TCL 5 Series User manual

Hi! Let’s get started.
5-Series
S546-CA

DO NOT RETURN TO STORE
TCL SUPPORT:
support.tcl.com/ca
1-877-300-9576
contact us first
with any questions
WE ARE
READY TO
HELP
TAKE CARE WHEN
REMOVING THE TV

1
WARNING
To reduce the risk of fire or electric shock, do
not expose this product to rain or moisture.
This product should not be exposed to dripping
or splashing. No objects filled with liquids, such
as vases, should be placed on the apparatus.
WARNING
The TV is unstable if it is not properly attached to
the base or mounted to the wall. Please follow the
base or wall mounting instructions provided in the
User’s Guide to ensure your safety.
Model No.
Purchase Date
Serial No.
Dealer/Address/Phone
Important Information
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here
and record the serial and model numbers in case you need them. These numbers are located on the
product.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. Keep the apparatus at least 8
inches away from the human body.
Input Signal Compatibility
480i, 480p, 720p/60Hz, 1080i/60Hz, 1080p/60Hz, 2160p/24/30/60Hz
480i
480i, 480p, 720p, 1080i (NTSC, ATSC, and QAM formats)
HDMI
Composite Video
Antenna/Cable
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
This symbol indicates important instructions
accompanying the product.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that this product incorporates
double insulation between hazardous main voltage
and user accessible parts. When servicing, use only
identical replacement parts.
CAUTION: Neutral fusing. Disconnect mains before servicing.
Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside.
Refer servicing to qualified service personnel.
Warning: The batteries should not be exposed to excessive heat, such as prolonged direct
sunlight, open flame, or fire of any kind.
Refer to the identification/rating label located on the back
panel of your product for its proper operating
voltage.
Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of the National
Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper
grounding and, in particular, specifies that the cable ground should beconnected to the grounding system
of the building as close to the point of cable entry as practical.
Important: This television is a table model and is designed to sit on a firm, flat surface. Do not
place the TV on soft carpeting or on a similar surface as this may cause the ventilation slots located on
the bottom of the unit to be blocked and may result in reduced product lifespan from overheating.
To assure
adequate ventilation for this product, maintain a spacing of one (1) inch from the top and
side of the
TV receiver and two (2) inches from the rear of the TV receiver and other surfaces.
Make sure the TV stand or base you use is of adequate size and strength to prevent the TV from
being accidentally tipped over, pushed o, or pulled o. This may cause personal injury and/or damage
the TV. Refer to the Important Safety Instructions on the next page.
The Power button on this TV and your remote control puts the TV into a very low-power standby
mode but will not completely turn the power o. In order to completely shut the power o, you will
need to disconnect the power cord from the outlet. The mains plug/appliance coupler is used to
completely turn o the device. If you prefer to completely turn o the device, you should install
the TV in a manner that allows you to disconnect the power cord when desired.

2
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
10. WARNING : Please refer the information on exterior bottom enclosure for electrical and safety information
before installing or operating the apparatus.
11. WARNING:The main plug is used to disconnect the device and should remain readily operable.
12. When not in use, tie up the power cordset with a cable tie or with something similar. It should not be
near sharp edges as it may cause abrasion of the power cordset. When put into use again, please make
sure the power cordset is not damaged. If any damage is found, please use a replacement power cord
specified by the manufacturer or that is identical to the original one.
13. No open flame sources, such as lit candles, should be placed on, under, or near the apparatus.
14.
Unplug this apparatus during lightning storms or when unused for long periods of time.
15. Only use attachments/accessories specified by the manufacturer.
16. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid any injury.
17. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
18. For safe operation of the apparatus, please follow these installation requirements
:
Keep at least 2 inches of ventilation space between the rear cover of the apparatus and the wall.
Keep at least 1 inch of ventilation space between the apparatus and all other surfaces. Do not allow
any of the apparatus’ ventilation openings to be blocked by objects that might obstruct them, such
as newspapers, curtains, table-cloths or any other objects. Do not expose the apparatus to any external
heat sources. Do not place any heat sources such as candles, lamps, etc. on the apparatus. Do not expose
the device to high levels of humidity or to any possible sources of moisture. When disposing of used
batteries
from the remote control, consult local regulations regarding proper disposal.
19. If an outside antenna or cable system is connected to the product, be sure the antenna or cable system
is grounded so as to provide some protection against voltage surges and built-up static charges. Section
810 of the National Electrical Code, ANSI/NFPA No. 70-2011 (Section 54 of Canadian Electrical Code,
Part 1) provides information with respect to proper grounding of the mast and supporting structure,
grounding of the lead in wire to an antenna-discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
See following example:
ANTENNA LEAD IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND CLAMPS
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRIC SERVICE
EQUIPMENT POWER SERVICE GROUNDING
ELECTRODE SYSTEM (NEC ART
250, PART H)

ELECTRONICS & PACKAGING RECYCLING INFORMATION
3
The terms HDMI, HDMI High-Definition MultimediaInterface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol are registered
trademarks of Dolby Laboratories Licensing Corporation. Manufactured
under license from Dolby Laboratories. Confidential unpublished works.
Copyright © 2012-2020 Dolby Laboratories. All rights reserved.
For information on recycling your old TVs, sound bars, and home comfort products, and to find drop-o
locations in your area, please visit the “Electronics Recycling” area of the TCL website at www.tcl.com.
Click on our convenient interactive map to quickly locate a solution in your community. TCL encourages
consumers to always look for a recycling or reuse alternative to discarding televisions and other electronics,
and in many areas TCL has programs for consumers to drop-o and recycle televisions free of charge.
Look for convenient How2Recycle® labels on the product box for help preparing your new TV packaging for
recycling. These labels show important information identifying the various types of packaging material included
with your new TV along with easy-to-understand recycling instructions.
Battery Caution & Disposal Information
1. For best results, use alkaline type batteries.
2. Install only new batteries of the same type in your product.
3. Failure to insert batteries in the correct polarity, as indicated in the battery compartment, may
shorten the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not use Rechargeable (Nickel Cadmium or Nickel Metal Hydride) batteries.
6. Do not mix Alkaline, Standard (Carbon-Zinc) or Rechargeable (Nickel Cadmium or Nickel Metal
Hydride) batteries.
7.
8. Batteries should be recycled or disposed of as per state and local guidelines.
Do not dispose of batteries in fire.
9. Replacement of a BATTERY with an incorrect type that can defeat a SAFEGUARD (for example,
in the case of some lithium BATTERY types).
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

4
What’s in the box
TV remote
What you need
Phillips head
screwdriver
For additional support, please visit support.tcl.com/ca
Make the most of your TV
Router + Internet Connection
(needed for streaming)
TCL TV 2 x AAA batteries
for remote
TV stands
Power cable 4 x Stand screws
Cable clips
M4X30mm for models of 50”/55”/65”
M5X25mm for models of 75”
50”/55”/65”
or or
75”
(2 x Cable clips)
50”/55”/65”
(4 x Cable clips)
75”

5
Step 1 Set up your TV
Ready for the step-by-step? You’re only minutes away from TV bliss!
the TV. Secure the stands to the TV with four (4) screws.
Put the column of the stands into the TV, align the stands with the screw holes located on
Remove your TV from the box
To prevent damage to the screen, carefully place your TV on a soft, cushioned surface.
A
B
To use the stand
Warning:
Never place a television set in an unstable location. A television set may fall, causing serious
personal injury or death. Many injuries, particularly to children, can be avoided by taking simple
precautions such as:
- Using cabinets or stands recommended by the manufacturer of the television set.
- Only using furniture that can safely support the television set.
- Ensuring the television set is not overhanging the edge of the supporting furniture.
-
Not placing the television set on tall furniture (for example, cupboards or bookcases) without
anchoring both the furniture and the television set to a suitable support.
-
Not placing the television set on cloth or other materials that may be located between the
television set and supporting furniture.
-
Educating children about the dangers of climbing on furniture to reach the television set
or its controls.
If your existing television set is being retained and relocated, the same considerations as
above should be applied.
Note: Make sure the installation direction of the stand is the same as illustrated.
Be careful, it’s heavy!
Screws
(50’’/55’’/65’’: M4x30mm 75’’: M5X25mm)
50’’/55’’/65’’/75’’
AA
B55’’/65’’/75’’
A
B
To use the cable clips
50’’/55’’/65’’ 75’’
A
B
Stick the two cable clips on the TV stands on the left and right.
On back of the TV, insert the two cable clips into the back of TV on the left and right.
A
B
Note: Make sure the installation direction of the cable clip is the same as illustrated.
Attach the two cable clips to the TV stands on the left and right.
C
C

Optional - To mount on a wall
(wall mount not included)
To mount on a wall
The VESA number is the horizontal and vertical measurement of the mounting holes. For
example, 200X200 refers to the fact that the mounting measurements are 200mm horizontally
and 200mm vertically.
Follow the instructions that come with the wall mount.
Your wall mount must be able to bear a minimum of five times the TV’s net weight to avoid
causing damage.
55” Models Purchase a VESA 300x200, 4 M6x12mm screws
To mount your TV to the wall, purchase a VESA wall mount
If you are mounting your TV to the wall, don’t attach the stands.
65” Models Purchase a VESA 300x300, 4 M6x12mm screws
50” Models Purchase a VESA 200x200, 4 M6x12mm screws
75” Models Purchase a VESA 400x300, 4 M6x25mm screws
6
Preparation must be done before mounting your TV on a wall.
Place your TV on a soft, cushioned surface.
1
4
2
Remove the 4 screws from the back of the TV.
Follow the instructions that come with the wall mount
to hang the TV on the wall.
3
Screw the VESA bracket tightly onto the back cover
with 4 VESA screws.
VESA screws:
50”/55”/65”: M6x12mm
75”: M6x25mm
Note: Do not place your TV in a location exposed to direct sunlight, heat, fire, or moisture.
Exposure will damage the TV.

Step 2 Power up
In this step, we’ll make sure all systems are a GO!
Connect your power cable to the TV, then plug
it in to the wall outlet.
and descriptions on the next page.
Connect other devices by referencing port label
Power Tip! Always replace depleted batteries with two
same brand-new batteries from the same manufacturer.
Never use damaged batteries.
If your remote gets warm/hot during use, discontinue
use and contact customer support immediately at
support.tcl.com/ca.
Insert batteries in the correct polarity as
indicated in the battery compartment.
Power your TV remote by inserting the included
batteries.
remoteGrab yourStep 3
The TV remote should feel right at home in your hand. We designed it to
be
incredibly intuitive for watching TV and navigating on-screen menus.
7
Tip! Follow the on-screen guide
to pair the remote control with
the TV when pressing the
button for the first time.
POWER Turn TV on and o
B
SETTINGS Display the dashboard on screen
D
TCL HOME Open TCL home on screen
N
HOME Return to home screen
H
BACK Return to previous screen
I
ELECTRONIC PROGRAM GUIDE Display the live
antenna TV channels
J
GOOGLE ASSISTANT BUTTON Press to activate the
remote’s Google Assistant microphone. Search content
through your voice by holding down the button.
F
VOLUME Raise and lower volume
G
VIRTUAL KEYBOARD Open virtual keyboard on screen
L
OPTIONS View more options when playing media.
A
WATCHLIST Open the watchlist menu or future function
C
MUTE Press the button to mute the sound.
K
QUICK PANEL Display the quick panel
M
REMOTE MICROPHONE Talk to the remote microphone
after pressing the Google Assistant button
E
E
F
H
G
A
B
C
D
IK
L N J
M

Step 4
8
Get to know your TV
H
L
I
HDMI PORTS
Highest quality audio/video connection.
Connect cable box, Blu-ray player, gaming console,
or other devices to your TV using HDMI cables.
ETHERNET Connect an Ethernet cable to your home
Internet router or switch.
F
ANTENNA/CABLE IN Connect an outdoor VHF/UHF
antenna or Cable TV feed.
OPTICAL (DIGITAL AUDIO OUT) Connect an optical
cable to an external digital audio system.
The AV Input can be used to connect older devices
that use analog audio/video outputs. Compatible
adapter (not included) connects to the RCA cable
(video - yellow and audio - white and red) that you
normally use to connect to that device.
AV IN adapter AV Input (analog audio/video).
K
USB PORT Connect a USB device to access photos,
music and movies.
J
G
HEADPHONE OUT Connect headphones or other
external speakers.
TV FRONT
TV SIDE
HDMI eARC/ARC PORT Connect HDMI eARC/ARC
E
(audio return channel) capable audio devices like
sound bars or
AV receivers.
I
G
J
K
L
F
E
G/H
IR RECEIVER Receives signal from
the TV remote.
STATUS LIGHT OF HANDS-FREE
VOICE CONTROL
Glows when you
activate the hands-free voice control.
(To learn more about the function,
go to page 13.)
A
POWER PORT Connect your TV
C
to the power source with the
included power cable.
POWER and OPTIONS BUTTON
B
Press once to open the menu.
Short click to change the menu and
long click to select.
AV IN
CABLE/ANT
AUDIO OUT
ETHERNET
eARC
/ARC
TV BACK
C
B
D
HANDS-FREE VOICE CONTROL MIC SWITCH
Enable or disable the TV’s integrated microphone.
D
A

Step 5 Complete guided setup
It’s the final stretch-hurray!
Let’s Connect
Once your language has been selected, you can quickly set up the TV using an Android phone
with the pre-installed Google Home app.
9
TV interface may vary and is subject to change.
Or you can follow the easy on-screen instructions to setup your TV. If you aren’t ready to
connect your TV to a wireless network, you can still use it as a regular TV.
And setup is done… Congratulations!
Continue using the remote to personalize your Home screen, streaming apps line-up, stream movies,
and so much more.
TCL SUPPORT:
support.tcl.com/ca
1-877-300-9576
contact us first with any questions
WE ARE READY TO HELP
Key things to know:
A paid subscription or other payments may be required for some streaming apps.
Streaming apps availability are subject to change and vary by country.
To enjoy all smart features and services on your TCL Google TV, a free Google account, a
free TCL account, and a reliable broadband internet connection, are required.

10
TCL North America Limited Warranty
All TCL LCD/LED Models
What your warranty covers
New LCD/LED Televisions (Commercial Use)
For how long after your purchase:
Six (6) months from date of purchase for parts and labor for commercial use.
Commercial use includes, but is not limited to, the use of this product in a commercial or business
environment, the use of this product in an institution or for institutional purposes, or other commercial
purposes including rental purposes.
One (1) year from date of purchase for parts and labor for non-commercial use.
Please have your original purchase receipt or proof of purchase (bill of sale or receipted invoice) which
states that condition of the unit (New, Used, etc.), the unit’s date of purchase, place of purchase and model/
serial number ready. The model/serial number information can be found on the back of your unit.
Call 1-877-300-9576 or visit support.tcl.com/ca
A representative must troubleshoot your problem over the telephone or through e-mail before receiving
service. If it is determined that your unit requires service, the service location will be at the sole discretion
of TCL North America based upon the TCL North America Limited Warranty Statement.
At the sole discretion of TCL North America, television screen sizes 43” and smaller will either be repaired
at an Authorized TCL Service Center or directly exchanged for a new or refurbished/recertified unit. At the
sole discretion of TCL North America, television screen sizes 44” through 75” or larger will either be repaired
or directly exchanged for a new or refurbished/recertified unit at an Authorized TCL Service Center or
repaired in-home. In the event of a service visit where the on-site technician, in his-her sole discretion,
deems the home or property conditions to be hazardous and/or unsafe, TCL North America reserves the
right to cancel or re-schedule the service visit, or opt for an exchange of the in-warranty unit for a
refurbished/recertified unit lieu of the in-home service visit.
If repaired at an Authorized TCL Service Center, TCL North America is not responsible for transportation
costs to the Authorized TCL Service Center. However, TCL North America will pay for return shipping.
TCL North America will provide instructions for packaging and shipping the unit. Units that are improperly
packed and damaged during shipping are not covered under your product warranty.
Proof of purchase in the form of a bill of sale or receipted invoice from an Authorized Dealer which is
evidence that the product is within the warranty period must be presented to obtain warranty service.
In the event that a unit is to be replaced, a picture of the back of the unit showing the model and serial
number and picture of the issue itself may be required.
PRE-AUTHORIZATION MUST BE OBTAINED BEFORE (1) SENDING ANY PRODUCT TO AN AUTHORIZED
TCL SERVICE CENTER, OR (2) OBTAINING ANY IN-HOME REPAIR/REPLACEMENT/ RENTAL SERVICES.
Defects in materials or workmanship to the original owner of this TCL product when purchased as new from
an Authorized Dealer of TCL brand products in Canada and packaged with this warranty statement.
How to get service
What we will do
At TCL North America’s discretion, (1) pay an Authorized TCL Service Center for both labor charges and
parts to repair your television, or (2) replace your television with a new or refurbished / remanufactured
equivalent value product. The decision to repair or replace will be made solely by TCL North America.
See “How to get service”.
New LCD/LED Televisions (Non-Commercial Use)
For how long after your purchase:

11
TCL North America Limited Warranty
THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. NO
VERBAL OR WRITTEN INFORMATION GIVEN BY TCL NORTH AMERICA, ITS AGENTS OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE OR MODIFY THE SCOPE OF THIS WARRANTY.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER. TCL NORTH AMERICA SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY
BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF CALIFORNIA.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY AND WARRANTY PERIOD SET FORTH ABOVE. THIS WARRANTY IS SUBJECT TO
CHANGE WITHOUT NOTICE. PLEASE VISIT WWW.TCL.COM TO VIEW THE MOST CURRENT VERSION.
LIMITATION OF WARRANTY
How State Law relates to this warranty
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations
on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you also may have other rights that vary from state to
state.
If you purchased your unit outside Canada or seek warranty coverage outside
Canada:
This warranty does not apply. Contact your dealer for warranty information.
Service calls which do not involve defective materials or workmanship are not
covered by this warranty. Costs of such service calls are the sole responsibility
of the purchaser.
What your warranty does not cover
A unit sold in “As-Is”, “Used”, “Factory Reconditioned”, “Factory Re-Certified”, or “Refurbished”, condition
or with faults.
Units physically broken during shipment from a Retailer. Please contact your Retailer for assistance.
Extended Service Plans purchased from Retailers. Please contact your Retailer for assistance.
Customer instruction. (Your Owner’s Manual describes how to install, adjust, and operate your unit. Any
additional information should be obtained from your Authorized Dealer).
Installation and related adjustments, or damage resulting from installation.
Damage resulting from non-approved installation or repair methods.
Signal reception problems not caused by your unit.
Damage from misuse, abuse, neglect, insects, normal wear and tear, cosmetic damage, mishandling,
faulty installation, or power line surges.
Markings or images on the television’s panel resulting from viewing fixed images (including but not limited
to certain 4:3 images on wide screen televisions, or data or images in fixed screen locations from banners,
video games, or certain broadcast networks).
Units that have original factory serial numbers that are unreadable or missing, or that have been changed,
defaced, or altered in any manner.
Batteries.
A television that has been modified or incorporated into other products, or that has had the serial number
removed or altered.
A unit purchased or serviced outside of Canada.
Acts of nature or God, such as but not limited to earthquake or lightning damage.
Special, incidental or consequential damages.

12
Broadcasting & Operating Environment
Broadcasting system US System NTSC-M
ATSC standard (8VSB), QAM
Receiving Channels VHF2-13
UHF14-69
CATV 14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)95-99 (A-5)-(A-1)
100-135 (100)-(135)
01 (4A)
Tuner type Frequency synthesized
Operating Temperature 5°C to 35°C (41°F to 95°F)
Operating Humidity 20% to 80%, non-condensing
Storage Temperature -15°C to 45°C (5°F to 113°F)
Storage Humidity 10% to 90%, non-condensing

13
Troubleshooting
Cannot connect to wireless network (WiFi)
• Select the correct wireless network name and verify the password entered (case sensitive).
• Relocate the router from objects that interfere with performance (cordless phones, baby monitors, etc.).
• Reboot the router by disconnecting the power for more than 2 minutes and reconnect.
What is the remote code for programming my Universal or Cable box remote control?
•
Problems connecting my cable box or antenna through a coax cable
• For best performance, use the HDMI connection. If not available, then:
•
Make sure the cable connections to the TV and your device are securely fastened.
•
Select cable or antenna input.
Access parental control
• The initial personal password for your TV is 1234.
•
You can change the personal password anytime.
•
If you forget your personal password, you can use 0423 to reset.
• Select the channel scan menu and follow the on-screen instructions to perform a full channel scan.
Having trouble completing the guided setup? Don’t worry, it’s usually an easy fix.
1-877-300-9576
Need more help?
support.tcl.com/ca
Please visit https://go.tcl.com/codes
How to use voice control through the remote control?
• In Google TV mode, press and hold the “HOME” and “OK” buttons on your remote at the same time.
•
Keep your remote within 3 ft. of your TV during the pairing process.
•
Then, when the TV display shows that the Google Assistant is ready – speak towards the remote
microphone by holding down the Google Assistant button to
ask a question or try a suggestion.
How to use hands-free voice control?
• In Google TV mode, press the Google Assistant button on your remote.
•
Select “Yes, I’m in”.
•
Say “OK Google” or “Hey Google” to activate the hands-free voice assistant without using
the remote control.
•
Speak towards the TV to ask a question or try a suggestion.
Follow these steps to enable the always-on hands-free voice control:
• Select “Settings” from the home screen.
• Select “System” > “Power & Energy” > “Screenless Service”.
• Turn on the “Screenless Service” and you can enjoy hands-free voice control
in TV standby mode.
• Select “System” > “Power & Energy” > “Quick Start” and turn it on.
Note: Make sure the hands-free voice control mic switch (refer to page 8 for its position) is turned on
before using this function.

Complete your Home Theater Experience
with a TCL Sound Bar!
STUNNING SOUND. MADE SIMPLE.
TCL’s Alto Sound Bar Lineup
are simple to setup and easy to use. With specialized sound modes, available
wireless subwoofers, and everything you need to connect to yourTCL TV,
Alto Sound Bars provide stunning sound, made easy.
To learn more visitTCL.com or your favorite retailer.
Alto 6+
Part No.: 80123-000105
TCL and the TCL Logo are owned by TCL Corporation
and under license to TCL North America. Other brand and
product names are the trademarks or registered trademarks
of their respective owners.
TCL North America
1860 Compton Avenue, Corona, California 92881, USA

Série 5
S546-CA
Bonjour ! Commençons.

Ne pas retourner au magasin
Pour toute question,
contactez-nous en
premier
Nous sommes
là pour vous
aider
Retirer l'appareil avec soin
Soutien TCL:
support.tcl.com/ca
1-877-300-9576

No de modèle
Date d'achat Nom du commerçant/adresse/téléphone
No de série
Avertissement: Les piles ne doivent pas être exposées à une chaleur excessive, telle qu'une exposition
directe et prolongée au soleil, une flamme nue ou à n'importe quel feu.
Reportez-vous à l'étiquette
d'identification / de classification située sur le panneau arrière de votre
produit pour connaître la tension de
fonctionnement appropriée.
À l'installateur de télévision par câble: ce rappel est destiné à attirer votre attention sur l'article 820-40
du Code national de l'électricité (article 54 du Code canadien de l'électricité, Partie 1) qui fournit des directives
pour une mise à la terre appropriée et spécifie comment le câble de mise à la terre du système doit être connecté
à l'installation de mise à la terre du bâtiment aussi près que possible du point d'entrée du câble.
Important: Ce téléviseur est un modèle de table et est conçu pour être posé sur une surface plane et solide. Ne
placez pas le téléviseur sur un tapis moelleux ou sur une surface similaire, car les fentes de ventilation situées au
bas de l'appareil risquent d'être bloquées et la surchaue qui en résulterait pourrait réduire la durée de vie du
produit. Pour garantir une bonne ventilation de ce produit, laissez un espace d'un (1) pouce entre le haut et le côté
du récepteur du téléviseur et un espace de deux (2) pouces entre l'arrière du récepteur du téléviseur et les autres
surfaces.
Assurez-vous que le support ou la base du téléviseur que vous utilisez a des dimensions et une résistance
susantes pour éviter que le téléviseur ne soit accidentellement renversé, poussé ou tiré. Cela peut entraîner des
blessures corporelles et/ou endommager le téléviseur. Reportez-vous aux instructions de sécurité importantes qui
sont précisées à la page suivante.
Le bouton d'alimentationdecetéléviseur et de votre télécommande met letéléviseur en mode veillede très
faible consommation, sans toutefois lemettrecomplètement hors tension. Pour couper l'alimentation, vous
devez débrancher le cordon d'alimentation de la prise. Le coupleurdeprise / appareil principal est utilisépour
éteindre complètement l'appareil. Si vous préférezéteindre complètement l'appareil,vous devez installer letél
éviseur demanière à pouvoir facilement débrancherle cordon d'alimentation si vous l esouhaitez.
Information produit
Conservez votre reçu de vente pour obtenir les pièces et le service de garantie, ainsi que la preuve d'achat.
Attachez-le ici et inscrivez les numéros de série et de modèle au cas où vous en auriez besoin. Ces numéros
sont situés sur le produit.
Avertissement: les changements ou modifications apportés à cette unité qui ne sont pas expressément
approuvés par la partie responsable de la conformité peuvent annuler l'autorité de l'utilisateur d'utiliser
1
Entrée Compatibilité du signal
HDMI
Vidéo composite
Antenne/Câble
480i, 480p, 720p/60Hz, 1080i/60Hz, 1080p/60Hz, 2160p/24/30/60Hz
480i
480i, 480p, 720p, 1080i (formats NTSC, ATSC, et QAM)
Ce symbole indique une «tension dangereuse»
à l'intérieur du produit, lequel présente un risque
d'électrocution ou de blessure.
Ce symbole indique les instructions
importantes accompagnant le produit.
Attention
Risque de décharge électrique.
Ne pas ouvrir.
Avertissement
Pour réduire le risque d'incendie ou d'électrocution,
n'exposez pas ce produit à la pluie ou à l'humidité.
Ce produit ne doit pas être exposé à l'égouttement
ou aux éclaboussures. Aucun objet rempli de liquides,
tel que des vases, ne doit être placé sur l'appareil.
Avertissement
Le téléviseur est instable s'il n'est pas correctement
fixé à la base ou monté sur le mur. Veuillez suivre les
instructions de montage de la base ou mural fournies
dans le Guide de l'utilisateur pour assurer votre sécurité.
Information importante
ATTENTION: Fusible sur le neutre. Débrancher I’alimentation avant I’entretien.
Attention: Pour réduire le risque de décharge électrique, ne pas démonter le panneau arrière. Aucune
pièce réparable par l'utilisateur à l'intérieur. Confiez l'entretien à un technicien qualifié.
Ce symbole indique que ce produit intègre une
double isolation entre la tension principale
dangereuse et les pièces accessibles à
l'utilisateur. Lors de l'entretien, n'utilisez que des
pièces de rechange identiques.

2
Consignesde sécurité importantes
1. Lire ces instructions.
2. Conserver ces instructions.
3. Tenir compte de tous les avertissements.
4. Suivre toutes les instructions.
5. Ne pas utiliser cet appareil près de l'eau.
7. Ne bloquez pas les ouvertures de ventilation. Installez conformément aux instructions du fabricant.
8. Ne pas installer à proximité de sources de chaleur telles que des radiateurs, des bouches de chaleur,
des poêles ou tout autre appareil (y compris les amplificateurs) produisant de la chaleur.
9. Protégez le cordon d'alimentation afin qu'il ne soit pas piétiné ou pincé, en particulier au niveau des
fiches, des prises de courant et de la sortie de câble de l'appareil.
10. Attention: Ve uillez consulter les informations sur le boîtier inférieur extérieur pour les informations
électriques et de sécurité avant d'installer ou de faire fonctionner l'appareil.
11. Attention: La fiche principale est utilisée pour débrancher l'appareil et doit rester facilement
accessible.
12. Lorsque vous n'utilisez pas votre téléviseur, attachez le cordon d'alimentation avec un serre-câble ou
un dispositif similaire. Le câble ne doit pas se trouver à proximité d'arêtes vives, car il pourrait s'abîmer.
Lors de la remise en service, vérifiez que le cordon d'alimentation n'est pas endommagé. Si ce dernier
devait être endommagé, utilisez un cordon d'alimentation de remplacement tel que spécifié par le
fabricant ou qui est identique à celui d'origine.
13. Aucune source de flamme nue, telle que des bougies allumées, ne doit être placée sur, sous ou à
proximité de l'appareil.
14. Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant de longues périodes.
15. N'utilisez que des articles ou accessoires spécifiés par le fabricant.
16. Utilisez uniquement avec le chariot, le support, le trépied, le support ou la table spécifié
par le fabricant ou vendu avec l'appareil. Lorsqu'un chariot est utilisé, faites attention
lorsque vous déplacez le chariot et l'appareil afin d'éviter toute blessure.
17. Confiez toute réparation à un technicien qualifié. Un entretien est requis lorsque l'appareil a été
endommagé de quelque façon que ce soit, par exemple un cordon d'alimentation ou une prise
endommagée, du liquide a été renversé ou des objets sont tombés dans l'appareil, a été exposé à la
pluie ou à l'humidité ou qu'il ne fonctionne pas normalement ou parce qu'il est tombé.
18. Pour un fonctionnement en toute sécurité de l'appareil, veuillez respecter les exigences d'installation
suivantes:
laissez aucun objet obstruer les orifices de ventilation de l'appareil, tels que journaux, rideaux, nappes ou
tout autre objet. N'exposez pas l'appareil à des sources de chaleur externes. Ne placez pas de sources de
chaleur telles que des bougies, des lampes, etc. sur l'appareil. N'exposez pas l'appareil à des niveaux élevés
d'humidité ou à d'éventuelles sources d'humidité. Lors de la mise au rebut des piles usagées de la
télécommande, veuillez consulter les réglementations locales concernant leur élimination correcte.
19. Si une antenne externe ou un systèmede câble est connecté au produit, assurez-vous que l'antenne ou
le systèmedecâbles est reliéà laterredefaçon àfournirune certaine protection contre les surtensions et
les charges statiques accumulées. L'article 810 duCode national de l'électricité, ANSI / NFPA no 70-2011
(article 54 du Code canadien de l'électricité, partie1) fournit des renseignements sur la mise à laterre du
mât et de lastructure portante,la miseà laterre du fil à uneantenne/unité de décharge, la taille des
conducteurs de miseàla terre,l'emplacement de l'unité dedécharge de l'antenne, la connexion aux
électrodes de miseà laterre et les exigences pour l'électrodedemise à la terre.
Comme dans l'exemple suivant:
Fil conducteur de l'antenne
Collier de mise à la terre
Unité de décharge de l'antenne
(NEC Section 810-20)
Colliers de mise à la terre
Conducteurs de mise à la terre
(NEC Section 810-21)
Équipement électrique Système d'électrode de mise
à la terre de service électrique
(NEC ART 250, PART H)
Ne
Nettoyez uniquement à l'aide d'un chion sec.
