Tapco DB-1P User manual




FEATURES
• Converts unbalanced line-level signals to balanced mic-level output
• Provides signal and impedance matching for the direct connection
of instruments to amplifiers and mixers
• 1/4" Input jacks for connecting instrument or speaker-level signals
(switch selectable)
• 1/4" Thru jack allows the unbalanced signal to be sent to an
onstage amplifier while the balanced signal is sent to a mixer
• Ground Lift switch helps eliminate hum and buzz problems in
musical instrument hookups
• Allows use of long cables without high-frequency loss
• The DB-1A can be powered either internally by two 9-volt batteries
or externally by phantom power from a mixer
• The DB-1P passive model has a noise filter for reducing buzz and
hiss (switch selectable)
DB-1A
INPUT THRU
OUT IN
POWER
SPKR
PKUP
LINE
GND
LIFT
13
2
456
1. INPUT — Connect the signal source to this 1/4" unbalanced TS jack.
2. POWER LED — Indicates when the power is on. When powered
from the internal batteries, it lights when a signal is plugged into the
INPUT jack. When powered from a mixer's phantom power, it lights
as long as the phantom power is applied.
3. THRU — This 1/4" unbalanced TS jack is in parallel with the INPUT
jack and provides a “Thru” connection of the input signal for
sending to an amplifier onstage.
4. PKUP/LINE — Move this switch to the left when connecting an
instrument with a passive pickup, like an electric guitar. Move this
switch to the right when connecting a line-level signal to the input.
5. SPKR — When connecting a speaker-level signal (for example, from
a guitar amplifier’s speaker output), move this switch to the right
(IN).
6. GND/LIFT — This switch makes or breaks the input ground to pin 1
of the XLR output jack. When the switch is to the left, the ground
is connected, and when the switch is to the right, the ground is
disconnected (LIFTED).
7. OUTPUT — This balanced XLR jack provides a low-impedance
mic-level signal for connecting to a microphone input on a mixer. If
the mixer has phantom power, it can be used to power the DB-1A.
Power automatically switches away from the internal batteries to
save battery life.
Pin 1 = Ground
Pin 2 = Hot (+) and in-phase with the input signal
Pin 3 = Cold (–)
OUTPUT
7
TO INSTALL OR CHANGE THE BATTERIES:
1. Using a small phillips screwdriver, remove the four screws on each
side and the two screws on the bottom of the DB-1A as shown in
Figure 1.
2. Slide the tray out of the cover.
3. Install two 9-volt batteries into the battery clips and slide the
batteries into the retaining bracket as shown.
4. Reassemble the DB-1A.
CAUTION: Do not use longer screws than the original
screws provided. Longer screws will short out the
circuit board and void the warranty.
Figure 1
1

Part No. 0015052 Rev. A 02/05
©2005 LOUD Technologies Inc. All Rights Reserved.
It is important to keep your receipt in a safe place, and not a bad idea to write your product information
here for future reference (i.e., insurance claims, tech support, return authorization, etc.).
PRODUCT SERIAL #:
PURCHASED AT:
DATE OF PURCHASE:
DB-1P
INPUT THRU
INST
AMP
FLAT
FILTER
1234
1. INPUT — Connect the signal source to this 1/4" unbalanced TS jack.
2. INST/AMP — Leave this switch out when connecting an instrument
or line-level signal to the INPUT jack. Push this switch in when
connecting a speaker-level signal (for example, from a guitar
amplifier’s speaker output).
3. FLAT/FILTER — Push this switch in to engage a high-cut filter to
reduce hiss and noise when using the AMP input setting. The filter
has no effect when the input is set to INST (2).
4. THRU — This 1/4" unbalanced TS jack is in parallel with the INPUT
jack and provides a “Thru” connection of the input signal for
sending to an amplifier onstage.
5. OUTPUT — This balanced XLR jack provides a low-impedance mic-
level signal for connecting to a microphone input on a mixer.
Pin 1 = Ground
Pin 2 = Hot (+) and in-phase with the input signal
Pin 3 = Cold (–)
6. GND/LIFT — This switch makes or breaks the input ground to pin 1
of the XLR output jack. When the switch is in the OUT position, the
ground is connected, and when the switch is pushed IN, the ground
is disconnected (LIFTED).
OUTPUT
GND
LIFT
5
6
2

SPECIFICATIONS
DB-1A
Frequency Response:
100 Hz – 20 kHz (+/– 0.05 dBm)
20 Hz – 20 kHz (+/– 0.80 dBm)
Maximum Input Level:
Pickup: +8 dBm
Line: +15 dBm
Speaker: +35 dBm
Input Impedance:
Pickup: 10M ohm
Line: 10M ohm
Speaker: 11k ohm
Gain:
Pickup: –8 dBm
Line: –28 dBm
Speaker: –48 dBm
Residual Noise:
Pickup: –106 dBm
Line: –109 dBm
Speaker: –109 dBm
Signal-to-Noise Ratio (with 15 dB headroom):
Pickup: –99 dB
Line: –109 dB
Speaker: –89 dB
Rise Time: 1 microsecond, no overshoot
THD + Noise: 0.01%
Output Impedance:
200 ohms
Power Requirements:
48 V phantom power or two 9 V batteries
Battery Life: 300 hours
Current Draw: < 7 mA DC
Dimensions:
Height: 2.0 in/51 mm
Width: 4.3 in/109 mm
Depth: 4.0 in/102 mm
Weight: 14 oz
Lonely? Looking for that special someone? Do you have a question about
your TAPCO DI Box?
Please call our Technical Support chaps at 1-877-827-2669, Monday to Friday, from 7 am to 5 pm PST.
After hours, visit www.tapcogear.com and look under Support, or e-mail us at [e-mail]
DB-1P
Frequency Response:
100 Hz – 20 kHz (+/– 0.05 dBm)
Nominal Input Level:
Inst: 0 dBm
Amp: 0 dBm
Nominal Output Level:
Inst: –21 dBm
Amp: -52 dBm
Gain:
Inst: –21 dBm
Amp: –52 dBm
Residual Noise:
Inst: –135 dBm
Amp: –135 dBm
THD: 0.01%
Dimensions:
Height: 2.0 in/51 mm
Width: 4.3 in/109 mm
Depth: 4.0 in/102 mm
Weight: 12 oz
Disclaimer
Since we are always striving to make our products better by
incorporating new and improved materials, components, and
manufacturing methods, we reserve the right to change these
specifications at any time without notice.
“TAPCO” is a registered trademark of LOUD Technologies Inc.
All other brand names mentioned are trademarks or registered
trademarks of their respective holders, and are hereby
acknowledged.
3

TAPCO LIMITED WARRANTY
A. LOUD Technologies Inc. warrants all materials,
workmanship and proper operation of this TAPCO
product for a period of one year from the original date
of purchase. If any defects are found in the materials
or workmanship, or if the product fails to function
properly during the applicable warranty period, LOUD
Technologies, at its option, will repair or replace the
product. This warranty applies only to equipment sold
and delivered within the U.S. by LOUD Technologies or its
authorized dealers.
B. Failure to register online or return the product registration
card will not void the one-year warranty.
C. Service and repairs of TAPCO products are to be
performed only at a factory-authorized service center.
Unauthorized service, repairs, or modification will void this
warranty. To obtain repairs under warranty, you must have
a copy of your sales receipt from the authorized TAPCO
dealer where you purchased the product. It is necessary
to establish purchase date and determine whether your
TAPCO product is within the warranty period.
D. To obtain factory-authorized service:
1. Call TAPCO Technical Support at 877/827-2669, 7 AM
to 5 PM Monday through Friday (Pacific Time) to get a
Service Request Number. Products returned without a
Service Request Number will be refused.
2. Pack the product in its original shipping carton. Also
include a note explaining exactly how to duplicate the
problem, a copy of the sales receipt with price and date
showing, and your return stree address (no P.O. boxes
or route numbers, please!). If we cannot duplicate the
problem or establish the starting date of your Limited
Warranty, we may, at our option, charge for service time.
3. Ship the product in its original shipping carton, freight
prepaid, to the authorized service center. The address of
your closest authorized service center will be given to you
by Technical Support.
IMPORTANT: Make sure that the Service Request
Number is plainly written on the shipping carton.
E. LOUD Technologies Inc. reserves the right to inspect
any products that may be the subject of any warranty
claims before repair or replacement is carried out. LOUD
Technologies may, at our option, require proof of the
original date of purchase in the form of a dated copy
of the original dealer’s invoice or sales receipt. Final
determination of warranty coverage lies solely with
LOUD Technologies Inc.
F. TAPCO products returned to one of the LOUD Technologies
factory-authorized service centers and deemed eligible for
repair or replacement under the terms of this warranty will
be repaired or replaced within thirty days of receipt. LOUD
Technologies and its authorized service centers may use
refurbished parts for repair or replacement of any product.
Products returned to LOUD Technologies that do not meet
the terms of this Warranty will not be repaired unless payment
is received for labor, materials, return freight, and insurance.
Products repaired under warranty will be returned freight
prepaid by LOUD Technologies to any location within the
boundaries of the USA.
G. LOUD Technologies warrants all repairs performed for 90
days or for the remainder of the original warranty period.
This warranty does not extend to damage resulting from
improper installation, misuse, neglect or abuse, or to
exterior appearance. This warranty is recognized only if
the inspection seals and serial number on the unit have not
been defaced or removed.
H. LOUD Technologies assumes no responsibility for the
quality or timeliness of repairs performed by Authorized
TAPCO Service Centers.
I. This warranty is extended to the original purchaser and
to anyone who may subsequently purchase this product
within the applicable warranty period. A copy of the sales
receipt is required to obtain warranty repairs.
J. This is your sole warranty. LOUD Technologies Inc. does
not authorize any third party, including any dealer or
sales representative, to assume any liability on behalf of
LOUD Technologies or to make any warranty for LOUD
Technologies Inc.
K. THE WARRANTY GIVEN ON THIS PAGE IS THE SOLE
WARRANTY GIVEN BY LOUD TECHNOLOGIES
INC. AND IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS AND IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. THE WARRANTY
GIVEN ON THIS PAGE SHALL BE STRICTLY
LIMITED IN DURATION TO ONE YEAR FROM
THE DATE OF ORIGINAL PURCHASE FROM AN
AUTHORIZED TAPCO DEALER. UPON EXPIRATION
OF THE APPLICABLE WARRANTY PERIOD, LOUD
TECHNOLOGIES INC. SHALL HAVE NO FURTHER
WARRANTY OBLIGATION OF ANY KIND. LOUD
TECHNOLOGIES INC. SHALL NOT BE LIABLE FOR
ANY INCIDENTAL, SPECIAL, OR CONSEQUENTIAL
DAMAGES THAT MAY RESULT FROM ANY DEFECT
IN THE TAPCO PRODUCT OR ANY WARRANTY
CLAIM. Some states do not allow exclusion or limitation
of incidental, special, or consequential damages or a
limitation on how long warranties last, so some of the
above limitations and exclusions may not apply to you.
This warranty provides specific legal rights and you
may have other rights which vary from state to state.
Please keep your sales receipt in a safe place.
4
