Tannoy DVS speaker User manual

DVS Series
Stylish Surface Mount Loudspeakers
Operation Manual

2
DVS Series Operation Manual rev 2.0.0

3
DVS Series Operation Manual rev 2.0.0
Table of Contents
1. Introduction 4
2. Safety Instructions 4
3. Product Feature Identication 5
4. Standard Accessories 6
5. Installation Guidelines 7
6. DVS Dimensions 8
7. Technical Specications 11
8. Warranty 14
Table of Contents

1. Introduction
4
DVS Series Operation Manual rev 2.0.0
1. Introduction
Designed for a wide variety of sound reinforcement applications the Tannoy DVS is an ultra compact loudspeaker
system capable of delivering high sound pressure levels with extremely low distortion, resulting in outstanding
clarity, denition and detail. A truly universal solution, the DVS offers outstanding durability and resistance to scuffs
and knocks. Able to deliver consistent performance under a wide range of adverse conditions the DVS is suited
to applications indoors or out. Available in black or white the DVS will effectively blend into most backgrounds.
Utilisation of the point source loudspeaker allows the DVS to be mounted on a wall or ceiling in either horizontal
or vertical orientations without affecting its performance. A range of hardware options ensures simple and
effective installation. Only available with built-in line transformer. For applications requiring extended low frequency
enhancement, a range of Tannoy sub-bass systems are available and can be used in conjunction with the DVS.
2. Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. The user is responsible for xing the hardware to the surface to ensure safe operation. The xings must
support the weight of the product – please consult the manual’s specication page for the appropriate weights.
Please consult the relevant construction codes in your region for further information on suitable hardware
xing methods.
Tannoy will not be held responsible for any damages caused by the improper installation of these loudspeakers.

3. Product Feature Identification
5
DVS Series Operation Manual rev 2.0.0
3. Product Feature Identification
INPUT CONNECTOR
Fit rubber grommet to ensure the
rear of the product is kept sealed

4. Standard Accessories
6
DVS Series Operation Manual rev 2.0.0
4. Standard Accessories
DINKLE SEAL
YOKE BRACKET
(SUPPLIED WITH
FIXINGS)

5. Installation Guidelines
7
DVS Series Operation Manual rev 2.0.0
5. Installation Guidelines
1. Fix the yoke bracket to the surface using a suitable xing method. (Fig.1)
2. Feed the speaker cable through the cable clamp cover then connect the
Euro-type plug to the wires, observing the correct polarity. (Fig.2)
3. For connection to the loudspeaker, use Pins 1 (+) and 2 (-).
Pins 3 (-) and 4 (+) are in parallel for connection to additional speakers
in a distributed line. (Fig.3)
4. Offer the speaker up to the bracket and attach using the thumb
screws provided (Fig.4)
5. Connect the Euro-type plug then replace the rubber grommet to
ensure the speaker is sealed. (Fig.5)
6. The DVS 4t models are tted with 30 W transformers. (Fig.6)
THE SPEAKER IS SUPPLIED IN LOW IMPEDANCE MODE.
NEVER CONNECT THE SPEAKER TO A 70/100 VOLT AMPLIFIER WHILE
IT IS SET FOR LOW IMPEDANCE.
7. The DVS 6t and DVS 8t models are tted with 60 W transformers. (Fig.7)
THE SPEAKER IS SUPPLIED IN LOW IMPEDANCE MODE.
NEVER CONNECT THE SPEAKER TO A 70/100 VOLT AMPLIFIER WHILE
IT IS SET FOR LOW IMPEDANCE.
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
Fig.6
Fig.7

6. DVS Dimensions
8
DVS Series Operation Manual rev 2.0.0
6. DVS Dimensions
DVS 4
165.6
(6.52”) 153.6
(6.05”)
170.4
(6.71”)
51.0
(2.01”)
277.0
(10.91”)
246.4
(9.70”)
259.0
(10.20”)
4.6
(0.18”)
182.0
(7.17”)
143.0
(5.63”)

6. DVS Dimensions
9
DVS Series Operation Manual rev 2.0.0
6. DVS Dimensions
DVS 6
53.0
(2.09”)
216.5
(8.52”) 206.3
(8.12”)
212.2
(8.36”)
340.5
(13.41”)
304.5
(11.99”)
4.6
(0.18”)
246.0
(9.69”) 206.5
(8.13”)
31.0
(1.22”)

6. DVS Dimensions
10
DVS Series Operation Manual rev 2.0.0
6. DVS Dimensions
DVS 8
296.0
(11.65”) 265.1
(10.44”)
60.5
(2.38”)
290.0
(11.42”)
451.8
(17.79”) 415.7
(16.37”)
357.0
(14.06”)
4.6
(0.18”)
298.0
(11.73”)
26.7
(1.05”)

7. Technical Specifications
11
DVS Series Operation Manual rev 2.0.0
7. Technical Specifications
DVS 4/DVS 4t Model
Ordering Information
Part Number Colour
8001 6710
DVS 4 Black
8001 6711
DVS 4 White
8001 6720
DVS 4t Black
8001 6721
DVS 4t White
Performance
System DVS 4
Frequency response (-3 dB) (1) 75 Hz - 20 kHz
Frequency range (-10 dB) (1) 60 Hz - 30 kHz
Rated sensitivity (1W @ 1m) (2) 84 dB
Dispersion (-6 dB) 110 degrees conical
Directivity factor (Q) 6.5 averaged 1 kHz to 10 kHz
Directivity Index (DI) 5.3 averaged 1 kHz to 10 kHz
Power Handling
Average 40 W
Programme 80 W
Peak 160 W
Recommended Amplier Power 80 W @ 6 ohms
Nominal Impedance (Lo, Z) 6 ohms
Rated maximum SPL (1 m, Lo Z) (2)
Average 100 dB
Peak 106 dB
Crossover Point 3.9 kHz - 2nd order LF, 2nd order HF
Distortion
10% full power (4.9 V) Harmonics
2nd 3rd
250 Hz 0.738% 0.772%
1 kHz 0.145% 0.234%
10 kHz 0.070% 0.070%
1% full power (1.55 V)
250 Hz 0.320% 0.311%
1 kHz 0.078% 0.174%
10 kHz 0.087% 0.087%
Transducers
Low Frequency 100 mm (4.00”) mineral loaded cone material
High Frequency 19 mm (0.75”)
Physical
Enclosure ABS
Grille Aluminium, Painted
Connectors Euroblock type removable locking connector with screw terminals with
“loop through” facility
Transformer Setting Rotary switch
Dimensions (H x W x D) 277.0 x 170.4 x 165.6 mm
(10.91” x 6.71” x 6.52”)
Net Weight (ea) 1.8 kg (3.96 lbs)
Shipped weight 5.4 kg (11.9 lbs)
Supplied Accessories Yoke bracket
Packed Quantity 2
Transformer Version (specications as above except)
Transformer Taps (via front rotary switch)
70 V 30 W (165 Ω) / 15 W (330 Ω) / 7.5 W (660 Ω) / 3.75 W (1320 Ω) /
OFF & low impedance operation
100 V 30 W (330 Ω) / 15 W (660 Ω) / 7.5 W (1320 Ω) /
OFF & low impedance operation
Maximum wire gauge for connector 2.5 mm2 CSA (AWG12)
Safety Agency Ratings UL-1480, CE
Net Weight (ea) 2.3 kg (5.07 lbs)
Shipped Weight 6.2 kg (13.66 lbs)
Notes:
1. Average over stated bandwidth. Measured at
1 metre on axis in an Anechoic Chamber
2. Unweighted pink noise input, measured at
1 metre in an Anechoic Chamber
A full range of measurements, performance data,
CLF and Ease™ Data for DVS 4 can be downloaded
from www.tannoypro.com.
Tannoy operates a policy of continuous research
and development. The introduction of new materials
or manufacturing methods will always equal or
exceed the publishing specications, which Tannoy
reserves the right to alter without prior notice. Please
verify the latest specications when dealing with
critical applications.
Copyright (c) 2016 Tannoy Limited. All rights reserved.
UL-1480

7. Technical Specifications
12
DVS Series Operation Manual rev 2.0.0
7. Technical Specifications
DVS 6/DVS 6t Model
Ordering Information
Part Number Colour
8001 6730
DVS 6 Black
8001 6731
DVS 6 White
8001 6740
DVS 6t Black
8001 6741
DVS 6t White
Performance
System DVS 6
Frequency response (-3 dB) (1) 80 Hz - 20 kHz
Frequency range (-10 dB) (1) 65 Hz - 30 kHz
Rated sensitivity (1W @ 1m) (2) 88 dB
Dispersion (-6 dB) 90 degrees conical
Directivity factor (Q) 10.6 averaged 1 kHz to 10 kHz
Directivity Index (DI) 9.6 averaged 1 kHz to 10 kHz
Power Handling
Average 60 W
Programme 120 W
Peak 240 W
Recommended Amplier Power 120 W @ 6 ohms
Nominal Impedance (Lo, Z) 6 ohms
Rated maximum SPL (1 m, Lo Z) (2)
Average 105 dB
Peak 111 dB
Crossover Point 4.3 kHz - 2nd order LF, 2nd order HF
Distortion
10% full power (6.0 V) Harmonics
2nd 3rd
250 Hz 0.934% 0.316%
1 kHz 0.292% 0.560%
10 kHz 0.740% 0.050%
1% full power (1.9 V)
250 Hz 0.225% 0.326%
1 kHz 0.082% 0.363%
10 kHz 0.147% 0.066%
Transducers
Low Frequency 160 mm (6.00”) mineral loaded cone material
High Frequency 19 mm (0.75”)
Physical
Enclosure ABS
Grille Aluminium, Painted
Connectors Euroblock type removable locking connector with screw terminals with
“loop through” facility
Transformer Setting Rotary switch
Dimensions (H x W x D) 340.5 x 212.2 x 216.5 mm
(13.41 x 8.36 x 8.52”)
Net Weight (ea) 3.1 kg (6.83 lbs)
Shipped weight 8.5 kg (18.94 lbs)
Supplied Accessories Yoke bracket
Packed Quantity 2
Transformer Version (specications as above except)
Transformer Taps (via front rotary switch)
70 V 60 W (83 Ω) / 30 W (165 Ω) / 15 W (330 Ω) / 7.5 W (660 Ω) /
OFF & low impedance operation
100 V 60 W (165 Ω) / 30 W (330 Ω) / 15 W (660 Ω) /
OFF & low impedance operation
Maximum wire gauge for connector 2.5 mm2 CSA (AWG12)
Safety Agency Ratings UL-1480, CE
Net Weight (ea) 4.1 kg (9.03 lbs)
Shipped Weight 10.6 kg (23.35 lbs)
Notes:
1. Average over stated bandwidth. Measured at
1 metre on axis in an Anechoic Chamber
2. Unweighted pink noise input, measured at
1 metre in an Anechoic Chamber
A full range of measurements, performance data,
CLF and Ease™ Data for DVS 6 can be downloaded
from www.tannoypro.com.
Tannoy operates a policy of continuous research
and development. The introduction of new materials
or manufacturing methods will always equal or
exceed the publishing specications, which Tannoy
reserves the right to alter without prior notice. Please
verify the latest specications when dealing with
critical applications.
Copyright (c) 2016 Tannoy Limited. All rights reserved.
UL-1480

7. Technical Specifications
13
DVS Series Operation Manual rev 2.0.0
7. Technical Specifications
DVS 8/DVS 8t Model
Ordering Information
Part Number Colour
8001 6750
DVS 8 Black
8001 6751
DVS 8 White
8001 6760
DVS 8t Black
8001 6761
DVS 8t White
Performance
System DVS 6
Frequency response (-3 dB) (1) 75 Hz - 20 kHz
Frequency range (-10 dB) (1) 60 Hz - 30 kHz
Rated sensitivity (1W @ 1m) (2) 90 dB
Dispersion (-6 dB) 80 degrees conical
Directivity factor (Q) 12.3 averaged 1 kHz to 10 kHz
Directivity Index (DI) 10.0 averaged 1 kHz to 10 kHz
Power Handling
Average 70 W
Programme 140 W
Peak 280 W
Recommended Amplier Power 140 W @ 6 ohms
Nominal Impedance (Lo, Z) 6 ohms
Rated maximum SPL (1 m, Lo Z) (2)
Average 108 dB
Peak 114 dB
Crossover Point 3.4 kHz - 2nd order LF, 2nd order HF
Distortion
10% full power (6.48 V) Harmonics
2nd 3rd
250 Hz 0.891% 0.217%
1 kHz 0.235% 0.643%
10 kHz 0.666% 0.093%
1% full power (2.05 V)
250 Hz 0.236% 0.192%
1 kHz 0.051% 0.409%
10 kHz 0.217% 0.081%
Transducers
Low Frequency 200 mm (8.00”) mineral loaded cone material
High Frequency 19 mm (0.75”)
Physical
Enclosure ABS
Grille Aluminium, Painted
Connectors Euroblock type removable locking connector with screw terminals with
“loop through” facility
Transformer Setting Rotary switch
Dimensions (H x W x D) 451.8 x 290.0 x 296.0 mm
(17.78 x 11.42 x 11.65”)
Net Weight (ea) 5.3 kg (11.67 lbs)
Shipped weight 14.6 kg (32.16 lbs)
Supplied Accessories Yoke bracket
Packed Quantity 2
Transformer Version (specications as above except)
Transformer Taps (via front rotary switch)
70 V 60 W (83 Ω) / 30 W (165 Ω) / 15 W (330 Ω) / 7.5 W (660 Ω) /
OFF & low impedance operation
100 V 60 W (165 Ω) / 30 W (330 Ω) / 15 W (660 Ω) /
OFF & low impedance operation
Maximum wire gauge for connector 2.5 mm2 CSA (AWG12)
Safety Agency Ratings UL-1480, CE
Net Weight (ea) 6.3 kg (13.88 lbs)
Shipped Weight 16.6 kg (36.56 lbs)
Notes:
1. Average over stated bandwidth. Measured at
1 metre on axis in an Anechoic Chamber
2. Unweighted pink noise input, measured at
1 metre in an Anechoic Chamber
A full range of measurements, performance data,
CLF and Ease™ Data for DVS 8 can be downloaded
from www.tannoypro.com.
Tannoy operates a policy of continuous research
and development. The introduction of new materials
or manufacturing methods will always equal or
exceed the publishing specications, which Tannoy
reserves the right to alter without prior notice. Please
verify the latest specications when dealing with
critical applications.
Copyright (c) 2016 Tannoy Limited. All rights reserved.
UL-1480

8. Warranty
14
DVS Series Operation Manual rev 2.0.0
8. Warranty
No maintenance of the DVS Series loudspeaker is necessary.
As part of the MUSIC Group, Tannoy is committed to providing the highest quality products, service and user
experience for our customers. One element of this commitment is our after sales support which now incorporates
our extended Limited Warranty. In the event of any concern that is not addressed by this extended Limited
Warranty we would ask you to contact us at car[email protected]
For full warranty details including the extended Limited Warranty, please visit
http://www.music-group.com/warranty.aspx and register your purchase online at www.music-group.com
orwww.tannoy.com

15
DVS Series Operation Manual rev 2.0.0
Notes
Notes

tannoypro.com
6481 0584/180216
Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing
methods will always equal or exceed the published specications. All specications are subject to change without notice.
Copyright (c) 2016 Music Group Innovation SC Ltd. All rights reserved.
