USER GUIDE
USER
GUIDE
VER 2.0.1
5
h
Edition
zThank you for purchasing this Drive Recorder.
zBefore using the Drive Recorder, please ensure that you
read and understand this USER GUIDE.
zPlease store this USER GUIDE in an easily accessible location.
z
Before connecting and installing
this Drive Recorder
please
5
Edition
z
Before
connecting
and
installing
this
Drive
Recorder
,
please
refer to the appropriate instruction manual for proper operation.

FCC
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class
This
equipment
has
been
tested
and
found
to
comply
with
the
limits
for
a
Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception which can be determined by turning the equipment off and
television
reception
,
which
can
be
determined
by
turning
the
equipment
off
and
on, the user is encouraged to try to correct the interference by one more of the
following measures:
-Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING
Any changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
3

SAFETY ADVICE
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER
-
SERVICEABLE PARTS INSIDE
NO
USER
-
SERVICEABLE
PARTS
INSIDE
.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Please make sure you follow the safety advice/instructions given in the user guide.
Caution
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Battery for RTC(Real Time Clock) inside
Caution
Damages due to production malfunction, loss of data, or other damages occurring while
Caution
Install the product where it does not block driver’s visibility and where there is
no airbag installed. This could cause an accident or might injure the passengers in
case of accident.
Battery
for
RTC(Real
Time
Clock)
inside
.
using this product shall not be the responsibility of the manufacturer. Although the
product is a device used for recording videos, the product may not save all videos in the
case of a malfunction. In the case of an accident, the sensor may not recognize the
shock when the impact is light and as a result it may not begin recording automatically.
Caution
When the impact is slight, such as a minor bump in the road, the G-Sensor
may not recognize the impact and as a result it may not begin recording
automatically Test and set your own G
Sensor level for your vehicle
WARNING:
TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
4
automatically
.
Test
and
set
your
own
G
-
Sensor
level
for
your
vehicle
.

GPS Reception
1. Activate the product in an area without large buildings
to im
p
rove GPS rece
p
tion.
pp
2. The temperature range for optimum operation of this
GPS receiver in your car is -10 ~ 50°C (14 ~ 122°F).
This commercial purpose GPS has an average range error of more
than 15 meters (49 ft)and the range error could be more than 100
meters (328 ft) due to environmental conditions like buildings,
roadside trees, etc.
3. When using the product for the first time or after a long
period of non use (more than three days), it may take a
little longer to recognize your current location.
It may take between five and thirty minutes to get GPS reception.
GPS reception may be impaired under the following circumstances.
1) If there is an object at the end of the GPS antenna.
2) If your vehicle has metallic elements on the windshields.
3) If equipment generating electromagnetic waves that interfere with the GPS
signal is installed in the vehicle e.g.: Other GPS devices such as a certain
tfil titdl MP3dCDl d l
t
ype o
f
w
i
re
l
ess ac
ti
va
t
e
d
a
l
arms,
MP3
an
d
CD
p
l
ayers an
d
camera a
l
arms
using GPS.
4) If you are using a receiver connected by cable, electric interference can be
avoided by simply changing the location of the receiver (antenna).
5) On heavily overcast or cloudy days, if the vehicle is in a covered location
such as under a bridge or raised roadway, in a tunnel, an underground
roadway or
parking area inside a building or surrounded by high
-
rise
roadway
or
parking
area
,
inside
a
building
or
surrounded
by
high
-
rise
buildings.
6) If GPS signal reception is poor, it may take longer to locate your current
position when the vehicle is moving than when it is stationary.
5

CONTENTS
You should have a set of the following items for each MotionTrak330 order.
1. MotionTrak330 unit
2. 4GB SD memory card
(The PC Viewer software is
in the provided SD card )
in
the
provided
SD
card
.
)
3. GPS Antenna module
4. Remote Controller
5. Audio/Video output cable
6. Power Cable
8. Wire Splice clip (5pcs)
7. Camera input cable
6
9. Sticker (double sided tape 1pc)
10. Velcro Sticker (1pc)

INTRODUCTION
FRONT
Audio/Video
Out
p
ut
REAR
SD Slot
SD Door
p
External MIC input
BUZZER
Internal Microphone Remote Control Input
GPS Input
Power Input &
Alarm (Car Signal)
7
Camera 1, 2 Input
GPS
Input
Alarm
(Car
Signal)
Input
(Turn left, Turn right,
Brake, Speed pulse)
Rear View
Camera Input

INTODUCTION
REMOTE CONTROLLER
Record LED
BLUE LED
Overwrite LED
RED LED
SHUTTER BUTTON
RED
LED
PLAY BUTTON
PANIC BUTTON
Audio Video Output Cable
Audio out 1
8
Video out 1 Video out 2
[Note] The same screen will be shown through the Video out 1 & 2.

INTODUCTION
Power & Car Signal Input
Red(+)
Black (Ground)
Yellow (Alarm3)
FUSE
250V 3A
Blue (Alarm1)
White (Speed pulse)
Green
(
Alarm2
)
()
9

FUNCTION (MAIN UNIT)
Automatic start
Make sure that peripherals including cameras are properly connected.
Turn on the vehicle power MotionTrak330 will be automatically started
Turn
on
the
vehicle
power
,
MotionTrak330
will
be
automatically
started
.
(Use the power cable provided.)
Event record
The Event recording will be started automatically by Motion detection
Notice : The unit will not start recording immediately after the power is
turned on. It takes around 1 minute for the built-in power backup system
to charge. Thereafter, the internal flash memory will be ready to record.
The
Event
recording
will
be
started
automatically
by
Motion
detection
,
Alarm1 to 3 or by the G-Sensor level.
The Panic recording can be started by pressing the [PANIC] button.
Normal record (Continuous record)
The Normal (continuous) recording will be automatically started after power on.
MotionTrak330 will not make a separate event file during the continuous
recording. It will mark the Event area as ‘Alarm1 to 3’, G-Sensor, Motion
detection or [PANIC] button in the continuous recording file which can be easily
detection
or
[PANIC]
button
in
the
continuous
recording
file
,
which
can
be
easily
searched for during playback.
Dual record (Event & Normal record)
If you set different record modes per camera, like camera1 set as Event record
and camera2 set as Normal record, then camera1 (Event record) will work
according to the record setting for example 10 frames per second recording.
However camera2 (Normal record) will record 1 frame per second, if there is no
event. If there is an Event, both cameras will record according to the record
Live screen on Monitor
MotionTrak330 will display the live screen on the monitor.
The camera channel can be changed using the information OSD.
(Refer to page 13)
Playback in the car
setting for example 10 frames per second recording.
10
Recorded files can be played back in the car.
PC Viewer Software
The software is pre-loaded on the SD card [pcsw] folder.

SD Memory Card Format
Remove the power first. Press and hold the [PLAYBACK] & [PANIC] button.
FUNCTION (MAIN UNIT)
Then connect the power.
Press and hold the [PLAYBACK] & [PANIC] more than 2 seconds after
booting. Then SD card initialization will start.
Once complete, all video & log files will be deleted and the configurations
will default to the factory settings.
Notice : PC Viewer software is pre-loaded on the SD card. Please ensure
you have installed the software to your PC before you format the card.
Built-in power backup (Super Capacitor)
When power to the unit is interrupted, MotionTrak330 creates the last file
using the internal Super Capacitor.
BLUE LED (RECORD)
The Blue LED shows the power is on.
The Blue LED blink during event recording.
RED LED (Overwriting)
The Red LED will be turned on when start overwriting.
Buzzer
“Beep” sound will occur when event/panic recording starts (this can be turned off
in the setting menu on the PC viewer, if required).
This also signals any system error
This
also
signals
any
system
error
.
VIDEO LOSS (warning)
“Beep” sound will occur continuously when video loss.
Check the camera and camera connection then turn off and on the unit to reset it.
And make sure the number of cameras you have connect before turning on the unit.
The number of cameras can be set in the settings menu on the PC viewer.
11

OPERATION
1. Make sure that the power cable is properly connected and turn on the car
power.
2. The Blue LED & Red LED will turn on and slowly blinking simultaneously
then the Blue LED will remain on.
The Blue LED light means the MotionTrak330 is now ready for the event
recording and has started Normal recording (Continuous recording).
3. The normal recording (Continuous recording) will be automatically started,
if it set up via your PC.
4. The event recording will automatically begin when triggered by Motion
Detection, Alarm1 to 3 or by the G-Sensor and will begin with one short
“Beep” sound.
5. The panic recording can be started by pressing the [PANIC] button.
Removing the SD memory card
Turn off the power and then check the Blue LED light. Once the Blue LED
light is off, take out the SD memory card.
Inserting the SD memory card
System Error Buzzer
Turn off the power and then check the Blue LED light. Once the Blue LED
light is off, insert the SD memory card.
System
Error
Buzzer
A “Beep” “Beep” sound will occur and the Blue & Red LED light will blink
simultaneously when there is a system error or the SD card is not inserted.
[Check the SD memory card when this occurs. To solve the problem, initialize
the SD card or if necessary replace the SD card].
12

OPERATION
Press [PLAY] button then the INFORMATION OSD (the summery of setting)
INFORMATION OSD
Press
[PLAY]
button
then
the
INFORMATION
OSD
(the
summery
of
setting)
will show up on the monitor as below.
CAM1 CAM2 CAM3
Activated
RecordMode Continue Continue Event
√√√√√√
System:NTSC
Quality:Super
Overwrite:ON
G‐SensorLevel:X:3,Y:3,Z:3
G‐SensorCalibration:
Firmware Version :2.0.0
Resolution:720X480
FPS:10
Audio:ON
√√
To change the live display channel, press [PANIC] button.
The INFORMATION OSD will be turned off automatically after 30 seconds.
To turn off the live view, press [PLAY] button or [SHUTTER] button.
Firmware

Version

:

2.0.0
CurrentTime:14:50:0707JUL2011
LIVE VIEW
Turn on the MotionTrak330 and press [PLAY] button to turn on the
INFORMATION OSD (the summery of setting) . To change the live display
channel, press [PANIC] button to select the camera.
And then press [PLAY] or [SHUTTER] button to escape.
13
Camera 1 => Camera2 => Camera3 => 3 Cameras together =>

OPERATION
G-Sensor Calibration
G
-
Sensor Calibration is needed after installing the MotionTrak330 to
detect
G
Sensor
Calibration
is
needed
after
installing
the
MotionTrak330
to
detect
the installed direction of the MotionTrak330 to accurately record the journey
direction.
Press and hold [PANIC] & [SHUTTER] button together and then power on
the G-Sensor Calibration screen will be displayed.
Pressandholdpanicandshutterbutton
simultaneouslymorethan2secondsforcalibration.
Press any single button to escape
Press

any

single

button

to

escape
.
Parkvehicleonaflatsurfacewith
atleast50meters(164ft)ofspacedirectly
aheadandpresspanicbuttononce.
Movedirectlyforwardandacceleratevehicletillbeep
soundoccur.
Retry
G‐SensorCalibrationisfinishedsuccessfully.
Pressanybuttonorwait30secondstoreboot.
G‐SensorCalibrationisfailed.
Parkvehicleonaflatsurfacewith
14
This G-Sensor calibration is only needed the first time the MotionTrak330 is
used.
atleast50meters(164ft)ofspacedirectlyahead
andpresspanicbuttononceagain.

OPERATION
PANIC RECORD BY PANIC BUTTON
The panic recording by [PANIC] button will start by pressing the [PANIC] button
The
panic
recording
by
[PANIC]
button
will
start
by
pressing
the
[PANIC]
button
with one short “Beep” sound. The Blue LED will blink during the panic
recording.
MotionTrak330 doesn’t make a separate panic file during the continuous
recording.
It will mark the panic area by [PANIC] button in the continuous recording file
which can be easily searched for during playback.
SNAPSHOT RECORD BY SHUTTER BUTTON
SNAPSHOT
RECORD
BY
SHUTTER
BUTTON
Press [SHUTTER] button the MotionTrak330 will take a snapshot of 1 image
with 5 seconds of audio with one short “Beep” sound.
15

OPERATION
PLAYBACK
Press and hold [PLAY] button for more than 2 seconds
Press
and
hold
[PLAY]
button
for
more
than
2
seconds
.
The latest recorded file will playback on the screen.
[WARNING] Recording cannot be done during playback.
Explanation of PLAYBACK control button
Channel change: Press [PANIC] button.
Move to the previous file: Press and hold [SHUTTER] & [PLAY] button.
Move to the next file: Press and hold [PANIC] & [PLAY] button
Move
to
the
next
file:
Press
and
hold
[PANIC]
&
[PLAY]
button
.
PLAY/PAUSE: Press [PLAY] button.
SLOW PLAY: Press [PLAY] button more than 1second.
Return to record mode: Press and hold [SHUTTER] button more than 2seconds.
Playback logic at the main unit.
Panic data Event data Normal data Playback
----------------------------------------------------------------
(o)
(o)
(o)
Only Panic data playback
16
(o)
(o)
(o)
Only
Panic
data
playback
(o) (o) (x) Only Panic data playback
(o) (x) (x) Only Panic data playback
(x) (o) (o) Only Event data playback
(x) (o) (x) Event data playback
(x) (x) (o) Normal data playback

SOFTWARE USER GUIDE
MotionTrak330 PC Viewer Guide
[PC SYSTEM REQUIREMENT]
OS Windows 2000, Windows XP
Recommended PC specifications for PC Viewer software
Windows Vista, Windows 7
CPU Pentium4 2.6GHz or higher
RAM 512MB or higher
Interface SD Memory Card Reader
HDD
Free s
p
ace
Install 20MB or higher
Backu
p
2GB or hi
g
her
17
If the PC does not meet the minimum system requirement, the PC
Viewer may not function properly.
p
pg
Display 1,024 x 768 pixel/High Color(16bit) or higher

INSTALLING PROCEDURES
1 Connect the SD card into your PC (if your computer does not have SD card
PC Viewer software is in the provided SD card.
1
.
Connect
the
SD
card
into
your
PC
(if
your
computer
does
not
have
SD
card
slot use the USB SD card reader) and open the “My Computer”.
2. Right-click the “DRIVEREC3” drive and select [Open] .
3. Double click [SETUP.EXE] in the [pcsw] folder.
4. Select the language and then follow the dialog box.
5. The “PCViewer” icon will be displayed on your desktop.
NOTE: To Un-install the “PC Viewer MotionTrak330”
Open the
“
Control Panel
”
Open
the
Control
Panel
.
Select [remove program] and remove [PC Viewer MotionTrak330].
18

Connect SD memory card
1. Insert the SD memory card into the SD card reader.
2. Run “PC Viewer MotionTrak330”.
3. Select [File] and then click “Select Data Folder” or Click [OPEN] button.
[OPEN] button
4 Select the SD memory card folder at the folder select window
4
.
Select
the
SD
memory
card
folder
at
the
folder
select
window
.
19

PC VIEWER SETTING
To set PC Viewer select [File] and then click” PC Viewer Setting”.
This setting is for the PC Viewer software itself.
To set the recorder, refer to page 27.
The ‘date’ formats and ‘speed’ of the unit will be set automatically according to
the PC Windows setting.
However it can be changed with this PC viewer setting menu.
To see a better quality of playback pictures on your PC, check [Deblocking] box.
To
see
a
better
quality
of
playback
pictures
on
your
PC,
check
[Deblocking]
box.
