Sytech SY-4099 User manual

1
Warning:To reduce therisk of fireor electric shock,do not exposethis apparatus torain
or moisture.
1) Please readthe instruction manualcarefully and followall the requirementsof safe
operation to operatethe device.
2) Do notuse this unitnear water.Donot place theunit over anycontainer with liquid
inside.
3) Do notinstall near anyheat sources suchas radiators,heat registers,stoves,orother
apparatus(including amplifiers)that produceheat.
4) Unplug thisunit during lightningstorms or whenunused for longtime.
5) AboutCleaning:Unplug the system,useonly wet clothto clean.Do notuse liquid
detergent or aerosol.
6) Only useaccessories specified bythe manufacturer.
7) Refer allservicing to qualifiedservice personnel,servicing isrequired when theunit
has been damagedin any way.Such as powersupply cord orplug damaged, liquid
spilled or objectsfalling into theunit,exposed to moisture,notoperating normally.
Don't try torepair the machineby yourself becauseof the dangerof high voltageand
electric shock.
8) Do notuse irregular shapeddiscs such asheart or star-shapeddiscs as theymay
cause to theunit malfunction.
Hi-voltage, Don't Openit
Remind user to be careful to
avoid electric shock
Thank you forchoosing our portableDVD player.Theunit applies thelatest state ofart
electronics and isdesigned for useat home,in hotelsand in officesetc for relaxation.
The compact sizemakes carrying easieras well asinstallation.Please read themanual
carefully prior touse and keepit well forfuture reference.
Table Of Contents
Safety Precaution 1
Package 2
Main Features 2
Main Unit Controls 3
System Connection 4
The Remote Control 6
Basic operation 8
System Setup 16
Specification 20
Troubleshooting 21
Safety Precaution

32
High brightness color9”LCD screen
Compatible with discof DVD,VCD,MP3,MPEG4,CD,JPEG,etc
Built-in stereo speaker
Built-in rechargeable Lithiumpolymer battery
Support PALor NTSC system
Support Multi-language OSD,speedforward/backward,repeat function
Zoom in/out function
Main Unit Controls
Package
Main Features
1
1
1
1
1
1
Remote Control withbattery
AC/DC Power Adapter
Cigarette LighterAdapter
User Manual
Earphone
DVD Player
1. USB Port
2. SETUP button
3. MENU button
4. MODE button
5. TITLE button
6.
7. OK button
8.
9. PLAY/PAUSE button
10. STOP button
11. DC IN9-12V
12. Power ON/OFF switch
13. AVOUT
14. Earphone jack
15. Volume knob
16. SD card slot
17. Open and close knob
( )/
( )/( )
( )
1
2
3
4
5
9
10
11
12
13
14
15
16
17
7
6
8

5
4
Note:
1.Car cigarettelighter adaptor isnot recommended torecharge the battery.
2.Car cigarettelight adaptor canonly be usedwhen the carpower supply is9-12V.
3.The mains plugis used asthe disconnect device,the disconnect deviceshould remain
readily operable.
Powering and installation
Plug one endof theAC/DC power adaptorinto the DCIN 9-12V jackon the rightof the
unit, then plugthe other endinto theAC power receptacle.Please refer tothe following
illustration.
If using carcigarette lighter adaptorto connect tothe power:
Plug one endof the cigarettelighter adaptor intothe DC IN9-12V jack onthe unit, plug
the other endinto the carcigarette lighter socket.See illustration below.
System Connection Connecting with externalSpeaker
The unit canbe connected withexternal speaker.Pleasesee the followingillustration.
AMPLIFIER
TV
SUBWOOFER
Left front speaker Right front speaker
Center speaker
Left rear speaker Right rear speaker
Note:
There is no5.1 channel inthe unit, however,after connecting toAPM itis available to output
audio in 5.1channel.
AUDIO INVIDEO IN
AV CABLE
Not supplied

76
1. Number button
2. TITLE(To display title information)
3. AUDIO(To select audiolanguage)
4. SETUP(To go to or exit setup menu)
5. Previous/Next button(To go
to previous/next chapteror scene
during playing)
6. Fast forward/backward
button(Toscan forward/backward
at 2,4,8,16,or 32times)
7. OSD(To display disc information
during playing suchas elapsed and
remaining time)
8. PLAY/PAUSE
9. STOP(press oncetostop playback,then
press to resumeplayback from the
point where youstopped; press stop
button twice tostop playback completely)
10. MODE(To select the source)
The Remote Control
11. ZOOM(To zoom in/outthe image
during the playback)
12. MENU(To enter or exit root menu)
13. SUBTITLE(To select subtitle language
when playing DVDdisc)
14. ANGLE(To change viewingangle
when playing discwith multi-angle)
15. A-B(Repeata specific portionfrom
point Ato B, pressit again tocancel
repeat playing)
16. REPEAT(To repeat playingtitle,
chapter or track)
17. RETURN(To return to the main menu)
18. MUTE(To turn to mute)
19. VOL +/- (To adjust thevolume)
20. ENTER(To confirm)
RC-M42E
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
CR2025 CR2025
Please put thebattery into theremote control asper below illustration.
When using remotecontrol,make sure theinfrared window ispointed to infraredreceiving
window of themachine.The distance betweenmachine and remotecontrol must bewithin
3 metres.Please referto the followingillustration.
The Use ofRemote Control
RC-M42E
Note:
1. To avoid falling off or placenear damp environment.
2. To avoid infrared receiving window of the unit being under direct sunlight.
3. Please usea new batteryto replace oldone if theremote control doesn'twork.

98
Basic Operation
RC-M42E RC-M42E
Playing disc ofDVD, MPEG4, SVCD,VCD, CD, MP3.
1.
2. Open thedisc door andinsert a discinto the doorwith the labelside facing up.
3. Close thedisc door.Theunit will loadthe disc andstart playing.
4. Press“ ”once to stop playback;press“ ”to resume playback from the point
where you stopped;press“ ”twice to stop playback completely.
5. During playback,press“ ”to pause; press it again to resume playback.
6. When the playingis finished, pleaseturn off thepower by slidingON/OFF switch toOFF.
7. For someDVD disc withTitle orChapter menu, press“MENU”button to entermenu
page, and use“ ”to select. PressENTER to confirm.
DVD MPEG4 SVCD VCD CD MP3
Note:
Please do notdisconnect USB devicesor plug outSD/MMC cards whilethey are working
with the unit.Functionalfailure may occurin case ofwrong operations.
In the SourceMode,you can press to select and ENTER key to enter the
source you want.
“ ” “ ”
DVD SD USB
Play/pause
Cursor button
ENTER
Title Menu
RC-M42E
DVD MPEG4 SVCD VCD CD
2X 4X
8X16X32X
2X 4X
8X
16X32X
Search forward
When playing discof DVD,MPEG4,SVCD,VCD,CD, themachine can searchforward or
backward.
1. Press“ ”,the unit will search forward. Press it repeatedly ,the machine will play
at 2, 4,8,16, 32 timesof speed.
2. Press“ ”, the unit will search backward.
Press it repeatedly,the machine will play at
2,4,8,16,32 times ofspeed.
When playing discof DVD,MPEG4,SVCD,VCD,CD,MP3,user canrepeat playing one
chapter, titleor the wholedisc.
For DVD disc,press“repeat”button,user can repeat playing one Chapter;press it
again to repeatplaying Title;pressit the thirdtime to repeatplaying the wholedisc.
For MP3 disc,press“repeat”button to repeat playing present file;press it again to repeat
playing the folder;pressit the thirdtime to cancelrepeat function.
Search backward
Chapter Title All
Repeat off
one folder
Repeat off
Fast forward andfast backward
Repeat playing
Track All Repeat off
For CD/VCD disc,press repeatedly to repeatthe track andthe whole disc.“repeat”button
MP3
VCD
SVCD
MPEG4
DVD CD

10 11
When playing discof DVD,MPEG4,SVCD,VCD,CD,MP3,user canrepeatedly play a
specific section.
During playback,press“A-B”button at a point A,then press
this button againin point B,theunit will automaticallyrepeat
playing the partbetween“A-B”
Press it thethird time,the unitwill return tonormal playback.
AB
A
During playing DVDdisc with multi-angle,press“Angle”button to changethe display angle.
Repeat playing offavorite scene
Angle
A-B
Angle
Number
RC-M42E
Note:
The function isavailable only fordiscs with multi-angle.
2X
3X
4X
1 /2X
1 /3X
1 /4X
During playback,press“Zoom”button,the image will be
enlarged;press it againthe image willbe enlarged again;
press it fourthtime,the image willzoom out,press it
repeatedly and theimage will returnto normal status.
Zoom in/out
When the imageis enlarged,user canpress“ / / / ”to move theimage.
Zoom in/ out
When playing discof DVD,MPEG4,SVCD,VCD,user can
zoom in orzoom out theimage.
MP3
VCD
SVCD
MPEG4
DVD CD
DVD
SVCD
DVD MPEG4 VCD
Mp3
......
\Ctyy\
00 36 03 43
Dir 001
Mp3
TRACK02
TRACK01
Mp3
Mp3
TRACK03
Playing JPEG filein data disc
Playing MP3 filesin data disc
Place MP3 discinto the discdoor. Press“ ” or“ENTER”button to choosean MP3
file;Press “ ”or“ENTER”button to playthe file selected.
TRACK05
Mp3
TRACK04
1. Place aJPEG disc intothe tray,the unit will start reading and play.
2. Press“ ”to select aJPEG file andpress“ENTER”button to confirm.
Note:you can press“MENU” to returnto the folderlist.Press “ ”or “ENTER” to
preview the fileselected.
3. To rotate thepicture counter-clockwise,press “ ”;Press “ ”to rotate the picture
clockwise.
4. Press OSDbutton when viewingpictures,you can selectdifferent refresh modeas
follows:
1. from topto bottom
2. from bottomto top
3. from leftside to rightside
4. from rightside to leftside
5. from lefttop to rightbottom
6. from righttop to leftbottom
7. from leftbottom to righttop
8. from rightbottom to lefttop
9. from horizontalcenter to bothsides
10.from vertical centerto both sides
11.from topand bottom to center
12.from right andleft to center
13.from four window'stop side tobottom side
14.from four window'sleft side toright side
15.from 4 edgesto center
5. During viewingfiles,“ ”may appearwhen pressing“Angle”or“Subtitle”or “Audio”
or“A-B”or“Title”etc; inthis situation theseoptions are unavailableto operate.
6. When viewingJPEG files,press“ ”,pictureswill be displayedin thumbnail mode,
press “ ” or “ENTER” buttonto select onepicture to view.

12 13
SD/MMC/USB main menu
After entering theSD/MMC or USB,thesystem will showMain Menu whichincludes 4
Function ICONS.You can selectthem by and press key to confirm.“ ” “ENTER”
Photo Mode
Please refer toP14 -15 fordetail explanation
Browser Mode
Please refer toP14 for detailexplanation
Music Mode
Please refer toP15 for detailexplanation
Movie Mode
Please refer toP16 for detailexplanation
Note:Media cards formattedin exFAT file systemare not supported.
00 00 03 43
001/008
\Ctyy\
......
Mp3 TRACK01
Mp3 TRACK02
Mp3 TRACK03
Mp3 TRACK04
Mp3 TRACK05
Browser mode
Photo mode
Slide Show Menu Prev Next
In the PhotoMode,the System willshow the thumbnailMode first.
, , , , :select and play.
Slide Show:play theJPEG.
Menu:Enter the HelpMenu.
Prev:Page Up.
Next:Page Down.
“ ” “ ” “ ” “ ” “ENTER”
In the BrowserMode,the system willshow the listof file andfolder.
, , key:select and play
:Enter the folder
:Quit the folder
Note:
If you wantto return tothe Main Menu,pleasemake sure thesystem is inlist of fileor
folder status,then press RETURN KEY.
“ ” “ ” “ENTER”
“ ”
“ ”
“”

14 15
1. from topto bottom
2. from bottomto top
3. from leftside to rightside
4. from rightside to leftside
5. from lefttop to rightbottom
6. from righttop to leftbottom
7. from leftbottom to righttop
8. from rightbottom to lefttop
9. from horizontalcenter to bothsides
10.from vertical centerto both sides
11.from topand bottom to center
12.from right andleft to center
13.from four window'stop side tobottom side
14.from four window'sleft side toright side
15.from 4 edgesto center
When playing JPEG:
1.Torotate the picturecounter-clockwise,press “ ”;Press“ ” torotate the picture
clockwise
2. Press OSD buttonwhen viewing pictures,youcan select differentrefresh mode as
follows:
In the MusicMode,the system willshow the listof music file,likeMp3 and soon.
Press , , ,select and play.
Press to fast forward/backward MP3 duringplaying.
Press to select thefunction button whenin stop status.
Page-:Page Up.
:play
Page+:Page Down
Note:Press Return Key to Returnto the MainMenu.
“ ” “ ” “ENTER”
“ ”
“ ” “ ”
“”
Music mode
00 00 03 43
001/008
Repeat Off
Mp3 TRACK01
Mp3 TRACK02
Mp3 TRACK03
Mp3 TRACK04
Mp3 TRACK05
128Kbps
PP
3. During viewingfiles,“ ”may appearwhen pressing“Angle”or“Subtitle”or“Audio”
or“A-B”or“Title”etc;in thissituation these optionsare unavailable tooperate.
4. When viewingJPEG files,press“ ”and“RETURN”key,pictures will bedisplayed in
thumbnail mode,press“ ”or“ENTER”button to selectone picture toview.
Note :
If you wantto return theMain Menu, pleasepress“RETURN”key in thethumbnail mode.
In the MovieMode,the system willshow the listof Movie file,likeAVIand so on.
, , Key:Select and Play.
When playing movieyou can press MENU and Return Key to back to the list of movie
file status.And ifyou want toReturn to theMain Menu,Please Press Return key in list
of Movie filestatus.
“ ” “ ” “ENTER”
“”“ ”
“”
Movie mode
001/006
AVI TRACK01
TRACK02
TRACK03
TRACK04
TRACK05
TRACK06
AVI
AVI
AVI
AVI
AVI
During playing theCD/HDCD disc,you canenter CD Rippingfunction.By pressing
subtitle button,DVD playerwill be ableto change theCD format intoMP3 format,
and then storeit in theUSB or SDcard.
CD RIPPING
CD RIP
Options Track
Track 01 03:36
SUMMARY
Selected Track 0
Selected Time 00:00
Track 02 03:36
Track 03 03:36
Track 04 03:36
Track 05 03:36
Track 06 03:36
Track 07 03:36
Speed Normal
Bitrate 128kbps
Create Id3 Yes
Device USB 1
Start Exit All None

16 17
CD RIP
Ripping Selected track
Track Progress
Total Progress
Track 01 9%
Cancel
SUMMARY
Now ripping
Track 01/01
During the converting,youcan select “CANCEL”to stop it.
Speed: In this item,you can setthe rip speed:Normal or Fast.
Bitrate: In this item,you can setthe bitrate. Ithas 6 choices,128Kbps,192Kbps,256Kbps,
320Kbps,96Kbps and 112Kbps.
Create ID3:In this item,you can createID3 when playingCD text.
Device: This item indicateswhether USB orSD CARD isconnected with DVDplayer.
Exit: Exit to theprevious menu.
All: Select all thefiles in thedisc for convertionand storage.
None: Cancel the .
Start: Move the cursorto the itemand press “ENTER”button, the convertionbegins.
selection
System Setup
Press SETUP button,the main menuwill be
displayed on thescreen
In the main Page,Press button to
highlight the item.
Press ENTER button to access.
Press “SETUP”button to exit.
“”
“ ”
“”
General Setup
Video Setup
Preference Setup
Setup Menu -- MainPage
General Setup Page
General Setup
TV Display Wide
Angle Mark ON
OSD Lang ENG
Screen Saver ON
On
Off
:Move :Return :Entry
Angle Mark:
Enter this optionto set the angle during
playback.
Optional setting:ON,OFF
The default is:ON
General Setup
TV Display Wide
Angle Mark ON
OSD Lang ENG
Screen Saver ON
English
French
German
Italian
:Move :Return :Entry
OSD Language:
In the optionuser can setOSD menu
language(English,French,German,Italian).
The default:English
TV Display Wide
Angle Mark ON
OSD Lang ENG
Screen Saver ON
On
Off
:Move :Return :Entry
General Setup
Screen Saver
Enter this option toset whether to activate
the screen saverfunction.
The default isON.
TV Type:
Enter this optionto select TV type(PAL,NTSC)
The default isPAL.
Video Setup
:Move :Return :Entry
Quality
Panel Quality
TV Type PAL PAL
NTSC

18 19
Video Setup Page
Video Setup
:Move :Return :Entry
TV Type PAL
Set the VideoQuality of AV OUT
Video Setup
:Move :Return :Entry
TV Type PAL
Set the VideoQuality of PANEL
Quality
Panel Quality
Quality
Panel Quality
Preference Page
Audio:
Enter this option,usercanselectpreferred
audio language for DVDs.
The default isEnglish.
Note
The audio languagedepend on the material
on each disc.
User can alsochange the audiolanguage
durin g playback by pressing theAudiobutton.
Preference Setup
:Move :Return :Entry
Audio ENG
Subtitle Off
Disc Menu ENG
Parental
Default
English
French
German
Italian Default:
Select this item andpress button to
reset.
ENTER
Preference Setup
:Move :Return :Entry
Audio ENG
Subtitle Off
Disc Menu ENG
Parental
Default Reset
Preference Setup
:Move :Return :Entry
Audio ENG
Subtitle Off
Disc Menu ENG
Parental
Default
English
French
German
Italian
Off
Disc Menu
This function allowsyou to choosethe menu
language stored on thedisc.
The default isEnglish.
Note:the disc menulanguages depend onthe
information available on thedisc.
Parental:
Enter this optionto set theparental control
level to someunsuitable disc scenesbeing
watched by thechildren.
Optional parental control levels:KID SAFE,
G, PG,PG 13,PGR,R, Nc17,ADULT.
The default isADULT.
The default password:8888.
:Move :Return :Entry
Audio ENG
Subtitle Off
Disc Menu ENG
Parental
Default
English
French
German
Italian
Preference Setup
1 KID SAFE
2 G
3 PG
4 PG 13
5 PGR
6 R
7 NC 17
8 ADULT
:Move :Return :Entry
Audio ENG
Subtitle Off
Disc Menu ENG
Parental
Default
Preference Setup
Subtitle
Select your preferredlanguage to showthe
subtitles on thescreen.
The default is OFF
The subtitle languagesdepend on the
information available oneach disc,Youcan
also change thesubtitle language during
playback by pressthe SUBTITLE button.

20 21
The machine utilize s long-life Li polymer battery for portable power supply.Thebattery has
no Memory Effect”and thus can be recharged safely regardless of whether the battery
is fully orpartially discharged.It's enoughto recharge nolonger than 3Heach time,fully
recharged battery canlast about 2hours with earphone.
“
The battery canbe only rechargedwhen turning powerto OFF state,and keep continuous
power supply,the red light will be on,and the light willturn yellow whenit's fully charged.
1. The normalworking temperature is:0 ~40 ;
2. Alwaysunplug AC/DCpower supply forthe unit whennot in use;
3. Heat willcreate during playing,it'snormal,while avoid longtime playing and
unattendance;
4. Avoidhaving the unit collide with anyobjects,and place awayfrom all possibleheat
sources or dampareas.
Caution:Danger of explosionif battery isincorrectly replaced. Replaceonly with the
same or equivalenttype.
°C °C
Using and MaintainingRechargeable Battery
Specification
Precautions related toBattery Recharge
Rechargeable battery use
Compatible disc: DVD/VCD/CD/MP3/MPEG4
Signal system: PAL/NTSC
Panel size: 9inch
Frequency response: 20Hz to 20kHz
Video output: 1Vp-p/75Ohm, unbalanced
Audio output:1.4Vrms/10kOhm
Audio S/N:Better than 80dB
Dynamic range: Betterthan 85dB
Laser: Semiconductor Laser, WaveLength: 650nm/795nm
Power source: DC9-12V
Power consumption: 10W
Operating temperature: 0~40°C
Weight: 0.85kg
Dimensions : 233.5x 175x 43mm
Battery Type:Li Polymer
Note:
1.The quality andspeed for readingJPEG photos depend on the resolution and
compression ratio ofthe photos. SomeJPEG photo maynot be played due to the disc
quality and theformats.
2.Some DVD+R/RW,DVD-R/RW,CD-R/RW discmay not beplayed due tothe quality on
burning conditions.
Troubleshooting
PROBLEM SOLUTION
Picture is distorted
If at anytime in thefuture you shouldneed to disposeof this productplease
note that wasteelectrical products shouldnot be disposedof with household
waste.Please recycle wherefacilities exist.Check withyour LocalAuthority
or retailer forrecycling advice.(Waste Electrical and Electronic equipment
Directive)
Owing to continuousimprovement,no prior noticewill be givenregarding changes on
above feature andspec.
Some discs havesections that prohibitrapid
scanning or chapterskip;If you tryto skip
through the warninginformation and credits
at the beginningof a movie,youwon't be able
to.This part ofthe movie isoften programmed
to prohibit skippingthrough it.
No forward or
reverse scan
The disc mightbe damaged.Try another disc;
it is normalfor some distortionto appear during
forward or reversescan.
The feature oraction cannot becompleted at
this time because:
1.The disc's softwarerestricts it.
2.The disc's softwaredoesn't support the
feature (e.g.,angles)
3.The feature isnot available atthe moment.
4.You've requested a title or chapter number
that is outof range.
The icon
appears on
screen
You can't advance through the opening credits
and warning informationthat appears atthe
beginning of moviesbecause the discis
programmed to prohibitthat action.
Can't advance
through a movie
Make sure themachine is connectedproperly.
Make sure allcables are securelyinserted into
the appropriate jacks.
No sound or
distorted sound

DECLARATIONOF CONFORMITY
Manufacturer: Satyatrade S.L.
Address: Pol. Ind.La Raya. C/Guadalquivir, 2.
Camarma de Esteruelas,28816 Madrid
Tel:[phone]
Fax: [phone]
NIF: B83254763
Manufacturing country: China
Description: Portable DVDplayer
Sytech® SY-4099 complies with the following directives:
CE Standard: Directive2004/108/EC
LVD Standard: 2006/95/EC
RoHS Standard: 2011/65/EU. Restriction ofhazardous substances
Signed: AjeetNebhwani Utamchandani
SoleAdministrator
