TCL 40S4800FS User manual

40S4800FS/50S4800FS/
55S4800FS

2
Chapter 1: Introduction
Precautions ............................................................... 3
Product .................................................................... 3
Power and Plug ....................................................... 3
Power Cord and Signal Cable ................................. 3
Use Environment ..................................................... 3
Cleaning................................................................... 3
Hanging the TV Set on the Wall............................... 3
Important Information............................................... 3
TV Controller............................................................. 4
Sockets...................................................................... 5
Remote Control Functions ...................................... 6
Chapter 2: Connections and Setup
Switching on ............................................................. 7
Switching off ............................................................. 7
Network Connection................................................. 8
Network Conguration............................................. 9
Initial Setup ............................................................. 10
Chapter 3: Homepage
Using Homepage - System .................................... 11
Multimedia ............................................................. 11
Source ................................................................... 11
Preference ............................................................. 11
Using Homepage - Application.............................. 12
Netix..................................................................... 12
Facebook............................................................... 12
Twitter .................................................................... 12
Wireless Display .................................................... 12
Opera TV Store...................................................... 12
Opera TV Browser ................................................. 12
YouTube................................................................. 12
Picasa.................................................................... 12
GoLive ................................................................... 12
Using Homepage - GoLive..................................... 13
Multimedia............................................................... 14
My Movie ............................................................... 14
My Music................................................................ 14
My Picture.............................................................. 14
My Browser............................................................ 14
Chapter 4: System Settings Menu
Channel ................................................................... 15
Auto Tuning............................................................ 15
DTV Manual Tuning............................................... 15
ATV Manual Tuning ............................................... 15
Country .................................................................. 15
Bandwidth Switch .................................................. 15
Table of Contents
Program Edit.......................................................... 15
Signal Information.................................................. 16
Software Update (OAD)......................................... 16
Picture ..................................................................... 16
Picture Mode.......................................................... 16
Color Temperature ................................................. 16
Aspect Ratio .......................................................... 16
Noise Reduction .................................................... 16
Dynamic Contrast .................................................. 16
Active Backlight ..................................................... 16
Screen ................................................................... 16
Sound ...................................................................... 16
Sound Mode .......................................................... 17
Audio Language..................................................... 17
Balance.................................................................. 17
Surround Sound..................................................... 17
Audio Type............................................................. 17
AD Switch .............................................................. 17
SPDIF Mode .......................................................... 17
Time ......................................................................... 17
Auto Sync .............................................................. 17
Clock...................................................................... 17
Off Time ................................................................. 17
Sleep Timer............................................................ 17
Time Zone.............................................................. 17
Option ...................................................................... 18
OSD Language...................................................... 18
Location ................................................................. 18
Subtitle Hearing Impaired ...................................... 18
Subtitle Language.................................................. 18
PVR File System.................................................... 18
Network Conguration ........................................... 18
Restore Factory Default......................................... 18
Software Update.................................................... 18
Lock ......................................................................... 18
Lock System .......................................................... 18
Set Password......................................................... 18
Block Program ....................................................... 18
Parental Guidance................................................. 18
Chapter 5: Special Function
PVR ..........................................................................19
EPG ..........................................................................19
Chapter 6: Other Information
Problems & Solutions ............................................ 21
Troubleshooting ..................................................... 22
Legal Statement...................................................... 23

3
•Keep the set away from direct sunlight.
•The apparatus shall not be exposed to dripping or
vases, shall be placed on the apparatus.
•Do not use the set in dusty environments.
•Operating Temperature: 5°C to 35°C (41°F to 95°F)
Operating Humidity: 20% to 80%, non-condensing
Storage Temperature: -15°C to 45°C (5°F to 113°F)
Storage Humidity: 10% to 90%, non-condensing
Cleaning
•Dust the set by wiping the screen and the cabinet with
a soft, clean cloth or some special liquid cleaner.
•Do not apply excessive force to the screen when
cleaning.
•Do not use water or other chemical cleaner to clean
the screen as this may damage the surface of the TV
screen.
Hanging the TV Set on the Wall
Warning: This operation requires two people.
To ensure a safe installation, observe the following
safety notes:
•Check that the wall can support the weight of the TV
set and wall mount assembly.
•Follow the mounting instructions provided with the
wall mount.
•The TV set must be installed on a vertical wall.
•Make sure to use only screws suitable for the material
of the wall.
•Make sure that the TV set cables are placed so that
there is no danger of tripping over them.
All other safety instructions about our TV sets are also
applicable here.
Wall mount not included.
Important Information
location, it can be potentially hazardous due to falling.
Many injuries, particularly to children, can be avoided by
taking simple precautions such as:
•Using cabinets or stands recommended by the
manufacturer of the television.
•Only using furniture that can safely support the
television.
•Ensuring the television is not overhanging the edge of
the supporting furniture.
•Not placing the television on tall furniture (for example,
cupboards or bookcases) without anchoring both the
furniture and the television to a suitable support.
•Not standing the television on cloth or other materials
placed between the television and supporting furniture.
•Educating children about the dangers of climbing on
furniture to reach the television or its controls.
Precautions
Read all of the instructions before operating the set.
Keep these instructions well for future use.
Product
•Do not block or cover the ventilation openings on the
back cover.
•Do not push objects of any kind into this unit through
the cabinet slots as they could touch the current
electric shock, or damage to the unit.
•Do not attempt to open the cabinet as this may cause
damage. There are no parts inside you can service by
•
may scratch or mar the TV screen.
•
•
Do not impact the TV screen with hard pressure as
this may damage the TV screen severely.
Power and Plug
•Unplug the set under the following conditions:
-If the set will not be used for a long period of time.
-If the power cord or the power outlet/plug is
damaged.
-Follow the instructions to install and adjust the
product. Adjust those controls that are covered in
these operating instructions as improper adjustment
of other controls may result in damage. If this
happens, unplug the set and refer to the service
personnel.
-If the set is subject to impact or has been dropped
and the cabinet has been damaged.
•Where the mains plug or an appliance coupler is used
as disconnect device, the disconnect device shall
remain readily operable.
(*Where an all-pole mains switch is used as the
disconnect device, the switch shall remain readily
operable.)
Power Cord and Signal Cable
•Do not allow anything to rest on or roll over the power
cord and the signal cable.
•Protect the power cord and the signal cable from
being trampled.
•Do not overload the power cord or the power outlet.
•Do not expose the power cord and the signal cable to
moisture.
Use Environment
•Do not place the set on an unstable cart, stand, or
table.
•Place the set on a place that allows good ventilation.
•Do not use the set near damp, and cold areas. Protect
the set from overheating.
Chapter 1 Introduction
The appliance is not intended for use by young children
or infirm persons without supervision. Young children
should be supervised to ensure that they do not play
with the appliance.

4
Introduction
Press MENU button to bring up the NAV menu, select to bring up the main menu. Long press
MENU button to return to the previous menu.

5
Sockets
Note: The location and names of the sockets on the TV may vary according to TV model, and not all sockets
available on all models.
HDMI 1
or HDMI 2
or HDMI 3
ANTENNA IN
AUDIO OUT adapter
VGA IN
VIDEO
R
L
AUDIO
IN
AV IN
USB 2.0
SPDIF
This socket can be used to connect to external modem or network access equipment.
SPDIF socket (output)
This socket can be used to connect a compatible digital audio receiver.
HDMI1/HDMI2/HDMI3 socket (input)
The HDMI (High-Denition Multimedia Interface) socket lets you connect a device,
such as a Blu-ray player, with a HDMI output for best picture quality. It also provides
an uncompressed digital connection that carries both video and audio data by way of
an integrated mini-plug cable.
USB 2.0 socket (input)
This socket can be used to connect a USB device.
ANTENNA IN socket (input)
AV RCA audio + video sockets (input)
The AV IN sockets can be used to connect a range of equipment, including video
recorders, camcorders, decoders, satellite receivers, DVD players, or games
consoles.
The VIDEO socket provides composite video connection.
VGA IN socket (input)
This socket can be used to connect a computer.
Note: VGA IN shares the same audio sockets with AV IN.
AUDIO OUT adapter socket (output)
Use an RCA audio cable to connect your TV to a compatible audio receiver.
Introduction
This socket can be used to connect a AC supply.

6
Introduction
Smart TV
P.MODE
S.MODE
OPTION Shortcut to Freeze Off, PVR DISK , PVR and Football Mode on.
TEXT SUBTITLE LIST
OPTION
In DTV mode, pree to select audio language.
TEXT
SUBTITLE
LIST
Not use(for some model use)
Goes to the smart TV homepage.
In USB mode,Press
to select sound track mode
Searches forward.
Searches backward.
Note: The above six buttons can be used for playing music, pictures and
videos in the USB menu.
In DTV mode,Turns on or off the audio description function)Yellow buttons

7
Switching on
Follow the instructions on this page on how to switch on your TV set
and the remote control before going on to following pages describing
how to use the channel set-up procedure.
1. Insert two AAA batteries in the remote control.
Precautions on using batteries:
- Make sure you use the correct polarity.
- Do not mix new and used batteries.
- Do not use rechargeable batteries.
- Do not expose batteries to excessive heat such as sunshine,
them, as this could cause them to leak or explode.
- Remove the batteries from the remote control if you are not using
it for a long period of time.
2. Connect the power cable FIRST to the television, THEN to a mains
socket. (Note: If the power cable is connected to the television,
please only connect the power cable to the mains socket.)
Your TV set should only be connected to an AC supply. It must not
be connected to a DC supply. If the plug is detached from the ca-
ble, do not, under any circumstances, connect it to a mains socket,
as there is a risk of electric shock.
Note
socket of the television may differ depending on the model.
3. Connect an outside aerial to the ANTENNA IN socket at the back
of the TV set.
The aerial socket (75 OHM - VHF / UHF / cable) can be used for
Note: If you want to receive the signal from your cable or cable
box, please connect a coaxial cable to the CABLE IN socket at the
back of the TV set, On certain models only.
4. When powered on, the TV will be turned on directly or be in
standby mode.
If the power indicator lights up, the TV set is in standby mode.
Press the button on the remote control or on the TV set to turn
on the TV.
Switching off
-To put the TV set into standby mode, press the button on the
remote control. The TV set remains powered up, but with low
energy consumption.
-To switch off the TV set, unplug the mains socket from the mains
outlet.
Chapter 2 Connections and Setup

8
Network Connection
To access the Internet, you must subscribe to high speed broadband Internet service with your Internet service
provider (ISP).
Your TV can be connected to your home network in two ways:
-Wired, using the RJ45 (LAN) connector on the back panel.
-Wireless, using the internal wireless your home wireless network.
Note: Instructions below are just the usual ways to connect your TV to the wired or wireless network. The connection
home network, please refer to your ISP.
Connecting to a wired network
To connect to a wired network:
1. Ensure you have:
-An Ethernet cable long enough to reach your TV
-A router or modem with an available Ethernet port
-A high-speed Internet connection
-An Ethernet (LAN) port on the back of the TV
2. Connect your Ethernet cable to the router and to
the Ethernet port on the back of the TV.
3. Use the Network Configuration menu to
configure the TV.
Connecting to a wireless network
To connect to a wireless network
1. Ensure you have:
-A router broadcasting a high-speed wireless
signal
-A high-speed Internet connection
2. Use the Network Configuration menu to
configure the TV.
Modem Internet
TV Set
Router
Ethernet
Port on the
back panel
or
Connections and Setup
Wireless Router
Modem
TV Set
Built-in wireless
connection

9
DHCP: In DHCP mode, your TV set will get IP
address, Netmask, Gateway and DNS automatically.
Press to OK to start.
MAC Address: Press OK to see the MAC address
of your TV set. Then press MENU to return or press
EXIT to exit the menu.
- Wireless Network:
In wireless menu, press ◄/► to turn wireless
network on or off.
Wi-Fi Network On
WIFI NETWORKS
MAC Address
MENU
WIFI NETWORKS: After Wi-Fi Network is set to
On, press OK to start searching for all available
wireless networks. This may take a few seconds.
After the searching is complete, select an accessible
WIFI network to connect. For some WIFI network,
you need to input the right password to access.
Select Password and press OK, then press ►. A
virtual keyboard appears. Input the password, and
then press OK to connect.
WIFI NETWORKS
MENUOK
HiWiFi 1
FAST_WiFi
AU_WiFi
PUB_WiFi
Home
HelloWiFi
SmileWiFi
Disconnect Refresh View Detail
MAC Address: Press OK to see the MAC address
of your TV set. Then press MENU to return or press
EXIT to exit menu.
Network Configuration
After you connect your home network to the TV, follow
the steps below to congure the network settings of your
TV.
Your TV set supports both wired and wireless network
connection.
Network
Wired Network
Wi-Fi Network
MENU
Note: For wired network connection, you need to insert
your Ethernet cable into the Ethernet port rst.
- Wired Network:
Configuration: Press OK to enter, and then press
◄/► to select Static or DHCP.
Wired Network
Configuration
MAC Address
MENU
Static: In Static mode, you should input right IP
address, Netmask, Gateway and DNS to access
network. Press ▲/▼ to select an option, press OK
to enter, and then press the numeric buttons to input
numbers or press ◄/► to select numbers.
Netwrok Configuration Static
IP 0.0.0.0
Netmask 0.0.0.0
Gateway 0.0.0.0
DNS 0.0.0.0
OK
MENU
Connections and Setup

10
4. Press /to select Country and press OK to
start the search automatically. All available TV
programmes will be searched. This operation takes
a few minutes. The display shows the progress of
the search and the number of programmes found.
Country
South Africa
Australia
Austria
Belgium
Bulgaria
Croatia
OK MENU
Channel Tuning
ATV: 4 Programme(s)
DTV: 0 Programme(s)
Radio: 0 Programme(s)
Data: 0 Programme(s)
19 %... 202.25 MHz ATV
MENU
Note: To prevent the channel setup process from
being interrupted, wait for the message indicating
that the setup is complete.
5. During the setup, user can follow the hint available
at the bottom of the screen to return to the last step
by pressing MENU, or press EXIT to interrupt the
search halfway.
6. After the initial setup is complete, the channels
are arranged in a preset order. If you wish to skip
channels, or organize channels, select Channel
Edit and press OK to enter.
Initial Setup
Initial setup involves selecting all the settings required to
be able to search for and store all the channels you can
receive. Make sure that the television is switched on
and follow all the steps in turn specied hereafter.
1. The first time you switch the set on, the Initial Setup
menu appears. Press / to select your language
and press OK to enter the next step.
Please Select an OSD Language
English
Spanish
OK MENU
Vietnamese
French
Russian
Arabian
2. Select your location: Home or Shop, and press OK
to enter the next step.
Location
Home
Shop
OK MENU
3. Select the tuning type,and press OK to enter the
next step.
DVB Tuning Type
DVB-T
OK MENU
Connections and Setup
