1 for more details.
3. Mount the Control Thermostat hardware using the
brackets included.
4. Open the enclosure cover.
5. Install ½” cable gland(s) supplied and torque nuts to
60 in-lbs; or use liquid-tight conduit fittings as
required.
6. If only one cable entry is used, plug the unused hole
with the liquid-tight plug supplied.
7. To maintain the IP rating, jacketed cable wires are
recommended with cable diameter of 0.21” – 0.33”.
Torque sealing cable glands to 40-55 in-lbs,
depending on the cable diameter and jacket
hardness.
8. AC powered: Connect the AC power wires (e.g. from
the HVAC 24VAC transformer) to wire terminals
COMMON and 24VAC/DC maintaining the correct
polarity. See Figure 2
9. DC Powered: Connect the DC power supply wire (+)
to 24VAC/VDC and (-) to COMMON.
See Figure 3.
10. If the Control Thermostat hardware is being
connected inline with the BACnet thermostat,
connect the thermostat power wires to the same
Control Thermostat hardware terminals COM/GND
and 24VAC/DC. See Figure 2
11. RS-485/BACnet serial connections: Connect the
Control Thermostat screw terminal D+ to MS/TP+ on
the BACnet thermostat, D- to MS/TP- and GND to GND
;or connect to D+ to D+, D- to D- and GND to GND on
any other RS-485 serially controlled devices.
See Figure 4.
12. Ensure all control lines are reattached to the
thermostat.
13. Contact Synapse for Support- [phone]
Figure 1. Installation options
INSTALLATION GUIDE
WARNINGS AND CAUTIONS:
•If you are unsure about any part of these instructions, consult an electrician.
•Use this device with copper or copper clad wire only.
Mounting: For best RF performance and signal strength, do not mount this device
inside a metal box. Final installed unit should also be mounted with open space on 2 or
more sides.
Control Thermostat
Operating Temperature: 0C to +60C / Input Power: 12-24VDC or 24VAC, 50-60Hz
WARNINGS AND CAUTIONS:
•TO AVOID FIRE, SHOCK, OR DEATH; TURN OFF POWER AT CIRCUIT BREAKER OR
FUSE AND TEST THAT POWER IS OFF BEFORE WIRING!
•Risk of Electric Shock - More than one disconnect switch may be required to de-
energize the equipment before servicing.
•To be installed and/or used in accordance with appropriate electrical codes and
regulations.
Inline Installation
Adjacent Installation
Control
Thermostat
Control
Thermostat

DOC-1000560-B-1
CERTIFICATIONS
Certifications: c(UL)us, FCC/IC, RoHS
IC: 7084A-SM220
FCC ID: U9O-SM220
UL File Number: E513705
Type 1 Action, Polution Degree 2, Impulse Voltage 330V
RATINGS
Input Power: 12-24VDC or 24VAC, 50-60Hz
Max Current Draw: 60 mA @ 24VAC
Environment: 0C to +60C, 10 to 95% RH, non-
condensing
REGULATORY INFORMATION AND CERTIFICATIONS
RF Exposure Statement: This equipment complies with
FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and
operated with minimum distance of 20cm between the
radiator and your body. This transmitter must not be co-
located or operating in conjunction with any other
antenna or transmitter.
Industry Canada (IC) certifications: This digital
apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus set out in the
Radio Interference Regulations of the Canadian
Department of Communications.
Le present appareil numerique n’emet pas de bruits
radioelectriques depassant les limites applicable aux
appareils numeriques de la class B prescrites dans le
Reglement sur le brouillage radioelectrique edicte par le
ministere des Communications du Canada.
FCC certifications and regulatory information (USA
only)
FCC Part 15 Class B: This device complies with part 15
of the FCC rules. Operation is subject to the following two
conditions: (1) These devices may not cause harmful
interference, and (2) These devices must accept any
interference received, including interference that may
cause harmful operation.
RADIO FREQUENCY INTERFERENCE (RFI) (FCC
15.105): This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
(1) Re-orient or relocate the receiving antenna; (2)
Increase the separation between the equipment and the
receiver; (3) Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected; (4) Consult the dealer or an experienced
radio/TV technician for help.
Declaration of Conformity (FCC 96-208 & 95-19):
Synapse Wireless, Inc. declares that the product name
“CONTROL-485-101” to which this declaration relates,
meet the requirements specified by the Federal
Communications Commission as detailed in the following
specifications:
• Part 15, Subpart B, for Class B equipment
• FCC 96-208 as it applies to Class B personal computers
and peripherals
• This product has been tested at an External Test
Laboratory certified per FCC rules and has been found to
meet the FCC, Part 15, Emission Limits. Documentation is
on file and available from Synapse Wireless, Inc.
If the FCC ID for the module inside this product enclosure
is not visible when installed inside another device, then
the outside of the device into which this product is
installed must also display a label referring to the
enclosed module FCC ID. Modifications (FCC 15.21):
Changes or modifications to this equipment not expressly
approved by Synapse Wireless, Inc., may void the user’s
authority to operate this equipment.
CERTIFICATIONS
Model : CONTROL-485-101
Contains FCC ID : U9O-SM220
Contains IC : 7084A-SM220
UL File No :E513705
Contact Synapse for Support- [phone]
Figure 2. 24VAC connections
Figure 3. 24VDC connections
Figure 4. RS-485/BACnet connections
connections
