GENERAL SAFETY RULES AU
MODEL NO. AMA009
USER MANUAL
Hover Mower Attachment
9096-A00901
WARNING • PLEASE READ
For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions
can result in serious personal injury. Spend a few moments to familiarize yourself with your hover mower before each
use.
WARNING! When using tools, basic safety precautions, including the following, should always be followed to reduce the
risk of serious personal injury and/or damage to the unit.
Read all these instructions before operating this product and save these instructions.
Meaning of symbols marked on the product
Read the user manual before using the machine
Whenever the machine is in use, safety goggles must be worn
to safeguard against flying object, as must ear protectors,
such as a soundproof helmet, in order to protect the operator’s
hearing. If the operator is working in an area where there is a
risk of falling objects, a safety helmet must also be worn.
Wear safety boots to protect against electric shock
Do not operate unit without proper attachments and
guards in place.
Keep hands away from blade
Keep people or animals at least 15m away from the
machine during operation
Wear gloves to protect your hands
READ YOUR USER MANUAL AND ALL SUPPLE-
MENTS (IF ANY ENCLOSED) THOROUGHLY BEFORE
OPERATING YOUR UNIT.
1. Wear close fitting, tough work clothing that will
provide protection, such as long slacks or trousers,
safety work shoes, heavy duty work gloves, hard hat,
a safety face shield, or safety glasses for eye protec-
tion and a good grade of ear plugs or other sound
barriers for hearing protection.
2. Turn unit off before setting it down.
3. Always hold unit firmly with both hands, the
thumb and fingers encircling the handles.
4. Keep all screws and fasteners tight. Never operate
your equipment when it is improperly adjusted or not
completely and securely assembled.
5. Keep handles dry, clean and free of fuel mixture.
6. Check area you will be trimming for debris that
may be struck or thrown during operation.
7. Keep all parts of your body and clothing away
from blade when starting or running engine. Before
starting engine, make sure blade will not come in
contact with any obstacle.
8. Stop engine before examining blade.
9. Store equipment away from possible flammable
materials, such as gas-powered water heaters,
clothes dryers, or oil-fired furnaces, portable
heaters, etc.
10. Always keep the blade and engine free of debris
build-up.
11. Operation of equipment should always be restricted
to mature and properly instructed individuals.
12. Inspect the area before starting the unit. Remove all
debris and hard and sharp objects such as rocks,
glass, wire, etc. that can cause damage during oper-
ation.
13. Operate this unit in a well-ventilated area outdoors.
Carbon monoxide exhaust fumes can be lethal in a
confined area.
14. This unit is for household use only.
15. Look behind and use care when walking backwards.
16. Never operate without good visibility and light.
17. Exercise caution to avoid slipping or falling.
18. Maintain hover mower with care. Keep blades sharp
at all times, and clean for best and safest perform-
ance. Follow maintenance instructions. Always use a
clean cloth when cleaning. Never use brake fluid,
gasoline, petroleum-based products, or any strong
solvents to clean your unit.
Refer to trimmer instructions for full starting and mainte-
nance instructions.
1.
WARNING: Gasoline is highly flammable, and its
vapours can explode if ignited. Take the following
precautions.
2. Store fuel only in containers specifically designed
and approved for the storage of such materials.
3. Always stop the engine and allow it to cool before fill-
ing the fuel tank. Never remove the cap of the fuel
tank, or add fuel, when the engine is hot. Never oper-
ate the unit without the fuel cap securely in place.
Loosen the fuel tank cap slowly to relieve any pres-
sure in the tank.
4. Mix and add fuel in a clean, well-ventilated area out-
doors where there are no sparks or flames. Slowly
remove the fuel cap only after stopping the engine.
Do not smoke while fuelling or mixing fuel. Wipe up
any spilt fuel from the unit immediately.
5. Avoid creating a source of ignition for spilled fuel. Do
not start the engine until the fuel vapours dissipate.
6. Move the unit at least 10 feet (3m) from the fuelling
source area side before starting the engine. Do not
smoke, keep sparks and open flames away from the
area when adding fuel or operating the unit.
7. Never start or run the unit inside a closed room or
building. Breathing exhaust fumes can kill. Operate
this unit only in a well ventilated area outdoors.
WARNING: Keep children, bystanders, and
animals 50 feet (15 meters) away. If
approached stop unit immediately.
SAFETY WARNING FOR PETROL POWERED HEAD

2
AU
1. Drive Shaft
2. Rubber Cover
3. Hover Deck
4. Blade
5. Impeller
6. Connecter
7. Clamp
8. Rubber Tube
GENERAL IDENTIFICATION
1
23
5
4
Refer to trimmer instructions for full starting and mainte-
nance instructions.
1. WARNING : To reduce the risk of electrical shock,
use only extension cords approved for outdoor use.
2. CORD SETS : Make sure your cord set is in good
condition. When using a cord set, be sure to use a
cord that is heavy enough to carry the current that
your unit will draw. An undersized cord set will cause
a drop in line voltage resulting in a loss of power and
overheating.
3. Ensure that the hover mower is attached to an elec-
tric trimmer that is connected to a Residual Current
Device (RCD) with a tripping current of not more than
30mA is in the circuit.
4. If an extension cord is used make sure that it is for
outdoor use and marked as such. The recommended
size of the extension cord is not lighter than 1.5mm
and a maximum of 10 metres in length.
5. When connected to an electric trimmer, before use
check the supply and extension cord for signs of
damage or ageing. If the cord becomes damaged
during use, disconnect the cord from the supply
immediately. DO NOTTOUCHTHE CORD BEFORE
DISCONNECTING THE SUPPLY.
6. When connected to an electric trimmer, do not use
the appliance if the cord is damaged or worn.
7. Ensure that the extension cable is completely
uncoiled before use to prevent overheating and loss
of efficiency.
8. Inspect all extension cords and the unit power conec-
tion periodically. Look closely for deterioration, cuts
or cracks in the insulation. Also inspect the connec-
tions for damage. Replace the cords if any defects or
damage appears.
9. Do not use the unit in the rain.
10. Do not handle the plug or unit with wet hands or while
standing on any wet surfaces.
11. Do not leave the unit plugged in when not in use,
changing attachments or add-ons, or while being
serviced.
12. Always disconnect from the mains when leaving it
unattended.
13. Switch off the motor and pull out the plug when the
machine is not being used, being cleaned, being
moved from one place to another or when the blades
are being changed or adjusted.
14. If there is an interruption to the power supply or the
extension cord is damaged, switch off the machine
immediately and remove the plug from the power
mains.
15. If the power cord is damaged, only have it repaired by
an Autorised Talon Service Agent.
16. Do not move the machine by pulling on the electrical
cable.
17. Never use an electrically powered unit in the rain or
when the grass is wet.
18. When mowing, keep the power cable away from the
mower. Your direction of work should be away from
the power point.
19. After use, disconnect the machine from the power
supply and check for damage. If you have the slight-
est doubts, check with an Authorised Talon Service
Agent.
Warning: After switching off the machine, the cutting
blade continues to rotate for a few more seconds.
1. Frequently inspect the condition of the cutting
blades. Damaged blades must be replaced immedi-
ately. Blunt blades should be sharpened.
2. Damaged blades and worn bolts are major haz-
zards.
3. When connected to an electric trimmer, do not use
the appliance if the cord is damaged or worn.
4. Read the instructions carefully. Be familiar with the
controls and proper use of the equipment.
5. Keep extension cord away from cutting blades.
6. Never operate the hover mower while barefoot or
wearing sandals or thongs. Wear long tousers and
heavy shoes.
7. This appliance is not intended for use by young chil-
dren or infirm persons.
8. Young children should be supervised so that they
do not play with the unit.
9. Avoid using the hover mower, while people, espe-
cially children and the infirm, or pets are nearby.
10. Use the mower only in daylight or in good artificial
light.
11. Never operate the hover mower with a damaged
base.
12. When starting up and when in operation, keep the
cutting section away from all parts of the body,
especially the hands and feet.
13. Do not start the machine when it is not in the oper-
ating position.
14. Throughly inspect the hover mower for loose or
damaged parts before each use. Do not use the unit
until adjustments or repair are made.
15. Only use the manufacturer’s recommended replace-
ment parts and accessories.
16. Inspect and maintain the hover mower regularly.
Have the mower repaired by an Authorised Talon
Repair Agent only.
17. Check that all grass and dirt have been removed
from all ventilation shafts.
18. Do not use the hover mower in enclosed or poorly
ventilated spaces or in the presence of inflammable
an/or explosive substances such as liquids, gasses
and powders.
19. Do not cross roads or gravel paths with hover
mower while in operation.
20. Keep a balanced and stable stance when using the
hover mower.
21. Do not cut grass which is not on the ground. For
example, do not cut grass which is on rocks.
SAFETY WARNING FOR ELECTRIC HEAD
6
7
8
AU
ADDITIONAL SAFETY PRECAUTIONS FOR HOVER
MOWERS
22. Ensure that the area being cut is free from sticks,
stones and debris. Remove any objects that could
be thrown during cutting or could wind around the
cutting mechanism.
23. If you hit or become entangled with a foreign object,
stop the motor immediately and check for damage.
Do not operate the mower with loose or damaged
parts.
24. Do not cut against hard objects. This could cause
injury to the operator and cause damage to the
machine.
25. Never pick up or carry a mower when it is operating.
26. Exercise caution when mowing on sloping ground.
Watch your footing and wear non-slip footwear.
Mow along the slope not up and down it. Do not
mow on steep slopes. Be espically cautious when
changing direction on slopes - stand above the
mower to avoid risk of injury.
27. Do not mow by pulling the machine towards you or
by walking backwards.
28. Always keep hands and feet away from rotating
parts.
29. When the machine is not in use, store it in a dry,
and high or locked-up place, out of reach of chil-
dren.
30. Only use the machine as instructed in this user
manual.
31. Check regularly that the nuts, bolts, screws and
other fittings are tight and secure.
32. Keep the hover mower free of grass, leaves and
other debris buid-up.
33. Do not try to repair the machine or access internal
parts. Use Authorised Talon Service Agents only.
34. Do not get distracted and concentrate on what you
are doing. Use common sense. Never operate the
hover mower when you are tired, sick or under the
influence of alcohol or drugs.
35. Keep these instructions. Refer to them frequently
and use them to instruct other users. If you loan
someone this unit, also loan them these instructions.
Failure to follow operating instructions and safety pre-
cautions in this instructions manual can result in serious
injury. Read the manual before starting or operating this
unit.
2

AU
4
• HOW TO MOW
1. To obtain the best results, cut area of grass by mov-
ing in a straight line proceeding slowly.
2. Cut your grass at least twice a week during the grow-
ing season.
3. Do not overload the mower. Mowing thick grass may
cause the motor speed to drop. If the motor speed
drops, you may overload the motor of the trimmer
your hover mower is attached to.
4. When mowing long thick grass a first cut with the cut-
ting height at its highest level will help reduce the
load.
• ADDITIONAL SAFETY PRECAUTIONS
WARNING / CAUTION
• IF UNFAMILIAR WITH mowing techniques, practice
the procedures with ENGINE in “OFF” position.
• ALWAYS CLEAR WORK area of debris such as cans,
bottles, rocks, etc. Striking objects can cause serious
injury to operator or bystanders and also damage
equipment. If an object is accidentally hit, immediately
TURN ENGINE OFF and examine equipment. Never
operate unit with damaged or defective equipment.
• ALWAYS TRIM OR CUT AT HIGH ENGINE SPEEDS.
Do not run engine slowly at start or during mowing
operations.
• DO NOT use equipment for purposes other than
trimming or mowing grass.
•NEVER raise hover mower above knee height during
operation.
• DO NOT operate unit with other people or animals in
the immediate vicinity. Allow a minimum of 50 feet (15
meters) between operator and other people and
animals when trimming or mowing. Allow a distance of
100 feet (30 meters) between operator and other
people and animals.
• IF OPERATING UNIT ON A SLOPE, stand below the
hover mower attachment. DO NOT OPERATE on a
slope or hilly incline if there is the slightest chance of
slipping or losing your footing.
1. The cutting blades are made from high quality,
hardened steel and with normal usage, they will not
require resharpening. However, if you accidentally
hit a wire fence, stones, glass or other hard objects,
you may put a nick in the blade. There is no need to
remove this nick as long as it does not interfere with
the movement of the blade. If it does interfere, turn
the power source off and use a fine toothed file or
sharpening stone to remove the nick.
2. If you drop the hover mower attachment, carefully
inspect it for damage. If the blade is bent, housing
cracked, or handles broken or if you see any other
condition that may affect operation contact a
professional service center for repairs before putting
it back into use.
3. Fertilizers and other garden chemicals contain
agents which greatly accelerate the corrosion of
metals. Do not store the tool on or adjacent to
fertilizers or chemicals.
4. With the unit powered off, use only mild soap and a
damp cloth to clean the tool. Never let any liquid get
inside the tool; never immerse any part of the tool
into a liquid.
NOTE: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustments should be per-
formed by a Talon authorised repair service center using
identical replacement parts.
OPERATING INSTRUCTIONS
MAINTENANCE AND REPAIR INSTRUCTIONS
AU
3
SPECIFICATIONS
Blade Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12” (300mm)
Shaft Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .660mm
Shaft Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7/8”
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.15 kg
• INSTALLING THE SHAFT
1. Insert the drive shaft assembly(A) into the flexible rub-
ber tube(B) so that the rivet (C) in the shaft rests in the
recess at the top of the rubber tube. (Fig. 1A)
IMPORTANT: Ensure that the front of the hover
mower is facing an outwards direction. Incorrect
installation of the shaft will result in poor cutting and
hover performance.
2. To secure the drive shaft assembly in place, tighten
the adjustable clamp(D) with a screwdriver (not sup-
plied). (Fig. 1B)
3. Silde the rubber cover(A) over the end of the shaft(B)
and onto the hover mower housing. Insert the tabs(C)
into the slits.(Fig. 1C & 1D)
• ADJUSTING THE CUTTING HEIGHT
Your hover mower comes with the two cutting
height adjustment spacers already installed. To adjust the
cutting height refer to the following instructions:
1. Using an adjustable spanner (not supplied), untighten
the bolt (A) by holding the impeller (B) firmly with one
hand and turn the bolt anti-clockwise with the other.
(Fig. 2A)
2. Remove the washers (F) and bolt (G) from the blade.
(Fig. 2B)
3. Remove the blade(E) from the pegs of the height
adjustment spacers(D). (Fig.2B)
NOTE: To increase the height of the cut, remove spacers.
To decrease the hight of the cut, add spacers.
5. When you are staisfied with the cutting height, re-
install the blade (E) making sure that the pegs on the
spacers fit into the spacer holes in the blade (E). (Fig.
1B)
6. Insert washers (F) and bolt (G). To fasten bolt to
blade, using an adjustable spanner (not supplied),
hold the impeller (C) with one hand and turn the bolt
colckwise with the other. (Fig. 2B)
• INSTALLING THE ATTACHMENT
1. Grip the lower shaft (A). Press the release lever (B)
while pushing the lower shaft into the tool-link coup-
ing. (Fig. 3A)
2. Locate and lock the release lever into the primary hole
(C) in the shaft. (Fig. 3A)
3. Tighten the knob (D) securely clockwise before using
the unit. (Fig. 3B)
CAUTION: Always wear heavy-duty work
gloves when handling and installing a blade.
A
B
Fig. 1C Fig. 1D
C
D
C
Fig. 2A Fig. 2B
E
F
G
CAUTION: Make sure the release lever is
locked in the primary hole and knob is
securely tightened before operating this unit.
CAUTION: All attachments are designed to
be used in the primary hole unless otherwise
indicated in the specific attachment’s opera-
tor’s manual. If the incorrect hole is used, it
could result in injury, or damage to the unit.
B
A
Fig. 3A Fig. 3B
C
D
ASSEMBLY INSTRUCTIONS
Fig. 1A
B
A
C
D
Fig. 1B
A
B
