T.D.S. C-4650-SUPER User manual

ASSEMBLY INSTRUCTIONS FOR
C-4650-SUPER LAT MACHINE
T.D.S. FITNESS EQUIPMENT
P.O. BOX 4189
ELMIRA, NY 14904, USA
607-733-6789
Page - 1 of 4

4650-SUPER LAT/ROW MACHINE
32” X 72” X 83.5” H - 220 lbs.
3
6A
6B
6D 6E
TOP
CABLE
HEAD
3
6C
7C
FRONT
POST
LOWER
CABLE
KNEE CATCH
SEAT
SEAT BKT
SEAT
MOUNT
7A
(2) FOOT
PLATE
1
1
BASE
5
KNEE
CATCH
MOUNT
1
7D
1
4
2
SPACER(2)
SPRING(2)
WEIGHT
CARRIAGE
6F
REAR POST
WEIGHT
BARS (2)
FREE
PULLEY
BKT
Page - 2 of 4

4650 SUPER LAT/ROW MACHINE
ASSEMBLY INSTRUCTIONS
THIS UNIT REQUIRES (2) 9/16 WRENCHES AND (2) 3/4 WRENCHES FOR ASSEMBLY. DO NOT TIGHTEN
HARDWARE UNTIL INSTRUCTED.
1). PUSH (3) 2 X 4 FOOT ONTO BASE. ATTACH REAR POST, FRONT POST, SEAT MOUNT AND (2) FOOT
PLATES WITH (8) 1/2 X 5 BOLTS (16) 1/2 FLAT WASHERS AND (8) 1/2 LOCKNUTS.
2). PUSH (2) BAR BUSHINGS INTO HOLES ON BASE. INSERT (2) WEIGHT BARS INTO BASE. PLACE (2)
SPRINGS AND (2) SPACERS ONTO WEIGHT BARS. PUSH (2) BAR BUSHING INTO WEIGHT CARRIAGE. PLACE
CARRIAGE ONTO WEIGHT BARS.
3). PUSH (2) POST BUSHINGS INTO HEAD. ATTACH HEAD TO FRONT AND REAR POST WITH (2) 3/8öX 3ö
BOLTS, (4) 3/8 FLAT WASHERS AND (2) 3/8 LOCKNUTS. SET UNIT ON LEVEL SURFACE AND TIGHTEN
HARDWARE.
4). ATTACH KNEE CATCH MOUNT TO FRONT POST WITH (2) 3/8 X 2 3/4 BOLTS, (4) 3/8 FLAT WASHERS AND
(2) 3/8 LOCKNUTS. TIGHTEN HARDWARE. INSTALL TURN POP PIN INTO MOUNT. PUSH (2) 4 X 8 CUSHIONS
ONTO KNEE CATCH. INSTALL (2) CHROME CAPS ONTO BARS. INSERT CATCH INTO MOUNT AND SET
HEIGHT WITH TURN POP PIN.
5). INSERT TURN POP PIN INTO SEAT MOUNT. ATTACH SEAT TO SEAT BRACKET WITH (2) 3/8 X 1 BOLTS AND
(2) 3/8 FLAT WASHERS. FINGER TIGHT. CENTER SEAT ON BRACKET AND TIGHTEN HARDWARE. DO NOT
OVER TIGHTEN. INSERT BRACKET INTO MOUNT AND SET HEIGHT WITH TURN POP PIN.
6). INSTALL (8) BRONZE BUSHINGS INTO PULLEY MOUNT HOLES IN HEAD.
6A). LOOP CABLE OVER PULLEY. ATTACH PULLEY TO HEAD WITH (1) 3/8 X 3 BOLT, (2) 3/8 FLAT WASHERS
AND (1) 3/8 LOCKNUT.
6B). LOOP CABLE OVER PULLEY. ATTACH PULLEY TO HEAD WITH (1) 3/8 X 3 BOLT, (2) 3/8 FLAT WASHER
AND (1) LOCKNUT.
6C). LOOP CABLE OVER PULLEY. ATTACH PULLEY TO (2) FREE PULLEY BRACKETS WITH (1) 3/8 X 2 BOLT, (2)
3/8 FLAT WASHERS AND (1) LOCKNUT.
6D). LOOP CABLE OVER PULLEY. ATTACH PULLEY TO HEAD WITH (1) 3/8 X 2 BOLT, (2) 3/8 FLAT WASHER
AND (1) 3/8 LOCKNUT.
6E). LOOP CABLE OVER PULLEY. ATTACH PULLEY TO SEAT WITH (1) 3/8 X 3 BOLT, (2) 3/8 FLAT WASHERS
AND (1) LOCKNUT.
6F). HOOK CABLE TO WEIGHT CARRIAGE.
7). PUSH BUSHING INTO HOLE ON BOTTOM OF FRONT POST.
7A). LOOP CABLE UNDER PULLEY. ATTACH PULLET TO SEAT MOUNT WITH (1) 3/8 X 3 1/4 BOLT, (2) 3/8 FLAT
WASHERS AND (1) LOCKNUT.
7B). LEAD CABLE THRU BUSHING IN BOTTOM OF FRONT POST. LOOP CABLE UNDER PULLEY AND ATTACH
PULLEY TO FRONT POST WITH (1) 3/8 X 2 BOLT, (2) 3/8 FLAT WASHERS AND (1) LOCKNUT.
Page - 3 of 4

7C). LOOP CABLE OVER PULLEY. ATTACH PULLEY TO FREE PULLEY BRACKET WITH (1) 3/8 X 2 BOLT,
(2) 3/8 FLAT WASHERS AND (1) 3/8 LOCKNUT.
7D). HOOK CHAIN TO BRACKET ON BASE. HOOK LOWER CABLE TO CHAIN.
8). FILL OPEN TUBES WITH (4) 2 SQUARE PLUGS, (1) 1 3/4 SQUARE PLUG, (2) 1 7/8 ROUND PLUGS
AND (2) 2 ROUND PLUGS.
HARDWARE LIST FOR 4650 SUPER LAT/ROW
(2) 3/8 X 1
(2) 3/8 X 2
(2) 3/8 X 2 3/4
(7) 3/8 X 3
(1) 3/8 X 3 1/4
(26) 3/8 FLAT WASHERS
(12) 3/8 LOCKNUTS
(8) 1/2 X 5 BOLTS
(16) 1/2 FLAT WASHERS
(8) ½ LOCKNUTS
(2) POP PINS
(2) CHROME CAPS
(2) SPRINGS
(6) POLE BUSHINGS
(1) POST BUSHINGS
(8) BRONZE BUSHINGS
(4) 2 SQUARE PLUGS
(1) 1 3/4 SQUARE PLUG
(2) 1 7/8 ROUND PLUG
(2) 2 ROUND PLUG
(3) 2 X 4 FOOT
Page - 4 of 4

4650-SUPER LAT/ROW MACHINE
PACKING LIST
BOX - 2 OF 2
WEIGHT
BARS 2PCS
REAR
POST
1 PC
FRONT
POST
1PC
SEAT 1PC
HARDWARE 1PC
LITERATURE 1 PKG
2 CABLES 1PKG
8 PULLEYS 1PKG

4650-SUPER LAT/ROW MACHINE
PACKING LIST
BOX - 1 OF 2
KNEE CATCH
MOUNT
KNEE
CATCH 1PC
FOOT
PLATE
2 PCS
4X8 CUSHIONS
2 PCS
WEIGHT CARRIAGE 1PC
SPACERS 2PCS
BASE 1PC FREE PULLEY
BRACKET 2PCS
SEAT
MOUNT 1PC
LOW
ROW
BAR 1PC
SEAT
BRACKET
1PC
HEAD 1PC
LAT BAR PC
