Synergy Air SYN-APC User manual

Synergy Air Power Cycle
SYN-APC
User Manual
Version: 1.2

pg. 2
Contents
BEFORE YOU START ........................................................................................... 3
Safety Instructions ................................................................................................ 4
DANGER............................................................................................................... 5
ATTENTION .......................................................................................................... 6
WARNING............................................................................................................. 7
Installation and Assembly.................................................................................. 8
Technical Specifications.......................................................................................... 8
Environmental Specifications .................................................................................. 9
Synergy Air Power Cycle INSTRUCTIONS FOR USE............................................. 9
Installation ......................................................................................................... 10
Handlebar and seat adjustment............................................................................. 10
Adjusting the handlebar/Seat height (plus forward & backward position).................... 10
Adjusting the seat height...................................................................................... 11
Pedals and toe straps........................................................................................... 11
Maintenance ....................................................................................................... 11

pg. 3
Daily Maintenance ............................................................................................... 11
Weekly Maintenance ............................................................................................ 12
Six Monthly Maintenance...................................................................................... 12
Twelve Monthly Maintenance ................................................................................ 12
Exploded diagram................................................................................................ 14
Synergy Fitness Duty of Care Acknowledgement ..................................................... 15
BEFORE YOU START
The following safety sign is affixed to the Synergy Air Power Cycle.

pg. 4
*Please read the following safety instructions, precautions and information before operating the
Synergy Air Power Cycle. Failure to adhere to the following will void warranty.
Safety Instructions
•The product must be correctly assembled and tested before operation.
•The Synergy Air Power Cycle must remain vertical when installed.
•The equipment must be installed indoors in a location free of moisture and dust.
•The owner of this equipment must inform all users of the safety precautions and the methods of correct
usage. Use this bike only for its intended purpose as described in the manual
•Always operate the equipment in accordance with these instructions.
•Keep your hands away from all moving parts. Never turn the pedal crank arms by hand.
•Do not remove your feet from the pedals while they are in motion.
•Do not dismount the bike until the pedals have come to a complete stop.
•Do not attempt to use this bike at high speeds or in standing positions until you have practiced and are
comfortable at lower speeds.
•The user is to wear appropriate clothing and shoes whilst using the Synergy Air Power Cycle. Baggy or
loose clothes will catch on the equipment and must be avoided.

pg. 5
•Never drop or insert any object into any opening on this bike.
•Do not spill food or drink on the product.
•Children under the age of 12 are not to use the machine.
•Pets are not to use the machine.
•The maximum weight supported by the Synergy Air Power Cycle is 180kg/396lbs.
•Only one user at a time is permitted to use the Synergy Air Power Cycle.
•Regularly check operation and component parts of the machine. Securely tighten any loose fittings or
connections. To assure that the safety level of this bike is maintained, examine components for wear and
tear on a regular basis. Components that are worn excessively or inoperable should be replaced
immediately or the bike should be put out of use until it is repaired.
DANGER
•Do not wet the surface of the Synergy Air Power Cycle with any liquids. Cleaning involves only the use
of a fine mist sprayer or a damp cloth.
•Any liquid container in proximity to the Synergy Air Power Cycle must have a tight fitting cap or lid. Do
not use the Synergy Air Power Cycle if a liquid has been spilt on any surface.
•If the operation of the Synergy Air Power Cycle, does not feel correct, or a hazard is suspected, do not

pg. 6
attempt to repair the Synergy Air Power Cycle. Contact your service agent.
ATTENTION
Please consult your physician before commencing any exercise program.
If you experience chest pains, nausea, dizziness or shortness of breath, stop exercising immediately and consult
your physician before continuing.
Permission must be obtained from a health professional for any of the following health conditions of the user:
•pregnancy,
•heart disease,
•high blood pressure,
•diabetes,
•chronic respiratory disease,
•high cholesterol,
•cigarette related or other chronic disease,
•physical disability.

pg. 7
Stop exercising immediately if dizziness, chest pain, nausea or other health abnormality is felt during exercise.
Please consult your physician before continuing the exercise.
Any repair or maintenance work must be conducted by a qualified engineer or recognized service agent.
WARNING
The Synergy Air Power Cycle is user powered. The user controls the speed of the movement.
There is no emergency stop function in the Synergy Air Power Cycle.
Every user must become familiar with the mechanism and functions before using the Synergy Air Power Cycle.
Ensure entry to the Synergy Air Power Cycle is via the rear, gripping the handles when embarking or disembarking
the Synergy Air Power Cycle.
The Synergy Air Power Cycle must be installed vertically on a hard, level surface.
Keep hands away from all moving surfaces and components.

pg. 8
Do not allow a towel or clothing to become caught in the moving surface of the Synergy Air Power Cycle.
Shoelaces must be enclosed and short enough not to touch the foot pedals. Do not use high heels, or shoes with
leather soles.
Always use the handles when embarking or disembarking the Synergy Air Power Cycle.
Examine the Synergy Air Power Cycle regularly for safe operation. Repair any problem immediately it is identified.
Implement a regular maintenance plan for the Synergy Power Tower at minimum quarterly intervals.
Installation and Assembly
Technical Specifications
The Synergy Air Power Cycle does not require any electrical wall outlet.
The Synergy Air Power Cycle is a non-motorized product.
The Synergy Air Power Cycle uses patented Continuously Variable Transmission (CVT) and air turbine to provide
resistance.
Dimensions: 130cm (H) x 60cm (W) x 130cm (L)
51” x 23” x 51”

pg. 9
No
Description
QTY
1
Handlebar
1
3
Main frame with turbine
1
4
Left crank with peddle
1
5
Right crank with peddle
1
6
Seat
1
Environmental Specifications
•Operating conditions: temperature 10℃~ 40℃/ 50OF ~ 104OF Humidity 20% ~ 95%
•Transport and storage conditions: temperature -18℃~ 49℃/ -1OF ~ 120OF. Humidity 20-95%
Synergy Air Power Cycle INSTRUCTIONS FOR USE
The Synergy Air Power Cycle is designed to be used as an individual or group cycle in fitness studios and health
clubs.
It has a fixed wheel driven fan and should only be used under professional supervision.

pg. 10
Installation
It is important that the Synergy Air Power Cycle is correctly assembled and we recommend that installation and
assembly be carried out by suitably qualified personnel.
Upon arrival, the user may only be required to attach the console to the console post.
Handlebar and seat adjustment.
It is important that the handlebars and seat are set at the correct height for your body. Ask your instructor for
assistance.
Adjusting the handlebar/Seat height (plus forward & backward position)
1. Make sure the handlebar is securely tightened and that there is no lateral or vertical movement of the
handlebar.
2. Undo the Quick Release knob which is located in front of head tube. Slide the handlebar/stem up or down
to the required height and then retighten.
3. The handlebar/stem position can also be adjusted forwards or backwards. Undo the Quick Release lever
located below the slider.

pg. 11
4. Slide the handlebar/stem assembly forwards or backwards until you reach the required position, then
securely re-tighten the Quick Release lever.
Adjusting the seat height
Refer to the above notes.
*Note: there is a safety line engraved on the seat post. On no account should the seat post ever be
raised above this line.
Pedals and toe straps
Your feet should be securely positioned in the toe clips during the exercise. Put your foot as far forward as you
can into the toe-clip and then pull the strap tight.
Maintenance
Like any other mechanical cycling device, the Synergy Air Power Cycle should be regularly maintained.
In environments with severe pollution, the frequency of inspections and maintenance should be increased.
Daily Maintenance
Daily cleaning and inspection, and lubrication will keep the Synergy Air Power Cycle in optimal condition.

pg. 12
Listen out for any unusual noise and loose components. Do not ignore but address the issue immediately.
Weekly Maintenance
Clean the frame and plastic surfaces with a soft cloth or brush. Do not use abrasive cleaning materials or brushes.
Protect all metal surfaces with Lanolin Spray. Spray onto a cloth and wipe surfaces. Note- Do not apply Lanoline
to handles and/or Foot plates
Clean the console with a soft cloth.
Check all bearings, pedals, handlebar, seat adjustment knobs are still secure and functioning optimally. If
required, tighten crank arms, handlebars, pedals.
Six Monthly Maintenance
Check of belt/chain tension. Call a service agent if in doubt
Inspect main frame bolts
Twelve Monthly Maintenance

pg. 13
Tighten main frame bolts and feet bolts

pg. 14
Exploded diagram

pg. 15
Synergy Fitness Duty of Care Acknowledgement
DUTY OF CARE ACKNOWLEDGEMENT: I acknowledge & understand that the fitness
equipment being supplied to our Facility must be used correctly and that incorrect use or using excessive weight relative to the
capability of the user can easily result in injury. Accordingly, as part of our 'Duty of Care', I understand that it is our responsibility to ensure:
1. That all equipment users, prior to using the equipment must receive a comprehensive induction, by a qualified fitness professional, in the
correct use and safe operation of the fitness equipment. As part of the equipment induction process, we must ensure that patrons are made
aware of the safety 'Warning' labels on each machine and that reference is made to the exercise Instructional Placards' fitted to Strength pin
loaded machines.
2. It is understood that many of the machines, racks & benches can be used for a wide range of variable exercise options, making it impossible
to provide an instructional placard for every exercise option & variant. Accordingly, the equipment purchaser acknowledges that it is the
responsibility of the exercise facility to instruct and supervise users in the safe, correct and appropriate use of these machines.
PLEASE NOTE - Any piece of fitness equipment is capable of being pulled over if used incorrectly. It is the buyer's responsibility to determine if
they wish to fix the equipment to the floor.
© 2017 SYNERGY PHYSICAL CONDITIONING SYSTEMS Pty. Ltd.
NOTE: Synergy Physical Conditioning Systems reserve the right to change the specification without notice
