Heat exchanger Maxi-Heat Titanium
MA40-15E
ENGLISH
Model A B C D E F G H I J Weight
empty/lled
11377 - MFT260 139 mm Ø129 mm 1” 597 mm 84 mm 2” 168 mm 250 mm 429 mm 82 mm 3/10 kg
11380 - MFT680 222 mm Ø196 mm 2” 626 mm 143 mm Ø75 (DN65) 294 mm 340 mm 340 mm 109 mm 8/24 kg
It is important to read this manual carefully in order to ensure smooth functioning and long service life of the pool equipment.
Pahlén AB is not responsible for the product warranty in case of any damage due to improper installation, mishandling or
maintenance.
Product description
Maxi-Flo Titan is a type of tubular heat exchanger with spiral-shaped tubes for the optimal heat transfer. It is made of titanium
to be used in the systems with a high corrosion risk.
Titanium is advantageously used in the pool systems where salt water or chlorinator is used.
Maxi-Flo Titan must be connected to a heat source, such as boiler, heat pump or storage tank for the solar energy collecting
facility.
Maxi-Flo Titan is available in two versions: 75kW and 200kW.
Technical data MFT260
Item no. 11377
MFT680
Item no. 11380
Capacity
(at 60°C temperature difference) 75kW 200kW
Flow Primary side
Secondary side
35 l/min
300 l/min
95 l/min
600 l/min
Pressure drop Primary side
Secondary side
0.9 mVp
1.8 mVp
0.1 mVp
3 mVp
Max. temperature 120°C 120°C
Max. pressure Primary side
Secondary side
10bar
5bar
10bar
4bar
MFT260
Item no. 11377
MFT680
Item no. 11380
The product is intended for the following water
values:
Total chlorine content: max 3.5 mg/liter (ppm)*
Chlorine (salt) total: max 35 000 mg/liter
pH-value: 7.2 - 7.6
Alkalinity: 60-120 mg/liter (ppm)
Calcium hardness: 100-300 mg/liter (ppm)
Iron: max 0.1 mg/liter *
Copper: max 0.2 mg/liter *
Manganese: max 0.05 mg/liter *
Phosphorus: max 0.01 mg/liter *
Nitrate: max 50 mg/liter *
Outside these values the product warranty does not
apply
* Complies to EN 16713-3
Dimensions

6
File: R10502-8
2015-12-03 ASA
Maxi-Flo
R
10
9
11
12
13
1
3
2
4
5
7
6
8
5
5
Vvxl MFT680 Maxi-Flo 200kW M12352 - Borrinstruktion
A
20
7
70
17
222 3
7
Q:\Mekanik\Mek-ritningar\M12352.idw
MFT680, A=340
MFT1020, A=800
Montering:
- Montera det övrefästet på väggen med minst tre skruvar.
- Montera det nerdre fästet i det avlånga hålet enligt skissen.
- Häng upp värmeväxlaren och skjut upp det nedre fästet tills
värmeväxlaren ligger an mot fästet.
- Markera för minst tre av de runda hålen och lyft ned
värmeväxlaren.
- Fäst det nedre fästet i minst tre av de runda hålen.
- Häng upp värmeväxlaren.
- Montera flänsarna enligt monteringsanvisning.
A
H
Heat exchanger Maxi-Heat Titanium
MA40-15E
ENGLISH
1. Heat exchanger
2. Boiler, storage tank or heat pump
3. Primary hot water circuit
4. Thermostat
5. Cutoff valve
6. Check valve
7. Circulation pump
8. Secondary circuit (pool water)
9. Filter
10. Pump
11. From the pool
12. Return to the pool
13. Drain outlet
Installation
Place the heat exchanger as in the drawing.
When installed above the pool water, the pipes should be laid in the loop, so that the heat exchanger cannot get self-drained.
Dosing of chlorine, acid or similar substances must always be done AFTER the heat exchanger.
If the pool circulation is terminated or suspended, the circulation pump on the primary side shall be switched off.
At the risk of freezing and if the pool is closed for the winter for longer than 1 month, the heat exchanger must be drained of
all water.
Mounting
Measure and mark where the heat exchanger is to be located.
Wall xture should be mounted on a solid, at surface/wall.
Modell MFT260
1. Mount the supplied wall brackets onto the wall.
2. Insert a strap into every wall mount.
3. Hold the heat exchanger and tighten the straps around it.
Model MFT680
1. Insert the supplied wall brackets as is shown in Fig.2.
Mount the top bracket with three screws in the round holes.
Mount the bottom bracket rst into the hole with a screwdriver.
2. Hang up the heat exchanger.
Slide up the bottom bracket until the heat exchanger lies against the xture.
Mark at least three of the round mounting holes and put down the heat exchanger.
Fasten the lower xture (at least three of the round holes).
3. Hang up the heat exchanger.
4. Mount the self-adhesive gaskets for heat exchanger tube spigots.
5. Place the detachable ange onto the heat exchanger tube
spigot, see Fig. 3.
Drag the screws through the anges and make sure
that the screws on the left side of the heat exchanger
go through the hole in the wall bracket (A).
6. Tighten the screws (with a washer and nut)
with a torque of 30 Nm.
Flange sleeve (2x)
Heat exchanger connection
This ange and collar
sleeve not supplied.
Packing
self-adesive surface against
the heat exchanger
Screw M16x80 (4x)
Washer M16 (4x)
Washer M16 (4x)
Nut M16 (4x)
Pic. 3
Pic. 2
