Tech Toyz Aerodrone MQ4C-24/6485 User manual

AGES 14+
MQ4C-24/6485
WIRELESS INDOOR/OUTDOOR
QUAD-COPTER
INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS CAREFULLY
& RETAIN FOR FUTURE USE

Welcome!
Thank you for purchasing Wireless Indoor/Outdoor Quad-copter. Please store this manual in a
safe place for future reference.
GETTING STARTED
•Remove the unit from the box.
• Remove any packaging from the product.
• Please read all instructions and retain all packaging until you have checked and counted all
of the parts.
PACKAGE CONTENTS
•Wireless Indoor/Outdoor Quad-copter
• Remote Controller
• USB charging cable
• Rechargeable battery
• Mini screwdriver
• Instruction Manual
1. Instructions to assemble the Controller
Use the Mini screwdriver to loosen the screw and open the battery cover as the arrow direction indicated (Pic 1).
Install 2 x “AA” batteries (not included) inside the battery compartment of the controller.
Notice:
1. Install the battery as per the plus or minus polarity.
2. Do not mix new and old batteries.
Note: Prior to flying your Quad-copter for the first
time, fully charge the battery to ensure best
performance.

2. Battery Charging Instructions
1. Connect the USB charging cable (included) to the computer USB port and connect the other end to the battery
connector (Pic 2).
2. The Red LED light will turn OFF while charging. After the battery is fully charged, the Red LED light will turn ON.
Charging time is around 40 minutes.
Pic 2
Caution:
1. Allow 10-15 minutes for the battery to cool down
before recharging.
2. Do not overcharge the battery.
3. If the battery becomes too hot while charging then
remove it from charging immediately and allow it
cool down.
4. Do not reconstruct battery.
5. Do not connect the battery to an electrical outlet.
3. Suitable Flying Conditions
1. Places with no/limited obstacles are recommended.
2. Do not fly your Quad-copter in strong winds, as it
may affect the remote-control system and interfere
with your control leading to a crash or damage to
the unit.
3. Do not fly in rain/damp conditions.
4. Flies best, indoors.
Caution: Never allow young children to use this product alone. Parental guidance is highly recommended during
the use of this device. DO NOT operate your Quad-copter if someone else is operating a similar device in the same
operating range, as it may interfere with the frequency range and impact the controlling capacity of the
Quad-copter.
Prepare for take off
1. Install the fully recharged battery into the bottom bracket of Quad-copter, and connect the battery connector to
the socket in the Quad-copter. Blue and Red LED lights will flash on successful connection.
2. Place the Quad-copter on a flat surface.
3. Recheck the area to make sure it is clear from people, pets, trees, buildings, high voltage wires and other
obstructions.
4. Push the throttle stick upward to take off. If the Quad-copter flies uncontrollably in a certain direction, push the
respective trimming button to even out its flight. Please refer to “5. Additional Information”.
Caution: Always turn OFF the controller before you unplug the battery from the Quad-copter. Do not apply full
power on the throttle while taking off as it may lead to a quick descend which may cause injury.
4. Control Information
Warning: Do not fly in strong wind, as it may overpower your Quad-copter and cause loss of control.
Flying time: On a full charge, and in low wind conditions, the Quad-copter will fly for 4 - 5 minutes.
Ascend or descend
When you push the left
stick (throttle stick) up
or down, the
Quad-copter begins to
ascend or descend.
Turning left or right
When the left stick
(rudder stick) is moved
left or right, the
Quad-copter turns left
or right.

Fly forward or backward
When the right stick
(rudder stick) is moved
up or down, the
Quad-copter flies
forward or backward.
Fly left or right
When the right stick
(rudder stick) is moved
left or right, the
Quad-copter flies left or
right.
5. Additional Information
When the Quad-copter flies forward or backward uncontrollably, press the Forward Backward Trimming Button.
When the Quad-copter flies uncontrollably towards left or right, press the Side Flying Action Trimmer button.
When the Quad-copter spins left or right continuously, press the Left / Right Trimmer key.
6. Troubleshooting Guide
Problem
Possible Cause
Solution
Remote
doesn’t work
Batteries installed with incorrect polarity
Check and make sure that the batteries are installed as
per the right polarity.
Batteries are drained.
Install new batteries.
Quadcopter
flies out of
control
Windy environment.
Do not fly in windy environment. As it will limit or
disturb your flying control.
The helicopter does not receive commands
appropriately.
Push the left throttle stick upward, and then pull it
back in to the original position.
Quadcopter
doesn’t fly
high enough
Rotor speed is too slow.
Push the left stick (throttle stick) upward.
Quad-copter is not fully charged.
Fully Charge your Quad-copter.
If you need additional support, please contact Midwest Trading Group Customer Service at [email protected]
or by calling 1 [phone].

7. Additional Information
1. The control distance will get shortened when the Quad-copter is under low power condition.
2. Windy environment may reduce the remote controlling capacity.
3. Following practices can help enhance Quad-copter’s performance:
a. If the Quad-copter doesn’t fly high enough, stop flying and unplug the battery.
b. If the Quad-copter has not been used for a long period of time, fully charge the batteries before flying
the Quad-copter.
c. If the Quad-copter gets damaged or deformed, refrain from using it until fully repaired.
d. If you don’t intend to use the remote control for a long time, remove all batteries, in order to avoid
battery leakage from damaging this device.
4. Hard crashes and/or falls of the Quad-copter can lead to irreparable damage and/or shorten Quad-copter’s life.
8. Warning
1. You are responsible for the using of the Quad-copter with necessary precautions, to ensure that it doesn’t harm
or cause any injury to anybody or damage to any property.
2. When you assemble and fly the Quad-copter, you must operate it according to the instruction manual.
3. The user is responsible completely for correct operation and use of product. We and the dealer accept no
responsibility or liability for damage and/or loss caused due to inappropriate usage and operation of this device.
4. Not recommended for children under 14 years of age
CARE AND MAINTENANCE
▪Clean the unit with a soft, damp cloth. Never use chemicals or hard abrasives.
▪Keep this unit away from wet or damp surroundings.
▪The crossed out wheelie bin symbol on this item indicates that this product needs to be disposed of in an
environmentally friendly way when it becomes of no further use or has worn out. Contact your local authorities for
details of where to take the item for re-cycling.
▪Do not dispose of batteries in a fire. They may explode.
Do not dispose of battery packs in a fire, throw them in a trash receptacle. They need to be disposed of in an
environmentally friendly way when it becomes of no further use. Contact your local authorities for details of where to
take them for re-cycling.

FCC INSTRUCTIONS
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the product.
NOTE: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This product generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If the product does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the product and receiver.
- Connect the product into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure
condition without restriction.
Limited Warranty
This manufacturer's product warranty extends to the original consumer purchaser of the product. Neither the retailer nor
any other company involved in the sale or promotion of this product is a co-warrantor of this manufacturer warranty.
WARRANTY DURATION: All materials and workmanship are warranted to the original consumer purchaser for a period of
thirty (30) days from the original purchase date.
WARRANTY COVERAGE: This product is warranted against defective materials or workmanship. This warranty is void if the
product has been damaged by accident, in shipment, unreasonable use, misuse, neglect, improper service, commercial
use, repairs by unauthorized personnel or other causes not arising out of defects in materials or workmanship. This
warranty doesn’t cover the following which may be supplied with this product, including but not limited to; LCD Screens,
glass parts, lenses, bulbs etc. This warranty is effective only if the product is purchased and operated in USA and Canada,
and does not extend to any units which have been used in violation of written instructions furnished by manufacturer or to
units which have been altered or modified or, to damaged products or parts thereof which have had the serial number
removed, altered, defaced or rendered illegible.
WARRANTY DISCLAIMERS: This warranty is in lieu of all warranties expressed or implied and no representative or person is
authorized to assume for manufacturer any other liability in connection with the sale of our products. There shall be no
claims for defects or failure under any theory of tort, contractor commercial law including but not limited to, negligence,
gross negligence, strict liability, breach of warranty and breach of contract. Under no circumstances will Manufacturer’s /
Distributor’s maximum liability exceed the retail value of the product.
WARRANTY PERFORMANCE: During the above 30 day warranty period, a product with a defect will be either repaired or
replaced with a reconditioned comparable model (at manufacturer's option). The repaired or replacement product will be
in warranty for the balance of the 30 day warranty period and an additional one-month period. No charge will be
applicable for such repair or replacement.
SERVICE AND REPAIR: If service is required for this product, you should first contact Midwest Trading Group Customer
Service at [email protected] or by calling 1 [phone], Monday to Friday 10am to 6pm EST.
NOTE: Manufacturer cannot assume responsibility for loss or damage during incoming shipment. As a precautionary
measure, carefully package the product for shipment, and insure it with the carrier. Be sure to enclose the following details
with the product: your full name, return address and daytime phone number, a note describing the problem you
experienced, a copy of your sales receipt or other proof of purchase to determine warranty status. C.O.D. shipments
cannot be accepted.
