Taiden TMX-HDSDI2HDMI User manual

Please read this manual before using the apparatus and keep it for future reference
3G HD-SDI to HDMI User's Manual
V1.0
TMX-HDSDI2HDMI 3G HD-SDI to HDMI Converter
TAIDEN INDUSTRIAL CO.,LTD. Printed in SHENZHEN 01/2015
Technical Specifications
.....1 SD/HD-SDI,3G HD-SDI,BNC
..1 SD/HD-SDI,3G HD-SDI,BNC
.....1 HDMI CEC HDCP)
............................................1 VGA
SDI .......1.485 Gb/s 2.97 Gb/s
.................................1 3PIN
.............................................. 15
................................................ 85 dB
......................................... 60 dB
.................................30 - 20 kHz (-3 dB)
...............RS232 3PIN
.... 9600 8
......... 1
...
.............................................9 - 12 V DC
.....................................0 - +50
.................................-20 - +70
..............................................10% - 90%
..................................150 100 40 mm
......................................................0.4 kg
Video
General specs
Audio
Input ............1 SD/HD-SDI, 3G HD-SDI on a BNC
connector
Output..........1 SD/HD-SDI, 3G HD-SDI on a BNC
connector; 1 HDMI connector
(unsupport CEC and HDCP); 1 VGA
Input/output data rate....1.485 Gb/s and 2.97 Gb/s
Output............................................1 3-pin Phoenix
Impedance.................................................. 15
S/N............................................................. 85 dB
Stereo channel separation......................... 60 dB
Frequency response.................30 - 20 kHz (-3 dB)
COM (RS-232)..................................3-pin Phoenix
.............Baudrate: 9600, data: 8 bits
... .....................stop: 1 bit, no parity
Power supply........................................9 - 12 V DC
Temperature
Operating........................................0 to + 50
Storage........................................-20 to + 70
Humidity.......................................
Dimensions...............................40 150 100 mm
Weight...........................................................0.4 kg
..........10% - 90%
Control
Commendatory assignation of resolutions
Input
Output
1280 720p60
SDI to VGASDI to HDMI
AUTO
1280 720p50
1920 1080p30
1920 1080i60
1920 1080i50
1920 1080p50
1920 1080p60
1280
720p60
1280
720p50
1920
1080i60
1920
1080i50
1920
1080p60 1920
1080p50 1024
768p60
1280
1024p60

HDMI
Display with HDMI input
VGA
Display with VGA input
Loud speaker
From TMX-0808SDI
or other SDI source
TMX-HDSDI2HDMI
TMX-HDSDI2HDMI
VGA OUTPUT
HDMI OUTPUTHDMI OUTPUT
L R
AUDIO
OUTPUT
AUDIO
OUTPUT
OUTPUT
RESOLUTION
OUTPUT
RESOLUTION
Functions and Indications
System Connection
Note Please use the power adapter only.specific
LOOP OUTPUT
DC 9V-12V 0.7ADC 9V-12V 0.7A
RS-232
POWER
LOS
TX RX
SDI INPUTSDI INPUT
Audio Output
VGA
VGA Output
Output Resolution
HDMI
HDMI Output
RS-232
SDI
SDI Input
Loss Of Signal
SDI
Loop Output
Grounding
DC 9 V-12 V 0.7 A
1
2<>
VGA 800 600p60/75,1400 1050p60
1024 768p60/75,1360 768p60,
1280 1024p60/75;
HDMI VGA
720 480p60, 720 576p50,
1280 720p60/50/30/25,
1920 1080p60/50/30/25,
1920 1080i60/50, AUTO
3<>
VGA HDMI
4 < > 1-2s
HDMI AUTO
VGA
5 LOS
Video loss!
SDI
HD 720p: 25,30,50,60;
HD 1080i: 50,60;
HD 1080p: 24,25,30;
3G 1080p: 50,60
HDMI
S
tput selection
In
etup
1. Connect to the devices and power on, the indicator
of the power will be turn on.
2. Use the < or > button to select the resolution of
output:
VGA output:
. Every time to press the < and > buttons at the
same time can switch the output type between
VGA and HDMI, it can only put out one type at a
time.
. Press the < and > buttons at the same time for 1-2
seconds when power on to set the output type as
HDMI and the resolution as AUTO, and close the
output of VGA at the same time
. The LOS indicator will turn on when the video
signal lost, Video loss! will be displayed on
the screen and the video image will be froze or
a blue screen will be displayed.
800 600p60/75,1400 1050p60,
1024 768p60/75,1360 768p60,
1280 1024p60/75;
HDMI output: (includes the resolutions of VGA)
720 480p60, 720 576p50,
1280 720p60/50/30/25,
1920 1080p60/50/30/25,
1920 1080i60/50, AUTO.
3
4
.
5
SDI input supports multiform video and can configure
parameters according to the type of video input
automatically:
HD 720p: 25,30,50,60;
HD 1080i: 50,60;
HD 1080p: 24,25,30;
3G 1080p: 50,60.
The HDMI indicator will be turn on when the HDMI interface
has output signal.
Note:
Setup and Operation
TMX-HDSDI2HDMI SDI
DSP
HDMI VGA
TMX-HDSDI2HDMI transfers SDI input into HDMI
signal as digital audio and video output, and also into
VGA signal at the same time, that is convenient for
local monitor.
