Sytech SY-1673 User manual

SY·1673
POCKET RADIO
USER
MANUAL

Welcome
Thank you for purchasing the new AM/FM Radio SY-1673. Please read this manual carefully before operating your
product and pay close attention to the precautions, which are mentioned below. Store this user manual in a safe
place for future reference
Contents
Radio User Manual Earphone
Parts of the SY-1673
1- Earphone input. 3.5mm
2- Dial scale
3- Volume knob
4- Tuning knob
5- Band selector
6- On/Off – X-Bass filter
7- Tuning indicator
8- Battery compartment
Precautions
•Avoid exposure to extreme temperature, direct sunlight, moisture, sand, dust, or mechanical shock; never
leave the unit in a car parked in the sun.
•In vehicles or in buildings, radio reception may be difficult or noisy, Try listening near a window.
•If there is lightning when you are using this unit, take off the headphone immediately.

Hearing safety
Caution
To prevent possible hearing damage, do not listen at high volume levels for long periods, Set the volume to a safe
level. The louder the volume, the shorter the safe listening time.
Be sure to observe the following guidelines when using your earphone.
•Listen at reasonable volumes for reasonable periods of time.
•Be careful not to adjust the volume continuously upwards as your hearing can be damaged
•Do not turn up the volume so high that you cannot hear around you.
•Excessive sound pressure from earphones and headphone can cause hearing loss.
Installing the battery
1- Open the battery compartment and insert 2 pcs “AAA” / “UM4” size battery into the compartment following
the correct polarity. (Batteries are not included)
Notes on the battery
•When the sound gets distorted or unstable, replace the batteries.
•To avoid damage from battery leakage and corrosion, remove the battery when you do not use the unit for a
long time.
•Do not mix different types of batteries or old and new batteries.
Radio function
•Before switching on your radio, make sure the volume is set to a low level.
• Slide the On/Off button (6) to the On position.
• For Bass Enhancement, slide the On/Off button to “Bass”
• Select the desired band AM – FM or FM stereo by sliding the button (5).
•Tune the desired frequency by rotating the “TUN” knob (4).
•The Tuning light indicator will turn on once the radio station is heard clearly and without interference.
Tips: For a better reception in FM, extend the earphone cable.
For a better reception in AM, rotate the unit horizontally to improve the signal strength.

Selecting the band
•Slide the band selector switch located on the side of the radio.
Note: During operation, the product may have radio interference which is caused by electromagnetic waves
such as y mobile phones, TV, Neon light, etc.. Use the radio keeping in mind there is enough separation
between the radio and the interfering appliances.
Main Specifications
• Frequency range: FM 88-108 MHz / AM 530- 1600 KHz
• SNR: 40 dB
• Earphone jack: 3.5mm output
• Earphone output power: 20mw
• Power supply: DC-3V. 2 x batteries “R03”- “AAA”
• Dimensions: 41(W) x 82(H) x 16(D) mm
• Weight: 33g (Batteries excluded)
Declaration of conformity
Manufacturer Name: Satyatrade S. L.
Address: Pol.Ind.La Raya. C/ Guadalquivir, 2.
Camarma de Esteruelas, 28816 Madrid
Tel: [phone]
Fax: [phone]
NIF: B83254763
Manufacturing country: China
Description: AM/FM Radio
Sytech® SY-1673 complies with the following directives:
EMC Standard: Directive 2014/53/EU
Rohs Standard: Directive 2011/65/UE Restriction of dangerous substances.
Signed: Ajeet Nebhwani Utamchandani
Sole Administrator
www.sytech.es
