Compact Multipurpose Type Compatible with High-Voltage Pulse
■FEATURES
●Amorphous core is used as the common mode coil core for the RSEL series, which helps prevent devise errors.
●Wire type and lug terminal type are available with the same shape.
●Optional low-leakage characteristic type is also available.
●Compliant with RoHS directives.
■SAFETY STANDARDS
UL1283 File No. E62388
CSA C22.2 No.8 File No. 208777
EN60939 Licence Ref. No. SE/07115-1
■PRODUCT IDENTIFICATION
■CIRCUIT DIAGRAMS
RSAL‒2＊＊＊□□
L ：Low-leakage current characteristic type
W：Wire type (AWG20)
A ：Lug terminal type (Faston #110)
Rated current
Number indicating the rated voltage
Series name
1
2
4
3
R S A L- 2 ＊＊＊ W
R S A L- 2 ＊＊＊ A
1
2
4
3
R S A L- 2 ＊＊＊ W L
R S A L- 2 ＊＊＊ A L
RSAL SERIES
●
Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and specific bromine-based
flame retardants, PBB and PBDE, have not been used, except for exempted applications.
●Faston® is a registered trademark of Tyco Electronics AMP Corp. Incorporated.

2
■ELECTRICAL CHARACTERISTICS
■DERATINGS
RSAL-20R5W
RSAL-2001W
RSAL-2002W
RSAL-2003W
RSAL-2006W
250V
0.5A
1A
2A
3A
6A
AC.2500V
60s
［ Betweenline
toground
］
100MΩmin.
［DC.500V/
1min］
1.0mA
max.
［250V/60Hz］
-25to+85℃ 55℃
700max.
600max.
250max.
150max.
80max.
0.3to8
0.3to8
0.5to8
1to7
3to7
0.4to30
0.5to30
0.7to30
0.8to30
1to30
RSAL-20R5WL
RSAL-2001WL
RSAL-2002WL
RSAL-2003WL
RSAL-2006WL
0.5A
1A
2A
3A
6A
250V
AC.2500V
60s
［ Betweenline
toground
］
100MΩmin.
［DC.500V/
1min］
10μA
max.
［250V/60Hz］
-25to+85℃ 55℃
700max.
600max.
250max.
150max.
80max.
0.1to5
0.1to5
0.1to5
0.2to5
1to30
0.4to30
0.5to30
0.7to30
0.8to30
1to30
PartNo.
Rated
voltage
（AC/DC）
Rated
current
（AC/DC）
Withstand
voltage
Insulation
resistance
Leakage
current
Operating
temperature
range
With
derating
over
DC
resistance
（mΩ）
Commonmode
at25dB
Attenuationfrequencyrange(MHz)
Differentialmode
at25dB
PartNo.
Rated
voltage
（AC/DC）
Rated
current
（AC/DC）
Withstand
voltage
Insulation
resistance
Leakage
current
Operating
temperature
range
With
derating
over
DC
resistance
（mΩ）
58
58
61
61
61
RSAL-20R5A
RSAL-2001A
RSAL-2002A
RSAL-2003A
RSAL-2006A
0.5A
1A
2A
3A
6A
700max.
600max.
250max.
150max.
80max.
0.3to8
0.3to8
0.5to8
1to7
3to7
0.4to30
0.5to30
0.7to30
0.8to30
1to30
43
43
46
46
46
56
56
59
59
59
RSAL-20R5AL
RSAL-2001AL
RSAL-2002AL
RSAL-2003AL
RSAL-2006AL
0.5A
1A
2A
3A
6A
700max.
600max.
250max.
150max.
80max.
0.1to5
0.1to5
0.1to5
0.2to5
1to30
0.4to30
0.5to30
0.7to30
0.8to30
1to30
41
41
44
44
44
Weight
（g）
Weight
（g）
Commonmode
at15dB
Attenuationfrequencyrange(MHz)
Differentialmode
at25dB
120
100
80
60
40
20
0
Rated current (%)
–25 –10 0102030405060708090
Ambient temperature Ta (˚C)

3
■SHAPES AND DIMENSIONS
RSAL-20R5/2001/2002/2003/2006W（L）
RSAL-20R5/2001/2002/2003/2006A（L）
Part No.
RSAL-20R5W(L)
RSAL-2001W(L)
RSAL-2002W(L)
RSAL-2003W(L)
RSAL-2006W(L)
RSAL-20R5A(L)
RSAL-2001A(L)
RSAL-2002A(L)
RSAL-2003A(L)
RSAL-2006A(L)
A
45
45
B
50
50
C
20
20
D
40
40
E
3.5
3.5
F
4.5
4.5
G1
300
-
G2
-
9
Dimensions in mm
E
A
C
F
D
B
G1
E
A
C
F
D
B
G2

4
