Tactical technologies TPC1 User manual

N645
Designed & Manufactured
®
Installation Manual
AC - DC / DC - DC Convertor - 12Vdc Output
TPC1
Tel: [phone] www.tac-tech.com.au Fax: [phone]

N645
No user serviceable parts inside
Do not remove module covers
General
This power convertor is designed for indoor use only.
The TPC1 is a low prole DC - DC / AC - DC Convertor designed to convert either 24V AC or 18-48V DC to a
reliable, clean output voltage between 11-15Vdc (12V nominal) and is rated for 1.5A continuous output.
Note: Input voltage must not exceed 48V DC - permanent damage may result.
This model features output current limiting and thermal shutdown protection with auto recovery.
Connection
Connect input power to terminals marked “Input” (see diagram overleaf ).
Note that these terminals are not polarity conscious.
Load equipment may be connected to terminals marked “Out”.
Conrm polarity before connecting.
Output voltage is factory set to 12.2Vdc - see note below:
Battery Operation: If battery operation is required, adjust output voltage to 13.8Vdc (using an insulated
screwdriver and digital multimeter). Battery charge current is limited to < 100mA - this should be taken into
account when calculating output load. If output load (including battery charging) exceeds 1.5A, TPC-1 will
current limit & shut down. Observe polarity of battery when connecting.
Input and output LED’s should be illuminated when operating normally.
There are no fuses or user serviceable components inside the cabinet - return to your supplier or Tactical
Technologies for service or repair.
Equipment must be installed & serviced
by suitably qualied service personnel
in a restricted access area. There are no
user serviceable parts inside.
Document: TPC1_Rev C.pdf
CAUTION

A B C D E F G
LAYOUT
AOutput Voltage Adjustment (Use an insulated screwdriver to adjust)
BInput OK LED
CInput Terminals: 18Vdc - 48Vdc or 24Vac nominal
DOutput Terminals: 11 - 15Vdc / 1.5A Max (factory set to 12.2Vdc)
EBattery Connection - output must be adjusted to 13.8Vdc for battery operation
FOutput OK LED
GMounting Holes
Document: TPC1_Rev C.pdf

®
Designed & Manufactured
TPC 1
Input Voltage 18Vdc - 48Vdc or 24Vac nominal
Output Voltage Factory set to 12.2Vdc (11 - 15Vdc adjustable )
Output Current 1.5A Max.
Output Protection Current Limiting with Auto Recovery, Thermal Shutdown
Operating Temperature 0º C to 45º C
Soft Start 1 - 2 seconds (typical)
EMC Standards C-Tick N645 / CISPR11:2004 - Class B
Dimensions 115 W x 65 D x 40 H mm
Tel: [phone] Butterfield St, Blacktown NSW 2148 Fax: [phone]
TPC1
AC-DC / DC-DC Convertor
®
Securing Your Power Needs ®
Now and into the Future . . .
www.tac-tech.com.au
Specications : ( In the interests of product improvement, Tactical reserves the right to change specications without notice)
