Lithium-Ion Phosphate Energy Storage System
R4836 Operation Manual
R4836_Operating_Manual_13.05.2021.indd 1R4836_Operating_Manual_13.05.2021.indd 1 17.5.2021 14:15:0617.5.2021 14:15:06

R4836_Operating_Manual_13.05.2021.indd 2R4836_Operating_Manual_13.05.2021.indd 2 17.5.2021 14:15:0617.5.2021 14:15:06

Contents
1. Symbol in label, manual and product 5
2. Safety Precautions 6
2.1 Before Connecting 6
2.2 In Using 7
3. Introduction 7
3.1 Features 7
3.2 Specication 9
3.3 Equipment interface instruction 11
4. Safe handling of lithium batteries guide 15
4.1 Schematic diagram of solution 15
4.2 Danger label 15
4.3 Tools 15
4.4 Safety Gear 16
5. Installation and operation 16
5.1 Package items 16
5.2 Installation location 18
5.3 Grounding 18
5.4 Put into cabinet or racks 19
5.5 Put into bracket 21
5.6 Suitable breaker 24
5.7 Power on 24
5.8 Power off 26
5.9 Multi-group mode 26
6. Trouble shooting 28
7. Emergency Situations 30
8. Remarks 32
R4836_Operating_Manual_13.05.2021.indd 3R4836_Operating_Manual_13.05.2021.indd 3 17.5.2021 14:15:0617.5.2021 14:15:06

R4836_Operating_Manual_13.05.2021.indd 4R4836_Operating_Manual_13.05.2021.indd 4 17.5.2021 14:15:0617.5.2021 14:15:06

1. Symbol in label, manual and product
Caution! Warning! Reminding.
Safety related information.
Risk of battery system failure or life cycle reduces.
Do not reverse connection the positive and negative.
Do not place near open ame.
Do not place at the children and pet touchable area.
Warning electric shock.
Warning Fire.
Do not place near ammable material.
Read the product and operation manual before operating the
battery system!
Grounding.
Recycle label.
The certicate label for EMC.
Label for Waste Electrical and Electronic Equipment (WEEE)
Directive (2012/19/EU).
The certicate label for Safety by TÜV Rheinland.
5
R4836_Operating_Manual_13.05.2021.indd 5R4836_Operating_Manual_13.05.2021.indd 5 17.5.2021 14:15:0617.5.2021 14:15:06

2. Safety Precautions
Reminding
1. It is important and necessary to read the user manual carefully (in the accessories)
before installing or using battery. Failure to do so or to follow any of the instructions
or warnings in this document can result in electrical shock, serious injury, or death,
or can damage battery, potentially rendering it inoperable.
2. If the battery is stored for long time, it is required to charge them every six months,
and the SOC should be no less than 90%.
3. Battery needs to be recharged within 12 hours, after fully discharged
4. Do not install the product in outdoor environment, or an environment out of the oper-
ation temperature or humidity range listed in manual.
5. Do not expose cable outside
6. Do not connect power terminal reversely.
7. All the battery terminals must be disconnected for maintenance
8. Please contact the supplier within 24 hours if there is something abnormal.
9. Do not use cleaning solvents to clean battery.
10. Do not expose battery to ammable or harsh chemicals or vapors.
11. Do not paint any part of battery, include any internal or external components.
12. Do not connect battery with PV solar wiring directly.
13. The warranty claims are excluded for direct or indirect damage due to items above.
14. Any foreign object is prohibited to insert into any part of battery.
Warning
2.1 Before Connecting
1. After unpacking, please check product and packing list rst, if product is damaged or
lack of parts, please contact with the local retailer
2. Before installation, be sure to cut off the grid power and make sure the battery is in
the turned-off mode
3. Wiring must be correct, do not mistake the positive and negative cables, and ensure
no short circuit with the external device
4. It is prohibited to connect the battery and AC power directly
5. The embedded BMS in the battery is designed for 48VDC, please DO NOT connect
battery in series
6
R4836_Operating_Manual_13.05.2021.indd 6R4836_Operating_Manual_13.05.2021.indd 6 17.5.2021 14:15:0717.5.2021 14:15:07

6. Battery must connect to ground and the resistance must be less than 0.1Ω
7. Please ensured the electrical parameters of battery system are compatible to related
equipment
8. Keep the battery away from water and re.
2.2 In Using
1. If the battery system needs to be moved or repaired, the power must be cut off and
the battery is completely shutdown
2. It is prohibited to connect the battery with different type of battery.
3. It is prohibited to connect batteries with faulty or incompatible inverter
4. It is prohibited to disassemble the battery (QC tab removed or damaged);
5. In case of re, only dry powder re extinguisher can be used, liquid re extinguishers
are prohibited
6. Please do not open, repair or disassemble the battery except staffs from TAB or
authorized by TAB. We do not undertake any consequences or related responsibility
which because of violation of safety operation or violating of design, production and
equipment safety standards.
3. Introduction
R4836 lithium iron phosphate battery is the new energy storage products developed and
produced under TAB’s quality requirements, it can be used to support reliable power for
various types of equipment and systems.
R4836 has built-in BMS battery management system, which can manage and monitor cells
information including voltage, current and temperature.
3.1 Features
1. NEW: Build-in soft-start function able to reduce current strike when inverter need to
start from battery.
2. NEW: Dual active protection on BMS level.
3. NEW: Automatic address setting when connect in multi-group.
4. NEW: Support wake up by 5~12V signal from RJ45 port.
5. NEW: Support upgrade battery module from upper controller via CAN or RS485
communication.
7
R4836_Operating_Manual_13.05.2021.indd 7R4836_Operating_Manual_13.05.2021.indd 7 17.5.2021 14:15:0717.5.2021 14:15:07

6. NEW: Enable 95% depth of discharge, available for the inverter which completely
follow TAB latest protocol to operate.
7. The module is non-toxic, non-pollution and environmentally friendly
8. Cathode material is made from LiFePO4 with safety performance and long cycle
life.
9. Battery management system (BMS) has protection functions including over-dis-
charge, over-charge, over-current and high/low temperature.
10. The system can automatically manage charge and discharge state and balance
voltage of each cell
11. Flexible conguration, multiple battery modules can be in parallel for expanding
capacity and power
12. Adopted self-cooling mode rapidly reduced system entire noise
13. The module has less self-discharge, up to 6 months without charging it on shelf, no
memory effect, excellent performance of shallow charge and discharge
14. Small size and light weight, standard of 19-inch embedded designed module is
comfortable for installation and maintenance
15. Compatible with R4824
*Mixture using master battery priority: R4836>R4824
For same type of module always use the latest production unit as master.
*Mixture using battery deployment option:
Master battery (1st) R4836/R4824
Slave 2nd ~8th R4836/R4824
Slave 9th ~16th R4836/R4824
8
R4836_Operating_Manual_13.05.2021.indd 8R4836_Operating_Manual_13.05.2021.indd 8 17.5.2021 14:15:0717.5.2021 14:15:07

3.2 Specication
9
R4836_Operating_Manual_13.05.2021.indd 9R4836_Operating_Manual_13.05.2021.indd 9 17.5.2021 14:15:0817.5.2021 14:15:08

Basic Parameters R4836
Nominal Voltage (V) 48
Nominal Capacity (Wh) 3552
Usable Capacity (Wh) 3374.4
Dimension (mm) 442*420*132
Weight (Kg) 32
Discharge Voltage (V) 44.5 ~ 53.5
Charge Voltage (V) 52.5 ~ 53.5
Recommend Charge/Discharge Current (A) 37
Max. Charge/Discharge Current (A) 74-89@60sec
Peak Charge/Discharge Current (A) 90~200@15sec
Communication RS485, CAN
Depth of discharge (%) 95
Conguration (max. in 1 battery group) 16pcs
Working Temperature 0°C~50°C Charge
-10°C~50°C Discharge
Shelf Temperature -20°C~60°C
Short current/duration time <4000A/2ms
Cooling type Natural
Protective class I
IP rating of enclosure IP20
Humidity 5% ~ 95%(RH) No Condensation
Altitude(m) <4000
Certication TÜV / CE / UN38.3/UL
Design life 15+ Years (25°C/77°F)
Cycle Life >6,000 25°C
Reference to standards IEC62619, IEC63056, IEC62040, IEC62477-1,
UL1973,U1642,UL9540A, VDE2510-50, IEC61000-6-2,
IEC61000-6-3, UN38.3
10
R4836_Operating_Manual_13.05.2021.indd 10R4836_Operating_Manual_13.05.2021.indd 10 17.5.2021 14:15:0817.5.2021 14:15:08

3.3 Equipment interface instruction
Power Switch
ON: ready to turn on.
OFF: power off. For storage or shipping.
Start
Turn on: press more than 0.5s to start the battery module
Turn off: press more than 0.5s to turn off the battery.
RUN
Green LED lighting to show the battery running status
Alarm
Red LED ashing to show the battery has alarm; lighting to show the battery is under pro-
tection.
SOC
6 green LEDs to show the battery’s current capacity.
ADD Switch
Dip1: RS485 baud rate: 1: 9600; 0: 115200. After change, please restart battery.
Dip2: CAN terminal resistance on BMS side. 1: NONE. 0: connected. After change, no re-
start required. In single group mode, please keep dip2 at 0 position. For multi-groups,
please refer to [5.9].
Dip3~ 4, reserved.
11
R4836_Operating_Manual_13.05.2021.indd 11R4836_Operating_Manual_13.05.2021.indd 11 17.5.2021 14:15:0917.5.2021 14:15:09

Based on design of BMS, the dip switch is deployed physically reversely.
For instance:
Dip1 Dip2 Dip3 Dip4 The corresponding
position of switch
Status
0 0 0 0
RS485:115200
CAN terminal resistance: connected
1 0 0 0
RS485:9600
CAN terminal resistance: connected
0 1 0 0
RS485: 115200
CAN terminal resistance: NONE
Console
For manufacturer or professional engineer to debug or service.
Pin3 232-TX
Pin4* +5~+12V for wake up
Pin5* GND for wake up
Pin6 232-RX
Pin8 232-GND
*Wake up signal shall ≥0.5Sec, current between 5~15mA. After send
wake up signal, the voltage shall disappear for normal operation.
Contact
Pin1 Input, passive signal.
On: turn off battery. Off: normal.
Pin2
Pin3 Output1. On: stop charge. +
Pin4 -
Pin5 Output2. On: stop discharge. +
Pin6 -
Pin7 Output3. On: BMS error. +
Pin8 -
Output request signal voltage ≤25V.
12
R4836_Operating_Manual_13.05.2021.indd 12R4836_Operating_Manual_13.05.2021.indd 12 17.5.2021 14:15:0917.5.2021 14:15:09

CAN
500 Kbps. 120Ω. For connection to LV-HUB, inverter, or upper battery.
RS485
9600 or 115200 bps.120Ω. For connection to inverter, or slave battery.
Link Port 0, 1
for communication between multiple parallel batteries.
Denition of RJ45 Port Pin
A/CAN B/RS485
Pin1 These pins shall be NULL.
If not, may inuence communication
between BMS and inverter.
Pin2
Pin3
Pin4 CAN-H CAN-H (single group)
Pin5 CAH-L CAN-L (single group)
Pin6 CAN-GND CAN-GND (single group)
Pin7 485A 485A
Pin8 485B 485B
Power Terminals
Power cable terminals: there are two pair of terminals with same
function, one connects to equipment, the other one paralleling to
other battery module for capacity expanding.
For power cables uses water-proofed connectors. must keep
pressing this Lock Button while pulling out the power plug.
13
R4836_Operating_Manual_13.05.2021.indd 13R4836_Operating_Manual_13.05.2021.indd 13 17.5.2021 14:15:1017.5.2021 14:15:10

LED Status Indicators
Condition RUN ALR 1 2 3 4 5 6
Power off - - - - - - - -
Power on
Idle/Normal - - - - - - -
Charge
-
Show soc; highest LED ash
on: 0.5s; off 0.5s
Discharge Show soc
Alarm ALR: ; Other LEDs are same as above.
System error/
Protect
- - - - - -
/ON
ash, on: 0.3s; off: 3.7s
/ash, on:0.5s; off: 1.5s
BMS basic function
Protection and alarm Management and monitor
Charge/Discharge End Cells Balance
Charge Over Voltage Intelligent Charge Model
Discharge Under Voltage Charge/Discharge Current Limit
Charge/Discharge Over Current Capacity Retention Calculate
High/Low Temperature(cell/BMS) Administrator Monitor
Short Circuit Operation Record
Power Cable Reverse
Soft start of inverter
14
R4836_Operating_Manual_13.05.2021.indd 14R4836_Operating_Manual_13.05.2021.indd 14 17.5.2021 14:15:1017.5.2021 14:15:10

4. Safe handling of lithium batteries guide
4.1 Schematic diagram of solution
4.2 Danger label
4.3 Tools
The following tools are required to install the battery pack
Wire cutter Crimping Modular Plier Screw Driver
15
R4836_Operating_Manual_13.05.2021.indd 15R4836_Operating_Manual_13.05.2021.indd 15 17.5.2021 14:15:1017.5.2021 14:15:10

NOTE
Use properly insulated tools to prevent accidental electric shock or short circuits.
If insulated tools are not available, cover the entire exposed metal surfaces of the available
tools, except their tips, with electrical tape.
4.4 Safety Gear
It is recommended to wear the following safety gear when dealing with the battery pack
Insulated gloves Safety goggles Safety shoes
5. Installation and operation
5.1 Package items
Unpacking and check the Packing List
1) For battery module package:
- Battery Module
- Two 4AWG power cables and one RJ45 communication cable:
16
R4836_Operating_Manual_13.05.2021.indd 16R4836_Operating_Manual_13.05.2021.indd 16 17.5.2021 14:15:1117.5.2021 14:15:11

10AWG grounding cable:
2) For External cable kits:
NOTE
Power and communication cables to connect to inverter belongs to an External Cable Kit,
NOT include in battery carton box. They are in another extra small cable box. If there is
anything missed please contact dealer.
Two power cables (4AWG, peak current capacity 120A, constant 100A) and communica-
tion cable for each energy storage system.
For the external cables, the length shall less than 3 meters.
1000
180
180
180
2000
2000
3000
17
R4836_Operating_Manual_13.05.2021.indd 17R4836_Operating_Manual_13.05.2021.indd 17 17.5.2021 14:15:1117.5.2021 14:15:11

SN of RJ45cable Mark Pin
WI0SCAN30RJ1 With blue mark:
Battery-Inverter
Pin1~3: NULL
Pin4~8: pin to pin
For connection to inverter
WI0SCAN35RJ3 With silver mark:
Battery-Battery
Pin1~8: pin to pin For parallel connection
between master batteries
5.2 Installation location
Make sure that the installation location meets the following conditions:
1. The area is completely waterproof
2. The oor is at and level.
3. There are no ammable or explosive materials.
4. The ambient temperature is within the range from 0°C to 50°C.
5. The temperature and humidity are maintained at a constant level.
6. There is minimal dust and dirt in the area.
7. The distance from heat source is more than 2 meters.
8. The distance from air outlet of inverter is more than 0.5 meters.
9. The installation areas shall avoid of direct sunlight.
10. There is no mandatory ventilation requirements for battery module, but please
avoid of installation in conned area. The aeration shall avoid of high salinity, hu-
midity or temperature.
Caution
If the ambient temperature is out of the operating range, the battery stops operating to pro-
tect itself. The optimal temperature range for the battery pack to operate is 10°C to 40°C.
Frequent exposure to harsh temperatures may deteriorate the performance and life of the
battery.
5.3 Grounding
Grounding cables shall be 10AWG or higher yellow-green cables.
After connection, the resistance from battery grounding point to
Ground connection point of room or installed place shall smaller
than 0.1Ω.
1) Based on metal directly touch between the module’s surface
and rack’s surface. If using painted rack, the corresponding
place shall remove the painting.
18
R4836_Operating_Manual_13.05.2021.indd 18R4836_Operating_Manual_13.05.2021.indd 18 17.5.2021 14:15:1217.5.2021 14:15:12

2) Install a grounding cable to the grounding point of the modules.
5.4 Put into cabinet or racks
Put battery modules into cabinet and connect the cables:
1. Put the battery into the cabinet
2. Drive the 4 pcs screws
3. Connect the cables between battery modules
4. Connect the cables to inverter
19
R4836_Operating_Manual_13.05.2021.indd 19R4836_Operating_Manual_13.05.2021.indd 19 17.5.2021 14:15:1217.5.2021 14:15:12

20
R4836_Operating_Manual_13.05.2021.indd 20R4836_Operating_Manual_13.05.2021.indd 20 17.5.2021 14:15:1317.5.2021 14:15:13
