Sytech SY-X1232BT User manual

WELCOME
ThankyouforpurchasingthenewSytechBluetoothHeadsetSY‐X1232BT.PleasetheseOperatingInstructionsthrough
carefullybeforeusingthedevice,inordertoavoiddamageduetoincorrectuse.Pleasepayparticularattentiontothe
safetyinformation.Ifyoupassthedeviceontoathirdparty,theseOperatingInstructionsmustalsobehandedover.

OVERVIEW
















WHAT'SINTHEBOX

ITEMSDETAILS
Bluetoothearphones1X
MicroUSBcable1X
Eartips2Xinstalled;4Xbackup
Earhooks2X
Usermanual1X


HOWTOCHARGE
1.ThebatteryislowwhentheLEDindicatorshowsablinkingredlight,pleasechargeit.
2.Forcharging,pleaseconnecttheunittoareliablepowersourcewiththeMicroUSBcableincludedinthepackage.
Whilecharging,theLEDindicatorwillshowasolidredlight.
3.Thestandardchargingtimeis1.5hours.Whenchargingcompletes,theLEDindicatorwillshowasolidbluelight.
Notice:
PleasekeepyourUSBportdryandclean.Pleasedonotchargeyourdevicerightafterexercisinginpreventionofelectricity
leakagecausedbyremainingsweat.

HOWTOPAIR 
1.Turntheunitoffandwaitforaround3seconds,thenholdthemulti‐functionbutton"M"for8secondsuntiltheLED
indicatorblinksalternatingbetweenred&bluelight.
2.Searchfor"SY‐X1232BT"onyourBluetoothdevicemenuandclickonittopair.
3.PairingissuccessfulwhentheLEDindicatorshowsasinglebluelightblinkevery5seconds.


LEDINDICATION

COLORSTATUSINDICATE
RedBlinkingLowbattery
RedSolidCharging
BlueSolidChargingcomplete
BlueandRedAlteringBlinksPairing
BlueBlinkevery5secondsConnectedsuccessfully

OPERATION

BASICOPERATION
FunctionOperationSignal/Prompt
PoweronPressandholdthe"M"button
for4seconds
Violetlightstaysfor1second;
Audio
PoweroffPressandholdthe"M"button
for4seconds
Violetlightstaysfor1second;
Audio
PairingPressandholdthe"M"button
for8seconds
Alternatingred&bluelight;
Audio
Connected Singleblueblinkevery5
secondswhenconnected;
Audio
Autoreconnect
ManualreconnectPressthe"M"button

MUSICFUNCTION
FunctionOperationSignal/Prompt
Play/PausePressthe"M"buttonAudio
VolumecontrolPressthe"+"/"‐"buttonAudio(atmax)
PreviousorNextPress&holdthe"+"or"‐"
buttonfor2seconds
Audio

CALLFUNCTION
FunctionOperationSignal/Prompt
AnswerorEndPressthe"M"buttonAudio
RejectLongpressthe"M"buttonAudio
RedialQuicklydoubleclickthe"M"
button
Audio
CallswitchLongpressthe"M"button
duringacall
Audio








TROUBLESHOOTING

ProblemPossibleCauseSolution
Can'tturnon LowbatteryCharge
Can'tfindinlist OutofrangeBringcloserandreconnect
NomusicorcallvoiceDisconnectornotinBluetooth
phonemode
Reconnectorswitchto
Bluetoothphonemode

SPECIFICATIONS
BluetoothVersion:V4.1
BluetoothProfiles:A2DP/HFP/HSP/AVRCP
TransmitPower:Class2
TransmissionDistance:>10M
FrequencyRange:2.402‐2.480GHz
TalkingTime:Around6hours
MusicTime:Around6hours
StandbyTime:Around240hours
MicSensitivity:‐45±3dB
Multipoint:Support2phonesconnection
SpeakerDiameter:9mm
SpeakerImpedance:16OHM
SpeakerRatedpower:5mW(MAX:10mW)
SpeakerFrequencyResponse:50Hz‐15KHz
SpeakerS.P.L:98dB±3dB
Connection/Charge:MicroUSB
Chargetime:Around1.5h
Battery:Polymerbattery:3.7V/80mAh
Output:10mW*2

MULTI‐CONNECTION
1.SuccessfullypairtheunitwiththefirstBluetoothdevice,thenturnofftheunitandBluetoothfunctionofthepaired
device.
2.Turnontheunitagain,andnowpairitwiththesecondBluetoothdevice.
3.TurnontheBluetoothfunctionofthefirstdevice,andpairitonceagainwiththeunit.
4.TheSY‐X1232BTisnowmulti‐connectedwithbothBluetoothdevices,andeasilyswitchable.
Notice:Bluetoothconnectionprioritymayexistduetothedifferencebetweendevices.

STORAGEANDMAINTENANCE
1.Storage:
Storeyourproductincoolanddryplace.

2.Maintenance:
a.Therecommendedworkingtemperaturerangeis0‐45℃(32‐113℉);overhot/cold/humidenvironmentmaybadly
reducetheproductbatterylifeandharmtheoverallperformance.
b.Avoidusingtheproductduringalightingstorm.
c.Pleasechargeyourunitfirstbeforeusingthedeviceafteralongwhile.
d.Cleantheproductwithapieceofdrycloth.
e.Ifremainingwater/sweatisfoundinsidetheUSBport,simplydryitwithasoftcloth.
f.Keeptheproductawayfromsharpedges/points.







DECLARATIONOFCONFORMITY
ManufacturerName:SatyatradeS.L.
Address:Pol.Ind.LaRaya.C/Guadalquivir,2.
CamarmadeEsteruelas,28816Madrid
Tel:902430967
Fax:918864285
NIF:B83254763
Manufacturingcountry:China
Description:SportsEarphones
Sytech®SY‐X1232BTcomplieswiththefollowingdirectives:

CEStandard:Directive2014/53/EU
RohsStandard:Directive2011/65/EU

Signed:AjeetNebhwaniUtamchandani
SoleAdministrator

