TECALEMIT WONDERBOX User manual

SETTING UP USB WONDERBOX DELIVERY POINTS
IN HD MANAGER
WONDERBOX
GO WITH THE FLOW.
www.tecalemitUSA.com I [email protected] Tel [phone] I Fax [phone]
QUICK GUIDE

GO WITH THE FLOW.
www.tecalemitUSA.com I [email protected] Tel [phone] I Fax [phone]
STEPS TO SET UP USB WONDERBOX DELIVERY POINTS
IN HD MANAGER:
You will need to download the HD Manager software onto one PC for use. The
software is located on the USB stick that comes with the Wonderbox or Tecalemit
Technical Support can send a link for download.
• Open your HD Manager Software.
• Click on the Masterdata tab.
• Click on HDA in the green bar.
• Click on the Fuel Terminal tab.
• In the "Identier" eld, type a name you would like to call your Wonderbox.
• In the "Type" eld, drop down the box so it reads "HAD eco” (Wonderbox).
• Go to the "Communication" eld and drop and select the "USB Flash Drive"
option.
• Click the "Save" button on the bottom right.
• Now click on the Delivery Point tab.
• On the right-hand side, type in the product you are dispensing in the "Product
name" and "Displayed name" eld.
• Click the "Save" button to the right.
• Now go to the left-hand side of the screen.
• In the "Delivery Point" eld 1.
• Fill in the "Fueling Limit" eld with how much product drivers/vehicles are
able to get during a single transaction.
• Fill in the "Fueling Time Out" eld with how many minutes the transaction
will last without the box seeing pulses from the meter.

GO WITH THE FLOW.
www.tecalemitUSA.com I [email protected] Tel [phone] I Fax [phone]
• Fill in the "Max Fueling Pause" with the amount of minutes the driver/vehicle
has to get the amount set in the "Fueling Limit" eld.
• Make sure the "Product Name" eld is set to the product being dispensed on
the unit.
• Make sure "Lock delivery point" is un-checked. If it is checked this will lock
the unit, and disable the drivers/vehicles from getting fuel.
• Click "Save" at the bottom of the screen.
CONTINUED
STEPS TO SET UP USB WONDERBOX DELIVERY POINTS
IN HD MANAGER:
