Task Force Tips CROSSFIRE Quick guide

INSTRUCTIONS FOR SAFE OPERATION AND MAINTENANCE
Read instruction manual before use. Operation of this device without understanding
the manual and receiving proper training is a misuse of this equipment. A person who
has not read and understood all operating and safety instructions, is not qualified to
operate the CROSSFIRE portable/deck gun.
This instruction manual is intended to familiarize firefighters and maintenance personnel with the operation, servicing, and
safety procedures associated with the CROSSFIRE portable/deck gun.
This manual should be kept available to all operating and maintenance personnel.
DANGER
CROSSFIRE
MANUAL:
WITH STOW-A-WAY 800 BASE
TFTX-XXXXXXTFTX-XXXXXX
SERIAL#:SERIAL #: MODEL#:XFT-NJMODEL#:XFT-NJ
©Copyright Task Force Tips, Inc. 1999-2011 LIX-040 September 13, 2011 Rev05
TASK FORCE TIPS, Inc. 3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
MADE IN USA •www.tft.com
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Firefighting and Emergency Response are inherently dangerous
activities requiring proper training in their hazards and the use of extreme
caution at all times.
2. It is your responsibility to read and understand any user's instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Firefighting and /or Emergency Response and in the use, precautions,
and care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the
manufacturer’s instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
DANGER
PERSONAL RESPONSIBILITY CODE
Fire and Emergency Manufacturers and Services Association, Inc.
P.O. Box 147, Lynnfield, MA 01940 • www.FEMSA.org
FEMSA
Maximum recommended flow:
1250 GPM (5000 L/min)
on truck mount adaptor,
800 GPM (3000 L/min)
on portable base.
Maximum recommended
inlet pressure is 175 psi (12 bar).
TASK FORCE TIPS
®
FIRE FIGHTING EQUIPMENT
®

2
1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 SAFETY
3.0 GENERAL INFORMATION
4.0 CROSSFIRE® DEPLOYMENT
3.1 PART IDENTIFICATION
4.1 QUICK CONNECT SWIVEL JOINT
4.2 INSTALLING MONITOR ON BASE
.3 REMOVING MONITOR TOP FROM BASE
4.4 SIDE-TO-SIDE ROTATION & ROTATION
LOCK
4.5 ELEVATION CONTROL & STOP PIN
4.6 AUTOMATIC DRAIN
4.7 TRUCK MOUNT BASE
4.8 TRUCK MOUNTING OF THE PORTABLE
BASE
4.9 CROSSFIRE® USAGE
4.10 FLOWS & PRESSURES
4.10.1 STACKED TIPS
4.10.2 AUTOMATIC MASTER STREAM
NOZZLES
4.10.3 STREAM STRAIGHTENERS
4.11 TRANSPORTING MONITOR ON TRUCK
MOUNT BASE
5.0 STOW-A-WAY 800 BASE
6.0 MAINTENANCE
7.0 SPECIFICATIONS
8.0 DRAWINGS AND PARTS LIST
9.0 WARRANTY - CROSSFIRE SERIES
10.0 INSPECTION CHECKLIST
5.1 SITE SELECTION
5.2 EXTENDING PORTABLE BASE LEGS
5.3 RETRACTING PORTABLE BASE LEGS
5.4 PORTABLE BASE LEG SPIKES
5.5 PORTABLE BASE ANCHORING
5.6 ADDING A FLOW SAFETY VALVE
5.7 HOSE CONNECTION
5.8 PORTABLE BASE STORAGE
5.9 PRESSURE RELIEF OPTION
5.10 PRESSURE RELIEF VALVE SETTING
6.1 GREASE WORM GEAR
6.2 PERFORMANCE TESTING
TABLE OF CONTENTS
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI standard Z535.4-1998 the definitions of the three signal words are as follows:
DANGER
CAUTION
WARNING
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
2.0 SAFETY
The operation of this monitor, particularly with the portable base can be dangerous.
The following must be observed at all times.
Low nozzle elevation angles can cause portable monitors to slide or lift off the ground which can
result in injury or death. Do not operate the monitor on the portable base below the elevation safety
stop.
An out of control monitor can cause injury or death. To reduce risk of instability, do not attempt to
move the portable monitor with water flowing.
Injury can occur from an inadequately supported monitor. When the monitor is used on a truck the
mounting must be capable of supporting 900 lbs (400 KG) of nozzle reaction force. Note: the
storage bracket is intended for storage of the monitor only. It is not strong enough to withstand the
forces of monitor operation. Flanges and pipe made from plastic are inadequate for monitor
mounting and must not be used.
DANGER
DANGER
WARNING

3
A sliding monitor can cause injury. To protect against sliding:
• make sure the base legs are locked in position with all leg spikes in contact with the ground.
• securely tie the monitor to an object capable of withstanding 900 lbs (400 kg) of force.
• use additional tie downs on hard surfaces such as concrete, asphalt, and metal.
• avoid lifting the monitor when moving the hoses around it.
WARNING
WARNING This equipment is intended for use by trained personnel for firefighting. Their use for other
purposes may involve hazards not addressed by this manual. Seek appropriate guidance and
training to reduce risk of injury.
Some volatile liquids can be ignited by static discharge. Static build-up can occur from:
Electrochemical separation of charge as water drains through low conductivity, refined
products.
Applying foam over a low conductivity liquid of sufficient depth to retain the charge created as
the foam blanket drains.
Streaming currents as water or foam is introduced into the storage tank.
!
!
!
1
WARNING
Water is a conductor of electricity. Application of water solutions on high voltage equipment can
cause injury or death by electrocution. The amount of current that may be carried back to the nozzle
will depend on the following factors:
Voltage of the line or equipment
Distance from the nozzle to the line or equipment
Size of the stream
Whether the stream is solid or broken
Purity of the water
!
!
!
!
!
2
WARNING
1
2
Electrostatic Hazards of Foam Blanketing Operations by Peter Howels. Industrial Fire Safety July/August 1993
The Fire Fighter and Electrical Equipment, The University of Michigan Extension Service, Fourth Printing 1983. Page 47.
Master stream flows are very powerful and capable of causing injury and property damage. Make
sure the monitor is securely attached to the base and pointing in a safe direction before water to the
monitor is turned on. Use care in directing the stream.
CAUTION
Do not couple aluminum to brass. Dissimilar metals coupled together can cause galvanic
corrosion that can result in inability to unscrew threads or complete loss of thread engagement.
CAUTION Nozzle must be properly connected. Mismatched or damaged threads may cause nozzle to leak or
uncouple under pressure and could cause injury.
CAUTION
3.0 GENERAL INFORMATION
The CROSSFIRE monitor is the most rugged and innovative deck/portable master stream device ever offered to the fire service.
Attachment of the CROSSFIRE to the base is quick, easy, positive, and can be visually verified. The release mechanism is locked out by
water pressure. The rotation lock is a simple lever which securely holds the CROSSFIRE monitor in position. An automatic drain allows
water to drain from the monitor when not in use.

4
3.1 CROSSFIRE PART IDENTIFICATION
Figures 3.1.1, 3.1.2, & 3.1.3 show the CROSSFIRE monitor, STOW-A-WAY 800 portable base, truck mount adapter and identifies the
various parts and controls.
Figure 3.1.3
Figure 3.1.2
Figure 3.1.1
CROSSFIRE
MONITOR TOP
STOW-A-WAY 800
BASE
TRUCK MOUNT
ADAPTOR COMPANION
FLANGE
Carrying Handle
Inlet
Pressure Gauge
Elevation Pin Stop
Anchor Strap
& Storage Cover
Elevation Control
Grease Fitting
Stainless Steel Leg
Rotation Lock
Slide Bar
Carrying Handle
Automatic Drain
Safety Plunger
Leg Lock Knob
Pawls
Anchor
Attachment Point

5
4.0 CROSSFIRE DEPLOYMENT
4.1 QUICK CONNECT SWIVEL JOINT
4.3 REMOVING MONITOR TOP FROM BASE
4.2 INSTALLING MONITOR ON BASE
4.4 SIDE-TO-SIDE ROTATION AND ROTATION LOCK
The CROSSFIRE monitor can be used on either a truck mount adaptor, Extend-A-Gun or portable base. Installation on either base
makes use of a quick connect swivel joint. The use of each base and the quick connect joint is explained in the following sections.
Two pawls, actuated by the slide bar, engage in the base swivel to make the quick connect joint. A safety plunger engages in the slide
bar to prevent accidental unlocking of the slide bar when the monitor is under pressure.
To install the monitor on either the truck mount flange or portable base: Refer to figures 4.2.1, 4.2.2, & 4.2.3.
Side-to-side rotation is accomplished by rotating the monitor on its base. The rotational position can be locked by moving the rotation
lock lever to its down position as shown in Figures 4.4.1 & 4.4.2. Before the monitor is removed from the base, the rotation lock should
be manually disengaged. A small spring holds the rotational lock in the unlocked position. When not rotating the monitor on the base,
keep the rotation lock locked.
To remove the monitor from it’s base:
• Stop all water flow.
• Depress the safety plunger and lift the slide bar which will disengage the spring loaded pawls from the groove in the base.
• Lift the monitor straight up off the base by the handle on top of the monitor.
Figure 4.2.1 Figure 4.2.2 Figure 4.2.3
Slide bar up, safety
plunger is not engaged.
Slide bar locked, safety
plunger is engaged.
A
B C
A) Turn elevation handwheel to make sure the
elevation of the nozzle is above the 35° safety stop.
Verify that the elevation stop pin is down and
engaged.
Make sure the slide bar is in the up position.
B) Hold the monitor by the top
carrying handle, position
monitor over base and slide
straight down.
C) Push the slide bar down,
watch the pawls engage the
groove in the base and the
safety plunger engage in the
hole in the slide bar.
C
A
B

6
XL090
DANGER
Operating On Portable
Base Below This Stop
(pin pulled) Is Dangerous.
An automatic drain empties water from a low point in the monitor piping to prevent freezing and help empty hose lines. The valve is
designed to close automatically when pressure in the monitor exceeds approximately 5 psi and open again when the pressure drops
to that point. When the automatic drain is not desirable it may be disabled. To disable the drain valve refer to the exploded view on page
12 and follow the steps below:
1) Unscrew the drain assembly (40, 41, 42, & 43) and remove the screw and washer (42 & 43)
2) Flip over the rubber drain valve (41) so that the raised edge is against the face of the housing (40).
3) Reassemble.
4.5 ELEVATION CONTROL AND STOP PIN
When mounted on a truck base, the nozzle may be lowered below the 35° safety stop by pulling out the stop pin and rotating the
handwheel below the 35° stop. When the nozzle is raised back above 35°, the spring loaded stop pin will snap back into position
automatically limiting the elevation of the nozzle with respect to the base to 35°.
4.6 AUTOMATIC DRAIN
A sliding monitor can cause injury. When used on a portable base, keep the horizontal
angle between the water stream and the anchor strap as small as possible. At large
angles the base can slide in an arc around the anchor point.
Operating on a portable base below this safety stop is DANGEROUS. Do not operate
on portable base below safety stop. Injury or death can occur if the monitor and base
slides or lifts off the ground.
Figure 4.4.1
Unlocked
Figure 4.5.1
Elevaton control
Figure 4.4.2
Locked
Figure 4.5.2
Elevation stop pin out
Figure 4.5.3
Elevation stop pin in
DANGER
WARNING
When a nozzle is flowing water the reaction force acts in a straight line that is directly
opposite the water flowing out the end of the nozzle. If a nozzle on a monitor on a
portable base is pointed straight up, all of the reaction force is directed straight down
and there is no sideways force that can cause the base to slide. As the nozzle is
angled downward at the same flow, the reaction force remains the same, but some of
that force becomes a force acting sideways and some acts in a downward direction.
When the nozzle is at an angle of 45° the force acting sideways is equal to the force
acting downward on the base. As the elevation angle of the nozzle is lowered the
sideways force increases while the downward force decreases. At an angle of 35°, (the angle at the elevation safety stop),
approximately 82% of the nozzle reaction force is acting sideways on the base. When the nozzle is at a zero degree angle, with respect
to the base, the entire reaction force is acting sideways on the base and there is no downward force at all. The lower the elevation angle
of the nozzle, with respect to the base, the greater the force that causes sliding, and the more likely sliding will occur.
35°

7
4.7 TRUCK MOUNT BASE
The CROSSFIRE® monitor may be used from a truck by using a truck mount adapter. The truck mount adapter can be bolted to the
riser pipe with a 3" ANSI 150# or 4" ANSI 150# companion flange and gasket using 5/8" bolts. It can also be screwed directly on a male
pipe thread. Use of pipe thread sealant is recommended. The riser must be supported to safely withstand a nozzle reaction force of up
to 900 lbs (400 KG). Make sure that no interference exists between the monitor and other deck mounted equipment in any direction.
See truck mount base installation instructions for details, document #LIX-045.
A drain valve should be provided in the riser pipe which supplies the monitor. The riser should be drained immediately after each use
during cold weather to prevent freezing and possible damage. The monitor has an automatic drain. If this drain has been disabled (see
section 4.6), the monitor must be drained by lowering the nozzle below horizontal. Installation instructions are supplied with the truck
mount base.
4.8 TRUCK MOUNTING OF THE PORTABLE BASE
In some cases a user may not have a riser directly off of the pump that can be used for mounting the monitor. In this case it may be
desirable to supply the monitor with hose lines connected to the side discharge of the pumper. In these circumstances it is
recommended that the user purchase a Deck Mount Plate, TFT part XF400-KIT, from the manufacturer. Please call 1-800-348-2686 for
further information and advice concerning mounting alternatives. Installation instructions are shipped with this accessory. The storage
bracket, TFT part XF-B, for the base unit IS NOT STRONG ENOUGH to withstand the forces encountered with an operating monitor
and is not intended for this purpose.
4.9 CROSSFIRE® USAGE
Because of the arched trajectory of a fire stream, it is recommended that a spotter be used to accurately direct the stream from the
monitor. Master streams flows are powerful and capable of injury and damage to property. Use great care in directing the stream.
4.10 FLOWS & PRESSURES
The CROSSFIRE® monitor is designed for maximum flows of 1250 gpm (5000 l/min) on the truck mount adaptor, 800 gpm (3000 l/min)
on the STOW-A-WAY portable base and a maximum pressure of 175 psi (12 bar). Do not exceed these limits.
4.10.1 STACKED TIPS
NOZZLE
DIAMETER
NOZZLE
DIAMETER
(MM)
NOZZLE PRESSURE
NOZZLE PRESSURE
150 PSI
10 BAR
1-3/8"
1-1/2"
1-3/4"
2"
35
38
44
50
80 PSI
5.5 BAR
500
600
810
1060
240
280
380
500
FLOW
(GPM)
REACTION
(LBS)
1900
2300
3000
3900
110
130
170
220
FLOW
(L/min)
REACTION
(KG)
175 PSI
730
870
1190
—
520
620
840
—
REACTION
(LBS)
FLOW
(GPM)
12 BAR
2800
3300
4500
—
240
280
370
—
REACTION
(KG)
FLOW
(L/min)
680
810
1100
—
440
520
712
—
REACTION
(LBS)
FLOW
(GPM)
2600
3000
4100
—
200
230
310
—
REACTION
(KG)
FLOW
(L/min)
100 PSI
7 BAR
50 PSI
3.5 BAR
560
660
910
1190
300
350
480
630
REACTION
(LBS)
FLOW
(GPM)
2200
2500
3400
4400
140
160
220
280
REACTION
(KG)
FLOW
(L/min)
400
470
640
840
1500
1800
2400
3100
150
180
240
310
70
80
110
140
REACTION
(LBS)
REACTION
(KG)
FLOW
(GPM)
FLOW
(L/min)
Flow exceeds rating of portable base. Use only when monitor is truck mounted.
Flow exceeds rating of truck mounted monitor.
Flow exceeds rating of portable base. Use only when monitor is truck mounted.
Flow exceeds rating of truck mounted monitor.

8
The portable base legs are extended by following these steps:
(Refer to figures 5.2.1, 5.2.2, & 5.2.3)
a) Hold the base carrying handle with one hand and grasp the end of one
of the longer legs with the other hand. Pull this leg away from the base
forward in an arc, until the locking pin engages. The locking pin is spring
loaded and automatically engages when the legs are in the correct
position. Watch the leg lock knob drop down, even with the lower band
on the base, indicated by an arrow.
b) Repeat procedure (a) to extend other set of legs.
Figure 5.2.1
Hold base carrying handle and
grasp end of longer leg
Figure 5.2.2
One set of legs opened and
locked in position
Figure 5.2.3
Both sets of legs opened and
locked in position
5.0 STOW-A-WAY 800 BASE
The portable base allows the monitor to be positioned in places that are not accessible with a fire truck. The legs are made of stainless
spring steel and will flex when in use to compensate for small ground irregularities. It is intended for maximum flows of 800 gpm (3000
l/min).
5.1 SITE SELECTION
Safe operation of the monitor on the portable base begins with site selection. The site should be a safe distance from the fire yet within
reach of the nozzle stream. Select a flat even surface within 8 feet of a sturdy stationary object that can be used as an attachment point
for the anchor strap. Set up the portable base with the anchor point between the portable base and desired target of the nozzle stream.
5.2 EXTENDING PORTABLE BASE LEGS
c) Set portable base on even ground with all leg spikes in contact with the ground.
If the monitor is to be transported on a truck mount base, the horizontal lock should be kept locked to keep the monitor from spinning
on its base. The rotational position can be locked by moving the rotation lock lever to its down position. The nozzle may be supported
by a bracket or pointed straight up.
4.10.2 AUTOMATIC MASTER STREAM NOZZLES
Automatic nozzles maintain a constant pressure by adjusting their opening to match the available flow. Consult the nozzle
manufacturer for maximum flow and pressure ratings. In all cases, do not exceed 1250 gpm (5000 l/min) or 175 psi (12 bar) on a truck
mounted monitor or 800 gpm (3000 l/min) on the STOW-A-WAY base.
4.10.3 STREAM STRAIGHTENERS
4.11 TRANSPORTING MONITOR ON TRUCK MOUNT BASE
Stream quality, especially with smooth bore nozzles, is generally improved with a stream straightener because the water must make
many bends passing through a monitor.

9
Lift off the storage cap and remove the anchor strap from inside the base. Keep the anchor strap near the monitor as it will be used to
anchor monitor before use.
5.4 PORTABLE BASE LEG SPIKES
The STOW-A-WAY Base has 5 tungsten carbide tipped spikes on the legs and base to resist sliding by digging into the surface the base
is sitting on. The amount of sideways force these spikes can withstand depends upon several factors, particularly, the amount of
downward and sideways force that is on the base and the hardness and texture of the surface the spikes are in contact with. At low
elevation angles it is difficult for these spikes to resist sliding. This is why the portable base must be well anchored. These spikes are
essential to safe operation of the monitor base and must be in contact with the ground at all times. Do not operate without first securing
the monitor with safety lines to prevent sliding. Set the monitor on an even surface so that all the spikes contact the ground. See section
6.0 for spike inspection procedures.
5.5 PORTABLE BASE ANCHORING
A sliding monitor can cause injury. Remove all slack between the anchor and base
before flowing water.
At low nozzle elevation angles the base may also require additional anchoring. The ability of a single anchor to stop sliding is a function
of the horizontal angle between the strap and water stream. When the stream is in line with the anchor any sliding will be arrested by the
anchor. As the horizontal angle increases between the anchor strap and the stream, the base can begin to slide in an arc around the
anchor point. In this situation multiple anchor points may be required.
The strap should be stored inside the monitor base when not in use. The black rubber cap on the strap will hold the strap in the base
and protect the sealing surface of the quick connect swivel joint.
Whenever the monitor is operated on the portable base, the
base must be anchored to a substantial immovable object.
An attachment point is provided on the front of the base for
this purpose. A strap, with a minimum breaking strength of
3000 lbs (1300 kg) of force, is supplied with the portable
base. A loop on the end of the strap may be placed over the
anchor point or the strap may be wrapped around an object,
such as a tree, and the snap end of the strap passed through
the loop and pulled tight. Keep the entire length of the strap
as close to the ground as possible. Snap the hook into the
hole in the front of the portable base below the carrying
handle. The length of the strap may be adjusted by the sliding
the buckle on the strap. If the strap is too short to reach a
suitable anchor, it may be extended with strong rope or chain.
Keep the distance between the base and anchor point as
short as possible.
WARNING
For carrying and storage, the legs are retracted as follows:
a) Pull up on one of the spring loaded leg lock knobs, grasp the forward leg, on the same
side, and push it, in an arc, towards the rear of the unit. The leg lock knob may be released
as soon as the front leg begins to move out of position. Continue to push until both legs
come in contact with the rear stop.
b) Repeat procedure (a) to retract the other legs.
5.3 RETRACTING PORTABLE BASE LEGS
The STOW-A-WAY 800 portable base does not contain a flow safety valve.
A flow safety valve upgrade kit #XF500-KIT may be added to this portable base at any time to gain the features of the flow safety valve.
The kit may be installed in the field or at the factory.
The flow safety valve reduces the flow area through the monitor by 90%., should the base loose contact with the ground for any reason.
In the reduced flow condition, the nozzle reaction is less thereby reducing the risk of injury.
5.6 ADDING A FLOW SAFETY VALVE

10
1
2
5.7 HOSE CONNECTION
Make the hose connection(s) to the portable base and extend the hose(s) straight back from the portable base at least 10 feet (3
meters). If only one inlet of a double inlet base be used, a clapper valve will automatically close off the other inlet. Use caution when
turning on the water to the monitor on the portable base. As the hose fills it will become stiff and may cause the monitor and portable
base to slide or tip or both. Open the pumper valve to the monitor slowly.
5.8 PORTABLE BASE STORAGE
The portable base may be stored in a compartment, on the optional storage
bracket, TFT part number XF-B. This bracket is NOT designed to withstand the
reaction forces of an operating monitor stream. It is to be used for storage and
transportation only. The storage bracket may be mounted on a horizontal surface,
horizontally or vertically on a vertical surface, or on the underside of a horizontal
surface such as the top of a compartment. A strap helps hold the base on the
bracket. Mounting instructions are supplied with the bracket.
5.9 PRESSURE RELIEF OPTION
XF-B
STORAGE
BRACKET
XF-B
STORAGE
BRACKET
1 2 3
The optional pressure relief valve on the single inlet portable base can be adjusted
to open between 50 and 200 psi. The pressure relief valve, TFT part A1820, is set at
the factory to open at 150 psi. To change the relief pressure refer to the label on the
bottom side of the pressure relief valve. A pressure relief valve can be added to the
single inlet portable base by removing the cover on the side of the base. For
additional information call 800-348-2686.
6.0 MAINTENANCE
The CROSSFIRE® monitor and its base require little maintenance. The unit should be kept clean and free of dirt by flushing with water
after each use. All controls should be checked for freedom of movement and condition. Any inoperable or damaged part should be
repaired or replaced immediately. Specific areas to check are as follows:
Truck Mount Base:
1) Sealing surface above swivel joint must be smooth.
2) Swivel joint must rotate freely.
Portable Base:
1) Sealing surface above swivel joint must be smooth.
2) Swivel joint must rotate freely.
3) Legs and leg lock pins must move freely and lock in position.
4) Leg spikes must be sharp.
(replace if flats at tip of spikes exceed 1/16" diameter)
1
2
3
4
Monitor:
1) Handwheel must rotate freely.
2) Elevation stop pin must return to safe position.
3) Quick disconnect latch and safety catch must operate freely.
4) Rotation lock must operate freely and keep monitor from rotating
when engaged.
5.10 PRESSURE RELIEF VALVE SETTING
To set the relief valve pressure turn the adjusting screw on the relief valve housing
until the surface of the screw is even with the desired pressure. Do not cap or plug
discharge opening.
Adjusting
Screw
Relief Valve
Discharge
Opening
4
1
3
2
3
2
1
TFTX-XXXXXX
SERIAL#:SERIAL#: MODEL#:XFT-NJMODEL#:XFT-NJ
0
psi
200
120
12
80
60
40
20
10
4
0
2
bar
14
68
100
160
180
140

11
Performance tests shall be conducted on the Crossfire Monitor after a repair, or anytime a problem is reported to verify operation in
accordance with Task Force Tips test procedures. Consult factory for the procedure that corresponds to the model and the serial number
of the Monitor. Any equipment which fails the related test criteria should be removed from service immediately. Troubleshooting
guides are available with each test procedure or equipment can be returned to the factory for service and testing.
6.1 GREASE WORM GEAR
Turn the handwheel to move the nozzle to its highest elevation and pump grease (medium viscosity automotive) into
the fitting in the worm gear housing until excess appears.
6.2 PERFORMANCE TESTS
7.0 SPECIFICATIONS
CROSSFIRE Monitor STOW-A-WAY 800 Base*
Weight
Storage Volume
L-W-H
Height Above Truck Flange
Height Above Truck Deck (min)
Height Above Ground on Base
Line of Reaction Force Above Ground
Flow Area (minimum)
Maximum Flow
Maximum Pressure
Materials Used
Inlets Available
17 lbs
6.7 kg
4060 in
.066m
20" x 14-1/2" x 14"
.51 x .37 x .36m
12-1/2 in
320mm
14 in
360mm
16-1/2 in
420mm
4in
100mm
8.3 in
5360mm
1250 GPM
5000 L/min
175 PSI
12 bar
Cast Aluminum, Aluminum,
Stainless Steel
One
3
3
2
2
20.7 lbs
9.4 kg
1620 in
.027m3
20"x9"x9"
.51 x .23 x .23m
NA
NA
NA
NA
8.3 in
800 GPM
3000 L/min
175 PSI
12 bar
Cast Aluminum, Aluminum,
Stainless Steel
Numerous Single & Double Inlets
2-1/2"-6"
3
2
5360mm2
Dimensions shown for STOW-A-WAY 800 portable base with double inlet 2-1/2" model.

12
# DESCRIPTION QTY PART #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18
20
21
23
24
SHAFT NUT 1 X210
SNAP RING 1 VR4220
BEARING 1 VM4250
WORM WITH KEYWAY 1 X220
KEY 1/8 X 1.00 1 X225
BUSHING 1 X230
BOOT 1 X240
DANGER LABEL 1 XL090
11/4-28 GREASE FITTING 1 VT25-28ZERK
PULL PIN 1 X340
PULL PIN SPRING 1 X345
PULL PIN HOUSING 1 X350
KEY RING 1 VR4300
5/16-18 X 1-1/4 SHCS 2 VT31-18SH1.2
3/8-16X7/8SHCS 1 VT37-16SH875
PEG - CARRYING HANDLE 1 X362
BIG BEND/BELL ASSEMBLY 1 X800**
200 PSI/BAR GAGE/BUMPER 1 X823
HANDWHEEL ASSEMBLY 1 X810
ROTATION LOCK PIVOT 1 X180
ROTATION LOCK INSERT 1 X170
25 ROTATION LOCK SPRING 1 X152
26 ROTATION LOCK LEVER 1 X821
# DESCRIPTION QTY PART #
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
45A
46
47
48
PAWL 2 X135
DETENT SPRING 2 H770
WEAR STRIP 1 X120
CUP SEAL .366 NITRILE 70A 1 X125
SLIDE BAR 1 X140
#6-32 X 1/4 BUTTON HEAD 2 VT06E32BH250
COVER 1 X142
CLEVIS PIN RETAINER 1 X137
O-RING-018 1 VO-018
PLUNGER WAVE SPRING 1 X165
SAFETY PLUNGER 1 X150
2.5 NH ELBOW/VANE ASSEMBLY 1 X339NJ**
O-RING-241 1 VO-241
DRAIN HOUSING 1 X375
DRAIN PLUG 1 X382
FLAT WASHER 1 VW687X281-50
1/4-28 X 1/2 BHCS 1 VT25-28BH500
O-RING 130 1 VO-130
5/16 SS BALLS 38 VB.312
5/16 TORLON BALLS 38 VB.312TO
3/8-24 x 3/8 SOCKET SET 2 VT37F24SS312
MANUAL - CROSSFIRE WITH 1 LIX-040
STOW-A-WAY BASE
DVD - CROSSFIRE 1 LIX-200
8.0 DRAWINGS & PARTS LIST
** NOTE: Specify desired color and hose thread at time of order.
CROSSFIRE
Model No. XFT-NJ
®
INSTRUCTIONS FOR SAFE OPERATION AND MAINTENANCEINSTRUCTIONS FOR SAFE OPERATION AND MAINTENANCE
Read instruction manual before use. Operation of this device
without understanding the manual and receiving proper training is a
misuse of this equipment. A person who has not read and
understood all operating and safety instructions, is not qualified to
operate the CROSSFIRE portable/deck gun.
Read instruction manual before use. Operation of this device
without understanding the manual and receiving proper training is a
misuse of this equipment. A person who has not read and
understood all operating and safety instructions, is not qualified to
operate the CROSSFIRE portable/deck gun.
This instruction manual is intended to familiarize firefighters and maintenance
personnel with the operation, servicing, and safety procedures associated with the
CROSSFIRE portable/deck gun.
This manual should be kept available to all operating and maintenance personnel.
This instruction manual is intended to familiarize firefighters and maintenance
personnel with the operation, servicing, and safety procedures associated with the
CR O SSF I R Epo r t a b l e / d e c kgu n .
This manual should be kept available to all operating and maintenance personnel.
Maximum recommended
flow is 1250 GPM on
truck mount adaptor, 800
GPM on portable base.
Maximum recommended
inlet pressure is 175 psi.
Maximum recommended
flow is 1250 GPM on
truck mount adaptor, 800
GPM on portable base.
Maximum recommended
inlet pressure is 175 psi.
CROSSFIRE
DANGER
MANUAL:
WITH STOW-A-WAY 800 BASE
MANUAL:
WITH STOW-A-WAY 800 BASE
OPERATIONS MANUAL:
DVD SUPPLEMENT
CROSSFIRE
This DVD is not intended to replace the reading and
understanding of the CROSSFIRE operations manual.
The safest, most versatile
master stream device...Ever!

13
# DESCRIPTION QTY PART #
1
2
3
4
5
6
7
8
10
11
35
36
37
38
40
41
42
43
SAFETY VALVE HANDLE LABEL 1 XL070
VALVE HANDLE 1 X540
1/4 x 1 3/8 SPIROL PIN 1 VP250X1.375H
TORSION SPRING 1 X560
BUTTERFLY 1 X550
5/32 x 1 1/8 SPIROL PIN 3 V1920
O-RING-118 2 VO-118
BUSHING 2 X565
O-RING-113 2 VO-113
VALVE SHAFT 1 X570
PADDLE 1 X530
1/4-20 x 7/8 FLAT HEAD 1 VT25E20FH875
WEAR PLATE 1 X585
PADDLE PIVOT 2 X590
PADDLE PIVOT SPRING 2 X575
3/32 x 1/2 SPIROL PIN 1 VP094X500H
TRIP PIN 1 X580
TRIP PIN SPRING 1 X582
STOW-A-WAY 800®
without Safety Valve
# DESCRIPTION QTY PART #
12
13
14
15
16
17
18
20
21
22
23
24
25
26
27
28
30
31
32
33
34
44
45
46
47
48
49
50
51
52
SWIVEL RING 1 X425
5/16 SS BALLS 76 VB.312
SWIVEL SCREW 2 X405
SHOT PIN KNOB 2 X430
KNOB BARREL 2 X440
SHOT PIN SPRING 2 X445
5/32 x 7/8 SPIROL PIN 2 V1900
SHOT PIN 2 X435
BASE 1 X420
BELLEVILLE WASHER 12 D07590
INSTRUCTION LEG LABEL 1-3 1 XL010
FRONT LEG - LEFT 1 X470L
INSTRUCTION LEG LABEL 4-5 1 XL020
REAR LEG - LEFT 1 X460L
SPIKE 4 X480
BOTTOM PLATE 1 X450
3/8-16 X 3/4 FLAT HEAD SHCS 4 VT37-16FH750
REAR LEG - RIGHT 1 X460R
TFT LEG LABEL 1 XL050
FRONT LEG - RIGHT 1 X470R
SAFE-TAK LEG LABEL 1 XL040
#10-32 x 3/4 BUTTON HEAD 1 VT10E32BH750
STAINLESS STEEL WASHER 18-8 2 V2038
STRAP CAP 1 X457
#10-32 HEX NUT 1 VT10-32NT
STRAP ASSEMBLY 1 RX455
1/4-28 X ½ BUTTONHEAD 2 VT25-28BH500
2.5" CLAPPER WASHER 2 X752
O-RING-118 2 VO-118
PLUG 2 X510
XF500-KIT
VALVE UPGRADE KIT
See
Section
5.6

14
HIGH FLOW SINGLE INLET OPTION
14 RELIEF VALVE WITHOUT THREAD, ALUMINUM 1 A1810
15 7/16-14 X 1 HEX HEAD BOLT 18-8 STAINLESS STEEL 4 VT43-14HX1.0
16 LDH BLANK CAP HARDCOAT USE ON X651 1 X631
17 SAFETY VALVE BASE LABEL 1 XL080
18 O-RING-236 3-1/4 ID 1/8 C/S 3.234 +/-.024 ID.139 +/-.004 C/S 1 VO-236
19 O-RING-244 4-1/4 ID 1/8 C/S 4.234+-.030 ID .139+-.004 C/S 1 VO-244
20 LDH ADAPTOR W/PSM5.25 1 X651
21 REAR SPIKE 1 X482
22 ¼-28 X ¾ BUTTON HEAD 1 VT25Y28BH750
23 PLASTIC STRIP 5.25 - MOLDED 1 A1291
24 CUP SEAL 5.25 X 4.75 X ¼ PRECISION ASSOCIATES #666-427 1 A1296
25 LOCKING LEVER - MOLDED 1 A4171
26 SPRING TORSION (STORZ LOCK) 9991067 MIDSTATE # 210049 1 A4230
27 COUPLING HEAD STROZ 5 X 5.25 PSF HARDCOAT 1 A4135
31 GASKET 5 PRESSURE MOLDED 9991000 1 A4220
32 BALL 7/16 STAINLESS 302 GRADE 100 1 VB.437
33 MATE PSM4.25 X PSF5.25 - HARDCOAD 1 A4730
35 PLASTIC STRIP 4.25 - MOLDED 1 A1292
36 CUP SEAL 4.25 X 3.750 X 1/4 1 A1297
37 COUPLING RL 3.0NHF X PSF4.25 1 A4650N
COUPLING RL 3.5NHF X PSF4.25 1 A4655N
38 GASKET 3.0 HOSE COUPLING 1 V3194
GASKET 3.5 HOSE COUPLING 1 V3196
39 4.0 NH FEMALE X PSF5.25 1 A4660N
40 4.0 HOSE COUPLING GASKET 1 V3198
# DESCRIPTION Qty Part #
1 STORZ 4" FTS PSF4.25 - PARTS SET FULL TIME SWIVEL 1 A4114.1
2 MATE PSM4.25 X PSF5.25 LOCKOUT PART SET 1 A4730.2
DESCRIPTION QTY PART
4" Storz Coupling is available (not shown)
19
20
21
22
23
25
27
24
31
26
17
16
18
15
14
40
39 24 23
24
23
33
35
36
37
38
32
18

15
9.0 WARRANTY - CROSSFIRE SERIES
Task Force Tips, Inc., 2800 East Evans Avenue, Valparaiso, Indiana 46383 (“TFT”) warrants to the original purchaser of its Crossfire
Monitor and Stow-A-Way 800 Base (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from
defects in material and workmanship during the five (5) year period from the date of purchase.
TFT’s obligation under this warranty is specifically limited to replacing or repairing the equipment (or its parts) which are shown by
TFT’s examination to be in a defective condition attributable to TFT. To qualify for this limited warranty, the claimant must return the
equipment to TFT, at 2800 East Evans Avenue, Valparaiso, Indiana 46383, within a reasonable time after discovery of the defect. TFT
will examine the equipment. If TFT determines that there is a defect attributable to it, it will correct the problem within a reasonable time.
If the equipment is covered by this limited warranty, TFT will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is an
intended or unintended beneficiary of the equipment, shall not be entitled to recover from TFT any consequential or incidental
damages for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT. It is agreed
and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone
else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL IMPLIED
WARRANTIES OF MERCHANT ABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE. THERE IS NO
WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THE DOCUMENT.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
DOUBLE INLET OPTION
# DESCRIPTION QTY PART #
1
2
3
4
5
6
7
8
1/4-28 x 1/2 SOCKET SET 2 VT25-28SS500
3/16 SS BALL 96 V2120
SAFETY VALVE BASE LABEL OR 1 XL080 OR
NO VALVE BASE LABEL XL085
2.5" WYE 1 X712
2.5" CLAPPER 1 X772
2.5" CLAPPER GASKET 2 X762
WASHER 2 VW1.9X26-076
1/4-20 x 7/8 SHCS, SS 1 VT25-20SH875
# DESCRIPTION QTY PART #
10
11
12
13
14
15
16
17
18
O-RING-244 1 VO-244
1/4-20 STAINLESS NUT 1 VT25-20NT
1/4-28 X 3/4 BUTTON HEAD 1 VT25-28BH750
PIVOT BOLT 1 X784
O-RING-013 1 VO-013
CLAPPER PIVOT 1 X732
REAR SPIKE 1 X482
2.5" NH COUPLING (pictured) 2 M307N
2.5" COUPLING GASKET (pictured) 2 V3190

10.0 INSPECTION CHECKLIST
Monitor must be inspected for proper operation and function according to this checklist before each use. Before flowing water
check:
Any monitor failing any part of the inspection checklist is unsafe and must have the problem
corrected before use. Operating a monitor that fails any of the above inspections is a misuse of this
equipment.
Hose(s) and nozzle are securely attached.
There is no obvious damage such as missing,
broken, or loose parts.
1
3
5
2
4
6
Legs are fully opened and locked in place.
All leg spikes are in contact with the ground.
Monitor is securely tied down with no slack
in anchor strap.
Flow Limited to 800 gpm (3000 l/min)
Master nozzle pumped to 800 gpm
or
Stacked Tips Limited to:
PORTABLE BASE
GENERAL
WARNING
1-3/8" dia 175 PSI
1-1/2" dia 140 PSI
1-3/4" dia 75 PSI
2" dia 40 PSI
35 MM 12 BAR
38 MM 9.7 BAR
44 MM 5.2 BAR
50 MM 2.8 BAR
8
7
9
12
10
11
Do Not point monitor in an unsafe direction.
Rotation lock lever securely locks rotation.
Monitor top freely swivels on base when
unlocked.
Elevation handwheel adjusts elevation freely.
Nozzle elevation is above safety stop.
Monitor top is securely attached.
MONITOR TOP
C
A
B
35°
©Copyright Task Force Tips, Inc. 1999-2011 LIX-040 September 13, 2011 Rev05
TASK FORCE TIPS, Inc. 3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
MADE IN USA •www.tft.com
