T&D RTR-500B1 User manual
2009.04 16004244230 3rd Edition
RTR-500B1
Large Capacity Battery Pack
About this Product
This product is a Large Capacity Battery Pack especially designed for use with our
RTR-500x Series data loggers.
Caution: If this product is used in combination with any product other than those
specified above, T&D Corporation shall in no manner, whatsoever,
guarantee the operation of this product.
Package Contents
The package contains the following:
Large Capacity Battery Pack Rubber Packing Attachment hook
Drying agent
(Silica Gel)
Double-sided
Adhesive Tape ×1
(for fastening silica gel)
Screw ×２
(extras for fastening back of
main unit)
Specifications
Power ： Lithium Battery ×１(LS26500)
Battery Life ： about 2 years and 6 months
（Monitoring at 1 minute interval=about 20
months ※1）
Waterproof Capability ： Splash proof
Weight ： about 75g (including lithium battery)
Operating Temperature ： -40-80℃※2
Note:
※1：Battery Life varies depending on measuring environment,
recording interval, transmission frequency, and ambient
temperature. The battery life estimated here is calculated using
a new battery under normal operating conditions and in no way
should be understood as a guarantee of battery life.
※2：Operating temperature depends on the specifications for the data
logger being used.
How to Attach
Caution: If you do not wish to lose the recorded data, please finish this operation
in less than 1 minute from the time that you remove the battery from the
RTR-500x Series unit. (We suggest that you download recorded data
before attaching the adaptor. For details about downloading data, see
the User’s Manual that comes with the software you are using or the
Base Unit being used for our Thermo Recorder RTR-500x Series Data
Loggers.)
1. Remove the back lid from the RTR-500x Series unit, open the unit
and take out the battery.
2. Attach the double-sided adhesive tape to the back of the drying agent
and fix to the inner side of the RTR-500B1.
3. Insert the accompanying lithium battery into the battery pack.
4.Check the RTR-500B1 rubber packing for abrasions, cuts and dirt. If
the packing is in good condition, insert into the grooves making sure
that it is properly fit.
Caution:
● Abrasions or dirt may cause small opening to occur through which water
or other foreign objects can enter and cause damage to the unit.
● The rubber packing is a special item and is not sold in stores. If it
becomes damaged, please replace it by ordering [Maintenance Set](TR-
00P1) or by ordering a new [Large Capacity Battery Pack Battery Set]
(RTR-500B2).
5. Making sure that the 2 electrical wires are in the grooves as in
diagram A (below left), insert A (as in right diagram) into the battery
space of the RTR-500x Series unit. Close the case and fasten the
screws.
Caution: If the electrical wires are not properly in their grooves, the lid
may not completely close. Please make sure that the wires are
in their grooves before continuing.
If no recording settings have been made before carrying out this
operation, recording will begin from the time section A is inserted into
the battery space.
※If, after inserting section A, nothing appears in the unit's LCD display,
please repeat the steps above and attach again, For details about the
display, see the appropriate user's manual for the RTR-500x Series
unit.
6. If necessary, put on the attachment hook.
A
A
Shimadachi 817-1, Matsumoto, Nagano 390-0852 Japan
Tel:+81-263-40-0131 Fax:+81-263-40-3152
E-mail: suppor[email protected]
Homepage: http://www.tandd.com/
◆Notices about this User's Manual
●Please read this manual carefully before using the product.
●All rights of this User's Manual belong to T&D Corporation. It is prohibited to
use, duplicate and/or arrange a part or whole of this User's Manual without
the permission of T&D Corporation.
●Please follow the safety precautions carefully. We cannot guarantee nor are
we responsible for safety if this product is used in any manner other than was
intended.
●T&D Corporation accepts no responsibility for any malfunction of and /or
trouble with this product or with your computer that is caused by the improper
handling of this product and will deem such trouble or malfunction as falling
outside the conditions for free repair of the attached warranty.
●T&D Corporation accepts no responsibility for any result or effects from using
this User's Manual.
●Figures and illustrations in this manual may be slightly simplified and may
differ from the actual product.
●On screen messages, figures or illustrations in this manual may vary slightly
or be simplified from the actual messages and product.
●We sincerely hope that the contents of this manual are true and complete. If
you find any information to have been omitted, or if the information within is
confusing or mistaken please, contact your retailer or T&D Corporation.
●Microsoft ®, Windows ® and WindowsNT® are registered trademarks of
Microsoft Corporation USA and are binding in the USA and all other
countries. Company names and product names are trademarks or registered
trademarks of each company.
●This User's Manual cannot be reissued, so please keep it in a safe place.
●Please carefully read this User's Manual and Free Repair Warranty.
