Tate IsoFlo Troubleshooting guide

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
Tate IsoFlo™Tate ContraFlo™
IsoFlo™and ContraFlo™
User Installation Guide
Please Read and Save
These Instructions

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
CONTENTS
Contents.............................................................................................................................................................................. 2
Introduction ........................................................................................................................................................................ 3
Safety Warnings and Cautions ............................................................................................................................................ 3
Included Components......................................................................................................................................................... 6
Additional System Components.......................................................................................................................................... 6
Required Tools .................................................................................................................................................................... 6
Moving The Enclosure......................................................................................................................................................... 7
Roof Installation.................................................................................................................................................................. 8
Chimney Assembly and Installation.................................................................................................................................... 9
Chimney Roof Installation................................................................................................................................................. 11
Door Installation ............................................................................................................................................................... 12
SideWall Installation ......................................................................................................................................................... 14
EIA Rail Installation ........................................................................................................................................................... 15
Captive Nuts Installation................................................................................................................................................... 16
Bolt Down Kit Installation ................................................................................................................................................. 17
Baying kit Installation........................................................................................................................................................ 18

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
INTRODUCTION
Thank you for choosing a Tate Airflow product. Tate Airflow products are engineered to maximize the
efficiency of your data center raised floor air handling system. We would be interested in hearing any
comments you may have on this installation manual, product, or overall experience. Please call or e-mail our
Technical Service Department:
Phone: [phone]
E-mail: [email protected]
SAFETY WARNINGS AND CAUTIONS
General
oThis document is subject to change without prior notification. No guarantees are given for the
accuracy of the information contained herein. The information is in particular not to be
understood to imply warranted qualities in any product.
oWear personal protective equipment (PPE) as applicable during installation. PPE may include
gloves, safety eyeglasses, hardhats, or additional equipment depending on exact job site
conditions.
oDo not leave the site unattended until the installation is complete.
Target group
oThis document is aimed at persons entrusted with the installation of IT racks and rack products.
Installation work must only be performed by trained persons. Tate assumes that you possess
the necessary qualifications to perform installation work and that you are aware of the hazards
which may arise when working with racks and rack products.
Safety notes
ATTENTION: IMMEDIATE DANGER TO LIFE AND LIMB IS POSSIBLE IF
PROPER SAFETY IS NOT OBSERVED.
Unpacking and moving
ATTENTION: THE RACK IS TOP-HEAVY AND CAN TILT OVER. AT LEAST TWO
PERSONS ARE REQUIRED WHEN MOVING OR UNPACKING THE RACK.
oFailure to observe this rule may lead to serious injuries and/or material damage.
Operating environment:

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
ATTENTION: THE RACK IS DESIGNED EXCLUSIVELY FOR USE
AS INTENDED IN INDOOR ENVIRONMENTS.
oAlso observe the information provided by the manufacturer(s) of the components to be
installed. Particular attention must be paid to the permissible environmental parameters, such
as temperature and humidity, and to the demands placed on the ambient air.
ATTENTION: IN CASE OF INSTALLATIONS WITH EXPOSED OR PARTIALLY EXPOSED
ELECTRICAL COMPONENTS LOCATED NEAR AN INFLAMMABLE SURFACE, THE
RACK MUST ALSO BE SEALED IN THE BASE WITH GLAND PLATES.
oFailure to observe this rule may lead to serious injuries and/or damage to the devices or
equipment.
Rack stabilization:
oStabilization measures are recommended or even imperative, depending on the place of
installation and/or the rack configuration.
Accessories:
oGrounding
Each Rack must be properly connected to the grounding system at the place of
installation before commissioning.
To this end, it is recommended that the central grounding point included in the scope of
supply is used.
Ground connections must only be made by trained expert personnel holding
corresponding certificates of qualification.
Rack configuration
oThe installation of devices and equipment must comply with the applicable regulations
pertaining to the installation of electrical and data processing devices and equipment.
THE RACK IS SPECIFIED FOR A MAXIMUM OF 3200LB STATIC TOTAL LOAD
CAPACITY.
oInstallation work must only be performed by trained expert personnel holding corresponding
certificates of qualification.
oDetermine the positions of the individual components before starting the actual configuration
of the Rack. Factors such as weight, accessibility, power supply requirements, temperature and
air circulation influence the order of installation and the positioning of the individual
components in the rack. The heaviest components should always be installed in the bottom of
the Rack, as that increases the stability of the rack.

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
EQUIPMENT SHOULD ALWAYS BE INSTALLED FROM THE BOTTOM OF THE RACK
FIRST AND WORK TOWARDS THE TOP OF THE RACK. INSTALLING EQUIPMENT AT
THE TOP OF THE RACK FIRST MAY INCREASE RISK OF TIPPING.
IF ENCLOSURE IS USED IN A STAND-ALONE APPLICATION, IT MUST BE INSTALLED
WITH A BOLT-DOWN KIT.
At least two persons are required to install or remove equipment or components which weigh more
than 50 lbs (22.5 kg).
oAlways ensure proper fixing and safe placement of all components and rack elements.
oWhether installed as a stand-alone configuration or in a rack suite, Racks must always be closed
with appropriate side panels prior to commissioning.
oCaution in case of withdrawable components and component shelves
oTo avoid injuries or material damage, the Rack must be stabilised appropriately before pulling
out any withdrawable components or component shelves.
oAlways pull only one component or component shelf out at a time. The rack may become
unstable if several components are pulled out at once.

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
INCLUDED COMPONENTS
IsoFlo or ContraFlow Enclosure (x1)
M12 x 20 Torx Low Head Cap Screw (x4)
Safety Washer (x2)
24”-48” Adjustable Chimney Kit (x1) [Optional, depending on ordered model]
ADDITIONAL SYSTEM COMPONENTS
24” Chimney Kit [IsoFlo Only]
24”-48” Chimney Kit [IsoFlo Only]
IsoFlo/ContraFlo Side Wall Kit
IsoFlo Partition Wall Kit [IsoFlo Only]
ContraFlo Partition Wall Kit [ContraFlo Only]
Bolt-down kit
Vertical cable management kit
24” Baying Bracket Kit
60CM Baying Bracket Kit
Cage Nut Package
REQUIRED TOOLS

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
MOVING THE ENCLOSURE

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
ROOF INSTALLATION

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
CHIMNEY ASSEMBLY AND INSTALLATION
Assemble All Components for “Outer” shell of
24-48” Adjustable Chimney
1
Assemble four pieces
into a frame, Place on
level floor
2
Locate threaded
screws through holes
on adjacent frames
3
Install Washer onto threaded screws, then lock
washers
4
Install lock nuts onto threaded screws and
tighten down firmly
5
Repeat around frame
until assembled
6

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
Assemble all components for “Inner” shell of
24-48” adjustable chimney
Repeat previous
assembly process from
outer shell
8
7
Locate cage nuts,
connect to square holes
on each face of “inner”
shell
9
Carefully Lift “Inner” Shell and slide into
“Outer” Shell. This may take two people.
10
Locate thumb screws, Insert through
gasketed slot and tighten lightly
11
Assembly Complete

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
CHIMNEY ROOF INSTALLATION
The Chimney shall be installed and adjusted to a
height adjacent to the drop ceiling.
Additional 2’ Chimney extensions may be
required as to achieve the appropriate height
chimney, please be sure to provide the finished
floor height of the access floor to the drop ceiling
height so that your Tate representative can assist
in selecting the proper products.
Note: The chimney does not require to be affixed to
the drop ceiling.

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
DOOR INSTALLATION

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
SIDEWALL INSTALLATION

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
EIA RAIL INSTALLATION
B
B
A

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
CAPTIVE NUTS INSTALLATION

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
BOLT DOWN KIT INSTALLATION

User Installation Guide
r1.3-10/3/14
IsoFlo™ and ContraFlo™
7510 Montevideo Road © 2014 Tate Access Floors, Inc.
Jessup, MD 20794
Tel [phone] of 18
BAYING KIT INSTALLATION
