System Q ScatterBox POE154 User manual

Quick Start Guide - qPOE154 Copyright 2021 System Q Ltd
1
Full 1Gbps PoE Extender and 4 Way Switch
ScatterBox is a registered trademark of System Q Ltd
POE154 - Quick Start Guide
User Information
· The POE154 must be installed in a clean, dry environment
where it will not be exposed to high temperatures,
moisture or excessive dust.
· Do not touch the POE154 or any of its connections with
wet hands.
· There are no user serviceable parts in the POE154 and
opening or attempting to repair the product will void the
warranty.
· Do not install or use the device if the CAT5e/CAT6 Ethernet
Cables connected are damaged.
Use this on the end of a PoE circuit to create 4 more full 1Gig ports each with PoE. This means you don't
need a local PSU for the switch.
The extender an also be powered by 12V and act as a normal 1Gbps 4 way switch non-PoE.
How It Works
The POE154 is easy to install into an IP CCTV system as shown below. It can be installed at the end of a
100 meters network cable to extend the network and PoE supply by 100 meters at full speed.
Connections
Connect the PD INPUT on the POE154 to a network switch using a CAT5e/CAT6 Ethernet Cable
terminated into an RJ45 plug.
Connect a CAT5e/CAT6 Ethernet Cable into ports 1 - 4 and connect the load device or devices, such as
an IP camera. Ports 1-4 support single-port PoE power up to 30W.

Quick Start Guide - qPOE154 Copyright 2021 System Q Ltd
2This symbol indicates that equipment must not be mixed with general household waste. For treatment, recovery and recycling please return to your local designated
WEE/CG0783SS collection point as defined by your local council.
All specifications are approximate. System Q Ltd reserves the right to change product specificationsor features without notice. Whilst every effort is
made to ensure that these instructionsare complete and accurate, System Q Ltd cannot be held responsible for anylosses, no matter how they arise,
from errors or omissionsin these instructions,or the performance or non-performance ofthe equipment refered to.
Full 1Gbps PoE Extender and 4 Way Switch
ScatterBox is a registered trademark of System Q Ltd
LED Status Indicators
Input / Output
LED
Condition
Status
PD INPUT
Network Link
On
The port is connected
Off
No connection to the port
Flashing
The port is transmitting or receiving data
POE
On
The port is linked and receiving power
Off
The port is not receiving power
Ports 1 - 4
Network Link
On
The port is connected
Off
No connection to the port
Flashing
The port is transmitting or receiving data
POE
On
The port is linked and providing power to a device
Off
The port is not providing power to a device
Troubleshooting
Problem
Possible Cause
Solution
No Power light on
Switch
No power to the device
Check power to device from external source. Check that
the power lead (IEC lead) is plugged in to the PSU and
the PSU is plugged into the switch.
Loose connection
Check that the power lead (IEC lead) is plugged in to the
PSU and the PSU is plugged into the switch.
Network light not
flashing
Poor quality cable or
termination
Check the Ethernet cabling to your device is of good
quality and is terminated correctly.
No PoE on
connected device
Poor quality cable or
termination
Check the Ethernet cabling to your device is of good
quality and is terminated correctly
Total power
consumption exceeded
Check the load devices are not above the total power
consumption of the switch.
Cable length
Check the distance of Ethernet cable to your device.
Ethernet cables have a 100m maximum length.
Slow flashing LEDs,
No Network or PoE
on load devices
Faulty cable or device
Turn the power off to the switch & unplug the load
devices (Check Ethernet cabling to load devices). Leave
the switch turned off for 10 seconds and then power the
switch back up, plug each device back into switch
individually to help troubleshoot the suspect cable.
Specification
Output Connection
4 x RJ45
Input Connection
1 x RJ45
Max Cable Output
100m
Max Input
60W (IEEE 802 3BT)
Power
30W per port (60W Whole device maximum)
Bandwidth
10/100Mbps/Full Gigabit
Use
Internal Use Only
Power
PoE / 12V DC
Dimensions
H) 28 x (W) 120 x (D) 86mm
