Tech Controllers ST-507 User manual

User's manual
2
Table of contents
I. Safety 3
II. Description 4
III. Installing the module 5
IV. Configuring the module 6
IV.a) Logging in on the website 6
IV.b) Homepage 8
IV.c) Changing the settings of zone view 11
IV.d) Statistics 11
IV.e) Settings 12
V. TECHNICAL DATA 13

ST-507
3
I. Safety
Before using the device for the first time, the user should read the following regulations carefully. Not
obeying the rules included in this manual may lead to personal injuries and device damage. The user's
manual should be stored in a safe place for further reference.
In order to avoid unnecessary errors and accidents it should be ensured that every person using the
device has familiarized themselves with the principle of its operation as well as its security functions. If
the device is to be sold or put in a different place make sure that the user's manual is there with the
device so that any potential user has access to essential information about the device. The manufacturer
does not accept responsibility for any injuries or damage resulting from negligence; therefore, users are
obliged to take the necessary safety measures listed in this manual to protect their lives and property.
WARNING
High voltage. Make sure the regulator is disconnected from the mains before performing any
activities involving the power supply (connecting cables, installing the device etc.).
The device should be installed by a qualified electrician.
The regulator should not be operated by children.
NOTE
The controller may be damaged if struck by lightning. Make sure the plug is disconnected from
the power supply during storm.
Any other use than specified by the manufacturer is forbidden.
Before and during the heating season, the controller should be checked for the condition of its
cables. The user should also check if the controller is properly mounted and clean it of dusty or
dirty.
Care for the natural environment is our priority. Being aware of the fact that we
manufacture electronic devices obligates us to dispose of used elements and
electronic equipment in a manner which is safe for nature. As a result, the
company has received a registry number assigned by the Main Inspector of
Environmental Protection. The symbol of a crossed out rubbish bin on a product
means that the product must not be thrown out to ordinary waste bins. By
segregating waste intended for recycling, we help protect the natural
environment. It is the user's responsibility to transfer waste electrical and
electronic equipment to a selected collection point for recycling of waste
generated from electronic and electrical equipment.

User's manual
4
II. Description
The ST-507 Internet module is a device enabling remote control over the installation's operation via the
Internet and is intended for cooperation with the ST-26402 strip.
The user controls the operation of valves in particular zones and may also change the set
temperature, define weekly schedules etc. The user may monitor the history of temperatures in each
zone in the form of legible charts.
Functions of the Internet module:
•remote control over the operation of the ST-26402 strip
•monitoring the history of temperatures
•editing the set temperature in each zone
•e-mail notifications about alarms
Controller's equipment
•power supply unit 5V DC
•RS T-connection
•RS communication cable for the boiler's controller

ST-507
5
III. Installing the module
The module should be installed by a qualified person.
CAUTION
Incorrect connection of cables may lead to module damage.

User's manual
6
IV. Configuring the module
Installing the module with a controller
In the case of cooperation with the ST-26402 strip, the installation and operation process is intuitive.
After a correct connection of the module, the Internet module should be enabled in the strip's fitter's
menu (Menu >> Fitter's Menu >> Internet module >> Registration) – a registration code will be
generated and it should be entered on the website.
CAUTION
The generated code is valid only for 60 minutes. If the registration on the website does not
take place within that time, a new code should be generated.
CAUTION
We recommend using Mozilla Firefox or Google Chrome web browsers.
IV.a) Logging in on the website
After the code in the controller has been generated, the user should visit the website
http://oeg.emodul.eu. First, the user's account should be created:
Registration panel for a new account at oeg.emodul.eu.

ST-507
7
After logging in to the account in the tab Settings, the user should enter the registration code generated
by the controller. Any name may be assigned to the module (in the field module description):
CAUTION
Several different ST-507 modules may be operated from one account at oeg.emodul.eu.
Registration panel for a new module.

User's manual
8
IV.b) Homepage
The homepage is displayed in the tab Home with tiles illustrating the current condition of the zones.
Clicking a tile, the user proceeds to the screen where he may select the zone operation mode.
CAUTION
The message "No Communication" means an interruption in the communication with the
temperature sensor in a given zone. The most common reason for such situation is a dead
battery – it should be replaced.
Screenshot showing an example of the main screen with zone tiles.
Screenshot showing a screen for changing the set temperature as well as
editing the schedules.

ST-507
9
The upper value means the current temperature in the zone, while the lower value –the set tempera-
ture.
The set temperature in a given zone depends by default on the settings of the selected weekly schedule.
However, the mode Constant Temperature allows the user to adjust a separate set value which will be
valid in a given zone, regardless of the time of the day.
The mode Time Limit allows the user to adjust a given set temperature which will be valid only
for a given period of time. After this time, the set temperature in a given zone will again depend only
on the weekly schedule.
Clicking the icon Schedule in the field the user proceeds to the screen where he may select the weekly
schedule:
The strip has two types of weekly schedules:
1. Local schedule
This is a weekly schedule assigned only to a given zone. After the strip detects the room sensor, it is
automatically assigned as valid in a given zone. The user may freely edit it.
2. Global schedule (Schedule 1..5)
The global schedule may be assigned to any number of zones. Changes introduced in the global sched-
ule are valid in all zones in which a given global schedule is set as valid.
Screenshot showing the selection screen for the weekly schedule.

User's manual
10
After selecting the schedule and clicking OK, the user proceeds to the screen where he may edit the
settings of the weekly schedule:
Editing each schedule allows the user to define two programs of settings as well as to select days in
which these programs will be valid (e.g. Monday to Friday as well as weekends). The starting point for
each program is the set temperature. In each of the programs the user may define up to three time
intervals in which the temperature will be different than the set value. The boundaries of intervals cannot
overlap.
The set temperature will be valid in hours for which the intervals were not defined. The time intervals
may be adjusted with accuracy to 15 minutes.
Screenshot showing the screen for editing the settings of the weekly schedule.

ST-507
11
IV.c) Changing the settings of zone view
The user may adjust the appearance of the homepage to his needs, changing the names of zones as well
as the background of particular tiles. These changes may be introduced in the tab Zones.
IV.d) Statistics
In the tab Statistics the user may monitor the charts of temperatures from different scopes of time: a
day, a week or a month, as well as statistics from previous months:
Screenshot showing an example of a temperature chart.
Screenshot showing an example of the tab containing the parameters of particular zones.

User's manual
12
IV.e) Settings
The tab Settings allows the user to register a new module, change the e-mail address as well as change
the account's password:
Screenshot showing the tab Settings.

ST-507
13
V. TECHNICAL DATA
No.
Specification
1
Power supply voltage
5V DC
2
Maximum current intake
200 mA
3
Transmission
IEEE 802.3 10 Mb/s
4
Connection with the network
RJ 45 connection
5
Connection with the controller
RJ12 connection

User's manual
14

ST-507
15
Declaration of conformity No 188/2015
The company TECH, based in Wieprz (34-122) at ul. Biała Droga 31,
declares with complete liability that our Internet module ST-507 meets the
requirements of the following EC directives:
R&TTE Directive 1999/5/EC;
Low Voltage Directive (LVD) 2006/95/EC;
EMC Directive 2004/108/EC.
Harmonized standards were used to assess the conformity:
PN -EN 60950-1-:2007;
PN-EN 55022:2011;
PN-EN 55024:2011.
Wieprz, October 26, 2015
