TCL 5-Series Specification sheet

Hi! Let’s get started.
5-Series
S546
REGISTER NOW
See inside for details &
protect your purchase

Product Replacement
Free 1-time replacement if product cannot be fixed.
TCL Parts & Service
Genuine TCL parts & factory certified service.
No Deductible
$0 out of pocket expense.
Pixel Repair and Burn-In Coverage
Don’t let shadow xels prevent you from clear viewing.
Accidental Damage Protection
Coverage for drops, breaks and spills starts after 30 days.
Complimentary Remove & Reinstall
Don’t risk it-we’ll remove and reinstall televisions 65” and larger.
Lost Your Remote?
No problem! We’ll replace your remote, so you never have to
leave your couch. One time only.
Priority Service
Free shipping and rapid turn-around time.
Extended Manufacturer Coverage
Extended parts & labor coverage for manufacturer defects.
PROTECT PROTECT PLUS
Thank you for choosing TCL. We want your ownership experience to bring you as much joy as the
you purchase during registration. Add a TCL Protection Plan within your first 30 days of ownership
to receive the best value and we won’t let anything get in the way of your viewing pleasure.
Add a TCL Protection Plan when you register your
product and be covered from life’s mishaps
Benefits & Description
Up To 4 Years
3-5 Days 3-5 Days
Up To 4 Years
Text a photo of the
camera icon to 71403
TEXT TO REGISTER
Or register online at www.register.tcl.com
Need help? Visit photoregister.com/help or text HELP to 71403
Register and protect your purchase
TCL-5GGLTV

DO NOT RETURN TO STORE
TCL SUPPORT:
support.tcl.com/us
1-877-300-9576
contact us first
with any questions
WE ARE
READY TO
HELP
TAKE CARE WHEN
REMOVING THE TV

1
WARNING
To reduce the risk of fire or electric shock, do
not expose this product to rain or moisture.
This product should not be exposed to dripping
or splashing. No objects filled with liquids, such
as vases, should be placed on the apparatus.
WARNING
The TV is unstable if it is not properly attached to
the base or mounted to the wall. Please follow the
base or wall mounting instructions provided in the
User’s Guide to ensure your safety.
Warning: The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
Model No.
Purchase Date
Serial No.
Dealer/Address/Phone
Important Information
Refer to the identification/rating label located on the back panel of your product for its proper operating
voltage.
Cable TV Installer:
This reminder is provided to call your attention to Article 820-40 of the National
Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper
grounding and, in particular, specifies that the cable ground should be connected to the grounding system
of the building as close to the point of cable entry as practical.
Important: This television is a table model and is designed to sit on a firm, flat surface. Don’t place
the TV on soft carpeting or similar surface because the ventilation slots on the bottom of the unit will
be blocked, resulting in reduced lifetime from overheating. To assure adequate ventilation for this
product, maintain a spacing of 1 inch from the top and side of the TV receiver and 2 inches from the
rear of the TV receiver and other surfaces.
Also, make sure the stand or base you use is of adequate size and strength to prevent the TV from
being accidentally tipped over, pushed o , or pulled o . This could cause personal injury and/or damage
to the TV. Refer to the Important Safety Instructions on the next page.
The Power button on this TV and your remote control puts the TV into a very low-power standby
mode but will not completely turn the power o . In order to completely shut the power o , you will
need to disconnect the power cord from the outlet. The mains plug/appliance coupler is used to
completely turn o the device. If you prefer to completely turn o the device, you should install
the TV in a manner that allows you to disconnect the power cord when desired.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here
and record the serial and model numbers in case you need them. These numbers are located on the
product.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. Keep the apparatus at least 8
inches away from the human body.
For the best viewing experience, remove the energy guide label from the TV front panel or TV screen
before use.
Input Signal Compatibility
480i, 480p, 720p/60Hz, 1080i/60Hz, 1080p/60Hz, 2160p/24/30/60Hz
480i
480i, 480p, 720p, 1080i (NTSC, ATSC, and QAM formats)
HDMI
Composite Video
Antenna/Cable
Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside.
Refer servicing to qualified service personnel.
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
This symbol indicates important instructions
accompanying the product.
CAUTION/ATTENTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
This symbol indicates that this product incorporates
double insulation between hazardous main voltage
and user accessible parts. When servicing, use only
identical replacement parts.
RISQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR.
CAUTION: Neutral fusing. Disconnect mains before servicing.
ATTENTION: Fusible sur le neutre. Débrancher I’alimentation avant I’entretien.

2
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
10. WARNING: Please refer the information on exterior bottom enclosure for electrical and safety information
before installing or operating the apparatus.
11. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily
operable.
12. When not in use and during movement, please take care of the power cordset, e.g. tie up the power
cordset with cable tie or something like that. It shall be free from sharp edges and the like that can
cause abrasion of the power cordset. When put into use again, please make sure the power cordset
being not damaged. If any damages found, please look for the service person to replace the power
cordset specified by the manufacturer or have the same characteristics as the original one.
13. No naked flame sources, such as lighted candles, should be placed on the apparatus.
14. Unplug this apparatus during lightning storms or when unused for long periods of time.
15. Only use attachments/accessories specified by the manufacturer.
16. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
17. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
18. For safe operation of the apparatus, observe these installation requirements:
Keep at least 2 inches of ventilation space between the rear cover of the apparatus and the wall.
Keep at least 1 inch of ventilation space between the apparatus and all other surfaces. Do not allow
any of the apparatus’ ventilation openings to be blocked by objects that might obstruct them, such
as newspapers, curtains, table-cloths or any other objects. Do not expose the apparatus to any external
heat sources. Do not place any heat sources such as candles, lamps, etc. on the apparatus. Do not expose
the device to high levels of humidity or to any possible sources of moisture. When disposing of used
batteries
from the remote control, consult local regulations regarding proper disposal.
19. If an outside antenna or cable system is connected to the product, be sure the antenna or cable system
is grounded so as to provide some protection against voltage surges and built-up static charges. Section
810 of the National Electrical Code, ANSI/NFPA No. 70-2011 (Section 54 of Canadian Electrical Code,
Part 1) provides information with respect to proper grounding of the mast and supporting structure,
grounding of the lead in wire to an antenna-discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
See following example:
ANTENNA LEAD IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND CLAMPS
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
ELECTRIC SERVICE
EQUIPMENT
POWER SERVICE GROUNDING
ELECTRODE SYSTEM (NEC ART
250, PART H)

ELECTRONICS & PACKAGING RECYCLING INFORMATION
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit di erent from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
5-series, include models (S546)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
Supplier Name: TTE Technology, Inc. (dba TCL North America)
Supplier Address: 1860 Compton Avenue, Corona, California 92881, USA
Supplier phone number and internet contact information: 1-877-300-9576 support.tcl.com/us
Battery Caution & Disposal Information
1. For best results, use alkaline type batteries.
2. Install only new batteries of the same type in your product.
3.
Failure to insert batteries in the correct polarity, as indicated in the battery compartment, may shorten
the life of the batteries or cause batteries to leak.
4. Do not mix old and new batteries.
5. Do not use Rechargeable (Nickel Cadmium or Nickel Metal Hydride) batteries.
6. Do not mix Alkaline, Standard (Carbon-Zinc) or Rechargeable (Nickel Cadmium or Nickel Metal Hydride)
batteries.
7.
8. Batteries should be recycled or disposed of as per state and local guidelines.
Do not dispose of batteries in fire.
3
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
9. Replacement of a BATTERY with an incorrect type that can defeat a SAFEGUARD (for example,
in the case of some lithium BATTERY types).
Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol are registered
trademarks of Dolby Laboratories Licensing Corporation. Manufactured
under license from Dolby Laboratories. Confidential unpublished works.
Copyright © 2012-2020 Dolby Laboratories. All rights reserved.
For information on recycling your old TVs, sound bars, and home comfort products, and to find drop-off
locations in your area, please visit the “Electronics Recycling” area of the TCL website at www.tcl.com.
Click on our convenient interactive map to quickly locate a solution in your community. TCL encourages
consumers to always look for a recycling or reuse alternative to discarding televisions and other electronics,
and in many areas TCL has programs for consumers to drop-off and recycle televisions free of charge.
Look for convenient How2Recycle® labels on the product box for help preparing your new TV packaging for
recycling. These labels show important information identifying the various types of packaging material included
with your new TV along with easy-to-understand recycling instructions.

4
What’s in the box
TV remote
What you need
Phillips head
screwdriver
For additional support, please visit support.tcl.com/us
Make the most of your TV
Router + Internet Connection
(needed for streaming)
TCL TV 2 x AAA batteries
for remote
TV stands
Power cable 4 x Stand screws
Cable clips
M4X30mm for models of 50”/55”/65”
M5X25mm for models of 75”
50’’/55’’/65’’
or or
75’’
(2 x Cable clips)
50’’/55’’/65’’
(4 x Cable clips)
75’’

5
Step 1 Set up your TV
Ready for the step-by-step? You’re only minutes away from TV bliss!
the TV. Secure the stands to the TV with four (4) screws.
Put the column of the stands into the TV, align the stands with the screw holes located on
Remove your TV from the box
To prevent damage to the screen, carefully place your TV on a soft, cushioned surface.
A
B
To use the stand
Warning:
Never place a television set in an unstable location. A television set may fall, causing serious
personal injury or death. Many injuries, particularly to children, can be avoided by taking simple
precautions such as:
- Using cabinets or stands recommended by the manufacturer of the television set.
- Only using furniture that can safely support the television set.
- Ensuring the television set is not overhanging the edge of the supporting furniture.
-
Not placing the television set on tall furniture (for example, cupboards or bookcases) without
anchoring both the furniture and the television set to a suitable support.
-
Not placing the television set on cloth or other materials that may be located between the
television set and supporting furniture.
-
Educating children about the dangers of climbing on furniture to reach the television set
or its controls.
If your existing television set is being retained and relocated, the same considerations as
above should be applied.
Note: Make sure the installation direction of the stand is the same as illustrated.
Be careful, it’s heavy!
Screws
(50’’/55’’/65’’: M4x30mm 75’’: M5X25mm)
50’’/55’’/65’’/75’’
AA
B55’’/65’’/75’’
A
B
To use the cable clips
50’’/55’’/65’’ 75’’
A
B
Stick the two cable clips on the TV stands on the left and right.
On back of the TV, instert the two cable clips into the back of TV on the left and right.
A
B
Note: Make sure the installation direction of the cable clip is the same as illustrated.
Attach the two cable clips to the TV stands on the left and right.
C
C

Optional - To mount on a wall
(wall mount not included)
Preparation must be done before mounting your TV on a wall.
To mount on a wall
The VESA number is the horizontal and vertical measurement of the mounting holes. For
example, 200X200 refers to the fact that the mounting measurements are 200mm horizontally
and 200mm vertically.
Follow the instructions that come with the wall mount.
Your wall mount must be able to bear a minimum of five times the TV’s net weight to avoid
causing damage.
55” Models Purchase a VESA 300x200, 4 M6x12mm screws
To mount your TV to the wall, purchase a VESA wall mount
If you are mounting your TV to the wall, don’t attach the stands.
65” Models Purchase a VESA 300x300, 4 M6x12mm screws
50” Models Purchase a VESA 200x200, 4 M6x12mm screws
75” Models Purchase a VESA 400x300, 4 M6x25mm screws
6
Place your TV on a soft, cushioned surface.
1
4
2
Remove the 4 screws from the back of the TV.
Follow the instructions that come with the wall mount
to hang the TV on the wall.
3
Screw the VESA bracket tightly onto the back cover
with 4 VESA screws.
VESA screws:
50”/55”/65”: M6x12mm
75”: M6x25mm
1RWH'RQRWSODFH\RXU79LQDORFDWLRQH[SRVHGWRGLUHFWVXQOLJKWKHDW´UHRUPRLVWXUH
([SRVXUHZLOOGDPDJHWKH79.

Step 2
7
Power up
In this step, we’ll make sure all systems are a GO!
Connect your power cable to the TV, then plug
it in to the wall outlet.
and descriptions on the next page.
Connect other devices by referencing port label
Power Tip! Always replace depleted batteries with two
same brand-new batteries from the same manufacturer.
Never use damaged batteries.
If your remote gets warm/hot during use, discontinue
use and contact customer support immediately at
support.tcl.com/us.
Insert batteries in the correct polarity as
indicated in the battery compartment.
Tip! Follow the on-screen guide
to pair the remote control with
the TV when pressing the
button for the first time.
Power your TV remote by inserting the included
batteries.
remoteGrab yourStep 3
The TV remote should feel right at home in your hand. We designed it to
be incredibly intuitive for watching TV and navigating on-screen menus.
POWER Turn TV on and off
B
SETTINGS Display the dashboard on screen
D
TCL HOME Open TCL home on screen
N
HOME Return to home screen
H
BACK Return to previous screen
I
ELECTRONIC PROGRAM GUIDE Display the live menuJ
GOOGLE ASSISTANT BUTTON Press to activate the
remote’s Google Assistant microphone. Search content
through your voice by holding down the button.
F
VOLUME Raise and lower volume
G
VIRTUAL KEYBOARD Open virtual keyboard on screen
L
NETFLIX Open Netflix
O
YouTube Open YouTube
P
TCL CHANNEL Open TCL Channel
Q
Prime Video Open Prime Video
R
OPTIONS View more options when playing the media
A
WATCHLIST Open the watchlist menu
C
MUTE Press the button to mute the sound. In Google TV,
holding the button down about 3 seconds can display
the “TalkBack”.
K
QUICK PANEL Display the quick panel
M
REMOTE MICROPHONE Talk to the remote microphone
after pressing the Google Assistant button
E
E
M
F
H
G
AB
C D
IK
L N
Q
O P
R
J

Step 4
8
Get to know your TV
H
L
I
HDMI PORTS
Highest quality audio/video connection.
Connect cable box, Blu-ray player, gaming console,
or other devices to your TV using HDMI cables.
ETHERNET Connect an Ethernet cable to your home
Internet router or switch.
F
ANTENNA/CABLE IN Connect an outdoor VHF/UHF
antenna or Cable TV feed.
OPTICAL (DIGITAL AUDIO OUT)
Connect an optical
cable to an external digital audio system.
The AV Input can be used to connect older devices
that use analog audio/video outputs. Compatible
adapter (not included) connects to the RCA cable
(video - yellow and audio - white and red) that you
normally use to connect to that device.
AV IN adapter AV Input (analog audio/video).
K
USB PORT
Connect a USB device to access photos,
music and movies.
J
G
HEADPHONE OUT Connect headphones or other
external speakers.
TV FRONT
TV SIDE
HDMI eARC/ARC PORT Connect HDMI eARC/ARC
E
(audio return channel) capable audio devices like
sound bars or
AV receivers.
I
G
J
K
L
F
E
G/H
IR RECEIVER Receives signal from
the TV remote.
STATUS LIGHT OF HANDS-FREE
VOICE CONTROL
Glows when you
activate the hands-free voice control.
(To learn more about the function,
go to page 13.)
A
POWER PORT Connect your TV
C
to the power source with the
included power cable.
POWER and OPTIONS BUTTON
B
Press once to open the menu.
Short click to change the menu and
long click to select.
AV IN
CABLE/ANT
AUDIO OUT
ETHERNET
eARC
/ARC
TV BACK
C
B
D
HANDS-FREE VOICE CONTROL MIC SWITCH
Enable or disable the TV’s integrated microphone.
D
A

Step 5 Complete guided setup
It’s the final stretch-hurray!
Let’s Connect
Once your language has been selected, you can quickly set up the TV using an Android phone
with the pre-installed Google Home app.
Or you can follow the easy on-screen instructions to setup your TV. If you aren’t ready to
connect your TV to a wireless network, you can still use it as a regular TV.
And setup is done… Congratulations!
Continue using the remote to personalize your Home screen, streaming channels and apps line-up,
stream movies, and so much more.
TCL SUPPORT:
support.tcl.com/us
1-877-300-9576
contact us first with any questions
WE ARE READY TO HELP
9
TV interface may vary and is subject to change.
Key things to know:
A paid subscription or other payments may be required for some streaming channels and apps.
Streaming channels and apps availability are subject to change and vary by country.

10
TCL North America Limited Warranty
All TCL LCD/LED Models
What your warranty covers
New LCD/LED Televisions (Commercial Use)
For how long after your purchase:
Six (6) months from date of purchase for parts and labor for commercial use.
Commercial use includes, but is not limited to, the use of this product in a commercial or business
environment, the use of this product in an institution or for institutional purposes, or other commercial
purposes including rental purposes.
One (1) year from date of purchase for parts and labor for non-commercial use.
Please have your original purchase receipt or proof of purchase (bill of sale or receipted invoice) which
states that condition of the unit (New, Used, etc.), the unit’s date of purchase, place of purchase and model/
serial number ready. The model/serial number information can be found on the back of your unit.
Call 1-877-300-9576 or visit support.tcl.com/us
A representative must troubleshoot your problem over the telephone or through e-mail before receiving
service. If it is determined that your unit requires service, the service location will be at the sole discretion
of TCL North America based upon the TCL North America Limited Warranty Statement.
At the sole discretion of TCL North America, television screen sizes 43” and smaller will either be repaired
at an Authorized TCL Service Center or directly exchanged for a new or refurbished/recertified unit. At the
sole discretion of TCL North America, television screen sizes 44” through 75” or larger will either be repaired
or directly exchanged for a new or refurbished/recertified unit at an Authorized TCL Service Center or
repaired in-home. In the event of a service visit where the on-site technician, in his-her sole discretion,
deems the home or property conditions to be hazardous and/or unsafe, TCL North America reserves the
right to cancel or re-schedule the service visit, or opt for an exchange of the in-warranty unit for a
refurbished/recertified unit lieu of the in-home service visit.
If repaired at an Authorized TCL Service Center, TCL North America is not responsible for transportation
costs to the Authorized TCL Service Center. However, TCL North America will pay for return shipping.
TCL North America will provide instructions for packaging and shipping the unit. Units that are improperly
packed and damaged during shipping are not covered under your product warranty.
Proof of purchase in the form of a bill of sale or receipted invoice from an Authorized Dealer which is
evidence that the product is within the warranty period must be presented to obtain warranty service.
In the event that a unit is to be replaced, a picture of the back of the unit showing the model and serial
number and picture of the issue itself may be required.
PRE-AUTHORIZATION MUST BE OBTAINED BEFORE (1) SENDING ANY PRODUCT TO AN AUTHORIZED
TCL SERVICE CENTER, OR (2) OBTAINING ANY IN-HOME REPAIR/REPLACEMENT/ RENTAL SERVICES.
Defects in materials or workmanship to the original owner of this TCL product when purchased as new from
an Authorized Dealer of TCL brand products in the United States and packaged with this warranty statement.
How to get service
What we will do
At TCL North America’s discretion, (1) pay an Authorized TCL Service Center for both labor charges and
parts to repair your television, or (2) replace your television with a new or refurbished / remanufactured
equivalent value product. The decision to repair or replace will be made solely by TCL North America.
See “How to get service”.
New LCD/LED Televisions (Non-Commercial Use)
For how long after your purchase:

11
TCL North America Limited Warranty
THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. NO
VERBAL OR WRITTEN INFORMATION GIVEN BY TCL NORTH AMERICA, ITS AGENTS OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE OR MODIFY THE SCOPE OF THIS WARRANTY.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER. TCL NORTH AMERICA SHALL NOT BE LIABLE FOR SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY
BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF CALIFORNIA.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY AND WARRANTY PERIOD SET FORTH ABOVE. THIS WARRANTY IS SUBJECT TO
CHANGE WITHOUT NOTICE. PLEASE VISIT WWW.TCL.COM TO VIEW THE MOST CURRENT VERSION.
LIMITATION OF WARRANTY
How State Law relates to this warranty
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations
on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you also may have other rights that vary from state to
state.
If you purchased your unit outside the United States or seek warranty coverage
outside the United States:
This warranty does not apply. Contact your dealer for warranty information.
Service calls which do not involve defective materials or workmanship are not
covered by this warranty. Costs of such service calls are the sole responsibility
of the purchaser.
What your warranty does not cover
A unit sold in “As-Is”, “Used”, “Factory Reconditioned”, “Factory Re-Certified”, or “Refurbished”, condition
or with faults.
Units physically broken during shipment from a Retailer. Please contact your Retailer for assistance.
Extended Service Plans purchased from Retailers. Please contact your Retailer for assistance.
Customer instruction. (Your Owner’s Manual describes how to install, adjust, and operate your unit. Any
additional information should be obtained from your Authorized Dealer).
Installation and related adjustments, or damage resulting from installation.
Damage resulting from non-approved installation or repair methods.
Signal reception problems not caused by your unit.
Damage from misuse, abuse, neglect, insects, normal wear and tear, cosmetic damage, mishandling,
faulty installation, or power line surges.
Markings or images on the television’s panel resulting from viewing fixed images (including but not limited
to certain 4:3 images on wide screen televisions, or data or images in fixed screen locations from banners,
video games, or certain broadcast networks).
Units that have original factory serial numbers that are unreadable or missing, or that have been changed,
defaced, or altered in any manner.
Batteries.
A television that has been modified or incorporated into other products, or that has had the serial number
removed or altered.
A unit purchased or serviced outside the USA.
Acts of nature or God, such as but not limited to earthquake or lightning damage.
Special, incidental or consequential damages.

12
Broadcasting & Operating Environment
Broadcasting system US System NTSC-M
ATSC standard (8VSB), QAM
Receiving Channels VHF2-13
UHF14-69
CATV 14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)95-99 (A-5)-(A-1)
100-135 (100)-(135)
01 (4A)
Tuner type Frequency synthesized
Operating Temperature 5°C to 35°C (41°F to 95°F)
Operating Humidity 20% to 80%, non-condensing
Storage Temperature -15°C to 45°C (5°F to 113°F)
Storage Humidity 10% to 90%, non-condensing

13
Troubleshooting
Cannot connect to wireless network (WiFi)
• Select the correct wireless network name and verify the password entered (case sensitive).
• Relocate the router from objects that interfere with performance (cordless phones, baby monitors, etc.).
• Reboot the router by disconnecting the power for more than 2 minutes and reconnect.
What is the remote code for programming my Universal or Cable box remote control?
•
Problems connecting my cable box or antenna through a coax cable
• For best performance, use the HDMI connection. If not available, then:
•
Make sure the cable connections to the TV and your device are securely fastened.
•
Select cable or antenna input.
Access parental control
• The initial personal password for your TV is 1234.
•
You can change the personal password anytime.
•
If you forget your personal password, you can use 0423 to reset.
• Select the channel scan menu and follow the on-screen instructions to perform a full channel scan.
Having trouble completing the guided setup? Don’t worry, it’s usually an easy fix.
1-877-300-9576
Need more help?
support.tcl.com/us
How do I turn Text-to-Speech (TTS) on or off?
• Select “Settings” from the home screen.
• Select “Device Preferences”.
• Select “Accessibility”.
• Select “TalkBack”.
•
•
For more information visit: https://go.tcl.com/tts-atv
Please visit https://go.tcl.com/codes
How to use voice control through the remote control?
• In Google TV mode, press and hold the “HOME” and “OK” buttons on your remote at the same time.
•
Keep your remote within 3 ft. of your TV during the pairing process.
•
Then, when the TV display shows that the Google Assistant is ready – speak towards the remote
microphone by holding down the Google Assistant button to
ask a question or try a suggestion.
How to use hands-free voice control?
• In Google TV mode, press the Google Assistant button on your remote.
•
Select “Continue” > “Allow” > “Turn on”.
•
Say “OK Google” or “Hey Google” to activate the hands-free voice assistant without using
the remote control.
• Speak towards the TV to ask a question or try a suggestion.

STUNNING SOUND. MADE SIMPLE.
Complete your home theater with a TCL Sound Bar.
provide stunning sound and simple setup. Available features including Dolby
Atmos surround sound and exclusive RAY·DANZ technology for a wider
soundstage deliver premium sound.
Learn more at TCL.com or visit your favorite retailer.
Al
Al
Al
t
t
o 9+
o 9
+
+
+
o 9
o 9
o 9
o 9
o 9
+
+
+
Part No.: 80123-000025
Copyright © 2021 by TCL. All rights reserved.
TCL and the TCL Logo are owned by TCL Corporation and
under license to TCL North America. Other brand and product
names are the trademarks or registered trademarks of their
respective owners.
TCL North America
1860 Compton Avenue, Corona, California 92881, USA
