Talent Little Misty LM-1 User manual

LM-1
Little Misty Professional Fog Machine
User Manual
Please read the instructions carefully before using

Thank you for buying this product.To take full advantage of all possibilities and for your own
safety, please read these operating instructions very carefully before you start using this unit.
FEATURES
This unit is radio-interference suppressed. This product meets the requirements of the current
European and national guidelines. Conformity has been established and the relevant
statements and documents have been deposited by the manufacturer.
 This device has been designed to produce decorative effect lighting and is used in light
show systems
 Powerful, all-round fogger
 Perfect for mobile DJs, parties, clubs, home use
 Strong, consistent fog output
 Equipped with a diecast 400 watt heater
 Manual remote control included
 Fog juice level indicator
 Can choose manual remote control and wireless remote control
BEFORE USE
 Before using this unit, please check to ensure there is no transportation damage.
Should there be any, do not use the device. Consult your dealer for return instructions.
 Important:This device left our factory in perfect condition, packaged for shipping. It is
absolutely necessary for the user to strictly follow the safety instructions and warnings
in this user manual. Any damage caused by mishandling is not subject to warranty. The
dealer will not accept responsibility for any resulting defects or problems caused by
disregarding this user manual.
 Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure
to include this user manual to ensure proper operation.
Check the contents:
Check that the carton contains the following items:
 Operating instructions
 400 fogger
 Remote control

SAFETY INSTRUCTIONS:
CAUTION: To reduce the risk of electric shock,do not remove the
top cover. There are no user-serviceable parts inside.
The lightning flash with arrowhead symbol within the equilateral triangle is intended
to alert the use or the presence of un-insulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of electric
shock.
The exclamation point within the equilateral triangle is intended to alert the user to
the presence of important operation and maintenance (servicing) instructions in the
literature accompanying this appliance.
This symbol means indoor use only.
This symbol means refer to the instructions.
This symbol determines the minimum distance from objects. The minimum distance
between fogger output and objects must be more than 3 feet. NEVER hold your
hands close to the fogger output. The fog is very hot and can cause serious
burns!!!
 To protect the environment, please try to recycle the packing material as much as
possible.
 To prevent fire or shock hazard, do not expose this appliance to rain or moisture.
 To avoid condensation to be formed inside, allow the unit to adapt to the surrounding
temperature when bringing it into a warm room after transport. Condensation can
prevent the unit from working at full performance and may even cause damage.
 This unit is for indoor use only.
 Do not place metal objects, or spill liquid, inside the unit. Electric shock or malfunction
may result if a foreign object enters the unit. Immediately remove power if this occurs.
 Locate the unit in well ventilated spot, away from any flammable material and/or liquids.
 Do not cover any ventilation openings as this may result in overheating.
 Prevent use in dusty environments and clean the unit regularly.
 Keep the unit away from children.
 Inexperienced persons should not operate this device.
 Maximum save ambient temperature is 104˚F. Do not use this unit at higher ambient
temperatures.
 The units’ surface temperature may reach up to 185˚F. Do not touch the housing with
bare hands during operation.
 Make sure to always place the unit on a stable surface, never install the fogger above
the audience. Liquid may drip from the fog output nozzle.
 Allow the device 10 minutes to cool before moving.
 Always unplug the unit when unused.
 Check that the available voltage is not higher than that stated on the rear panel of
the unit.
 The power cord should always be in perfect condition. Switch the unit immediately off if
the power cord is damaged. It must be replaced by the manufacturer,
service agent, or similarly qualified person in order to avoid a hazard.
 Never let the power cord come into contact with other cables!
 This unit must be grounded in order comply with safety regulations.
 In order to prevent electric shock, do not open the cover.

 Never repair a fuse or bypass the fuse holder. Always replace a damaged fuse with a
fuse of the same type and electrical specifications!
 In the event of serious operating problems, stop using the fixture and contact your
dealer immediately.
 The housing must be replaced if it is visibly damaged.
 Please use the original packaging when the device is to be transported.
 Due to safety reasons, it is prohibited to make unauthorized modifications to the unit.
DESCRIPTION:
1. FOG FLUID CONTAINER: Fill with CE-certified smoke fluid. Make sure that
the fog fluid container is never empty during operation, this will damage the pump
of the fogger.
2. FLUID LEVEL INDICATOR: Indicates how much fog fluid is still available.
3. NOZZLE: Fog output. WARNING: HOT! Observe a minimum distance of 3 feet.
4. REMOTE CONTROL INPUT: Use to connect the supplied remote control.
5. INPUT FUSE: If
the fuse is blown, first
locate and solve the
problem that caused
the fuse to
blow. When the
problem is solved,
replace a damaged
fuse with a fuse of the
same type and
electrical specifications.
6. POWER CABLE
7. POWER SWITCH
OPERATING INSTRUCTIONS
 Place the fogger on a flat, stable surface. Ensure that nobody places their
hands in front of the output nozzle. The fog is very hot and can cause serious burns!!!
 Ensure the fog liquid tank is not empty. Always use good quality fog liquid to fill up
the tank.Close tank immediarely to prevent dirt to enter the reservoir!
 Plug the supplied remote into the remote control input (4) on the back of the unit. Do not
insert or remove the remote while the fogger is connected to a power outlet.
 Ensure to plug the fogger
into a power receptacle that
is connected to ground.
 Switch the fogger on and wait
for about 4 minutes to allow
the fogger to warm up.
Use of the supplied remote
control:
1. REMOTE CABLE: Connect the
special 3-pin connector to the remote

input on the back of the fogger(4).
2. MANUAL FOGGING BUTTION: As long as the red LED is on, you can press this
button at any time to produce fog.
MAINTENANCE
 Switch off the unit, unplug the main power cable, and wait until the unit has cooled.
During inspection the following points should be checked:
 All screws used for installing the device and any of its parts should be tightly fastened
and are not corroded.
 Housings and fixed installation spots (celling, truss, suspensions) should be totally
free from any deformation.
 The main power cables must be in perfect condition and should be replaced immediately
when even a small problem is discovered.
Cleaning the fogger:
To prevent obstructions in the heater, pump and tubes, the fogger should be cleaned on a
regular basis. Every 100 hours of continuous operation is a good reference.
 Switch the fogger off.
 Remove the nozzle (metal part where the fog leaves the fogger).
 Remove the fog liquid from the tank.
 Fill the tank with about 1 liter of solution containing 80% distilled water and 20% white
vinegar.
 Switch the fogger on and wait for about 8 minutes (warm up time).
 Put the fogger in continuous operation mode until the tank is empty.
 Put the nozzle back in place.
 Completely clean the cleaning solution out of the tank and refill it with fog liquid.
Note: Cleaning should be done outside: an unpleasant smell is produced by the vinegar solution!
Attention:We strongly recommend internal cleaning to be carried out by qualified personnel！

TE C HNIC AL S P E C IF IC ATIONS
S moke output : 2,000 cu.ft per minute
W arm up time : Approximately 4 mins
Tank capacity : 0.25L
P ower consumption : 400 Watts
P ower supply : 110-120 VAC, 60Hz
Dimensions : 11.02" x 4.33" x 5.51"
W eight : 3.41 lbs.
