TCL 4 Series Specification sheet

Hi! Let’s get started.
4-Series
S434-CA

DO NOT RETURN TO STORE
TCL SUPPORT:
support.tcl.com/ca
1-877-300-9576
contact us first
with any questions
WE ARE
READY TO
HELP
TAKE CARE WHEN
REMOVING THE TV

1
Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts
inside. Refer servicing to qualified service personnel.
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
This symbol indicates important instructions
accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that this product incorporates
double insulation between hazardous main voltage
and user accessible parts. When servicing, use only
identical replacement parts.
WARNING
To reduce the risk of fire or electric shock, do
not expose this product to rain or moisture.
This product should not be exposed to dripping
or splashing. No objects filled with liquids, such
as vases, should be placed on the apparatus.
WARNING
The TV is unstable if it is not properly attached to
the base or mounted to the wall. Please follow the
base or wall mounting instructions provided in the
User’s Guide to ensure your safety.
Warning: The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
Model No.
Purchase Date
Serial No.
Dealer/Address/Phone
Important Information
Refer to the identification/rating label located on the back panel of your product for its proper operating
voltage.
Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of the National
Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper
grounding and, in particular, specifies that the cable ground should beconnected to the grounding system
of the building as close to the point of cable entry as practical.
Important: This television is a table model and is designed to sit on a firm, flat surface. Don’t place
the TV on soft carpeting or similar surface because the ventilation slots on the bottom of the unit will
be blocked, resulting in reduced lifetime from overheating. To assure adequate ventilation for this
product, maintain a spacing of 1 inch from the top and side of the TV receiver and 2 inches from the
rear of the TV receiver and other surfaces.
Also, make sure the stand or base you use is of adequate size and strength to prevent the TV from
being accidentally tipped over, pushed o , or pulled o . This could cause personal injury and/or damage
to the TV. Refer to the Important Safety Instructions on the next page.
The Power button on this TV and your remote control puts the TV into a very low-power standby
mode but will not completely turn the power o . In order to completely shut the power o , you will
need to disconnect the power cord from the outlet. The mains plug/appliance coupler is used to
completely turn o the device. If you prefer to completely turn o the device, you should install
the TV in a manner that allows you to disconnect the power cord when desired.
Product Registration
Please register your TCL TV purchase on-line at www.tcl.com/ca. It will make it easier to contact
you should it ever be necessary. Registration is not required for warranty coverage.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here
and record the serial and model numbers in case you need them. These numbers are located on the
product.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. Keep the apparatus at least 8
inches away from the human body.
For the best viewing experience, remove the energy guide label from the TV front panel or TV screen
before use.
Input Signal Compatibility
480i, 480p, 720p/60Hz, 1080i/60Hz, 1080p/60Hz, 2160p/24/30/60Hz
480i
480i, 480p, 720p, 1080i (NTSC, ATSC, and QAM formats)
HDMI
Composite Video
Antenna/Cable

2
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
10. WARNING: Please refer the information on exterior bottom enclosure for electrical and safety information
before installing or operating the apparatus.
11. WARNING:The mains plug is used as disconnect device, the disconnect device shall remain readily
operable.
12. When not in use and during movement, please take care of the power cordset, e.g. tie up the power
cordset with cable tie or something like that. It shall be free from sharp edges and the like that can
cause abrasion of the power cordset. When put into use again, please make sure the power cordset
being not damaged. If any damages found, please look for the service person to replace the power
cordset specified by the manufacturer or have the same characteristics as the original one.
13. No naked flame sources, such as lighted candles, should be placed on the apparatus.
14.
Unplug this apparatus during lightning storms or when unused for long periods of time.
15. Only use attachments/accessories specified by the manufacturer.
16. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
17. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
18. For safe operation of the apparatus, observe these installation requirements:
Keep at least 2 inches of ventilation space between the rear cover of the apparatus and the wall.
Keep at least 1 inch of ventilation space between the apparatus and all other surfaces. Do not allow
any of the apparatus’ ventilation openings to be blocked by objects that might obstruct them, such
as newspapers, curtains, table-cloths or any other objects. Do not expose the apparatus to any external
heat sources. Do not place any heat sources such as candles, lamps, etc. on the apparatus. Do not expose
the device to high levels of humidity or to any possible sources of moisture. When disposing of used
batteries
from the remote control, consult local regulations regarding proper disposal.
19. If an outside antenna or cable system is connected to the product, be sure the antenna or cable system
is grounded so as to provide some protection against voltage surges and built-up static charges. Section
810 of the National Electrical Code, ANSI/NFPA No. 70-2011 (Section 54 of Canadian Electrical Code,
Part 1) provides information with respect to proper grounding of the mast and supporting structure,
grounding of the lead in wire to an antenna-discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
See following example:
ANTENNA LEAD IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND CLAMPS
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRIC SERVICE
EQUIPMENT POWER SERVICE GROUNDING
ELECTRODE SYSTEM (NEC ART
250, PART H)

Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and
the double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI, HDMI High-Definition MultimediaInterface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
3
ELECTRONICS RECYCLING INFORMATION FOR CONSUMERS
TCL strives to provide a high level of service to our customers and in the communities we serve, and recommends
that consumers always look for a recycling or reuse alternative to throwing away televisions and other electronics.
We encourage customers in each province to recycle their end-of-life electronic devices using one of the many
and recycle televisions. For information on electronics recycling in Canada, please visit the “Electronics Recycling”
area of the TCL Canada website at
www.tcl.com/ca .
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Battery Caution & Disposal Information
1. For best results, use alkaline type batteries.
2. Install only new batteries of the same type in your product.
3. Failure to insert batteries in the correct polarity, as indicated in the battery compartment, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not use Rechargeable (Nickel Cadmium or Nickel Metal Hydride) batteries.
6. Do not mix Alkaline, Standard (Carbon-Zinc) or Rechargeable (Nickel Cadmium or Nickel Metal
Hydride) batteries.
7.
8. Batteries should be recycled or disposed of as per state and local guidelines.
Do not dispose of batteries in fire.

4
What’s in the box
TV stands AV Input cable adapter
2 x AAA batteries
for remote
TV remote
TCL TV
4 x Stand screws
43’’: ST4X25mm
Power cable
43’’/50’’/55’’/65’’ 75’’
or
or
50’’/55’’/65’’: M4x30mm
75’’: M5X25
What you need
Phillips head
screwdriver
For additional support, please see User Manual at: support.tcl.com/ca
Key things to know: A paid subscription or other payments may be required for some streaming channels.
Channel availability subject to change and varies by country.
Make the most of your Smart TV
Router + Internet Connection
(needed for streaming)

5
Step 1 Set up your TV
Ready for the step-by-step? You’re only minutes away from TV bliss!
the TV. Secure the stands to the TV with four (4) screws.
Put the column of the stands into the TV, align the stands with the screw holes located on
Remove your TV from the box
To prevent damage to the screen, carefully place your TV on a soft, cushioned surface.
A
B
To use the stand
Warning:
Never place a television set in an unstable location. A television set may fall, causing serious
personal injury or death. Many injuries, particularly to children, can be avoided by taking simple
precautions such as:
- Using cabinets or stands recommended by the manufacturer of the television set.
- Only using furniture that can safely support the television set.
- Ensuring the television set is not overhanging the edge of the supporting furniture.
-
Not placing the television set on tall furniture (for example, cupboards or bookcases) without
anchoring both the furniture and the television set to a suitable support.
-
Not placing the television set on cloth or other materials that may be located between the
television set and supporting furniture.
-
Educating children about the dangers of climbing on furniture to reach the television set
or its controls.
If your existing television set is being retained and relocated, the same considerations as
above should be applied.
The VESA number is the horizontal and vertical measurement of the mounting holes. For
example, 200X200 refers to the fact that the mounting measurements are 200mm horizontally
and 200mm vertically.
Follow the instructions that come with the wall mount.
Your wall mount must be able to bear a minimum of five times the TV’s net weight to avoid
causing damage.
To mount on a wall
Purchase a VESA 200x200 (4 M6x12mm screws)
If you are mounting your TV to the wall, don’t attach the stands.
To mount your TV to the wall, purchase a VESA wall mount
Models of 43’’
Models of 50’’ Purchase a VESA 200x300 (4 M6x12mm screws)
Models of 55’’ Purchase a VESA 300x300 (4 M6x12mm screws)
Models of 65’’ Purchase a VESA 300x300 (4 M6x12mm screws)
Models of 75’’ Purchase a VESA 300x300 (4 M6x16mm screws)
Screws
(43’’: ST4x25mm 50’’/55’’/65’’: M4x30mm 75’’: M5X25)
A
BB
75’’
Note: Make sure the installation direction of the stand is the same as illustrated.
43’’/50’’/55’’/65’’
Be careful, it’s heavy!
A

Step 2
6
Power up
Grab your remote Step 3
In this step, we’ll make sure all systems are GO!
Power your TV remote by inserting the included
batteries.
Connect other devices by referencing port label
and descriptions on the next page.
Power Tip! Always replace depleted batteries with two
same brand-new batteries from the same manufacturer.
Never use damaged batteries.
If your remote gets warm/hot during use, discontinue
use and contact customer support immediately at
support.tcl.com/ca.
The TV remote should feel right at home in your hand. We designed it to
be
incredibly intuitive for watching TV and navigating on-screen menus.
A
C
E
G
J
K
I
D
F
H
L
Insert batteries in the correct polarity as
indicated in the battery compartment.
POWER Turn TV on and o
SETTINGS Display the TV settings menu
HOME Return to home screen
OPTIONS Open the Option menu
BACK Return to previous screen
SOURCE Open input source shortcut
A
B
D
C
E
F
GOOGLE ASSISTANT Awake Google Assistant (Only
available with active Internet connection)
G
CHANNEL Change channels
H
VOLUME Raise and lower volume
Press and hold the button for about 3 seconds to
mute the sound.
I
VIRTUAL KEYBOARD Open virtual keyboard on screen
J
NETFLIX Open Netflix
K
YouTube Open YouTube
L
Tip! Follow the on-screen guide
to pair the remote control with
the TV when pressing the
button for the first time.
B
Connect your power cable to the TV, then plug
it in to the wall outlet.

Step 4
7
Get to know your TV
G
K
H
3 HDMI PORTS
Highest quality audio/video connection.
Connect cable box, Blu-ray player, gaming console,
or other devices to your TV using HDMI cables.
ETHERNET Connect an Ethernet cable to your
home
Internet router or switch.
E
ANTENNA/CABLE IN Connect an outdoor VHF/UHF
antenna or Cable TV feed.
OPTICAL (DIGITAL AUDIO OUT)
Connect an optical
cable to an external digital audio system.
Use the supplied adapter to connect to older devices
that use analog audio/video outputs. The supplied
adapter connects to the RCA cable (video - yellow
and audio - white and red) that you normally use to
connect to that device.
AV IN adapter AV Input (analog audio/video).
J
USB PORT Connect a USB device to access photos,
music and movies.
I
F
HEADPHONE OUT Connect headphones or other
external speakers.
TV FRONT
TV SIDE
43’’ 50’’/55’’/65’’/75’’
HDMI ARC PORT Connect HDMI ARC (audio return
D
channel) capable audio devices like sound bars or
AV receivers.
H
F
I
J
K
E
D
F/G
IR RECEIVER Receives signal from
the TV remote.
STATUS LIGHT
Glows when the
TV is in standby.
A
POWER PORT Connect your TV
C
to the power source with the
included power cable.
POWER and OPTIONS BUTTON
B
Press once to open the menu.
Press and hold to turn o the TV.
TV BACK
A
B
AV IN
CABLE/ANT
AUDIO OUT
ETHERNET
C
ETHERNET
CABLE/ANT
AV IN

Step 5 Complete guided setup
It’s the final stretch-hurray!
Let’s Connect
Once your language has been selected, you can quickly set up the TV using an Android phone
with the pre-installed Google app.
Or you can follow the easy on-screen instructions to setup your TV. If you aren’t ready to
connect your TV to a wireless network, you can still use it as a regular TV.
And setup is done…congratulations!
Continue using the remote to personalize your Home screen, streaming channels and apps line-up,
stream movies, and so much more.
TCL SUPPORT:
support.tcl.com/ca
1-877-300-9576
contact us first with any questions
WE ARE READY TO HELP
8
TV interface may vary and subject to change.

TCL North America Limited Warranty
All LCD/LED Models.
What your warranty covers: Defects in materials or workmanship to the original owner of this TCL
product when purchased as new from an Authorized Dealer of TCL brand products in the United States and
packaged with this warranty statement.
New LCD/LED Televisions (Non-Commercial Use)
For how long after your purchase:
One (1) year from date of purchase for parts and labor for non-commercial use.
New LCD/LED Televisions (Commercial Use)
For how long after your purchase:
Six (6) months from date of purchase for parts and labor for commercial use.
Commercial use includes, but is not limited to, the use of this product in a commercial or business
environment, the use of this product in an institution or for institutional purposes, or other commercial
purposes including rental purposes.
What we will do:
At TCL North America’s discretion, (1) pay an Authorized TCL Service Center for both labor charges and
parts to repair your television, or (2) replace your television with a new or refurbished / remanufactured
equivalent value product. The decision to repair or replace will be made solely by TCL North America.
See “How to get service”.
How to get service:
Call 1-877-300-9576.
Please have your original purchase receipt or proof of purchase (bill of sale or receipted invoice), the unit’s
date of purchase, place of purchase and model/serial number ready. The model/serial number information
can be found on the back of your unit.
A representative will troubleshoot your problem over the telephone. If it is determined that your unit
requires service, the service location will be at the sole discretion of TCL North America based upon the
TCL North America Limited Warranty Statement.
At the sole discretion of TCL North America, television screen sizes 43’’and smaller will either be repaired at an
Authorized TCL Service Center or directly exchanged for a new or refurbished/remanufactured unit. At the sole
discretion of TCL North America, television screen sizes 44’’or larger will either be repaired at an Authorized
TCL Service Center or repaired in-home.
If repaired at an Authorized TCL Service Center, a pre-paid shipping label will be provided and TCL North
America will pay for return shipping.
Proof of purchase in the form of a bill of sale or receipted invoice from an Authorized Dealer which is
evidence that the product is within the warranty period must be presented to obtain warranty service.
PRE-AUTHORIZATION MUST BE OBTAINED BEFORE (1) SENDING ANY PRODUCT TO AN AUTHORIZED
TCL SERVICE CENTER, OR (2) OBTAINING ANY IN-HOME REPAIR/REPLACEMENT/RENTAL SERVICES.
What your warranty does not cover:
Customer instruction. (Your Owner’s Manual describes how to install, adjust, and operate your unit. Any
additional information should be obtained from your Authorized Dealer).
Installation and related adjustments, or damage resulting from installation.
Damage resulting from non-approved installation methods.
Signal reception problems not caused by your unit.
Damage from misuse, abuse, neglect, normal wear and tear, cosmetic damage, mishandling, faulty
installation, or power line surges.
Markings or images on the television’s panel resulting from viewing fixed images (including but not limited
to certain 4:3 images on wide screen televisions, or data or images in fixed screen locations from banners,
video games, or certain broadcast networks).
A television that has been modified or incorporated into other products.
A unit purchased or serviced outside of Canada.
A unit sold in “As-Is”, “Factory Reconditioned”, “Factory Re-Certified”, or “Refurbished” condition or with
faults.
Acts of nature or God, such as but not limited to earthquake or lightning damage.
Special, incidental or consequential damages.
Product Registration:
Please register your TCL TV purchase on-line at www.tcl.com/ca. It will make it easier to contact you should
it ever be necessary. Registration is not required for warranty coverage.
9

10
TCL North America Limited Warranty
THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. NO
VERBAL OR WRITTEN INFORMATION GIVEN BY TCL NORTH AMERICA, ITS AGENTS OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE OR MODIFY THE SCOPE OF THIS WARRANTY.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CONSUMER. TCL NORTH AMERICA SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY
BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF
CALIFORNIA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO
THE APPLICABLE WARRANTY AND WARRANTY PERIOD SET FORTH ABOVE. THIS WARRANTY IS
SUBJECT TO CHANGE WITHOUT NOTICE. PLEASE VISIT WWW.TCL.COM/CA TO VIEW THE MOST
CURRENT VERSION.
LIMITATION OF WARRANTY
How State Law relates to this warranty:
Broadcasting & Operating Environment
Broadcasting system US System NTSC-M
ATSC standard (8VSB), QAM
Receiving Channels VHF2-13
UHF14-69
CATV14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)95-99 (A-5)-(A-1)
100-135 (100)-(135)
01 (4A)
Tuner type Frequency synthesized
Operating Temperature 5°C to 35°C (41°F to 95°F)
Operating Humidity 20% to 80%, non-condensing
Storage Temperature -15°C to 45°C (5°F to 113°F)
Storage Humidity 10% to 90%, non-condensing
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations
on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you also may have other rights that vary from stateto
state.
If you purchased your unit outside Canada or seek warranty coverage outside
Canada:
This warranty does not apply. Contact your dealer for warranty information.
Service calls which do not involve defective materials or workmanship are not
covered by this warranty. Costs of such service calls are the sole responsibility
of the purchaser.

11
Troubleshooting
Cannot connect to wireless network (WiFi)
• Select the correct wireless network name and verify the password entered (case sensitive).
• Relocate the router from objects that interfere with performance (cordless phones, baby monitors, etc.).
• Reboot the router by disconnecting the power for more than 2 minutes and reconnect.
What is the remote code for programming my Universal or Cable box remote control?
• Please visit https://support.tcl.com/ca-remote-codes
Problems connecting my cable box or antenna through a coax cable
• For best performance, use the HDMI connection. If not available, then:
•
Make sure the cable connections to the TV and your device are securely fastened.
•
Select the Antenna TV Input and follow the on-screen instructions to perform a channel scan.
Access parental control
• The initial personal password for your TV is 1234.
•
You can change the personal password anytime.
•
If you forget your personal password, you can use 0423 to reset.
Having trouble completing the guided setup? Don’t worry, it’s usually an easy fix.
1-877-300-9576
Need more help?
support.tcl.com/ca

ALTO 7/ 7+
ALTO 5 / 5+
Complete your Home Theater Experience
with a TCL Sound Bar!
STUNNING SOUND. MADE SIMPLE.
TCL’s Alto Sound Bar Lineup
Offeringa truly immersive home theaterexperience, TCL Alto Sound
Bars are simple to setup and easy to use. With specialized sound modes,
available wireless subwoofers, and everything you need to connect to
your TCL TV, Alto Sound Bars provide stunning sound, made easy.
To learnmore visit TCL.COM or your favorite retailer.
Part No.: 70-F8RT51-QSG1C
Android TV is a trademark of Google LLC. TCL and the TCL
Logo are owned by TCL Corporation and under license to
TCL North America. Other brand and product names are the
trademarks or registered trademarks of their respective
owners.
TCL North America
1860 Compton Ave. Corona, CA 92881, USA

4-Series
S434-CA
Bonjour ! Commençons.

Ne pas retourner au magasin
Pour toute question,
contactez-nous en
premier
Nous sommes
là pour vous
aider
Retirer l'appareil avec soin
Soutien TCL:
support.tcl.com/ca
1-877-300-9576

Attention: Pour réduire le risque de décharge électrique, ne pas démonter le panneau arrière.
Aucune pièce réparable par l'utilisateur à l'intérieur. Confiez l'entretien à un technicien qualifié.
Ce symbole indique une «tension dangereuse»
à l'intérieur du produit, lequel présente un risque
d'électrocution ou de blessure.
Ce symbole indique les instructions
importantes accompagnant le produit.
Attention
Risque de décharge électrique.
Ne pas ouvrir.
Ce symbole indique que ce produit intègre une
double isolation entre la tension principale
dangereuse et les pièces accessibles à l'utilisateur.
Lors de l'entretien, n'utilisez que des pièces de
rechange identiques.
Avertissement
Pour réduire le risque d'incendie ou d'électrocution,
n'exposez pas ce produit à la pluie ou à l'humidité.
Ce produit ne doit pas être exposé à l'égouttement
ou aux éclaboussures. Aucun objet rempli de liquides,
tel que des vases, ne doit être placé sur l'appareil.
Avertissement
Le téléviseur est instable s'il n'est pas correctement
fixé à la base ou monté sur le mur. Veuillez suivre les
instructions de montage de la base ou mural fournies
dans le Guide de l'utilisateur pour assurer votre sécurité.
No de modèle
Date d'achat Nom du commerçant/adresse/téléphone
No de série
Information importante
Avertissement: Les piles ne doivent pas être exposées à une chaleur excessive telle que le soleil, le feu ou
similaire. Reportez-vous à l'étiquette d'identification / de classification située sur le panneau arrière de votre
produit pour connaître la tension de fonctionnement appropriée.
À l'installateur de télévision par câble: ce rappel est destiné à attirer votre attention sur l'article 820-40
du Code national de l'électricité (article 54 du Code canadien de l'électricité, Partie 1) qui fournit des directives
pour une mise à la terre appropriée et spécifie comment le câble de mise à la terre du système doit être connecté
à l'installation de mise à la terre du bâtiment aussi près que possible du point d'entrée du câble.
Important: ce téléviseur est un modèle de table conçu pour être posé sur une surface plane et solide.
Ne placez pas le téléviseur sur un tapis moelleux ou sur une surface similaire, car les fentes de ventilation
En premier lieu, veuillez vous assurer que la base ou le support possède une taille et une solidité adéquates pour
empêcher l'appareil télé de tomber ou de basculer. Il pourrait en résulter des blessures ou des dommages à
l'appareil télé. Consultez les instructions de sécurité à la page suivante.
Le bouton d'alimentationdecetéléviseur et de votre télécommande met letéléviseur en mode veillede très
faible consommation, sans toutefois lemettrecomplètement hors tension. Pour couper l'alimentation, vous
devez débrancher le cordon d'alimentation de la prise. Le coupleurdeprise / appareil principal est utilisépour
éteindre complètement l'appareil. Si vous préférezéteindre complètement l'appareil,vous devez installer letél
éviseur demanière à pouvoir facilement débrancherle cordon d'alimentation si vous l esouhaitez.
Enregistrement du produit
Veuillez enregistrer votre achat de TCL TV en ligne sur www.tcl.com/ca. Il vous sera plus facile de vous
contacter si jamais cela s'avérait nécessaire. Cette inscription n'est pas requise pour la couverture de la garantie.
Information produit
Conservez votre reçu de vente pour obtenir les pièces et le service de garantie, ainsi que la preuve d'achat.
Attachez-le ici et inscrivez les numéros de série et de modèle au cas où vous en auriez besoin. Ces numéros
sont situés sur le produit.
Avertissement: les changements ou modifications apportés à cette unité qui ne sont pas expressément
approuvés par la partie responsable de la conformité peuvent annuler l'autorité de l'utilisateur d'utiliser
Avant d'utiliser, veuillez retirer l'étiquette du guide d'énergie de l'écran.
Entrée Compatibilité du signal
HDMI
Vidéo composite
Antenne/Câble
1
480i, 480p, 720p/60Hz, 1080i/60Hz, 1080p/60Hz, 2160p/24/30/60Hz
480i
480i, 480p, 720p, 1080i (NTSC, ATSC, and QAM formats)

2
Consignes de sécurité importantes
1. Lire ces instructions.
2. Conserver ces instructions.
3. Tenir compte de tous les avertissements.
4. Suivre toutes les instructions.
5. Ne pas utiliser cet appareil près de l'eau.
7. Ne bloquez pas les ouvertures de ventilation. Installez conformément aux instructions du fabricant.
8. Ne pas installer à proximité de sources de chaleur telles que des radiateurs, des bouches de chaleur,
des poêles ou tout autre appareil (y compris les amplificateurs) produisant de la chaleur.
9. Protégezle cordon d'alimentationafin qu'il ne soit pas piétiné ou pincé, enparticulierau niveaudes
fiches, des prises de courant et delasortiede câbledel'appareil.
10. Attention: Veuillez consulter les informations sur leboîtier inférieur extérieur pour les informations
électriques et de sécuritéavant d'installer ou defaire fonctionner l'appareil.
11. Attention: La prise principale est utilisée commedispositif dedéconnexion, le dispositif
de déconnexion doit resterfacilement accessible.
12. Lorsqu'il n'est pas utilisé et pendant le déplacement,veuillez prendre soin du cordon d'alimentation,
par ex. attacher lecordond'alimentation avec un serre-câbleoutoute attache similaire. Il doit être exempt
de bords tranchants ou similaires susceptibles deprovoquer l'abrasionducordon d'alimentation. Lors dela
remiseen service, assurez-vous que le cordon d'alimentation n'est pas endommagé. S'il présentedes
dommages, veuillez vous adresser à untechnicien pour remplacer le cordon d'alimentationspécifié par
le fabricant ou ayant les mêmes caractéristiques que le cordon d'origine.
13. Aucune flamme nue (ex. : bougies, chandelles) ne doit être poséesurl'appareil.
14. Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant de longues périodes.
15. N'utilisez que des articles ou accessoires spécifiés par le fabricant.
16. Utilisez uniquement avec le chariot, le support, le trépied, le support ou la table spécifié
par le fabricant ou vendu avec l'appareil. Lorsqu'un chariot est utilisé, soyez prudent lorsque
vous déplacez l'appareil pour éviter les blessures causées par un renversement.
17. Confiez toute réparation à un technicien qualifié. Un entretien est requis lorsque l'appareil a été
endommagé de quelque façon que ce soit, par exemple un cordon d'alimentation ou une prise
endommagée, du liquide a été renversé ou des objets sont tombés dans l'appareil, a été exposé à la
pluie ou à l'humidité ou qu'il ne fonctionne pas normalement ou parce qu'il est tombé.
18. Pour un fonctionnement sûr de l'appareil, respectez les exigences d'installation suivantes:
aissez aucun objet obstruer les orifices de ventilation de l'appareil, tels que journaux, rideaux, nappes ou
tout autre objet. N'exposez pas l'appareil à des sources de chaleur externes. Ne placez pas de sources de
chaleur telles que des bougies, des lampes, etc. sur l'appareil. N'exposez pas l'appareil à des niveaux élevés
d'humidité ou à d'éventuelles sources d'humidité. Lors de la mise au rebut des piles usagées de la
télécommande, consulter les réglementations locales concernant leur élimination correcte.
19. Si une antenne externe ou un système decâbleest connecté au produit, assurez-vous quel'antenne ou
le systèmedecâbles est relié à laterre defaçon à fournir unecertaine protection contre les surtensions et
les charges statiques accumulées. L'article 810 du Code national del'électricité, ANSI / NFPA no 70-2011
(article 54 du Codecanadien de l'électricité, partie 1) fournit des renseignements sur lamiseàlaterre du
mât et dela structure portante, lamiseàlaterre du fil àune antenne/unitédedécharge, latailledes
conducteurs demise à la terre, l'emplacement de l'unité dedécharge del'antenne, la connexion aux
électrodes de mise à la terre et les exigences pour l'électrode de mise àla terre.
Comme dans l'exemple suivant:
Fil conducteur de l'antenne
Collier de mise à la terre
AUnité de décharge de l'antenne
(NEC Section 810-20)
Colliers de mise à la terre
Conducteurs de mise à la terre
(NEC Section 810-21)
Équipement électrique Système d'électrode de mise
à la terre de service électrique
(NEC ART 250, PART H)

3
Ce produitintègre la technologie HDMI.
Les termes HDMI, HDMI High-Definition Multimedia Interface et le logo HDMI sont
des marques de commerce ou des marques déposées de HDMI Licensing Administrator,
Inc.
Fabrication souslicence par Dolby Laboratories.
Dolby, Dolby Audioet lesymbole double D sont des marques commerciales de Dolby
Laboratories.
Information sur le recyclage d’appareils électroniques pour les consommateurs
Nous recommandons aux consommateurs de toujours rechercher une solution de recyclage ou de réutilisation
avant de se départir de leurs vieux téléviseurs et autres appareils électroniques. Nous encourageons les clients
de chaque province à recycler leurs appareils électroniques en fin de vie en utilisant l'une des méthodes
pratiques disponibles aujourd'hui. Dans chaque province, de nombreux programmes ont été mis en place pour
permettre aux clients de déposer et de recycler les téléviseurs. Pour de plus amples renseignements sur le
recyclage des produits électroniques au Canada, veuillez visiter la section «recyclage d’appareils électroniques»
sur le site Web de TCL Canada: www.tcl.com/ca.
Information FCC
Cet équipement a été testé et déclaré conforme aux limites d'un appareil numérique de classe B, conformément à
la partie 15 des règles de la FCC. Ces limites sont conçues pour fournir une protection raisonnable contre les
interférences nuisibles dans une installation résidentielle. Cet équipement génère, utilise et peut émettre de
l'énergie radiofréquence et, s'il n'est pas installé et utilisé conformément aux instructions, peut causer des
interférences nuisibles aux communications radio. Cependant, il n'y a aucune garantie que des interférences ne se
produiront pas dans une installation particulière. Si cet équipement cause des interférences nuisibles à la réception
radio ou télévision, ce qui peut être déterminé en éteignant et allumant l'équipement, l'utilisateur est encouragé à
essayer de corriger l'interférence par une ou plusieurs des mesures suivantes:
Réorienter ou déplacer l'antenne de réception.
Augmentez la distance entre l'équipement et le récepteur.
Consulter le revendeur ou un technicien radio / TV expérimenté pour obtenir de l'aide.
Cet appareil numérique de classe B est conforme à la norme canadienne ICES-003.
Précautions concernant la batterie et informations sur l'élimination.
1. Pour une meilleure performance, utilisez des batteries de type alcaline.
2. Installez uniquement de nouvelles batteries de même type dans votre produit.
3. Si vous n'insérez pas dans le compartiment les piles dans la polarité indiquée, cela pourrait
réduire leur durée de vie ou provoquer une fuite.
4. Ne mélangez pas les anciennes piles avec des neuves.
5. N'utilisez pas de piles rechargeables (nickel-cadmium ou nickel-métal-hydrure).
6. Ne mélangez pas les piles alcalines, standards (carbone-zinc) ou rechargeables (nickel-cadmium
ou nickel-métal-hydrure).
7.
8. Les batteries doivent être recyclées ou éliminées conformément aux directives locales et nationales.
N'éliminez pas les piles dans un feu.
Cet appareil contient un ou des émetteurs/récepteurs exemptés de licence conformes aux normes RSS
pour les dispositifs exempts de licence en matière d'Innovation, de Sciences et Développement économique
L'utilisation est soumise aux deux conditions suivantes :
Cet équipement est conforme aux limites canadiennes d'exposition au rayonnement établies pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre corps.
2. Cet appareil doit accepter toute interférence, y compris celles susceptibles de provoquer un fonctionnement
non souhaité de l'appareil
1. Cet appareil ne peut pas produire d’interférences.

4
Contenu de la boîte
43’’: ST4X25mm
43’’/50’’/55’’/65’’ 75’’
or
or
50’’/55’’/65’’: M4x30mm
75’’: M5X25
Téléviseur TCL • Android Supports de
téléviseur Adaptateur de câble
d'entrée audiovidéo
Longueur: 120mm
Câble d'alimentation
amovible
4 vis pour supports
de téléviseur 2 piles AAA pour la
télécommande
Télécommande
Ce dont vous avez besoin
Tournevis cruciforme
(Phillips)
Pour de l'aide supplémentaire, veuillez lire le manuel utilisateur: support.tcl.com/ca
Informations utiles: un abonnement payant ou d'autres paiements peuvent être requis pour certaines chaînes de streaming.
La disponibilité des chaînes peut changer et varier selon les pays.
Tirez le meilleur parti de votre télé intelligente
Routeur + connexion Internet
