Tanova TB User manual

For Models:
All TB Models,
Handle and
Drawer Types
Installation Guide
Your Handy Step By Step
For further assistance in New Zealand
www.tanova.co.nz 0800 852 258
For further assistance in Australia
www.tanova.com.au 1300 123 700

2NEW ZEALAND
For further assistance call our free phone number 0800 852 258
or consult our website www.fit-nz.co.nz
• If your cabinet is made to suit the minimum internal sizes the bin
frame will fit snugly in the cabinet and allow easy installation.
These dimensions can be found on our website on each product’s
Download Brochure link.
• If your cabinet width is greater than the minimum internal width
and you are mounting a drawer front then you need to centralise
the bin frame in the cabinet.
• If you’re fitting a handle type, you need to fix to the opposite side
of the cabinet to the door hinges or a minimum of 25mm from
hinged side of cabinet.
NOTE: Please refer to Tanova Waste Solutions catalogue for internal dimensions.
1.
With your cabinet upside down (fig.1) position the bin frame as shown
with a minimum clearance of 2mm back from cabinet front (fig.2).
NOTE: If the system is a
Push to Open unit, 5mm
of clearance must be
maintained between
back of drawer front and
cabinet (including bump
stops if fitted).
Bringing assembly flush
with the front of the
cabinet will achieve this.
Fig. 1 Fig. 2
IMPORTANT: Minimum
clearance of 2mm from
the front of the cabinet.
2mm

3
AUSTRALIA
For further assistance call our free phone number 1300 123 700
or consult our website www.tanova.com.au
2.
Ideally you will fasten the bin frame through the top and side dimples to
provide excellent stability. To get access to all the dimples you may need to
extend the bin carriage as shown (fig.3 and fig.4).
3.
If you’re installing a handle type just fit the buckets into the bin carriage
and you are done.
4.
If you have a set of marking jigs go to step 5. If not measure off the fixing
points and mark on back of door then go to step 6.
5.
To mount your drawer front with marking jigs, insert the jigs as shown
below and position your front panel then give the front a bump wit your
hand to mark the screw positions on the reverse side of the door (fig.5).
Fig. 3
Secure bin to top
of cabinet.
Fig. 4
Secure bin frame to cabinet
sides through runner and dimples.
Fig. 5
Insert marking jig into top two slots
and turn 90˚ to lock in place.

NEW ZEALAND
For further assistance call our free phone number 0800 852 258
or consult our website www.fit-nz.co.nz
6.
Now pre drill a 2-3mm hole in the centre of your marks and fit drawer front to
bracket, tighten gently.
7.
Close bin drawer and check alignment, adjust and insert remaining 4 screws.
8.
Check alignment again and adjust.
9.
Now fasten the two remaining screws into lock off points to prevent drawer
front movement.
10.
Insert bins and you’re ready to go.
11.
Bags can be fitted (optional), just raise handles and place bag liner in bin and
around the rim, now lower handles to hold bag open and firmly in place.
For further assistance in New Zealand
www.tanova.co.nz 0800 852 258
For further assistance in Australia
www.tanova.com.au 1300 123 700
Fig. 6
Adjustment slots
Lock off points
