Synesso S Series User manual

1
5610 4th Ave S. / Seale, WA 98108—USA
Tel: [phone] / Fax: [phone]
Ordering Parts: [email protected]
Technical Support: [email protected]
Informaon: [email protected]
www.Synesso.com
SYNESSO S SERIES
OWNER’S MANUAL VERSION 2020.1
Last Revision: September 2020

2
TABLE OF CONTENTS
Introducon 3
Safety Warnings 4
Depressurizing Tanks, Tank Safety 5
Start Up Screen, Serial #, Soware Ver. 6
List of Tools and Supplies 6
Warranty & Water Standards 7-8
Plumbing Requirements 9
Electrical Requirements 10
Installaon and Installaon Diagrams 11-13
Startup 14
Operaon 15-17
Programming - Handheld Controller 18-29
Menu Level 1 - Operaons 18-22
Volumetric Programs 20
Error Codes 22
Menu Level 2 - Sengs 23-28
Program Mode / Temp. Scale 23
Error Log 28
Firmware 29
Maintenance 30-33
Quarterly Preventave Maintenance Guide 32
Annual Warranty Checklist 33
Flowmeter Calibraon Instrucons 34
Troubleshoong Guide 35-41

3
Please WRITE your Serial Number & Oset Infor-
maon here. This can be found on the 2nd & 3rd
Menu Levels of the Display Controller. Have this
available BEFORE calling for service or technical
support.
S/N: ________________________________
The osets for this machine are:
BG1: _____°F / BG2:_____°F / BG3:_____°F
Steam Tank:_____°F
Factory Contract Informaon:
Synesso Inc.
5610 4th Ave South
Seale, WA 98108 - USA
Tel: [phone] / Fax: [phone]
E-mail: [email protected]
Web: www.Synesso.com
Twier: @SynessoFactory
Instagram: Synessofactory
INTRODUCTION
Congratulaons on the purchase of your Synesso espresso machine. Please read this Technical Manual and
retain it in a safe locaon for future reference. If you have any quesons about your machine, please con-
tact Synesso and our knowledgeable sta will assist you
Included in the package with this machine you will nd the following:
• Thumb Drive containing the Owner’s Manual and other technical documents
• Pump/Motor Combinaon + hoses (3/8” compression ngs on all hoses)
• 8’ Long metal reinforced ¾” ID drain hose + hose clamp (aached)
• Fing, 1/4” male NPT x 90° x 3/8” Compression (if not CE)
• Accessory Package: Portalters (per customer specicaon), blind basket, Synesso 3 oz. (90ml) shot
glass, 4oz jar cleaning detergent, and a 58.4mm tamper.
• Electrical plugs are ONLY included on CSA Cered machines (Canada). For all other machines, the
owner of the machine must purchase an appropriate plug end for their machine. Please see the
installaon instrucons starng on page 11 for more informaon.
Serial Number
Your espresso machine has a unique serial number, this
number can be found on the serial number label located on
the back side of the handheld display controller. The number
can also be read on the display during start-up. Please have
this serial number available for reference when contacng
the factory.
This manual applies to Synesso models S200 and S300. “S Series” machines are fully volumetric with up to
6 programmable dispensed volumes, depending on sengs. The S series machines have an external pump
and motor.

4
The conductors of the power supply cord are
marked “L1”, “L2” for the ungrounded (“hot”)
supply conductors and “G” for an equipment
grounding lead.
Warning: Risk of Fire. Use UL Listed Grounding
Type Plug rate for 220 Volts, ______ Amperes,
_______ Phase, #______ Wire. Plug to be Selected
and Installed only by Qualied Service Personnel.
Electrical
WARNING: Disconnect from
power supply before servicing
AVERTISSEMENT: Couper
l’alimentaon avant l’entreen
et le depannage.
California
only:
WARNING
This product can expose you to
chemicals including lead, which is known to
the State of California to cause cancer, birth
defects, or other reproducve harm. For
more informaon, go to
www.P65Warnings.ca.gov.
Electrical
Box:
This equipment is to be installed to
comply with the applicable federal,
state or local plumbing codes.
Under drain
tray
Materials informaon for Synesso™ machines:
• All stainless steel coming into contact with the water supply is 300 series
• All brass ngs are low lead per the CA360 specicaons or beer
• All electronic devices are lead free
• All gaskets are made from food-contact safe material
Test Informaon:
• Brew (coee) tanks are hydrostacally tested to 375 psi
• Steam tanks are pressure tested to 75 psi
• The electrical system is subject to an electrical withstand test of: 1.20 kV AC for 1 sec-
ond, with a 7 mA limit.
IMPORTANT Informaon for Synesso™ Espresso Machines: DISCONNECT FROM POWER BEFORE SERVICING.
• Read the enre manual before operang this machine.
• Steam and condensaon from the steam wand discharge are very hot and may cause burns.
• The steam wand ps and bases become hot during use: do not touch these surfaces.
• Cover the steam wand p or submerge in a lled pitcher to safely divert the steam before opening the
steam valve.
• Never remove the steam wand from the product that is being heated when the valve is open.
• Never remove the portalter from the machine during the acve brewing process.
• Keep water and moisture away from any electrical device or live power.
• Steam tank water is heated to 260°F (126°C) or more; Use cauon near steam tank.
• The brew groups deliver water as hot as 210°F (99°C). Avoid exposure to this water.
• The hot water mix valve can be adjusted to deliver water as hot as 212°F (100°C), which can cause severe
burns: please use cauon when acvang this water source.
Safety Label Locaons:
Synesso™ complies with UL regulaons by posng the following labels on its machines:
SAFETY WARNINGS

5
BREW & STEAM TANK SAFETY
Espresso machines have numerous potenal hazards, and it is of paramount importance to Synesso that
people servicing our machines take all necessary precauons to ensure their personal safety. When working
on the machine’s boilers (unless otherwise instructed in the direcons):
• Turn the machine o and shut o the incoming water supply.
• Depressurize the boilers as shown below.
When working on any electrical wiring (unless checking voltage or amperage readings or otherwise instruct-
ed in the direcons) ensure that the machine is switched o at the red on/o switch on the front panel and
the machine is unplugged.
Depressurizing the Steam Tank:
Depressurizing the Brew Tanks:
1. Turn o the element circuit
breaker located under the machine.
2. Also turn o the water supply to
the machine.
4. The brew tanks are depressur-
ized once the pressure gauge
reads zero. Note – the brew
gauges are rated at 0-300 psi
3. In the second level menu,
change the brew valves from
“Normal” to “ON” this will
bleed the pressure.
“NORMAL” to “ON”
1. Turn o the element circuit
breaker located under the machine
2. Open the steam valve by moving
the steam actuator lever forward
3. The steam tank is depres-
surized when the steam gauge
reads zero. Note: the steam
gauge is rated @ 0-60 psi

6
RECOMMENDED TOOLS & SUPPLIES
• Mul Meter – reads volts, amps and ohms
(The Fluke T5-600 is recommended)
• Heat Shrink Gun or Torch
• Vacuum with a Hose
• Compressed Air
• Descaler – Citric Acid
• Flashlight
• Box Knife
• Thread Sealant – Red and Blue Locte
• Food Grade Grease (Super Lube) 1.8600
• Tube Bender for 1/4”, 5/16”, and 3/8” Tube
• Flare Tool - 45°
• Tube Cuer
• Brass Bristle Wire Brush
• 3/8” Drive Socket Wrench with 7/16”, 1/2” and
9/16” “Deep Sockets”
• Hammer Medium Size Ball Peen
• Wire Stripper / Crimper
• Small Punch and Chisel
• 3/8” ID rubber tube for draining
• Small Files – Round and Triangular
• Picks – Straight and Curved, an Ice Pick is great for
replacing portalter gaskets
• Dies: 1/8” NPT, 1/4” NPT, and 1/8” BSPP
• Taps: 8-32, 10 - 32, 3/8 – 16, and M6 x 1
booming Tap
• Allen Wrenches: 3/32”, 1/8”, 9/64”, 5/32, 3/16”,
1/4” (steam valve seat)
• Wrenches: 2x11/32, 1/4, 5/16, 3/8, 2x7/16, 1/2,
2x9/16 , 5/8, 11/16, 3/4, 12mm & 17mm
• Adjustable wrenches: Medium size 1 1/4”
opening and Small for ght spots
• Pliers: Channel Lock, Standard pliers and Side
Cuers
• Philips Head Screwdrivers: #2 short, #2 long and
#1
• Flat Head Screwdrivers: #2 short, #2 medium
length, #1 medium, #0 medium
• A large at head screwdriver (or small at nail
puller) to use as a pry bar or wedge.
• Pen and paper
• Hand cleaner and Towels
Tools and recommended items required to fully diagnose, service and maintain
Synesso espresso machines.
START UP SCREEN
The serial number contains important informaon:
2—is the number of brew groups on this machine
03—is the month the machine was built
18—is the last 2 digits of the year it was built
4277—is the machine sequence number
When power is turned on, this
screen is shown, displaying the
soware version and serial
number.

7
Limited 2 Year Plus Warranty
Synesso Inc. and/or your distributor warrants to the original purchaser that Synesso™ espresso machines are
free from defects in materials and workmanship under normal use and service for the period commencing
upon the date of shipping and connuing for 24 months from the original date of shipment. Synesso will
make a good faith eort for prompt correcon or other adjustment with respect to any non-wearing part
that proves to be defecve within the limited warranty period. The limited warranty is condional upon
proper use of the machine by the purchaser.
The limited warranty does not cover defects or damage resulng from: accident, misuse, abuse, shipping
damage, neglect, unusual physical, electrical or electromechanical stress, unauthorized customer modica-
ons or improper water ltraon.
WARRANTY & WATER STANDARDS
• Universal Brew Tank
• Steam Tank
• Marathon Motor
• Fluid-o-Tech Pump
• Pressure Relief Valve
• 1/4” Check Valves
• Thermal Overload Switch with Manual Reset
• Brew and Water Control Valves
In addion to the standard 2 Year Plus Warranty*, Synesso™ will cover the following items
under a Limited 5 year Warranty:
• Steam Valve Actuator
• Machine Body
• Machine Frame
• Heang Elements
• Wire Harness
• Flow Meters
• Copper Tubes
• Brass Fings
• Temperature Probes
• Lifeme Warranty on Group Head Actuator As-
semblies
Wearing parts not included in the 2 Year Plus Warranty* are:
• Portalter Gaskets
• Portalter Baskets
• Portalter Springs
• Group Diuser Screens
• Steam Valve Seals
• O-Rings or Seals
• Gauges
• Vacuum Breaker
• Body Panels - One Year Warranty
• Purge Buons - One Year Warranty
*To obtain the 2 Year &/or 5 Year Plus Warranty, the annual Preventave Maintenance
Guide and checklist must be completed by a qualied Synesso Technician. Aer twelve
months from the original date of shipment, the completed checklist must be emailed to
the Synesso Technical Support Department. [ [e-mail] ] Checklists must be re-
ceived before the thirteenth month from the original date of shipment in order to be valid.
See page 33 for the Annual Preventave Maintenance Checklist.
The 2 Year Plus Warranty* will cover all non-wearing parts including:

8
Proper water ltraon and regular lter changes are a requirement to keep your factory warranty valid
and your machine funconing properly. It is highly recommended that you contact a professional water
ltraon specialist in your area and have your water tested to determine the proper ltraon system. It is
important to note that many municipalies change their water sources throughout the year, so addional
water tests may become necessary.
Water Standards to keep your warranty valid:
In Synesso’s experience, Everpure Claris and Cirqua formulator systems can damage the
Synesso stainless steel tanks. Use of either system is highly discouraged and will void the
water related parts of the machine warranty.
Any part which is determined to be defecve in materials or workmanship should be returned to Synesso or
to an authorized service locaon, shipping costs prepaid, as Synesso designates. Synesso may repair or re-
place the product or part with new or factory refurbished equipment at Synesso’s sole discreon. If the
product or part is determined to be defecve and in compliance with the Limited Warranty condions, the
replacement part or product will be returned to the purchaser with shipping prepaid **.
Many jurisdicons have codes and regulaons governing sales, construcon, installaon, and/or use of
products for certain purposes, which may vary from area to area. While Synesso aempts to assure that its
products comply with such codes, it cannot guarantee compliance and cannot be responsible for how the
product is used or installed.
Synesso’s liability is limited to the purchase price of the product and shall not be held liable for damages
that extend beyond the product itself. Synesso’s liability of consequenal, incidental damages, indirect or
direct damages for personal injury, inability to properly use this product, loss of business prots or interrup-
on to business is expressly disclaimed.
** Regarding equipment sold or residing outside the United States: purchaser may be required to pay for
the shipping and associated costs for warranty parts, repairs and services. Please contact your local distribu-
tor to resolve the issue regionally, if possible.
WARRANTY & WATER STANDARDS
Total Dissolved Solids (TDS) 30 to 200 ppm (parts per million)
Total Hardness - in ppm 50 to 85 ppm
Total Hardness – in grains 3 to 5 grains (divide ppm by 17.1 to get grains)
pH 6.5 pH to 8 pH
Chloride 5-15 ppm – any Chlorides can be corrosive and harmful
Total Alkalinity Less than 100 ppm
Chlorine 0 ppm
Iron 0 ppm

9
PLUMBING REQUIREMENTS
This equipment must be installed to comply with the applicable federal, state or local plumbing codes.
WATER TREATMENT IS REQUIRED TO PRESERVE THE FULL MACHINE WARRANTY. Please ensure that the
incoming water complies with the warranty requirements listed on page 8.
Using the provided stainless steel braided hose, connect the pump to the shuto valve on the ltered cold
water line. Fings on the hoses and pumps are 3/8” tube compression. Thread sealant or Teon tape is not
necessary. Make connecons snug, but do not over ghten.
Turn incoming water ON and check for leaks.
Synesso machines require a minimum of 50 PSI (3.5 bar) of line pressure at 30 gal (120 L) per hour to have
the auto-ll system, for the steam tank funconing properly. Please ensure that the incoming water meets
this requirement or contact Synesso for alternave methods of boosng water pressure.
NOTE: Synesso sells a “Euro-hose” adaptor hose and ng which converts from a 3/8” tube ng to a pipe
ng, suitable for most non-US plumbing. Please refer to the picture below to idenfy the dierences
between the standard and Euro-style ngs and hoses.
1/4” NPT
3/8” Tube Compression
3/8” BSP Pipe
Standard Fing
Standard Hoses (48” or 84”)
Euro Hose
Euro Fing
(Euro Assembly - hose +
ng)

10
ELECTRICAL REQUIREMENTS
All Synesso machines are rated to operate on 220 VAC / 60 Hz or 230 VAC / 50 Hz frequency, single phase.
Machines will operate between 208 V and 240 V.
Listed amp rangs are all measured at 220 V. Incorrect voltage can cause malfuncon or damage to the ma-
chine. Plug or means of isolaon must be easily accessible.
An electrical socket and matching plug, rated at the proper voltage and amperage are required within three
feet of the machine. Plug ends are NOT included with the machine unless required by CSA or other cerca-
on.
Aach the plug end per manufacturer’s instrucons.
Make sure that the electronics switch and the heang element breaker are in the OFF posion, then plug the
power cord into the receptacle.
OPTIONAL: If recovery me is slow, or voltage is low, you may install an In-Line Buck-Boost transformer.
Buck-boost transformers come in dierent sizes. Please choose the appropriate one for your machine if re-
quired. Machines require a 1.0 KVA transformer.
SPECIAL ELECTRICAL INFORMATION FOR EMC-COMPLIANT MACHINES
(CE FOR EUROPE AND OTHER LOCATIONS)
To comply with EMC (Electromagnec Compability) regulaons, machines built prior to May 2019 included
a capacitor in the electronics box across the main power IN. To avoid an electric shock from the charge held
in the capacitor, unplug or isolate the machine with the electronics ON/OFF red rocker switch in the ON
posion.
North American Wire Color Worldwide Wire Color
Green Ground Green and Yellow Ground (Earth)
White 110 V Line 1 Brown 230 V
Black 110 V Line 2 Blue Neutral
Model Cord Plug Rang (UL Listed) Machine Max Amp Draw Machine Max Was
S200 30 amp 28 amp , 220 V / 60 Hz 5956 Was, 230 V / 50 Hz
S300 40 amp 36 amp , 220 V / 60 Hz 7656 Was, 230 V / 50 Hz

11
INSTALLATION & WORK STATION
To maintain the 2 year warranty, an authorized or cered espresso service representave
must perform the installaon of this espresso machine.
Site Preparaon - See Diagrams pages 12-13. The machine must be placed on a level horizontal surface that
can be easily cleaned and is capable of supporng a minimum of 300 lbs.
The counter top requires a depth of 28”, which provides a minimum clearance of 1” behind and 3” in front
of the machine.
The height of the surface can vary to suit the operator.
Make a 2 ½” minimum diameter hole through the counter top located according to the diagrams on pages
12 and 13. The hoses, drain tube, and electrical lines will all pass through this hole.
A 3/8” min. diameter cold water supply line from the lter with a shut o valve is required within 5’ of the
machine. The valve should be easily accessed for machine service.
The machine supply hose and pump ngs are 3/8” tube compression ngs.
A proper water ltraon or soening system must be installed on the incoming water supply. Water treat-
ment requirements will vary, and it is important to use a system designed to match the needs of your spe-
cic area. Water ltraon systems require periodic maintenance, including cartridge or lter replacement.
Proper ltraon and service is vital to the funcon of the machine and the quality of the espresso served.
Follow the instrucons provided by your water treatment system for proper installaon.
Note: Improper water ltraon can result in severe damage to the machine including scale deposits and cor-
rosion. DAMAGE CAUSED BY IMPROPER WATER TREATMENT WILL NOT BE COVERED BY THE MACHINE
WARRANTY. See page 8.
There must be adequate room under the counter to locate the motor and pump. The pump must be easily
accessible for adjustment, and the motor must have a minimum of 3” clearance on all sides for air ow.
A oor drain or sink must be available. The best locaon is directly under the machine. The 3/4” drain hose
should descend as vercally as possible for opmal drainage. An air gap is required between the end of the
drain hose and the highest water posion of a clogged drain. This is to prevent the possibility of drain water
backing up into the machine.

12
INSTALLATION & WORK STATION—S200

13
INSTALLATION & WORK STATION—S300

14
START UP
First Time Start-Up Instrucons
1. Connect the water lines and the drain hose. Turn the water ON. Water will begin to ow into the brew
groups.
2. Ensure the heang element breaker switch is in the OFF posion. Then switch the red electronics On/O
switch to the ON posion. The machine’s auto-ll feature will acvate and the steam tank will begin lling.
3. Bleed the air from the group heads by running each group unl water ows without spuering.
4. When the steam tank has stopped lling, set the heang element breaker to the ON posion. The machine
will begin heang to the set temperatures.
10Heang Element
Switch
ON: le posion (1)
OFF: right posion (0)
5. To set the pump pressure to 9 bar, locate the pump adjusng screw on the right side of the brass pump
housing. Loosen the lock nut and turn the screw with a screwdriver (Clockwise to INCREASE pressure,
Counterclockwise to DECREASE pressure). Make adjustments while running the shot programs to see the
current pump pressure. Once the desired pressure is reached, reghten the lock nut.
6. Please allow at least 30 minutes of “warm up” me before using your Synesso™ espresso machine to
brew shots or steam milk. The steam gauge (the le hand gauge) should read a minimum of 1.1 bar be-
fore the steam tank is at an operaonal pressure and will stop at 1.3 bar when the factory set tempera-
ture of 250°F is reached. The factory set temperatures for each brew tank is 203°F. Temperature readings
for the steam and brew tanks are displayed on the handheld controller. Temperature set points can be
adjusted by following the instrucons on pages 19 and 20. Once the readings are at the set temperature,
the machine is fully operaonal and ready for use.
Note: As the brew groups heat, the needle of the brew pressure gauge may rise above 11 bar. There is an ex-
pansion valve used to control the maximum pressure achieved. This valve is posioned to bleed into the
drain tray of the machine and is accessible for adjustment from the front of the machine without having to
remove machine panels. The expansion valve is factory set to bleed o pressure at 11-12 bar. If the needle
rises above 12 bar on the pressure gauge, the expansion valve should be adjusted to bleed o pressure near
11-12 bar so that the maximum pressure reading of the brew gauge cannot exceed 12 bar. The expansion
valve requires periodic adjustment throughout the lifeme of the machine to ensure that the pressure in the
brew system is not able to increase above 12 bar.
7. Once the steam pressure gauge reads at or above 1.1 bar, you may purge the steam wands. To purge the
steam wands, rst posion the wand p into the drain tray. Acvate the steam wand by pulling the steam
wand handle toward you. Aer allowing steam to escape for several seconds, turn the steam o by returning
the handle to the resng posion.

15
OPERATION
Introducon to S Series Operaon
S Series machines are designed to operate as fully volumetric machines. This means that any me a group is
acvated, it will run the selected program unl the set volume has been dispensed. S Series machines do
not have a manual operaon mode.
S Series machines come with a single pump/motor. They are designed to operate with two stages of pres-
sure proling for brewing espresso. The shot begins with preinfusion. Low pressure water saturates the
puck, swelling it to reduce channeling. Aer the programmed preinfuse me has elapsed, the full pump
pressure (typically 9 bar) stage begins. This stage will connue unl the programmed volume of water has
been dispensed. The pump and brew group then shut o to end extracon, returning the machine to idle
pressure.
S Series machines come equipped with a handheld controller and LCD display to allow for adjustments of
the machine tank temperatures and brew parameters. Each brew group has two available programs which
can be easily accessed and adjusted through the controller.
Preparing to Brew Espresso
1. Select the desired spout and basket conguraon. Single, double and boomless portalters are availa-
ble through Synesso™. The single spout portalter is used with a single (7g) basket to brew a single shot.
The double spouted and boomless portalters can be used with double (14g) or triple (18g or 21g) bas-
kets to brew double or triple shots. The double spouted portalter can separate a double shot into 2 sin-
gle shots of espresso.
2. Fill the portalter basket with coee grounds to just above level and wipe o the excess.
Note: For best results, use fresh coee. Ground coee should be brewed as soon as possible aer grinding.
3. Press straight down evenly on top of the grounds with the tamper. (A tamper is supplied with the ma-
chine).
4. If desired, purge the group to heat the diuser before proceeding to the brewing process. S Series ma-
chines have purge buons, which will dispense a med pulse of full pressure water to aid in cleaning or
warming the group between shots. Set the duraon of the purge in the handheld controller.
Center Posion - At Rest Shi Le - Start Program 1 or Stop Shi Right - Start Program 2 or Stop

16
Brewing Espresso
1. Engage the prepared portalter into the brew group that has the correct temperature seng for this es-
presso roast and pull handle rmly to the right to set the seal.
2. Shi the group head either to the le to run the le program or to the right to run the right program.
3. The program will preinfuse the puck for the set me, then engage the pump.
4. Once the set amount of water has been dispensed, the shot will end automacally.
5. You may change the preinfusion me and shot volume by using the handheld controller (see page 20 for
programming instrucons). Make changes between shots, not while brewing.
6. To stop a shot early, shi the handle in either direcon or press the purge buon.
7. Aer the shot, remove the portalter, tap out your spent puck, and clean the basket.
8. Purge the group. S Series machines have purge buons, which will dispense a med pulse of full pressure
water to aid in cleaning the group between shots. Set the duraon of the purge in the handheld control-
ler.
OPERATION
Shot Timer Display
Program 1 (Le Shi) Program 2 (Right Shi)
Flashing Triangle
Low Flow (occurs during brewing) or
Low H20 (accompanied by beeping)
Flashing Triangle / Time Out
Low Flow (shot is stopped)
Brew Valve Time Out
Shi Group Handle to Clear

17
Milk Steaming
1. Fill the pitcher halfway with fresh, cold milk. Smaller pitchers are recommended for drink sizes less than
10 oz. Note: Steamed, unused milk should be discarded and the pitcher rinsed before using.
2. Purge the steam wand by acvang it momentarily. This will expel any water in the wand that has collect-
ed due to condensaon between uses.
3. Insert the p of the steam wand deep into the milk pitcher. This will prevent milk from splashing once the
steam is turned on.
4. Open the steam valve by pulling the handle towards you.
5. Place one hand on the side of the steam pitcher to feel the rising temperature of the milk.
6. While the milk is sll cold, lower the pitcher unl the p of the steam wand is near to the surface. Allow
the steam jets to push some air beneath the surface, then raise the pitcher to lower the p of the wand
deeper into the milk. Note: The more air pushed into the milk, the more foamy the texture will be. Gen-
erally not more than a second of aeraon is needed for lae foam or several seconds for cappuccino
foam.
7. Connue steaming the milk while the wand is submerged. This will connue the heang process and min-
imize further foaming. Do not touch the steam wand to the boom of the milk pitcher; this can create an
inaccurate temperature measurement.
8. Heat the milk to approximately 150°F to 170°F (65°C to 76°C) then deacvate the steam wand. If you are
using your hand to help determine the temperature, it will feel about as hot as you can stand without
burning yourself. Milk thermometers are also an excellent way to determine the temperature of the milk.
Cauon: Do not overheat the milk and scald it. Scalded milk should not be used.
9. Remove the wand from the milk, purge with steam, and wipe clean immediately aer each use.
Note: The steam wands should be purged before and aer each use. Failure to purge the wands may
allow the steamed liquid to travel back through the wand and cause steam valve failure and spoiled, scalded
milk avor. These issues are fully preventable by habitually purging the wands, as described above, and keep-
ing the machine up-to-date on preventave maintenance.
Note: Although Synesso™ steam wands are made with a proprietary double-walled process that helps to
keep the outer wall cooler, the p and base can become very hot and cauon must be used.
Cleaning and Maintenance:
Machine upkeep is essenal in order to ensure a long lifeme of the machine and the proper funconing of
all components. Users should perform roune cleaning and schedule roune preventave maintenance to
keep the machine at opmal performance.
For more on Synesso recommended cleaning and maintenance procedures for the machine, please refer to
pages 30-33 of this manual.
OPERATION

18
PROGRAMMING
Overview
S Series machines have a handheld (wired) controller, pictured below, to allow the user to comfortably view
and change the machine sengs.
To change sengs on these screens, rst press the line buon on the le side of the display associated
with the seng you wish to change. The value will ash once selected. Press the up or down buons unl
the desired value is displayed. Press the line buon again to conrm the change. The value will stop ash-
ing. Use this procedure to change any variables in the controller menus.
The top line of every screen indicates the tle. In this case, Temperature Overview.
You can return to this screen at any me by pressing the home buon at the top right of the controller.
The machine will also return to this screen automacally aer a short me.
Lines 2, 3, and 4 may contain informaon or sengs, many of which can be changed by the operator. This
screen provides the current temperatures for each brew group along with the steam tank. The most recent
error will also be shown in the lower right corner. No sengs can be changed on this screen.
In some circumstances, numeric temperatures will not be shown. If a tank is reading ‘LOW’, this indicates
that the tank is below the temperature probe’s eecve range of measurement (170°F-270°F / 76.6°C-132.2°
C). Readings above the eecve range will show as ‘HIGH’.
The programmable temperature range for a brew group is from 180°F (82.2°C) up to 220°F (104.4°C). The
factory set temperature is 203°F (95°C). To change brew group set temperatures, refer to page 19.
The steam tank is set in factory to a default seng of 250°F (121.1°C). To change this temperature seng,
see page 20.
The [OK] on the right hand side of line 4 is indicang that there have been no errors detected by the control
system. If, in place of the [OK] you nd an error code (Ex: STLW01), refer to the Error Log codes on page 22.
To cycle to the next display screen, press the down arrow buon. (You may press the up arrow instead to
travel back to the previous screen.)
Line 2 Buon
Line 3 Buon
Line 4 Buon
Home
Up
Down
Line 1 Title
Menu Level 1: Temperature Overview; Home Screen

19
PROGRAMMING
Factory Sengs:
The factory sengs for your machine are as follows:
Brew Group Temperature 203°F
Steam Tank Temperature 250°F
Program Mode Universal (2 programs)
Temperature Units Fahrenheit
Le program: Right program:
Pre-Infusion 4 seconds Pre-Infusion 4 seconds
Total Water Count 280 Total Water Count 380
The set point is a goal temperature for the brew tank. The tank will heat to reach the set point, then use a PID
based algorithm to remain stable and balanced at that temperature when in use.
Allow 10-15 minutes for a brew group to adjust to a large set point change. Smaller changes take less me to
restabilize.
Line 2 indicates the set point for brew group 1, in this example “203.0F”.
Line 3 indicates the set point for brew group 2, in this example “203.0F”.
To cycle to the next display screen, press the down buon.
Menu Level 1: Brew Temperatures

20
PROGRAMMING
If the machine has been set to universal program mode, you will be able to change the “Le” and “Right”
program, seng the preinfusion me and water count for each. Each brew group will use these programs.
This is the default mode.
If the machine has been set to individual program mode, there will be a separate page for the le and right
programs on each brew group. This allows the groups to use dierent programs. This mode can be selected
in the 2nd level menu. (See page 23)
Line 2 indicates program 1, acvated by a le shi of the group top handle and program 2, acvated by a
right shi of the group top handle.
Line 3 indicates the adjustable preinfusion values in seconds for the le and right programs. If the value is
adjusted to 0 seconds, the preinfusion stage will be skipped.
Line 4 indicates the adjustable ow count values. There are about 4.5 counts per milliliter of water dispensed.
Some of this dispensed water is absorbed and retained by the coee puck, but generally, if you add 9 counts,
you should receive 2 addional mL of water.
To cycle to the next display screen, press the down buon.
Menu Level 1: Programs
Menu: Steam Tank and Hot Water Tap
Please see next page for details.
