DVD-ROM Slot-Loading Drive
DV-28SS-W
isatrademarkofDVDFormat/LogoLicensingCorporationregistered
intheU.S.,Japanandothercountries.
isatrademarkofKoninklijkePhilipsElectronicsN.V.
ReadSpeed DVD-ROM  8x(CAV)
(MaxSpeed) DVDR  8x(CAV)

DVDRDL (FinalizedDisc) 8x(CAV)
  DVD-RAM(4.7G) 5x(PCAV)
  CD-ROM  24x(CAV)

CD-R  24x(CAV)
  CD-RW  24x(CAV)
  CD-DA(DAE) 20x(CAV) 
DiscDiameter 12cm,8cm
Interface SerialATARevision2.6  
DataTransferRate Gen1ｉ 1.5Gbps 
AccessTime 110ms(typ)DVD-ROM
  90ms(typ)CD-ROM 
DataBuffer 2MB
LoadingMechanism SlotLoadingType
EnvironmentalConditions
AmbientTemperatures  Operating  5to55℃
  NonOperating -20to60℃
  Transportation -40to65℃
AmbientHumidity Operating  8to80%(non-condensing)*
  NonOperating 5to95%(non-condensing)*
  Transportation 5to95%(non-condensing)*
PowerRequirements DC5V5% 
Loading/EjectingLife 10,000timesormore
CurrentConsumption Standby/Sleep0.1mA/60mA(Averagecurrentmax) 

Duringstarting/Seek1500mA/1500mA(Max,Spikesless2ms) 
MTBF 60,000POH(10%duty)
Safty/EMIStandards UL,CUL,TUV,CB,CEandBSMI
Dimensions 128.0Wx12.7Hx129.4D(mm)
Mass(Weight) 170gorless
RoHSDirective Complied
Remarks
Pleasecheckthespecificationsheetsfordetailedconditionsandotherinformation.
＊Themaximumwet-bulbtemp.is29.4degreeC
8x DVD Readable
24x CD Readable
8x DVD Readable
24x CD Readable
Slot Loading
■SlimtypeSlotLoadingdesign
■Horizontalandverticalmountingformostsystemconfiguration
■EmergencyEjectFunction
Suitable for Notebook PCs
5.7±0.2(M2TAPCENTER)
9.7
1.9
36.25±0.2
6.25±0.2
92.4±0.2
65.1±0.2
52.6±0.2
6.9±0.4
102.6
3.8±0.2
110.1±0.2 110.1±0.2
DRIVELEFTEDGETOCONNECTORCENTER
DRIVEBACKEDGETO
CONNECTORBACKWALL
SATACONNECTOR
SATACONNECTOR
DRIVEBOTTOMEDGETO
CONNECTORTONGUETOPEDGE
±0.38
5.2
(129.4)
RECOMMENDATIONTORQUE:０．１７６N・m〜０．２３５N・m
（１．８ｋｇ・ｃｍ〜２．４ｋｇ・ｃｍ）
CLAMPING&TORQUE０．２５５N・mMAX（２．６ｋｇ・ｃｍMAX)
4-M2tappedholes
forinstallation
depth2.0MAX,1.4MIN
(LeftsideX2,RightsideX2)
12.7
3±0.2
CLAMPING&TORQUE:0.255N・mMAX（２．６ｋｇ・ｃｍMAX）
RECOMMENDATIONTORQUE:0.176N・m〜0.235N・m
(1.8kg・cm〜2.4kg・ｃｍ）
4-M2tappedholes
forinstallation
depth2.5MAX,1.4Min
126.1
(25.4)
89.45
128
10±0.2
(25.4)
27.3±0.2 27.3±0.2
0.2
6.2
10.6 9.4
4.8
1
3.3
CONVEX:0.6
2.8
21.25
43.5 41
128.4
3.7
4
1.3
94
85.5
81.5
2.4 123.4
13.7
10.5
ACCESSINDICATOR
EMERGENCYHOLE(∅1.5）
EJECTBUTTON
(NOTE)THISSIDEVIEWISFORBEZELONLY
Unit:mm
Externalviewofthedrive
(±0.4)
